Harbor Freight Tools 66093 Owner's Manual
SOLAR POWERED FOUNTAIN
PUMP
66093
SET UP AND OPERATING INSTRUCTIONS
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Before start-up, note the following:
CAUTION
uids, especially not fuels, cleaning uids,
or other chemical products.
This pump has been designed for use
with water only.
WARNING
Circulation of caustic uids, as well 1.
as the circulation of abrasive materials, must be avoided at all costs.
The pump must be protected from 2.
frost.
The pump must be protected from 3.
running dry.
Access by children should also be 4.
prevented with appropriate measures.
WARNING: Handling the Power Cord 5.
on this product will expose you to
lead, a chemical known to the State
of California to cause cancer, and
birth defects or other reproductive
harm. Wash hands after handling.
(California Health & Safety Code §
25249.5, et seq.)
The warnings, precautions, and in-6.
structions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
SPECIFICATIONS
Maximum Water Lift 2.62 Feet
Solar Panel Peak
Power
Maximum Flow Rate 42 GPH
Maximum Water Jet
Height
1.2 Watt
9 Inches
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
INSTALLATION
Use the Nozzle Adapters and Exten-1.
sion Tubes to construct a tube that
will rise one to three inches above the
surface of the water.
The Nozzle Adapters, Extension 2.
Tubes, and Fountain Heads, can be
assembled in a variety of different
ways to construct the length of tube
and desired spray pattern that suits
the needs of the fountin best.
Push the tube onto the top of the 3.
Pump.
Press a Fountain Head on top of the 4.
tube.
Fluid Type
The Pump is designed for use with
water with a maximum temperature of 77°
F (25°C). Do not use the pump for other
SKU 66093 For technical questions, please call 1-800-444-3353. Page 2
Route the cord of the Pump to an 5.
area that receives consistent sunlight.
