ENGLISH

User’s Manual

Thank you for buying a Samsung Camera.

This manual will guide you through using the camera, including capturing images,

downloading images and using the application software.

Please read this manual carefully before using your new camera.

《2》

■ Use this camera in the following order

Insert the
USB cable

Set up the

camera driver

Before connecting the camera to a PC, via the
USB cable, you will need to set up the camera
driver. Install the camera driver that is contained in
Application software CD-ROM. (p.96)

Take a picture. (p.20)

Insert the supplied USB cable into the PC’s USB
port and the camera’s USB connection terminal.
(p.102)

Check the camera’s power. If the power is turned
off, press the camera button to turn it on. (p.31)

Take a picture

Check the

camera’s power

Check

[Removable Disk]

Open Window’s EXPLORER and search for
[Removable Disk]. (p.103)

● If you use a card reader to copy the images on the memory card to your PC, the images
could be damaged. When transferring the images taken with the camera to your PC, be sure
to use the supplied USB cable to connect the camera to your PC. Please note that the
manufacturer holds no responsibility for loss or damage of images on the memory card due
to the use of a card reader.

Instructions

《3》

Contents

READY

●Getting to know your camera 5

●Danger 6

●Warning 6

●Caution 7

●An FCC warning 7

●System chart 8

●Identification of features 10

■Front & Top 10

■Back & Bottom 10

■Bottom/ 5-function button 11

■Cradle 11

■Self-timer lamp 12

■Camera Status Lamp 12

■Mode icon 12

●Connecting to a Power Source 13

■Using the SAC-41 14

■Using the battery 18

■Removing the battery 18

●Instructions on how to use the

memory card 19

●Inserting the memory card 21

●Removing the memory card 21

●

When Using the Camera for the First Time

22

●LCD monitor indicator 23

●Changing the recording mode 24

■Selecting the [Mode] menu 24

■How to use the Auto mode 26

■How to use the Movie clip mode 26

■Recording the movie clip without voice 27

■Using Successive Recording 27

■How to use the Manual mode 27

■How to use the Scene modes 28

■How to use the VOICE RECORDING

mode 29

■How to use the SF mode 29

●Things to Watch Out for When Taking

Pictures 30

●Using the camera buttons to adjust the
camera 31

■POWER button 31

■SHUTTER button 31

●ZOOM W/T button 31

●

Voice recording/ Voice memo/ UP button

34

●Macro/ Down button 35

●Focus lock 36

●Flash/ Left button 37

●Self-timer/ Right button 39

●MENU/ OK button 40

●M (Mode) button 40

●SF button 42

●+/- button 43

●Using the LCD monitor to adjust the camera

settings 47

●How to use the menu 49

●Mode 49

●Mode Set 50

●Size 51

●Quality / Frame rate 52

●Metering 53

●Continuous shot 53

●Sharpness 54

●OSD information 54

●Effect 55

●Special Effect 56

●Special Effect : Preset focus frames 56

●Special Effect : Composite shooting 58

●Special Effect : Photo Frame 60

●Movie Clip frame stabiliser 61

●Starting play mode 62

■Playing back a still image 62

RECORDING

PLAY

《4》

Contents

■Playing back a movie clip 63

■

How to capture the movie clip

63

■On camera movie trimming 64

■Playing back a recorded voice 65

●LCD monitor indicator 66

●Using the camera buttons to adjust the

camera 67

■Play mode button 67

●Thumbnail/ Enlargement button 68

●Voice memo/ Up button 69

●Play & Pause/ Down button 70

●Delete button 71

●Left / Right / Menu / OK button 72

●Album button 73

●Setting up the play back function using the

LCD monitor 76

●Starting the slide show 79

●Protecting images 81

●Deleting images 82

●Resize 83

●Effect 84

●Rotating an image 85

●DPOF 85

●DPOF : Standard 86

●DPOF : Index 86

●DPOF : Print size 87

●Copy To Card 88

●PictBridge 89

●PictBridge : Picture Selection 90

●PictBridge : Print Setting 91

●PictBridge : Printing 92

●PictBridge : RESET 93

●Setup menu 94

●File name 95

●Auto power off 96

●Language 97

●Formatting a memory card 97

●Setting up the Date/ Time/ Date type 98

●Imprinting the recording date 98

●Sound 99

●Connecting an External Device (USB) 99

●Auto Focus lamp 100

●LCD brightness 100

●Selecting Video out type 101

●Quick view 103

●Initialisation 103

●Setting up the Mycam menu 104

●Start up image 104

●Start up sound 105

●Shutter sound 105

●Important notes 106

●Warning indicator 108

●Before contacting a service centre 109

●Specifications 112

●Software Notes 114

●System Requirements 114

●About the software 115

●Setting up the application software 117

●Starting PC mode 127

●Removing the USB Driver for Windows

98SE 130

●Removable Disk 131

●Removing the removable disk 132

●Setting up the USB Driver for MAC 133

●Using the USB Driver for MAC 133

●Digimax Viewer 2.1 134

●Digimax Reader 135

●Using PhotoImpression 137

●FAQ 139

SETUP

SOFTWARE
