Hanwha Techwin QNV-8080R User Manual
QNV-8080R
5MP Network IR Dome Camera
Key Features
• Max. 5Megapixel (2592 x 1944) resolution
• 3.2~10mm(3.1x) motorized varifocal lens
• 0.15Lux (Color), 0Lux (B/W, IR LED on)
• Max. 30fps@5MP (H.265 / H.264)
• H.265, H.264, MJPEG codec support, Multiple streaming
• Day & Night, WDR (120dB)
• Tampering, Motion detection, Defocus detection
• Micro SD / SDHC / SDXC memory slot (Max. 128GB)
• Hallway view, WiseStream II support
• IR Viewable length 30m
• IP66, IK10, PoE
Dimensions Accessories (Optional)
57.7 (2.27")
57.7 (2.27 ")
106.1 (4.18")
106.1 (4.18 ")
Unit : mm (inch)
SBP-137WMW SBP-301HMW2
SBP-300LMW
SBP-300CMW
Ø100.0 (3.94")
Ø100.0 (3.94")
FIRST EDITION 052019 © 2019 Hanwha Techwin Co., Ltd. All rights reserved.
Ø137.0 (5.39")
Ø137.0 (5.39")
SBP-300WMW1
SBP-300WMW
QNV-8080R
VIDEO
Imaging Device 1/2.8" 5MP CMOS
Eective Pixels 2592(H) x 1944(V)
Min. Illumination
Video Out CVBS : 1.0 Vp-p / 75 composite, 720 x 480(N), 720 x 576(P) for installation
LENS
Focal Length (Zoom Ratio) 3.2~10mm (3.1x) motorized varifocal
Max. Aperture Ratio F1.6 (Wide)~F2.9 (Tele)
Angular Field of View H : 100.3°(Wide)~31.2°(Tele) / V : 72.3°(Wide)~23.5°(Tele) / H : 133.1°(Wide)~38.8°(Tele)
Focus Control Simple focus
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range 0˚~350˚ / 0˚~67˚ / 0˚~355˚
OPERATIONAL
IR Viewable Length 30m (98.42ft)
Camera Title Displayed up to 85 characters
Day & Night Auto (ICR)
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR
Motion Detection 4ea, polygonal zones
Privacy Masking 6ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti icker (1/5~1/12,000sec)
Video Rotation Flip, Mirror, Hallway view (90˚/270˚)
Analytics Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line
Alarm I/O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm events
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression H.265/H.264 : Main/High, MJPEG
Resolution
Max. Framerate
Smart Codec WiseStream
Video Quality Adjustment H.264/H.265 : Target bitrate level control / MJPEG : Quality level control
Bitrate Control H.264/H.265 : CBR or VBR / MJPEG : VBR
Streaming Unicast (6 users) / Multicast, Multiple streaming (Up to 3 proles)
Protocol
Security
Edge Storage Micro SD/SDHC/SDXC 1slot 128GB
Application Programming Interface
Webpage Language
Color : 0.15Lux (F1.6, 1/30sec)
BW : 0Lux (IR LED on)
File upload via FTP and e-mail, Notication via e-mail,
SD/SDHC/SDXC or NAS recording at event triggers, Alarm output
2592 x 1944, 1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480,
640 x 480, 640 x 360
H.265/H.264 : Max. 30fps/25fps (60Hz/50Hz)
MJPEG : Max. 15fps/12fps (60Hz/50Hz)
II
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
HTTPS(SSL) login authentication, Digest login authentication, IP address ltering,
User access log, 802.1X authentication(EAP-TLS, EAP-LEAP)
ONVIF Prole S/G/T
SUNAPI (HTTP API)
Wisenet open platform
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,
Portuguese, Czech, Polish, Turkish, Dutch
FIRST EDITION 052019 © 2019 Hanwha Techwin Co., Ltd. All rights reserved.
