Hanwell IM6001 User Manual
IM6001
Hanwell Smart Receiver 2
(SR2)
User Manual
hanwell.com
Intentionally Blank
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
Document History
Document Number: IM6001
Issue
No.
1 11 July 2018 First release. IR
2 23 October 2018
3 20 February 2019
4 17 June 2019
Issue Date Changes By
Addition of Appendix 3 and minor
amendments.
Addition of information on IEC mains inlet
socket and voltage selection switch.
Addition of Cautions, Warnings and
additional specifications.
IR
IR
IR
hanwell.com
Page 1 of 22 IM6001 - 3
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
Contents
Document History .............................................................................................................................. 1
1 Introduction ......................................................................................................................... 3
2 Pre-Requisites ..................................................................................................................... 4
2.1 Inventory .............................................................................................................................................. 4
2.2 SR2 Unit Ratings ................................................................................................................................ 4
2.3 SR2 Receiver Unit – External Appearance ................................................................................ 5
3 Copy of Document GD6014 .............................................................................................. 6
3.1 Physical Pre-requisites .................................................................................................................... 6
3.1.1 Virtual Pre-requisites ................................................................................................................... 7
4 Installing the SR2 ............................................................................................................... 8
4.1 Wall-mounting the SR2 .................................................................................................................. 8
4.2 Connecting the Receiver Unit ....................................................................................................... 9
4.3 Connecting the Power and Network .......................................................................................... 10
4.4 Configuring the SR2 Receiver’s Network Settings .................................................................. 11
5 Advanced SR2 Configuration .......................................................................................... 12
5.1 Fall Back Operation......................................................................................................................... 12
5.2 On-Board Sensors ........................................................................................................................... 12
5.3 Alarm Relay Operation ................................................................................................................... 12
5.4 Sensor Groups .................................................................................................................................. 13
5.5 Transmitter Preamble ..................................................................................................................... 13
6 Additional Connections .................................................................................................... 14
6.1 Alarm Relays ..................................................................................................................................... 14
6.2 MS1000 Control Panel.................................................................................................................... 15
6.3 On Board Sensors ........................................................................................................................... 15
7 Maintenance ...................................................................................................................... 17
7.1 Uninterruptable Power Supply (UPS) Battery .......................................................................... 17
7.2 Coin Cell Battery .............................................................................................................................. 17
7.3 Fuse Specifications ......................................................................................................................... 17
8 Contact Hanwell Solutions ...............................................................................................18
Appendix 1 – SR2 Connection Data .............................................................................................. 19
Appendix 2 - Setting up an SR2 with an IP Address for use with EMS or Synergy ............... 20
IM6001 - 3 Page 2 of 22
hanwell.com
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
1 Introduction
This Document details how to install the Hanwell Smart Receiver 2 (SR2) Unit.
The SR2 is a Network Enabled Receiver, designed for collecting environmental monitoring
data from multiple points within a site. In addition, it can be upgraded to a Transceiver which
both receives and re-transmits data.
It uses the standard TCP/IP communications protocol for rapid data handling.
hanwell.com
Page 3 of 22 IM6001 - 3
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
2 Pre-Requisites
Before installing and configuring the SR2, you should have read Document GD6014 Smart
Receiver Installation Pre-requisites which details the necessary pre-conditions for installation.
A copy of this is supplied in Section 3.
If a Radio Survey has not been completed, the SR2 unit should not be permanently mounted
to the wall until the radio reception has been tested for the proposed location.
2.1 Inventory
Your SR2 should be supplied with the following, as standard:
1 x SR2.
1 x 1m straight-through CAT5 cable.
IEC Power Cord with Locking System; see Figure 3 overleaf.
1 x UPS battery (unless an external one is to be used).
1 x External Receiver Unit (boxed separately).
USB-SP2; USB stick containing relevant manuals, including IM6001 (this document).
If you are missing any of these items, please contact Hanwell Solutions Ltd.; see Section 8.
You will also need the EMS application installed on your System.
2.2 SR2 Unit Ratings
Voltage:
Frequency:
Current:
Power:
115 – 240V Switchable
50 – 60Hz
180mA @230vAC
80W
WARNING!
To Avoid Possible Electric Shock or Personal Injury, Follow These Guidelines:
DO NOT operate this Unit without a properly grounded, properly polarised power cord.
DO NOT connect this Unit to a non-grounded, non-polarised outlet.
Caution
The SR2 Unit contains a Lead-Acid UPS battery which should never be left for extended
periods in a discharged state, to prevent damage to the battery’s cells.
IM6001 - 3 Page 4 of 22
hanwell.com
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
2.3 SR2 Receiver Unit – External Appearance
Figure 1 - SR2 Unit Control Panel
Internal Power Supply Unit (PSU) Fuse
Figure 2 - Underside of Unit
Locking Mechanism*
Figure 3 - IEC Power Cord with Locking Mechanism
hanwell.com
Page 5 of 22 IM6001 - 3
*Note: The SR2 MUST NOT
be powered via a
standard IEC Power
Cord without a
locking mechanism.
Hanwell Smart Receiver 2 (SR2)
Instruction Manual
3 Copy of Document GD6014
Hanwell Document GD6014 – Hanwell EMS Pre-Requisites should have been supplied when
the SR2 was ordered, so that the pre-requisites could be completed in advance. The contents
of it are reproduced here in case the original has been lost.
This Section lists the pre-requisites – physical and virtual – needed to install and configure an
SR2 for operation on a network. The required information can, in most cases, be obtained
from your IT Department.
Note: The network information must be available prior to the commissioning of the System.
3.1 Physical Pre-requisites
The following pre-requisites assume that a final location for the SR2(s) has been identified
following a Radio Survey. If this is not the case, then the following should be factored in when
deciding the SR2’s final location.
There should be:
A 24-hour mains power outlet within 1.5m of the planned location.
An enabled 10/100 Base T LAN socket at the planned location.
Note: If this is greater than 1m from the planned location, a suitable straight through
CAT5 lead is required. This can, in most cases, be supplied by your IT department.
A suitable wall structure on which the SR2 can be mounted so that the antenna is
vertical.
The planned location should NOT:
Be in an area subjected to high temperature or humidity levels.
Have any metallic objects within 0.3 metres of the antenna in any direction; this
includes any structures hidden within walls, pillars etc.
IM6001 - 3 Page 6 of 22
hanwell.com
