1250 LB. CAPACITY
MECHANICAL WHEEL DOLLY
67287
SET-UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2009 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information provided with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
Safety Warnings
WARNING Read all safety
warnings and instructions.
Failure to heed these markings
may result in personal injury and/or
property damage.
Save all warnings and
instructions for future reference.
Do not exceed the 1250 lb. rated 1.
capacity.
Use only on hard, level surfaces.2.
Lifting device only. Immediately after 3.
lifting, support the vehicle with appropriate means.
Do not work under vehicle while on 4.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
Page 2 For technical questions, please call 1-800-444-3353. SKU 67287
Dollies.
Wear ANSI-approved safety goggles 5.
and heavy-duty work gloves during
use.
Keep clear of load while lifting and 6.
lowering.
Lower load slowly.7.
Do not use for aircraft purposes.8.
Apply parking brake and chock tires 9.
before lifting vehicle.
Inspect before every use; do not use 10.
if parts are loose or damaged.
Keep your work area clean and well 11.
lit. Cluttered work areas invite accidents.
Before use, read manufacturer’s 18.
instruction manual for the vehicle (or
object) you will lift.
Keep bystanders, children, and 12.
visitors away while operating Wheel
Dolly. Distractions can cause you to
lose control.
Stay alert. Watch what you are do-13.
ing, and use common sense when
operating Wheel Dollies. Do not use
while tired or under the inuence of
drugs, alcohol, or medication. A moment of inattention while operating
Wheel Dollies may result in serious
personal injury.
Store idle Wheel Dolly out of reach of 14.
children and other untrained persons.
Jacks are dangerous in the hands of
untrained users.
Wheel Dolly service must be per-15.
formed only by qualied repair personnel. Service or maintenance
performed by unqualied personnel
could result in a risk of injury.
When servicing, use only identi-16.
cal replacement parts - refer to at-
tached, product-specic parts list and
diagram. Follow instructions in the
“Inspection, Maintenance, And Cleaning” section of this manual. Use of
unauthorized parts or failure to follow
maintenance instructions may create
a risk of injury and may void any applicable warranty.
Maintain labels and nameplates on 17.
the Wheel Dolly. These carry important information. If unreadable or
missing, contact Harbor Freight Tools
for a replacement.
Industrial applications must follow 19.
OSHA requirements.
Do not allow anyone in the vehicle 20.
while using the Wheel Dolly. Do not
start the vehicle while it is on Wheel
Dollies. Keep all bystanders a safe
distance away from the vehicle.
Before lowering vehicle, remove all 21.
tools and equipment from under the
vehicle.
The warnings, precautions, and 22.
instructions discussed in this manual
cannot cover all possible conditions
and situations that may occur. The
operator must understand that common sense and caution are factors,
which cannot be built into this product, but must be supplied by the
operator.
SAVE THESE
INSTRUCTIONS.
Page 3For technical questions, please call 1-800-444-3353.SKU 67287
SPECIFICATIONS
Weight Capacity 1250 lb.
Maximum Tire Width
Capacity
Distance Between
Rollers (Center to
Center)
Weight 38.8 lb.
10"
13-1/2” (Minimum)
28-3/4” (Maximum)
UNPACKING
When unpacking, make sure the
product is intact and undamaged. If any
parts are missing or broken, call Harbor
Freight Tools at 1-800-444-3353.
Note: Use four Wheel Dollies to ef-
ciently maneuver a parked vehicle in tight
spaces. It is designed to t most cars and
lightweight trucks. A vehicle resting on
four of the Vehicle Dollies can be pushed
forward, backward and even sideways.
ASSEMBLY
Use Nut (1) and Spring Washer (2) to 1.
fasten a Caster (3) to each of the Rod
Assemblies (4), the Outer Body Axle
Assembly (9) and the Inner Body Axle
Assembly (10). See the Parts Dia-
gram on Page 9 for reference.
Slide each Roller (8) over each Rod 2.
Assembly. See the Parts Diagram on
at back of manual for reference.
Repeat Step 3, on with the Inner 4.
Body Axle Assembly (10), making
sure all connections are tightened
rmly.
OPERATION
IMPORTANT! BEFORE FIRST USE:
Thoroughly lubricate and test the •
Wheel Dolly for proper operation.
Position Dolly in front of tire and slide 1.
Latch (24) to right. Lift Lock Pin (17)
and rotate counterclockwise until tab
faces away from Pedal Arm (19). See
Figure 1.
Tab
Figure 1
Place hands on Rollers (8) and 2.
spread apart to tire width required.
Roll Dolly forward, centering Rollers 3.
against tire.
Lock
Pin (17)
Pedal Arm
(19)
Latch (24)
Remove Lock Nut (5) and Bolt (6) 3.
from each Rod Assembly. Slide
Roller (8) and Washer (7) onto Rod
Assembly. Slide Rod Assembly into
square tube on Outer Body Axle As-
sembly (9). Fasten together using
Lock Nut and Bolt, making sure all
connections are tightened rmly.
Slide Latch to left. Then turn Lock Pin 1.
clockwise until it retracts into ratchet.
Turn tab counterclockwise, keeping
it away from end of Pedal Arm. See
Figure 2.
Lifting Wheel
Rev 09j; 09k
Page 4 For technical questions, please call 1-800-444-3353. SKU 67287
Tab
Pedal Arm
(19)
Figure 2
Latch (24)
Place foot on Pedal and pump in full 2.
strokes, forcing the Rollers to come in
(closer together).
Continue raising the tire until it is ap-3.
proximately 3/4” off the ground.
Tab
Figure 3
Channel
Latch (24)
Push Pedal down and release. 2.
Continue until tire fully rests on the
ground.
If needed, raise every other wheel 4.
with its own separate Wheel Dolly.
WARNING! Be ready for any move-
ment the vehicle may make when
next wheel comes off the ground.
WARNING! 5. Before the vehicle has
been placed on all four Wheel Dol-
lies, ensure that you have sufcient
assistance and manpower to safely
guide and control the vehicle.
Stay clear of any sloping areas or 6.
entry ramps, however shallow they
may appear. Sufcient space should
be allowed between the side of the
vehicle and an adjacent wall for the
vehicle to be withdrawn from its loca-
tion in a sideways manner.
Lowering Wheels
To lower the Wheel Dolly, slide the 1.
Latch counterclockwise (to the right).
Turn Tab clockwise, making sure it
aligns with the channel at the end of
the Pedal Arm. See Figure 3.
Removing Dolly
Keep Latch in right position.1.
Lift Lock Pin (17) and turn right 2.
(counterclockwise) until Tab faces
away from Pedal Arm.
Place hands on Rollers and spread 3.
them apart to clear tire.
Pull Dolly away from tire, retract 4.
Rollers, and turn Pin right to engage
ratchet. While keeping Tab away from
Pedal arm, push Pedal down and
lock in place with wire latch.
INSPECTION, MAINTENANCE,
AND CLEANING
Proceduresnotspecically
explained in this manual
must be performed only by a
qualiedtechnician.
Rev 09j; 09k
Page 5For technical questions, please call 1-800-444-3353.SKU 67287
TO PREVENT
SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged
equipment. If abnormal noise
or vibration occurs, have the
problem corrected before
further use.
Before each use, 1. inspect the gen-
eral condition of the Wheel Dolly.
Check for broken, cracked, or bent
parts, loose or missing parts, and any
condition that may affect the proper
operation of the product. If a problem
occurs, have the problem corrected
before further use.
Do not use damaged equipment.
Before each use, thoroughly test 2.
the Wheel Dolly for proper operation prior to its actual use.
Periodically lubricate the Wheels, 3.
roller pivots and Foot Pedal pivot with
oil. Lightly grease the four sides of
the main square tube section, making
sure to fully extend Wheel Dolly for
complete greasing.
After every use, wipe dry with a clean 4.
cloth. Then, store the Jack in a safe,
dry location out of reach of children
and other non-authorized people.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY
REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Rev 09j
Page 6 For technical questions, please call 1-800-444-3353. SKU 67287
PARTS LIST AND ASSEMBLY DIAGRAM
Part Description Q’ty
1 Nut M12 4
2 Spring Washer 12 4
3 Caster Assembly 4
4 Rod Assembly 2
5 Lock Nut M12 3
6 Bolt M12*55 2
7 Washer 4
8 Roller Assembly 2
9 Outer Body Axle Assembly 1
10 Inner Body Axle Assembly 1
11 Screw M6*10 1
12 Big Washer 6 2
13 Carry Head Assembly 1
Part Description Q’ty
14 Spring Ring 1
15 Bushing 1
16 Spring 1
17 Lock Pin 1
18 Spring Pin 4*16 1
19 Pedal Arm 1
20 Support Plate 1
21 Retaining Ring 8 2
22 Axis 1
23 Lock Nut M6 1
24 Latch 1
25 Retaining Spring 1
26 Bolt M12*80 1
Note: Some parts are listed and shown for illustration purposes only and are not avail-
able individually as replacement parts.
Rev 09j
Page 7For technical questions, please call 1-800-444-3353.SKU 67287
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet
high quality and durability standards, and
warrants to the original purchaser that this
product is free from defects in materials
and workmanship for the period of 90 days
from the date of purchase. This warranty
does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack
of maintenance. We shall in no event be
liable for death, injuries to persons or property, or for incidental, contingent, special
or consequential damages arising from the
use of our product. Some states do not allow the exclusion or limitation of incidental
or consequential damages, so the above
limitation of exclusion may not apply to
you. THIS WARRANTY IS EXPRESSLY IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY
AND FITNESS.
To take advantage of this warranty,
the product or part must be returned to us
with transportation charges prepaid. Proof
of purchase date and an explanation of the
complaint must accompany the merchan-
dise. If our inspection veries the defect,
we will either repair or replace the product
at our election or we may elect to refund
the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at
our expense, but if we determine there is
no defect, or that the defect resulted from
causes not within the scope of our warranty, then you must bear the cost of returning
the product.
This warranty gives you specic legal
rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd.
PO Box 6009 • Camarillo, CA 93011
(800) 444-3353
Page 8 For technical questions, please call 1-800-444-3353. SKU 67287
Loading...
