SOLAR CHARGER
65063
SET UP AND OPERATING INSTRUCTIONS
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Page 2
SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures. Write the product’s serial number
in the back of the manual (or month and
year of purchase if product has no number). Keep this manual and the receipt in
a safe and dry place for future reference.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
General Safety Warnings
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information provided with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
WARNING Read all safety
warnings and instructions.
Failure to follow the warnings and
instructions may result in electric
shock, re and/or serious injury.
Save all warnings and
instructions for future reference.
Work area safety1.
Keep work area clean and well lit. a.
Cluttered or dark areas invite acci-
dents.
Do not operate this product in b.
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. This product can create sparks which may ignite the dust
or fumes.
Electrical safety2.
The AC/DC Adapter Plug must a.
match the outlet. Never modify the
Plug in any way. Unmodied plugs
and matching outlets will reduce risk
of electric shock.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 2
Avoid body contact with grounded b.
surfaces such as pipes, radiators,
ranges and refrigerators. There is
an increased risk of electric shock if
your body is grounded.
Do not expose this product to rain c.
or wet conditions. Water entering
Page 3
this product will increase the risk of
electric shock.
Do not abuse the AC/DC Adapter d.
Cord. Never use the Cord for carrying, pulling or unplugging this
product. Keep Cord away from
heat, oil, sharp edges or moving
parts. Damaged or entangled cords
increase the risk of electric shock.
When operating the AC/DC Adapter e.
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
If operating the AC/DC Adapter in a f.
damp location is unavoidable, use
a Ground Fault Circuit Interrupter
(GFCI) protected supply. Use of
a GFCI reduces the risk of electric
shock.
Personal safety3.
Stay alert, watch what you are do-a.
ing and use common sense when
using this product. Do not use this
product while you are tired or un-
der the inuence of drugs, alcohol
or medication. A moment of inattention while operating this product may
result in serious personal injury.
Do not overreach. Keep proper b.
footing and balance at all times.
This enables better control of the
power tool in unexpected situations.
Dress properly. Do not wear loose c.
clothing or jewelry. Keep your
hair, clothing and gloves away
from moving parts. Loose clothes,
jewelry or long hair can be caught in
moving parts.
Product use and care4.
Do not force this product. Use the a.
correct product for your application. The correct product will do the
job better and safer at the rate for
which it was designed.
Disconnect the AC/DC Adapter b.
Plug from the power source and
the Battery from the Solar Charger
before making any adjustments,
changing accessories, or storing
the product.
Store this product out of the reach c.
of children and do not allow persons unfamiliar with this product
or these instructions to operate
the unit. Electrically powered prod-
ucts are dangerous in the hands of
untrained users.
Maintain this product. Check for d.
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect this
product’s operation. If damaged,
have the unit repaired before use.
Many accidents are caused by poorly
maintained products.
Use this product and its acces-e.
sories in accordance with these
instructions, taking into account
the working conditions and the
work to be performed. Use of this
product for operations different from
those intended could result in a haz-
ardous situation.
Battery use and care5.
Recharge only with the AD/DC a.
Adapter specied by the manufacturer. An Adapter that is suitable for
one type of Battery may create a risk
of re when used with another Battery.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 3
Page 4
Use this product only with speci-b.
cally designated batteries. Use of
any other Battery may create a risk of
injury and re.
Under abusive conditions, liquid c.
may be ejected from the Battery.
Avoid contact. If contact acciden-
tally occurs, ush with water. If
liquid contacts eyes, additionally
seek medical help. Liquid ejected
from the Battery may cause irritation
or burns.
Do not reverse the polarity of the 5.
load, the Solar Charger, or the Battery.
Clean the surface of the Solar Char-6.
ger periodically with a clean, soft
cloth for best performance. Do not
use solvents, acid, or alkali products.
For increased pickup of solar energy, 7.
it is recommended that the Solar
Panel be positioned so that it points
directly at the sun.
Service6.
Have your Solar Charger serviced a.
by a qualied repair person using
only identical replacement parts.
This will ensure that the safety of the
product is maintained.
Specic Safety Warnings
Maintain labels and nameplates 1.
on the Solar Charger. These carry
important safety information. If unreadable or missing, contact Harbor
Freight Tools for a replacement.
Avoid unintentional starting. Prepare 2.
to begin work before turning on the
unit.
CAUTION: When solar charging, this 3.
Charger becomes hot to the touch
when fully charged and for a period
after it is charged. Use care when
handling.
Do not leave the AC/DC Adapter 4.
unattended when it is plugged into an
electrical outlet. Unplug the Adapter
from its electrical outlet before leaving.
Performance of the Solar Charger 8.
may vary depending on site location,
angle of the Solar Panel in relation
to the arc of the sun, and available
sunlight.
This product is not a toy. Keep it out 9.
of reach of children.
People with pacemakers should 10.
consult their physician(s) before use.
Electromagnetic elds in close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure. In addition, people with
pacemakers should:
• Avoid operating alone.
• Do not use with power switch locked
on.
• Properly maintain and inspect to
avoid electrical shock.
• Any power cord must be properly
grounded. Ground Fault Circuit Interrupter (GFCI) should also be implemented – it prevents sustained electrical shock.
WARNING: Handling the AC/DC 11.
Adapter Cord on this product will expose you to lead, a chemical known
to the State of California to cause
cancer, and birth defects or other
reproductive harm. Wash hands after
SKU 65063 For technical questions, please call 1-800-444-3353. Page 4
Page 5
handling. (California Health & Safety
Code § 25249.5, et seq.)
The warnings, precautions, and in-12.
structions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
Double Insulated Tools: Tools
with Two Prong Plugs
SAVE THESE
INSTRUCTIONS.
GROUNDING
TO PREVENT
ELECTRIC SHOCK
AND DEATH FROM
INCORRECT GROUNDING
WIRE CONNECTION:
Check with a qualied
electrician if you are in doubt
as to whether the outlet is
properly grounded. Do not
modify the AC/DC Adapter
Cord Plug provided with the
Solar Charger. Do not use the
Solar Charger if the AC/DC
Adapter Power Cord or Plug
is damaged. If damaged,
have it repaired by a service
facility before use. If the Plug
will not t the outlet, have a
proper outlet installed by a
qualied electrician.
Tools marked “Double Insulated” do 1.
not require grounding. They have
a special double insulation system
which satises OSHA requirements
and complies with the applicable
standards of Underwriters Laboratories, Inc., the Canadian Standard
Association, and the National Electrical Code. (See Outlets for 2-Prong
Plug.)
Double insulated tools may be used 2.
in either of the 120 volt outlets shown
in the preceding illustration. (See
Outlets for 2-Prong Plug.)
Extension Cords
Grounded1. tools require a three wire
extension cord. Double Insulated
tools can use either a two or three
wire extension cord.
As the distance from the supply outlet 2.
increases, you must use a heavier
gauge extension cord. Using extension cords with inadequately sized
wire causes a serious drop in voltage,
resulting in loss of power and possible tool damage.
(See Table A.)
SKU 65063 For technical questions, please call 1-800-444-3353. Page 5
Page 6
The smaller the gauge number of the 3.
wire, the greater the capacity of the
cord. For example, a 14 gauge cord
can carry a higher current than a 16
gauge cord. (See Table A.)
When using more than one exten-4.
sion cord to make up the total length,
make sure each cord contains at
least the minimum wire size required.
(See Table A.)
V~
SYMBOLOGY
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
Volts Alternating Current
If you are using one extension cord 5.
for more than one tool, add the
nameplate amperes and use the sum
to determine the required minimum
cord size. (See Table A.)
If you are using an extension cord 6.
outdoors, make sure it is marked with
the sufx “W-A” (“W” in Canada) to
indicate it is acceptable for outdoor
use.
Make sure the extension cord is prop-7.
erly wired and in good electrical condition. Always replace a damaged
extension cord or have it repaired by
a qualied electrician before using it.
RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS*
NAMEPLATE
AMPERES
(at full load)
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
(110/240 VOLT)
EXTENSION CORD
LENGTH
25’
50’
75’
100’
150’
A
n0 xxxx/min.
Amperes
No Load Revolutions per Minute
(RPM)
PRODUCT SPECIFICATIONS
Designed to charge most
Product Applications
AC/DC Adapter Input 110 V~ / 60 Hz
AC/DC Adapter Output 5 VDC, 500mA
AC/DC Cord Type 22 AWG
AC/DC Plug Type 2-Prong, Grounded
Lithium Battery Capacity 1000 mAH
Unit Charging Capacity Approximately 4~6 Hours
Solar Power Output 80 mA/120 mA
Solar Charger Charge Time 4~6 Hours
AC/DC Charge Time 1~2 Hours
Charge Time from Charger to
Mobile cell phone
L.E.D. Functions
Accessories Plug Adapters (Qty. 5)
cell phones. Also adapts
to MP3, M4, PDA’s, digital
camera, etc.
60~90 Minutes
Red Charging:
(Turns to Green on Full
Charge).
Multi-Flashing:
(Indicates DC Power to
Charger).
Flashlight:
(Push Button on Side)
SKU 65063 For technical questions, please call 1-800-444-3353. Page 6
Page 7
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
FIGURE A
8
4
2
7
5
1
9
10
3
6
11
Product Features
Electric current input Lamp.1.
Electric current output Lamp.2.
Flashlight Lamp.3.
Circuit Reset.4.
Flashlight Switch Button.5.
Electric current input receptacle.6.
Electric current output receptacle.7.
Solar Panel.8.
Plug Adapters9.
Connection Cord10.
AC/DC Adapter11.
Lithium Battery (not shown)12.
(See Figure A.)
9
General Operating Procedures
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Unplug the Solar Charger
from its AC/DC Adapter before
performing any inspection,
maintenance, or cleaning
procedures.
To Charge The Solar Charger Battery
Using The AC/DC Adapter:
The approximate charge time, us-1.
ing the AC/DC Adapter (11) is 1 to 2
hours.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 7
Page 8
To charge the Battery (12) of the 2.
Solar Charger, insert the Plug of the
AC/DC Adapter (11) into the Electric
Current Input Receptacle (6).
(See Figure A.)
Plug the Power Cord of the AC/DC 3.
Adapter (11) into the nearest 110 volt,
grounded, electrical outlet.
(See Figure A.)
angle of the Solar Panel in relation
to the arc of the sun, and available
sunlight.
The Electric Current Input Lamp (1) 5.
will illuminate RED. In approximately
4 to 6 hours, the Lamp will illuminate
GREEN indicating the Solar Charger
is fully charged. Do not overcharge.
(See Figure A.)
The Electric Current Input Lamp (1) 4.
will illuminate RED. In approximately
60 to 90 minutes, the Lamp will illuminate GREEN indicating the Solar
Charger is fully charged. Do not
overcharge. (See Figure A.)
When fully charged, unplug the 5.
AC/DC Adapter (11) from its electrical
outlet. Then unplug the Plug of the
AC/DC Adapter from the Solar Charger’s Electric Current Input Receptacle (6). (See Figure A.)
To Charge The Solar Charger Battery
Using Solar Power:
The approximate charge time, using 1.
solar power is 4 to 6 hours.
To charge the Battery (12) of the So-2.
lar Charger, open the Solar Charger
to expose the Solar Panel (8). Then
set the Solar Charger on a clean, dry
location in full sunlight.
(See Figure A.)
For increased pickup of solar en-3.
ergy, and to minimize the collection
of debris on the Solar Panel (8), it is
recommended that the Solar Panel
be positioned so that it points directly
at the sun. (See Figure A.)
Performance of the Solar Charger 4.
may vary depending on site location,
When fully charged, close the Solar 6.
Charger to keep the Solar Panel (8)
free of dirt and debris.
(See Figure A.)
To Test The Circuit:
To make sure the Solar Charger is 1.
operating properly, press the Flashlight Switch Button (5) to see if the
LED illuminates. If it illuminates, the
circuit of the Solar Charger is operating properly. If the LED does not
illuminate, press the Circuit Reset (4).
This will reset the Solar Charger to
begin charging. (See Figure A.)
To Charge A Mobile Unit:
Select the proper Plug Adapter (9) for 1.
the mobile unit you wish to charge.
(See Figure A.)
Attach the Plug Adapter (9) to the 2.
Connection Cord (10).
(See Figure A.)
Insert the Plug Adapter (9) into the 3.
charging input receptacle of the mobile unit. (See Figure A.)
Insert the other end of the Connec-4.
tion Cord (10) into the Solar Charger’s Electric Current Output Receptacle (7). (See Figure A.)
SKU 65063 For technical questions, please call 1-800-444-3353. Page 8
Page 9
The Solar Charger will immediately 5.
begin charging the mobil unit, as indicated by the Electric Current Output
Lamp (2) illumnating.
(See Figure A.)
IMPORTANT: Refer to the mobile 6.
unit manufacturer’s recommended
charge time for the unit. Do not
overcharge. Overcharging may
damage the mobile unit.
When nished charging the mobil 7.
unit, unplug the Solar Charger’s Plug
Adapter (9) from the mobil unit.
(See Figure A.)
Disconnect the Plug Adapter (9) 8.
from its Connection Cord (10). Then
disconnect the Connection Cord from
the Solar Charger’s Electric Current
Output Receptacle (7).
(See Figure A.)
MAINTENANCE AND
SERVICING
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Unplug the AC/DC Adapter
from its electrical outlet
before performing any
inspection, maintenance, or
cleaning procedures.
TO PREVENT SERIOUS
INJURY FROM PRODUCT
FAILURE:
Do not use damaged
equipment. If abnormal noise
or vibration occurs, have the
problem corrected before
further use.
Inspection, Maintenance, and
Cleaning
BEFORE EACH USE, inspect the 1.
general condition of the Solar Charger and its accessories. Check for
loose screws, misalignment or binding of moving parts, cracked or broken parts, damaged electrical wiring,
and any other condition that may
affect its safe operation.
TO CHANGE THE LITHIUM BAT-2.
TERY: Poor product performance
may be a sign the Lithium Battery
(12) is worn out. It is recommended
that a qualied technician replace the
battery.
(See Figure B, next page.)
AFTER USE,3. clean the surface of
the Solar Charger periodically with a
clean, damp, soft cloth for best performance. Do not use solvents, acid,
or alkali products.
WARNING! If the Power Cord of 4.
the AC/DC Adapter is damaged, it
must be replaced only by a quali-
ed service technician.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 9
Page 10
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
TROUBLESHOOTING
Problem Possible Causes Possible Solutions
Battery will not
charge.
Solar Charger not
charging mobil
unit.
Follow all safety precautions whenever diagnosing or servicing the
tool. Disconnect power supply before service.
No AC power at outlet.1.
AC/DC cord and/or plug not 2.
connected.
Insufcient sunlight.3.
Solar panel dirty.4.
Connection cord not properly 1.
plugged in to Solar Charger
and/or mobil unit.
Circuit interruption.2.
Using wrong Plug adapter.3.
Solar Charger not designed to 4.
charge a specic mobil unit.
Solar Charger battery low.5.
Check AC power at outlet.1.
Check that AC/DC cord and/or plug is 2.
plugged in.
Check that Solar Panel is in full sunlight.3.
Check that Solar Panel is clean and dry.4.
Check that connection cord is properly 1.
connected to Solar Charger and mobil unit.
Press Circuit Reset. Then resume charging.2.
Check that proper plug adapter is being 3.
used.
Requires correct plug adapter.4.
Charge Solar Charger battery.5.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 10
Page 11
PARTS LIST & ASSEMBLY DIAGRAM
Part # Description Qty.
1 Input Indicator LED 1
2 Output Indicator LED 1
3 Flashlight Lamp 1
4 Circuit Reset 1
5 Flashlight Switch Button 1
6 AC/DC Adapter Input 1
7 DC Current Output 1
8 Solar Panel 2
9 Plug Adapter 5
10 Connection Cord 1
11 AC/DC Adapter 1
12 Lithium Battery (not shown) 1
8
4
2
7
5
1
9
10
9
3
6
11
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
SKU 65063 For technical questions, please call 1-800-444-3353. Page 11
Loading...
