Hanwha Techwin DIGIMAXV6 User Manual

DOWN/ LEFT/ RIGHT/ MENU/ OK button

DOWN/ LEFT/ RIGHT/ MENU/ OK buttons activate the following.

- DOWN button : While the menu is showing, press the DOWN button to move from the main menu to a sub menu, or to move down the sub menu cursor.

- LEFT button : While the menu is showing, press the LEFT button to select the menu

tab to the left of the cursor.

- RIGHT button : While the menu is showing, press the RIGHT button to select the menu

tab to the right of the cursor, or to move an secondary menu.

- MENU button : When you press the MENU button, the play mode menu will be

displayed on the LCD monitor. Pressing it again will return the LCD to the initial display.

- OK button : When the menu is displayed on the LCD monitor, the OK button is used

for confirming data that is changed by using the 5 function button.

The shooting information will be displayed on the LCD monitor. The last image stored in the memory is displayed on the LCD monitor by pressing the play mode button. Pressing the LCD( ) button in the PLAY mode will change the display as shown below. [Image & Icons] [Image & Information] [Image only]

[ Image & Icons ] [ Image & Information ] [ Image only ]

Pressing the LCD button

Pressing the

LCD button

Pressing the

LCD button

LCD( ) button

SIZE : 2816X2112

AV : F2.7 TV : 1/30

ISO : 50

FLASH : OFF

DATE : 2004/07/01

* The LCD button is not available for voice recording in play mode.

Delete ( ) button

This deletes images stored on the memory card.

Before deleting images from the camera, you should protect (p.67) or download images (p.106) to your computer that you wish to keep.

INFORMATION

Deleting Images in Play Mode

1. Select an image that you want to delete by pressing the

LEFT / RIGHT button and press the DELETE ( ) button.

2. A message will display as shown alongside on the LCD

monitor.

3. Press the OK button to delete the image.

DELETE ?

DEL:OK

CANCEL:

Deleting Images in Thumbnail Display Mode

1. Use the Up/Down/Left/Right buttons to select an image to delete.

2. Press the Delete button to display the following message in the LCD monitor.

Press the DELETE

button.

1 2 3

4 5 6

7 8 9

1 2 3

4 5 6

7 8 9

DELETE ?

DEL:OK

CANCEL:

3. Press the OK button to delete the image.

Setting up the play back function using the LCD monitor

PLAY mode functions can be changed by using the LCD monitor. In the PLAY mode, pressing the MENU button displays the menu on the LCD monitor. The menus you can set up in Play mode are as follows. To capture an image after setting up the play menu, press the PLAY button.

The items indicated by are default settings.

Menu tab Main menu Sub menu Secondary menu Page

PROTECT

DELETE

RESIZE

ROTATE

SLIDE

DPOF

p. 69

p. 67

p. 68

p. 70

p. 67

p. 70

~ p. 72

SELECT

ALL PICS

SELECT

ALL PICS

OFF / 1~10SEC

ON / OFF

CANCEL / EFFECT1, 2, 3, 4

UNLOCK / LOCK UNLOCK / LOCK

1600X1200

1280X960

800X600

LOGO

RIGHT

LEFT

UPDOWN

INTERVAL

REPEAT EFFECT

SIZE

STANDARD

INDEX

SELECT/ ALL PICS/ CANCEL

NO/ YES

SELECT/ ALL PICS/

CANCEL

Setting up the play back function using the LCD monitor

Menu tab Main menu Sub menu Secondary menu Page

AUTO

POSTCARD

4X6

8X10

A6 A4 B5

AUTO

FULL

1 2 4 6

8 AUTO PLAIN


FASTPHO.

AUTO SET

CUSTOM SET

IMAGES

p. 75

p. 74

YES

SIZE

LAYOUT

TYPE

ONE PIC

ALL PICS

This menu is available while the camera is connected to a PictBridge supporting printer (direct connection to the camera, sold separately) with a USB cable.

Setting up the play back function using the LCD monitor

QUALITY

Menu tab Main menu Sub menu Secondary menu Page

AUTO

DRAFT

NORMAL

FINE

AUTO

OFF

AUTO

OFF

STANDARD -

INDEX -

YES -

NO -

YES -

NO -

CUSTOM SET

p. 76

p. 77

p. 75

FILE NAME

DATE

DPOF PRINT

RESET

Menus are subject to change without prior notice.

Starting the slide show

Images can be displayed continuously at pre-set intervals. You can view the slide show by connecting the camera to an external monitor. Configure the interval for the slide show : Configure the length of time to display each picture in the slide show.

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [SLIDE] menu tab.

3. Select the [INTERVAL] sub menu by pressing the UP/ DOWN button and press the RIGHT button.

4. Use the Up/Down Button to establish the display interval.

- Slide Show Display Interval : OFF, 1 ~10 seconds

5. Use the Right Button to start the slide show. Use the Pause ( ) Button to pause and resume the slide show. To cancel the slide show in the middle of the show, press the Pause button and the LEFT or RIGHT button.

The loading time depends on the image size and quality. The slide show will start from an image that was displayed on the LCD monitor. The [PWR OFF] function can t be activated. While the slide show is playing, only the first frame of an MOVIE file is displayed.

INFORMATION

Configure slide show repeat mode : Automatically restart the slide show after displaying all pictures.

Steps 1 and 2 are the same as for the [INTERVAL] section.

3. Select the [REPEAT] sub menu by pressing the UP/ DOWN button and press the RIGHT button.

4. Use the Up/Down Button to select the repeat mode. [ON] : The slide show will repeat until turned off. [OFF]: The slide show will not repeat after the first

showing.

5. Press the OK button to confirm the setting.

6. Press the OK button again and the slide show will start.

SLIDE

INTERVAL

REPEAT EFFECT

MOVE: SET:OK

OFF

SLIDE

INTERVAL

REPEAT

EFFECT

BACK:

SET:OK

OFF

Starting the slide show

Protecting images

Configure slide show effects: Unique screen effects can be used for the slide show. Steps 1 and 2 are the same as for the [INTERVAL] section.

3. Select the [EFFECT] sub menu by pressing the UP/ DOWN button and press the RIGHT button.

4. Use the Up/Down Button to select the type of effect.

[CANCEL] : Normal display. [EFFECT 1] : Image is displayed slowly. [EFFECT 2] : Image is displayed slowly from the

center outwards. [EFFECT 3] : Image moves from the top left. [EFFECT 4] : The image slides diagonally from top left to bottom right.

5. Press the OK button to confirm the setting.

6. Press the OK button again and the slide show will start.

This is used to protect specific shots from being accidentally erased (LOCK). It also unprotects images that have been previously protected (UNLOCK).

Protecting Images

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [PROTECT] menu tab.

3. Select a desired sub menu by pressing the UP/ DOWN button and press the OK button. [SELECT] : Selection window for an image to be

protected/released is displayed.

- Up/Down/Left/Right : Select an image

- Zoom W/T Button : Protect/release the image

- Menu Button : Your changes will be saved and the

menu will disappear.

[ALL PICS] : Protect/release all saved images

- Zoom W/T Button : Protect/release the images

- Menu Button : Your changes will be saved and the

menu will disappear.

SLIDE

INTERVAL REPEAT

EFFECT BACK:

SET:OK

CANCEL

EFFECT1 EFFECT2

PROTECT

SELECT ALL PICS

EXIT:MENU MOVE:

SET:OK

UNLOCK T

SET:OK

UNLOCK T

Protecting images

- If you protect an image, the protect icon will be displayed

on the LCD monitor. (An unprotected image has no indicator)

- An image in LOCK mode will be protected from the

delete function or [DELETE] functions, but will NOT be protected from the [FORMAT] function.

Deleting images

Of all the files stored in the memory card, the unprotected files in the DCIM subfolder will be deleted. Remember that this will permanently delete unprotected images. Important shots should be stored on a computer before deletion takes place. The startup image is stored in the camera's internal memory (i.e., not on the memory card) and it will not be deleted even if you delete all files on the memory card.

Deleting images

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [DELETE]

menu tab.

3. Select a desired sub menu by pressing the UP/ DOWN

button and press the OK button.

[SELECT]: Selection window for an image to delete is

displayed.

- Up/Down/Left/Right: Select an image

- Zoom T Button: Select the image for deletion.

(V mark)

- OK Button: Press the OK Button to display confirmation

message Press the OK Button again to delete V marked images. [ALL PICS]: Displays confirmation window

Press the OK Button again to delete all unprotected images. If there aren t protected images, all the images are deleted and a [NO IMAGE!] message will display.

4. After deletion, the screen will be changed to the play mode screen.

DELETE

SELECT ALL PICS

EXIT:MENU MOVE:

DEL:OK

SELECT :T

DELETE ?

DEL:OK

CANCEL:

Resize

Change the resolution (size) of pictures taken. Select [LOGO] to save an image to be the start-up image. The resized image will have a new file name.

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [RESIZE]

menu tab.

3. Select a desired sub menu by pressing the UP/ DOWN

button and press the OK button. [RESIZE] sub menu : 1600X1200, 1280X960, 800X600,

LOGO

A large sized image can be resized to a smaller sized image, but not vice versa. Only still image(JPEG) images can be resized. TIFF, Movie clip(AVI) and Voice recording(WAV) files can’t be resized. You can change the resolution of only those files compressed in the JPEG 4:2:2 format. The resized image will have a new file name. The [LOGO] image is stored not on the memory card but on the internal memory. Only one [LOGO] image can be saved. If you save a new [LOGO] image, the existing startup image will be deleted. If the memory capacity is insufficient to store the resized image, a [CARD FULL!] message will display on the LCD monitor and the resized image will not be stored.

INFORMATION

Image Resize Types

RESIZE

1600X1200 1280X960 800X600

EXIT:MENU MOVE:

Size 1600X1200 1280X960 800X600 LOGO 2816 O O O O 2560 O O O O 2272 O O O O 2048 O O O O 1600 O O O O 1024 X X O O

640 X X X O

Rotating an image

DPOF

DPOF(Digital Print Order Format) allows you to embed printing information on your memory card’s MISC folder. Select the pictures to be printed and how many prints to make. The DPOF indicator will display on the LCD monitor when an image that has DPOF information plays back. Images can then be printed on DPOF printers, or at an increasing number of photo labs. This function is not available for Movie clips and Voice recording files.

You can rotate the stored images by 90, 180, or 270 degrees. You can view a picture in its proper orientation if the picture has been taken with the camera oriented vertically or up-side-down. Once the playback of the rotated picture is finished, it will switch back to the original state.

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [ROTATE] menu tab.

3. Select a desired sub menu by pressing the UP/ DOWN button.

[RIGHT] : Rotate picture in a clock-wise direction [LEFT] : Rotate picture in a counter-clock-wise

direction

[UPDOWN] : Rotate picture 180 degrees

[ Picture after 90 degrees ]

CCW rotation

[ Picture after 180 degrees ]

rotation

[ Picture after 90 degrees ]

CW rotation

4. Press the OK button. The rotated image will be displayed and the menu will disappear. If you display the rotated image on the LCD monitor, empty spaces may appear to the left and right of the image.

ROTATE

RIGHT LEFT UPDOWN

EXIT:MENU MOVE:

DPOF : STANDARD

Images (except for movie clips and voice file) are printed as index type.

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [DPOF]

menu tab.

3. Select the [INDEX] menu by pressing the UP/ DOWN

button and press the RIGHT button.

4. Select a desired sub menu by pressing the UP/ DOWN

button. If [NO] is selected : Cancel the index print setting. If [YES] is selected : The image will be printed in index

format.

5. Press the OK button to confirm the setting.

DPOF : INDEX

This function allows you to embed print quantity information on a stored image.

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [DPOF]

menu tab.

3. Select the [STANDARD] menu by pressing the UP/

DOWN button and press the RIGHT button.

4. Select a desired sub menu by pressing the UP/ DOWN

button and press the OK button. [SELECT]: Selection window for an image to print is

displayed.

- Up/Down/Left/Right: Select an image to print.

- Zoom W/T Button: Select the number of prints. [ALL PICS] : Configure number of prints for all pictures

except movie and voice files.

[CANCEL] : Cancel the print setup.

5. Press the OK button to confirm the setting.

If an image carries DPOF instructions, the DPOF indicator ( ) will show.

DPOF

BACK: SET:OK

SET:OK

0 PRINTS T

DPOF

STANDARD

INDEX

SIZE

BACK:

SET:OK

YES

STANDARD

INDEX SIZE

SELECT

ALL PICS CANCEL

DPOF

BACK: SET:OK

STANDARD

INDEX SIZE

0 PRINTS

DPOF : PRINT SIZE

You can specify the print size when printing images stored on the memory card. The [SIZE] menu is available only for DPOF 1.1 compatible printers.

Setting the Print Size

1. Press the play mode button and press the menu button.

2. Press the LEFT/ RIGHT button and select the [DPOF] menu tab.

3. Select the [SIZE] menu by pressing the UP/ DOWN button and press the RIGHT button.

4. Select a desired sub menu by pressing the UP/ DOWN button and press the OK button.

[SELECT] : Selection window for an image to be changed

printed size is displayed.

- Up/Down/Left/Right : Select an image.

- Zoom W/T Button : Change the print size.

- OK button : Your changes will be saved and the menu will disappear.

[ALL PICS] : Change print size of all saved images.

- Up/Down/Left/Right : Select an image.

- OK button : Confirm the changed setting.

[CANCEL] : Cancel all of the print size settings.

* DPOF [SIZE] secondary menu : CANCEL, 3X5, 4X6, 5X7,

8X10

DPOF

STANDARD INDEX

SIZE BACK:

SET:OK

SELECT

ALL PICS CANCEL

SET:OK

CANCEL T

DPOF

STANDARD INDEX

SIZE BACK:

SET:OK

CANCEL

PictBridge

If you selected [COMPUTER] in Step 5, when you connect the camera to your printer, the Mode dial lamp(Green) will illuminate and the connection will not be established. In this case, disconnect the USB cable, and then follow the procedure from Step 2 and onward.

SETUP

Q. VIEW RESET USB BACK: SET:OK

COMPUTER PRINTER

NOR 2816

Connecting the Camera to a Printer

1. Slide the power switch to turn the camera power on.

2. In a mode other than Voice Recording mode, press the MENU button.

3. Press the LEFT/ RIGHT button and select [SETUP] menu tab.

4. Select [USB] menu by pressing the UP/ DOWN button and press the RIGHT button.

5. Select [PRINTER] menu by pressing the UP/ DOWN button and press the OK button.

6. Press the menu button twice and the menu will disappear.

7. Use the supplied USB cable to connect the camera to the printer as shown below.

8. Turn on the printer to connect the camera to the printer.

You can use the USB cable to connect this camera to a printer that supports PictBridge (sold separately) and print the stored images directly. TIFF, Movie clips and voice files cannot be printed. You can set up the following settings from the PictBridge menu.

IMAGES : Select the pictures to be printed. PRINTER SETUP : Setting up printing(AUTO SET/CUSTOM SET) PRINT : Printing pictures DPOF AUTO PRINT : Printing the DPOF files RESET : Initializing the PictBridge functions

PictBridge: Picture Selection

Select pictures to print

1. Connect the camera to your printer. The USB menu must

be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. The [IMAGES] menu will appear.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button. When [ONE PIC] is selected : The PictBridge function will be applied only to the picture currently displayed. When [ALL PICS] is selected : The PictBridge function will be applied to all pictures, excluding TIFF, movie clips and voice files.

[ When [ONE PIC] is selected ] [ When [ALL PICS] is selected ]

- Press the Up/Down button to select the number of prints. Maximum 30 prints.

- Use the Left/Right button to select another picture and select the number of prints for another picture.

- After setting the number of prints, press the OK button to save.

- Press the Shutter button to return to the menu without setting the number of prints.

EXIT:SHUTTER SET:OK

IMAGES

ONE PIC ALL PICS

MOVE: SET:OK

Setting the Number of Copies to Print

- Select [ONE PIC] or [ALL PICS]. A screen where you can set the number of copies to print will appear as shown below.

PREV NEXT

EXIT:SHUTTER SET:OK

PictBridge: Print Setting

SIZE Setting the size of the printing paper

AUTO, POSTCARD, 4x6, 8x10, A6, A4, B5

LAYOUT

Setting the number of pictures to be printed on a sheet of paper

AUTO, FULL, 1, 2, 4, 6, 8

TYPE Setting the quality of the printing paper AUTO, PLAIN, PHOTO, FASTPHO.

QUALITY

Setting the quality of the picture to be printed

AUTO, DRAFT, NORMAL, FINE

DATE Setting whether to print the date AUTO, OFF, ON

FILE NAME Setting whether to print the file name AUTO, OFF, ON

AUTO SET

1. Connect the camera to your printer. The USB menu

must be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. Use the LEFT and RIGHT buttons to select the [AUTO

SET] menu tab.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button. [YES]: All values in the [CUSTOM SET] are

automatically changed.

[NO] : [CUSTOM SET] values are kept.

Some menu options are not supported in all manufacturer and printer models. If not supported, the menus are still displayed in the LCD, but are not selectable. If the setting values are not changed in the automatic/manual setting, the setting values are automatically kept.

AUTO SET

YES NO

MOVE: SET:OK

CUSTOM SET

SIZE LAYOUT TYPE

AUTO POST DARD 4X6

BACK:

SET:OK

1. Connect the camera to your printer. The [USB] menu

must be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. Use the LEFT and RIGHT buttons to select the

[CUSTOM SET] menu tab.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the RIGHT button.

4. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button.

CUSTOM SET : You can select the Paper Size, Print Format, Paper Type, Print Quality, Date Print, and File Name Print menus for printed pictures.

Function Sub menu

The menus you can set up are as follows:

PictBridge: Printing

Printing Pictures

1. Connect the camera to your printer. The USB menu

must be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. Use the LEFT and RIGHT buttons to select the [PRINT]

menu tab.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button.

[STANDARD] :

Print the pictures stored in the memory card in set numbers. One picture is printed on one piece of paper.

[INDEX] : Print multiple images on one sheet of paper.

STANDARD INDEX

MOVE: SET:OK

DPOF PRINT

YES NO

MOVE:

1. Connect the camera to your printer. The [USB] menu

must be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. Use the LEFT and RIGHT buttons to select the [ DPOF

PRINT] menu tab.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button. [YES]: Directly print the file with the DPOF information [NO] : Cancel the printing

Depending on the manufacturer and printer model, some menus may not be available. With a printer without supporting the DPOF, the menu is still displayed but not available.

NOW PRINTING

CANCEL:OK

1/1

4. The screen shown on the right will appear and the picture will be printed. If no picture is selected, the [NO IMAGE!] message will be displayed. Press the Menu/OK button while printing to cancel the printing and the [IMAGES] menu is displayed.

Number of pictures in a index print varies depends on the printer used.

DPOF PRINT : This allows you to directly print the files with DPOF information.

PictBridge : RESET

Initializes user-changed configurations.

1. Connect the camera to your printer. The [USB] menu

must be set to [PRINTER] before you connect the camera to the printer.(See p.86)

2. Use the LEFT and RIGHT buttons to select the [RESET]

menu tab.

3. Use the UP and DOWN buttons to select the desired

submenu value, and then press the OK button.

- If [YES] is selected : All print and image settings will be reset.

- If [NO] is selected : Settings will not be reset.

Default print setting varies depending on the printer manufacturer. For your printer’s default setting, refer to the user’s guide that came with your printer.

RESET

YES NO

MOVE: SET:OK

Setup menu

In this mode, you can set up basic settings. You can use the setup menu in all camera modes, except Voice Recording mode. The items indicated by are default settings.

Menu tab Main menu Sub menu Secondary menu Page

RESET

SERIES

OFF, 1~3~10MIN p.80

ENGLISH

P”CCK»…

FRANÇAIS PORTU.

DEUTSCH DUTCH ESPAÑOL DANSK

ITALIANO SVENSKA

SUOMI

THAI

YES

YY/MM/DD DD/MM/YY MM/DD/YY

OFF

DATE

D & TIME

OFF

LOW

MEDIUM

HIGH

04/07/01 13:00

FILE

PWR OFF

LANGUAGE

FORMAT

D & TIME

IMPRINT

SOUND

p.79

p.81

p.82

p.83

+ 42 hidden pages
