Harbor Freight Tools 92464 User Manual
Power INVerTer
2,000 waTT / 4,000 waTT Peak
92464
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Copyright© 2004 by Harbor Freight Tools®. All rights reserved. No portion
of this manual or any artwork contained herein may be reproduced in any shape or
form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
Specifications
Continuous Power 2,000 Watts
Peak Power 4,000 Watts
Input Voltage 12 Volts Nominal DC (11-15 Volts possible)
Output Voltage 120 Volts AC at 60 Hz
AC Receptacles (2) Two 3-Prong, Polarized Outlets
Fuse
Dimensions 14” L x 9” W x 3-1/2” H
Weight 11.6 lb.
Indicators Green LED = power on
Switch Rocker type, On / Off
Operating Temperature 30-105° F
Recommended Input
Cord
Features
30 Amps, 8 Qty.
(internal, for replacement only by a qualified technician)
Battery cable
(not included; #2 AWG or larger cables recommended)
- Modified sine wave with overload protection
- Low voltage alarm1 and shutdown
- Overvoltage shutoff
1 at 10.5 V; 2 at about 10 V; 3 at about 15 V
3
2
Save This Manual
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using this device, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Do not plug in a battery charger if the charger has a warning that dangerous
voltages are present at the battery terminals.
2. Keep work area clean. Cluttered areas invite injuries.
3. Keep inverter away from any direct heat source or combustible material.
4. Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Don’t expose to rain. Keep work area well lighted. Do not
SKU 92464 Page 2
For technical questions, please call 1-800-444-3353.
REV 03/05
use electrically powered tools in the presence of flammable gases or liquids.
5. Keep children away. Children must never be allowed in the work area. Do
not let them handle machines, tools, or extension cords.
6. Store idle equipment. When not in use, tools must be stored in a dry location
to inhibit rust. Always lock up tools and keep out of reach of children.
7. Use the right tool for the job. Do not attempt to force a small tool or attachment to do the work of a larger industrial tool. There are certain applications
for which this tool was designed. It will do the job better and more safely at the
rate for which it was intended. Do not modify this tool and do not use this tool
for a purpose for which it was not intended.
8. Dress properly. Do not wear loose clothing or jewelry as they can be caught
in moving parts. Protective, electrically nonconductive clothes and nonskid
footwear are recommended when working. Wear restrictive hair covering to
contain long hair.
9. Use eye protection. Always wear ANSI approved impact safety goggles when
using tools.
10. Do not overreach. Keep proper footing and balance at all times. Do not reach
over or across running machines.
11. Maintain tools with care. Keep tools sharp and clean for better and safer
performance. Follow instructions for changing accessories. Inspect tool cords
periodically and, if damaged, have them repaired by an authorized technician.
12. Disconnect power. Unplug inverter when not in use.
13. Avoid unintentional starting. Be sure the switch is in the Off position when
not in use and before plugging in any appliance.
14. Stay alert. Watch what you are doing, use common sense. Do not operate any
tool when you are tired.
15. Check for damaged parts. Before using any tool, any part that appears
damaged should be carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment and binding of moving
parts; any broken parts or mounting fixtures; and any other condition that may
affect proper operation. Any part that is damaged should be properly repaired
or replaced by a qualified technician. Do not use the tool if any switch does not
turn On and Off properly.
16. Servicing. This device should be serviced only by a qualified technician. This
item does not have any user-replaceable parts.
SKU 92464 Page 3
For technical questions, please call 1-800-444-3353.
