Hannspree SV42LMUB User Manual

Table of Contents

Regulatory Information ................................................................ 3

Description of Warning Symbols .................................................. 3

Safety Notices ............................................................................. 4

Preface ....................................................................................... 6

Warranty and Service .................................................................. 6

1. Getting Started ........................................................................8

1.1 Package Contents .............................................................8

1.2 Stand Base Assembly ........................................................9

1.3 Introducing the TV ........................................................... 11

1.4 Features ......................................................................... 11

1.5 Control Panel .................................................................. 12

1.6 Input and Output Jacks .................................................... 12

1.7 Remote Control ............................................................... 14

1.8 Inserting the Remote Control Batteries ............................. 18

2. Setting up your TV .................................................................20

2.1 Power Connection ........................................................... 20

2.2 Rear Connections............................................................ 20

2.3 Using the TV ................................................................... 22

2.3.1 Turning the TV On and Off ...................................... 22

2.3.2 Switching Source Signals........................................ 22

2.3.3 Performing an Automatic Channel Search ................ 22

2.3.4 Selecting Channels................................................. 22

2.3.5 Adjusting the Volume .............................................. 22

English

3. Adjusting On-Screen Display (OSD) Settings .......................... 23

3.1 OSD Setting Menus ......................................................... 24

3.2 Adjusting Picture Settings ................................................ 24

3.3 Adjusting Sound Settings ................................................. 25

3.4 Adjusting TV Settings ......................................................26

3.5 Adjusting Features Settings ............................................. 29

1

English

Table of Contents

3.6 Adjusting Eco Settings .................................................... 32

4. Troubleshooting ..................................................................... 33

5. Support Timing ...................................................................... 34

6. Support USB Compatible Formats ..........................................35

7. Specifications ........................................................................ 36

8. Dissembling the stand base ....................................................37

9. Using the Cable Organizer .....................................................38

2

Regulatory Information

CE Conformity Statement

This device is in conformity with the requirements of EU Council Directive
2004/108/EC on the approximation of the laws of the Member States relating to
electromagnetic compatibility and Directive 2006/95/EC on the harmonization of
the laws of Member States relating to electrical equipment for use within certain
voltage limits. Hannspree cannot accept responsibility for any failure to satisfy
the requirements resulting from a non-recommended modification of the device.

Description of Warning Symbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING

CAUTION

English

This symbol is used to alert users
to pay attention to important
descriptions regarding usage,
maintenance (repair), and
additional important information
related to this TV.

This symbol is used to alert users
to the risk of electric shocks due
to dangerous and uninsulated
components.

3

English

Safety Notices

Installation Safety Notes

Location

Avoid allowing the TV to get prolonged exposure to sunlight or other strong
sources of heat. Leave sufficient distance between the TV and the wall to
provide enough space for the emission of heat.

WARNING

To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture.

Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.

CAUTION

These servicing instructions are for use by qualified service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.

WARNING

To prevent the spread of fire, keep candles or other open flames away from
this product at all times.

4

Notes:

• The LED-LCD HDTV is for entertainment use only and visual
display tasks are excluded.

• This device uses a VGA connector to connect to a PC. To reduce
the influence of main frequency on the source signal, use a VGA
monitor cable with ferrite shield.

Personal Safety

1. To avoid overloading the power supply, never plug too many electrical
devices into an outlet, power strip, or extension cable.

2. Dangerous high-voltage electric power components are located inside the
TV. To avoid electric shock, do not disassemble the casing.

3. Do not place or drop metals, small objects, or flammable materials into
the vent of the TV.

4. If the TV is dropped, falls down, or is otherwise damaged, unplug the
power cord immediately and contact an authorized service technician.

5. If any fluid is sprayed or dropped into the TV, contact an authorized
service technician.

6. The screen of the TV is made of glass. Avoid hitting or scraping it. If the
screen is broken, do not touch the broken glass.

7. Do not allow children to use the TV unattended.

English

8. Be careful when disconnecting the power plug. Hold the plug. Do not
attempt to disconnect the plug by pulling on the power cord.

Installation

1. Do not place the TV in locations where there is excessive steam or dust.

2. Avoid blocking the TV's vents, do not place the TV on a bed, sofa, carpet,
or in a sealed cabinet.

5

English

3. Install the outdoor antenna away from power transmission lines to avoid
possible danger.

Preface

Thank you for purchasing a Hannspree Liquid Crystal Display Television (LED­LCD HDTV). Your new TV will allow you to enjoy superior audio and video while
enriching your lifestyle with advanced technology.

Please carefully read this manual in its entirety before setting up, using or
operating your TV. To ensure the safe and correct installation and operations of
the TV, it is important that the safety and operation instructions in this manual
are followed.

This instruction manual is designed to assist you in setting up and using the TV.
The information in this manual has been carefully checked for accuracy;
however, no guarantee is given to the correctness of the contents. The
information in this manual is subject to change without notice.

To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not
be liable for direct, indirect, special, exemplary, incidental or consequential
damages arising from any defect or omission in this manual, even if advised of
the possibility of such damages in advance.

Warranty and Service

For complete warranty service information, please refer to the “Warranty Card”
enclosed with your TV.

6

Copyright

© Copyright 2010 Hannspree, Inc.

All rights reserved. This manual is protected by copyright and distributed under
licenses restricting its use, copying and distribution. No part of this manual may
be reproduced in any form by any means without the prior written authorization
of Hannspree. The TV described in this manual may include copyrighted
software of Hannspree (or other third parties). Hannspree (or other third parties)
preserves the exclusive rights for copyrighted software, such as the right to
distribute or reproduce the copyrighted software. Accordingly, and to the extent
allowed by applicable law, any copyrighted software contained in the product
described herein shall not be distributed, modified, reverse engineered, or
reproduced in any manner without the prior written authorization of Hannspree
(or of other third parties).

The Hannspree logos presented herein are trademarks of Hannspree. All other
product names, trademarks or logos mentioned herein are used for identification
purpose only, and may be the trademarks or registered trademarks of their
respective owners.

The purchase of the product described herein shall not be deemed to grant,
either directly or by implication, estoppel or otherwise, any license under the
copyrights, patents, patent applications or trademarks of Hannspree, except for
the normal, non-exclusive use that arises by operation of law in the sale of a
product.

English

Trademark Notice

Hannspree products incorporate High-Definition Multimedia
Interface (HDMI™) technology.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.

License Notice and Trademark Acknowledgment

Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby
Laboratories.

7

English

1

Getting Started

1.1 Package Contents

Make sure the following components are included in the box. Please contact
Hannspree Customer Service immediately if anything is missing or damaged.

•TV

• User’s manual

• Quick start guide

• Warranty card

•Power cord

• Remote control and batteries

• TV cleaning cloth

• Stand screw x 3 (for 19"/22")

• Stand screws x 4 (for 25”/28”/32”/42”)

8

ME61

According to WEEE regulation, this TV can’t be handled as normal
trash in Europe when it is out of usage. Please refer to the recycle
information from our website to handle it.

1.2 Stand Base Assembly

SV19/SV22:

English

(1) Always assemble the TV base
with assistance from another person.

(2) Lay the TV over a towel or cloth to
prevent scratching to the frame or
glass and place near the edge of a
table.

(3) Follow the close-up, then place
the base with the right direction.

Be certain to hold the TV firmly with
your hand to avoid slipping.

Insert base, then 3 screws
(provided) and fasten securely.
Please fasten with cross
screwdriver.

Always carry the TV with assistance
from another person.

9

English

SV25/SV28/SV32/SV42:

(1) Always assemble the TV base
with assistance from another person.

(2) Lay the TV over a towel or cloth to
prevent scratching to the frame or
glass and place near the edge of a
table.

(3) Follow the close-up, then place
the base with the right direction.

Be certain to hold the TV firmly with
your hand to avoid slipping.

Insert base, then 4 screws
(provided) and fasten securely.
Please fasten with cross
screwdriver.

Always carry the TV with assistance
from another person.

10

1.3 Introducing the TV

You can watch Analog (PAL/SECAM), Digital (DVB-T/DVB-C) television channels,
and easily connect a VCR, STB or DVD player to the SCART, HDTV (Component),
AV (Composite), and HDMI input ports (location of these ports depends on model).
You can also use the TV as a monitor for your PC by connecting it through the VGA
port.

Convenient control buttons located on the TV and a handy remote control let you
change channels, adjust the volume, and change display settings through an easy­to-use on-screen display menu system. The built-in stereo speakers provide full rich
sound and a convenient audio output port lets you connect to an external audio
system or earphones.

1.4 Features

• TV Tuner: Built-in TV Tuner

• Audio/ Video support:
–SCART inputs
– VGA (PC) input
– HDMI inputs
– HDTV (Component) input
– R/L audio inputs
– PC line input
– 3.5 mm stereo earphone

output
– AV (Composite) input
– SPDIF output (digital audio

• Teletext level 1.5 with 1000 pages
memory

• Built-in stereo speakers

• Image Enhancement Technology

– 3:2 and 2:2 pull down
– 3D Comb Filter
–HD-ready TV
– 3D MA deinterlacing
– Dynamic backlight control
– Dynamic contrast

• Eco design

• Noise Reduction

out)

• On-Screen Display (OSD) menu
system

• USB (Music, photo and movie)

• USB update firmware

English

Note:

• The supporting devices mentioned in this manual may vary on different models.
For more information, please refer to the manufacturer’s user manual or the
Quick Start Guide of your TV model.

11

English

1.5 Control Panel

Description Button Function

Power Press to turn the TV on or off.

Input source INPUT Press to select the proper input source.

Menu MENU

Program select

Program select

Volume adjust VOL +

Volume adjust VOL -

Remote IR
sensor

Power/ Standby
indicator

Speakers Deliver high-quality sounds.

P

P

Press to turn the on-screen display (OSD)
menu on / off.

Press to increase the program number or
move upward to the previous item on the
OSD menu.

Press to decrease the program number or
move downward to the next item on the OSD
menu.

Press to increase the volume or move to the
right on the OSD menu.

Press to decrease the volume or move to the
left on the OSD menu.

Receive incoming remote control commands.

Indicate power or standby status. The LED
turns white when the device is turned on.

1.6 Input and Output Jacks

Description Connector Function

Cable/Antenna Connect to an antenna or cable TV.

12

Description Connector Function

English

Earphone Output

Component/
CVBS Inputs
(Audio)

Component
Inputs (Video)

PC Audio Input Connect to a PC’s line / audio port.

SCART 1

SCART 2
(32”/42” only)

VGA (PC) Input Connect to a PC’s VGA port.

Connect to earphones or external
speakers with built-in amplifier.

Connect to an external device, such as a
VCR, STB, or a DVD player.

Connect to an external device, such as a
VCR, STB, or a DVD player.

Connect to an external device, such as a
VCR, STB, or a DVD player with AV, S­Video, RGB, L/R IN, Analog TV Out, and
L/R Out.

Connect to an external device, such as a
VCR, STB, or a DVD player with AV, S­Video, L/R IN.

USB Connect to a USB device.

Video

CI Connect to a CI device.

VIDEO

Connect to an external device, such as a
VCR, STB, or a DVD player.

13

English

Description Connector Function

Connect an HDMI equipment or an

HDMI 1 Input

HDMI-DVI adapter cable to devices such
as a DVD player or set-top box.

HDMI 2 Input
(32”/42” only)

HDMI 3 Input

SPDIF

Power Connector Connect to the included power cord.

SPDIF

AC IN

Connect an HDMI equipment or an
HDMI-DVI adapter cable to devices such
as a DVD player or set-top box.

Connect an HDMI equipment or an
HDMI-DVI adapter cable to devices such
as a DVD player or set-top box.

Connect to a digital audio output device
such as a home theater.

1.7 Remote Control

Description Icon Function

Power Press to turn the TV on or off.

Input Signal
Type

INPUT

Press to select the input signal type selections:
TV, YPbPr, AV, SCART, PC, HDMI 1, HDMI 2,
and USB.

Keypad

Pro.List Pro.LIST

14

Use to select a program directly. Press 0-9 to
enter the program numbers (press 1 and 0 for
program 10).

Press to display the programs contained.

Description Icon Function

V

English

Last Press to return to the last channel selected.

Information INFO

Menu MENU

OK OK Press to confirm selection.

Arrows

Electronic
Program
Guide

Teletext mode Press to activate teletext.

Volume adjust

Mute

LAST

EPG

TEXT

OL / VOL

MUTE

Press to display current channel/program
information.

Press to turn the on-screen display (OSD)
menu on / off.

Press up, down, left or right to scroll through
the on-screen display menus.

Press to display detailed programming
information for channels (only for DTV).

Press VOL

Press VOL

Press to eliminate sound. Press it again or
press the volume adjust buttons to restore
sound.

+ to increase volume.

- to decrease volume.

Dual sound

Select
program

Red, Green,
Yellow, Blue

PS / PT

Press to change the multi sound selection of
the TV channel.

Press PS to increase the program number.
Press PT to decrease the program number.

Press the colored buttons to perform specific
tasks in the OSD menu or teletext mode.

15

English

X

Description Icon Function

Index

Mix

Adjust size

Subtitle

Hold

Reveal

Sound Mode

INDE

MIX

SIZE

SUBTITLE

HOLD

REVEAL

SOUND

Press to display a table of the available teletext
subjects.
(Programmable in the teletext mode only)

Press to display the teletext over the program
on the screen. (Programmable in the teletext
mode only)

Press to adjust screen size. (Programmable in
the teletext mode only)

With an ATV source, if teletext mode is
activated and the teletext has a subtitle page,
press to display the subtitle page.
With a DTV source, press to display the subtitle
OSD, and select the language.

Press to inactivate automatic page change
which only occurs when more than one teletext
page exists.
(Programmable in the teletext mode only)

Press to display the hidden information, such
as solutions to puzzles. (Programmable in the
teletext mode only)

Press continuously to toggle through all the
sound setting: Personal, Music, or Speech.

Picture Mode

Exit EXIT Press to exit from the menu.

Freeze

16

PIC

FREEZE

Press continuously to toggle through all the
picture setting: Vivid, Movie, Eco, Personal,
Standard.

Press to pause a video frame on-screen.
(Programmable in the TV source only)

Description Icon Function

Press repeatedly to set the sleep timer (Off,
10Min., 20Min., 30Min., 40Min., 50Min.,
60Min., 90Min., or 120Min.).
Cancel the timer by selecting the “Off” option.

Sleep timer

SLEEP

English

Aspect ratio

Note:

• For best results, use the remote control within a proper distance from the
front of the TV. Do not exceed an angle of 30 degrees when pointing at TV.

• The operational distance may be shortened when the signal sensor is
directly exposed to strong light.

• Aim the transmitter on the remote control at the signal sensor and ensure
that there are no obstacles between them.

ASPECT

Press to adjust the width-to-height ratio of the
image with aspect ratio: Auto, Normal, Zoom1,
Zoom2, and Full Screen.

17

English

1.8 Inserting the Remote Control Batteries

1 Open the battery compartment cover at the back of the remote control (A).

(A)

2 Insert the batteries paying attention to the polarity markings inside the

battery compartment (B).

3 Replace the battery compartment cover (C).

18

(B)

(C)

CAUTION

• If the remote control is not used for a long period, remove the
batteries and store them properly.

• Handle damaged or leaking batteries carefully, and wash hands with
soap if they come in contact with leaked chemical fluids.

• If your remote control has two batteries, do not mix new and old
batteries, or the life of the new batteries will be shortened. Chemical
fluids may leak from the old batteries.

• Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the equipment
manufacturer. Discard used batteries according to manufacturer’s
instructions.

• Refer to your local recycling or waste disposal rules and contact a
local waste disposal vendor to dispose of used batteries.

• The remote control cover may have a magnet in it, so do not place
magnetic sensitive items such as watches, credit cards, or flash
media close to the cover.

• Do not use force when pulling the remote control cover open; you
may damage the hinge.

English

19

English

2

Setting up your TV

2.1 Power Connection

1

Connect the power cord to the AC IN input jack on the rear of the TV.

2 Insert the plug at the other end of the power cord into a

2.2 Rear Connections

See the illustration and table below for device connection instructions.

power outlet

.

Speaker system

Camcorder

DVD player

PC

Blu-ray Disc
player

Home theater

Video Game
Console

DVD player

PC

3

2 1

32”/42”
only

AC IN

High quality speaker system

32”/42”
only

54 76

VCR/VCD/DVD/STB

Video Game
Console

10

9

8

TV cable / antenna

CI-based

devices

Camcorder

VCR/VCD/DVD

STB

Earphone

20

VCR

No. Connector Notes / Instructions

1 AUDIO In • The audio cable is optional.

2 VGA • The VGA and audio cables are optional.

AUDIO In

3 HDMI 1 • The HDMI cable is optional.

HDMI 2

HDMI 3

4 SPDIF • The SPDIF cable is optional.

5 Component

Video Inputs

Component

Audio Inputs

6 SCART 1 • If your AV devices are not equipped with SCART

SCART 2

7 Cable/Antenna • If you cannot receive channels after connecting to

8 Earphone • The internal TV speakers will not output sound

9 Composite

Video Input

Composite

Audio Inputs

10 CI • The Common Interface cable is optional.

Note:

The available connectors may vary depending on your TV model.

• When the HDMI to HDMI cable is connected,
connecting the audio cable is not necessary.
However it’s necessary to do so if a HDMI to DVI
cable is connected.

• The video and audio cables are optional.

connectors, you will also need a SCART adapter
except for a SCART to SCART cable.

• When a SCART adapter is used, the S-Video
connector and AV connectors cannot be
connected at the same time, or the wrong signals
might be generated.

• The SCART to SCART cable and SCART adapter
are optional.

a TV cable or antenna, try scanning for channels.

when a speaker or earphone is plugged in.

• The video and audio cables are optional.

English

21

English

2.3 Using the TV

2.3.1 Turning the TV On and Off

1

Press on the control panel or remote control.

when the device is turned on.

2

Press again.

The power LED turns off when the device is turned off.

The power LED turns white

2.3.2 Switching Source Signals

Press INPUT on the control panel or remote control to select the incoming source
signal.

2.3.3 Performing an Automatic Channel Search

Before using the TV to view programs, you need to activate the channel search first.

1

Press

MENU

on the control panel or remote control, then select to enter the

TV

menu.

2

Select

Channels

3 Press on the remote control to run the channel search.

>

Channel Scan

>

ATV only

or

ATV a nd DTV

.

2.3.4 Selecting Channels

•Press PS on the remote control (or P on the control panel) to increase
the channel number.

•Press PT on the remote control (or P on the control panel) to decrease
the channel number.

• Enter the specific channel number by pressing the number buttons on the
remote control.

2.3.5 Adjusting the Volume

1

Press

VOL+

on the control panel or

2 Press VOL- on the control panel or remote control to decrease the volume.

3 Press MUTE to eliminate sounds, and press MUTE again or press the

volume buttons to restore the original volume.

remote control

to increase the volume.

22

3 Adjusting On-Screen Display (OSD)

Settings

The On-Screen Display (OSD) menu system provides a quick and simple method to
adjust the TV settings. The OSD menu can be accessed conveniently through the
buttons on the remote control.


English

Standard
50
52
53

0

5

Cool

EXIT

Exit

INSTRUCTIONS:

Quick instructions for
adjusting the settings

MAIN MENUS:

Displays a list of
menus.

Smart Picture
Brightness
Contrast
Colour
Tint
Sharpness
Colour Temperature
Advanced Control

Remove Select

OK

ADJUSTABLE Options:

Displays the setting/value
of the adjustable options.

Function TV Control Panel Remote Control

OSD Menu MENU

Up P

Down P

Select/ Increase

Select/ Decrease

Return

VOL

VOL

MENU

Exit MENU

+

–

MENU

Arrow

Arrow

Arrow

Arrow

EXIT

EXIT

23

English

3.1 OSD Setting Menus

Follow the instructions indicated on the down side of the OSD Function Menu. Press

/P on the control panel or /

P

+ on the control panel or the arrow key to select an item, or MENU on the

VOL

arrow keys to scroll through the menus,

control panel or EXIT to exit the OSD menu.

The following menus can be set by different adjustment methods.

3.2 Adjusting Picture Settings

1 Press MENU to enter the OSD Main Menu

screen. The Picture menu is displayed.

2 Press to enter the Picture menu.
3 Press

4 Press

options settings.

/

to select an item.

/

to adjust the scales or


Smart Picture
Brightness
Contrast
Colour
Tint
Sharpness
Colour Temperature
Advanced Control

Remove SelectOKExit

Standard
50
52
53

0

5

Cool

EXIT

5 Press EXIT to return to the Picture menu entry.
6 Press EXIT to exit the OSD menu.

- The Picture menu can be used to adjust the Smart Picture, Brightness, Contrast,
Colour, Tint, Sharpness, Colour Temperature, Advanced Control, and Advanced
Video (PC only) settings.

• Smart Picture can be set to Standard, Vivid, Movie, Eco, or Personal.

• Brightness, Contrast, and Colour can be adjusted by pressing

the scales from 0 to 100.

/

• Tint can be adjusted by pressing

•

Sharpness

can be adjusted by pressing / to move the scales from 0 to 7.

to move the scales from -32 to 32.

• Colour Temperature can be set to Normal, Warm, or Cool.

• Advanced Control can be used to adjust the Noise Reduction, Flesh Tone,

Backlight, and X-Contrast.

• Noise Reduction can be set to Auto, Off, Low, Medium, or High.

• Flesh Tone can be set to On or Off.

•

Backlight

X-Contrast

•

can be adjusted by pressing / to adjust the scales from 0 to 100.

can be set to On or

Off

.

/

to move

24

•

Advanced Video

Temp erat ur e

can be used to adjust the

, and

Advanced Video


Brightness
Contrast
Colour Temperature

Advanced Video

Brightness, Contrast, Color

settings for PC mode.

100
100

Cool

English

Remove SelectOKExit

EXIT

Note: The options available on the OSD may vary depending on the input signal
source.

3.3 Adjusting Sound Settings

1 Press MENU to enter the OSD Main

Menu screen.

2 Press

to select the Sound menu.

3 Press to enter the Sound menu.
4 Press

5 Press

options settings.

/

to select an item.

/

to adjust the scales or

6 Press EXIT to return to the Sound menu entry.
7 Press EXIT to exit the OSD menu.

- The Sound menu can be used to adjust the Sound Mode, Equalizer 120Hz, Equalizer
500Hz, Equalizer 1.5KHz, Equalizer 5KHz, Equalizer 10KHz, Balance, Virtual
Surround, Digital Audio Out, AVL, Typ e, and Audio Description settings.

• Sound Mode can be set to Music, Speech, or Personal.

•

Equalizer 120Hz, Equalizer 500Hz, Equalizer 1.5KHz, Equalizer 5KHz

can be adjusted by pressing / to move the scales from -6 to 6.

10KHz

•

Balance

Virtual Surround

•

Digital Audio Out

•

can be adjusted by pressing / to move the scales from -50 to 50.

can be set to On or

can be set to

Off

Dolby Digital, PCM

Sound

Sound Mode
Equalizer 120Hz
Equalizer 500Hz
Equalizer 1.5KHz
Equalizer 5KHz
Equalizer 10KHz
Balance
Virtual Surround

Remove SelectOKExit

Personal
3
3
2
4
5
0
Off

EXIT

, and

Equalizer

.

, or

Off

.

25

English

•

AVL

can be set to On or

•

Typ e

can be set to

• To adjust the

first. Press

Audio Description

/ to adjust the scales from 0 to 100.

Off

.

Normal, Hard of Hearing

, select

Audio Description

, or

Audio Description

in the

.

Type

setting

Note: The options available on the OSD may vary depending on the input signal
source.

3.4 Adjusting TV Settings

1 Press INPUT and select TV as the signal

type.

2 Press MENU to enter the OSD Main Menu

screen.

3 Press

to select the TV menu.

TV

Tuner Mode
Country
Channels

Antenna
Austria

4 Press to enter the TV menu.
5 Press

6 Press

options settings.

/

to select an item.

/

to adjust the scales or

Remove SelectOKExit

EXIT

7 Press EXIT to return to the TV menu entry.
8 Press EXIT to exit the OSD menu.

- The TV menu can be used to adjust the Tuner Mode, Country, and Channels settings.

• Tuner Mode can be set to Antenna, and Cable.

• Country can be set to Austria, Belgium, Bulgaria, Croatia, Czech Republic,

Denmark, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy,

Luxembourg, Netherlands, Norway, Poland, Portugal, Romania, Russia,

Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Tur key, UK, Ukraine,

and Other.

• Channels can be used to perform or adjust the Channel Scan, Update Scan,

Single RF Scan, Analogue Manual Scan, Favourite Network Select, Channel

Skip, Channel Sort, Channel Edit, Decoder, Analogue Ch Fine Tune, and

Clean Channel List settings.

26

• Select Channel Scan to activate the automatic TV channel search.

Channels

Channel Scan

Update Scan
Single RF Scan
Analogue Manual Scan

Favourite Network Select

Channel Skip
Channel Sort
Channel Edit

Scan SelectOKBack

EXIT

Channel Scan

EXIT

Cancel

Status:Scanning...
Analog Channels: 0
Digital Channels: 0

0%

• Select Update Scan to automatically add channels to the existing channel list.

• Select Single RF Scan to search for digital channels within the selected RF

(Radio Frequency) channel.

Single RF Scan

Scan single RF channel. (Digital Only)

0%

RF Channel

Signal Strength5100

English

OK

Scan

EXIT

Back

• Select Analogue Manual Scan to search for analog channels within the specified

frequency range.

Analogue Manual Scan

Search for analogue channels

EXIT

Back

Start Frequency (MHz)

Scan Up
Scan Down

77.30

• Select Favourite Network Select to select your favourite TV channels from the

existing channel list.

27

English

•Use Channel Skip to prevent the desired channels from being accessed. Press

PS/PT on the remote control or P /P on the control panel.

Channel Skip

Analogue

1

2
3
4
5
6
7
8

Set SelectOKBack

Analogue
Analogue
Analogue
Analogue
Analogue
Analogue
Analogue

-----

-----

-----

-----

-----

-----

-----

-----

EXIT

• Select Channel Sort to change the order of the channel list.

• Channel Edit allows you to adjust the detailed items, including Channel Number,

Channel Name, Frequency, Colour System, and Sound System for each

channel.

Channels

Channel Scan
Update Scan
Single RF Scan
Analogue Manual Scan

Favourite Network Select

Channel Skip
Channel Sort

Channel Edit

Scan SelectOKBack

EXIT

Channel Edit

Transmitter

Channel Number:

Chanel Name:

Frequency
Colour System
Sound System

Set SelectOKBack

-----

Auto
I

1

-----

77.3

EXIT

- To change the channel number, select Channel Number and use the number keys
on the remote control to type numbers.

- To change the channel name, select Channel Name and use the number keys on
the remote control to type letters, digits, or symbols. Press keys repeatedly to toggle
different characters.

28

KEY CHARACTER

0 +- .0

1 A B C 1

2 DEF 2

3 G H I 3

4 JKL4

5 M N O 5

6 PQR 6

7 S T U 7

8 VWX 8

9 Y Z 9

- Frequency displays the current channel frequency.

- Colour System displays the type of current channel color system.

- Sound System displays the type of current channel sound system.

• Decoder supports the Canal+ (paid TV channel with encrypted programs).

• Select Analogue Ch Fine Tune to adjust precisely the analog channel frequency

to ensure high signal quality.

• Select Clean Channel List to delete all channels.

Note: The TV Settings are only available in TV mode.

3.5 Adjusting Features Settings

English

1 Press MENU to enter the OSD Main Menu

screen.

2 Press

to select the Features menu.

3 Press to enter the Features menu.
4 Press

5 Press

settings.

/

to select an item.

/

to change the options

6 Press EXIT to return to the Features menu entry.
7 Press EXIT to exit the OSD menu.

Features

Menu Language
4:3 Mode
Picture Format
Time
Subtitle
Teletext Language
Common Interface
OAD

Remove SelectOKExit

English
4:3
Auto

EXIT

29

English

- The Features menu can be used to adjust the Menu Language, 4:3 Mode, Picture
Format, Time, Subtitle, Teletext Language, Common Interface, OAD, Parental,
Reset Default, Auto Power Off, and SW ver. settings.

• Menu Language can be used to change the on-screen display (OSD) language.

• 4:3 Mode can be used to adjust the display aspect ratio to 4:3, and 16:9 settings.

• Time can be used to adjust the Time Zone, Time, and Sleep Timer settings.

• Subtitle can be used to adjust the Analogue Subtitle, 1st Subtitle, 2nd Subtitle,

and Subtitle Type settings.

• Teletext Language can be used to adjust the Digital Teletext Lang. and Decode

Page Lang. settings.

• Select Common Interface to view the CI supplier information.

• Select OAD to upgrade the software for the device.

• Select Reset Default to restore all settings to the defaults.

• Select SW Ver. to view the current firmware version.

• Select Parental to adjust Channel Block, Parental Guidance, Input Block, Set

Password, and Clear All settings. You will be prompted to enter the password

before entering the Parental sub-menu. By default, the password is “1234”.

Parental

Password

Parental

Channel Block

Parental Guidance
Input Block
Set Password
Clear All

EXIT

Back

• Select Channel Block to block desired channels.

• Select Parental Guidance to set Age Rating. Press

from 4 to 18 or to set as None.

• Select Input Block to block desired input sources.

•Set Auto Power Off to either On or Off.

30

Enter SelectOKBack

EXIT

/

to adjust the value

• Select Set Password to change the password.

Set Password

New

Confirm

EXIT

Back

• Select Clear All to restore defaults for all parental settings.

Note: Channel Block is only accessible in TV mode.

• Picture Format selections include Auto, Normal, Zoom1, Zoom2, and Full
Screen. Please see below for details.

Auto

Normal

Zoom1

English

Zoom2

Full Screen

Note: The options available on the OSD may vary depending on the input signal
source.

31

English

3.6 Adjusting Eco Settings

1 Press MENU to enter the OSD Main Menu

screen.

2 Press

to select the Eco menu.

Eco

3 Press to enter the Eco menu.
4 Press

settings.

/

to adjust the options

5 Press MENU to return to the Eco menu

entry.

6 Press EXIT to exit the OSD menu.

- The Eco menu can be used to adjust the Off and On settings.

Off
On

Remove SelectOKExit

EXIT

32

4

Troubleshooting

Situation Solution

• Connect the power cord properly.

• Check if the power LED is on or not.

No picture and sound.

No picture, or poor picture,
sound is OK.

Picture is not in color.

Picture is OK, no sound.

One of the speakers has no
sound.

Cannot receive some TV
channels using cable TV.

Want to reset TV settings.

Cannot operate menus.

Screen image turns over. • Make sure the video signal cable is connected properly.

Snow appears on the screen.

Blurred or overlapped
images.

Remote control doesn’t work.

• Press on the control panel or remote control.

• Press Input to cycle through connected video sources.

• Press

• Make sure all cables are connected properly.

• Check the antenna and cable connections.

• Adjust the Brightness in the Picture OSD menu.

• Adjust the Colour option in the Picture OSD menu.

• Make sure the source device is functioning properly.

• Make sure the audio cable is connected securely.

• Turn the mute off.

• Press VOL + on the control panel or remote control.

• Adjust the Balance in the Sound OSD menu.

• Try the Channel Scan function in the Channels OSD

• Use the Reset Default function in the Features OSD

• If OSD items are colored in gray, the system is in a state

• Adjust the location of the antenna, placing it far from

• Check the antenna and the video signal line connections.

• Adjust the sharpness setting.

• Choose programs with high quality signals.

• Adjust the direction of the antenna or replace the video

• Make sure the battery is inserted correctly.

• Replace the battery with a new one.

• Make sure the TV power cord is plugged in.

• Make sure the path between the remote control and the

• Try operating the remote control at a closer distance to

PS or PT to switch to other TV programs.

menu.

menu.

such that those settings are not available.

roads or sources of interference.

signal cable.

sensor is clear.

the TV.

English

33

English

5

Support Timing

PC Mode Support Timing

Mode Resolution

1 640 x 480

2 800 x 600 35.156 56.25

3 800 x 600 37.879 60.317

4 1024 x 768 48.363 60.004

5 1280 x 720 44.772 59.855

6 1280 x 768 47.776 59.87

7 1360 x 768 47.72 59.799

8 1280 x 1024 63.981 60.02

9 1920 x 1080 66.587 60

Horizontal Frequency

(KHz)

31.469 59.94

Vertical Frequency

Video Mode Support Timing

Resolution (active dot) HDMI/YPbPr

480i V

576i V

480p V

576p V

720p V

1080i V

1080p V

(Hz)

34

6

Support USB Compatible Formats

USB Device Compatibility

Device File Format

USB 2.0 device

File System FAT/FAT 32

Photo file format JPEG (*.JPG), PNG

Music format

Video file format

Notes:

• It does not support “NTFS“ and the maximum file size of a single file is 4GB.

• Progressive format jpeg files are not supported.

• Due to the compatibility limitation, not all of USB devices are able to be
displayed properly.

• Operation using USB hubs is not guaranteed.

• Due to the compatibility limitation, not all of external hard disks are able to be
detected correctly.

• Cables used to prolong the USB device must be certified as USB 2.0.

• In USB devices, video files may not be played properly if speed is not enough.

USB memory, USB card reader

MPEG1 (*.MP3) Bitrate: 32k, 64k, 96k, 128k, 196k, 256k, 320kbps
Sampling frequency: 32k, 44.1k, 48kHz

MPEG1/2 (*.AVI, *.MPG,*.MPEG, *.TS)
MPEG4 (*.AVI, *.MP4,*.MOV, *.MKV)
H.264 (*.AVI, *.MP4,*.MOV, *.MKV, *.TS)

English

35

English

7

Specifications

Model No. SV19LMMB SV22LMMB SV25LMMB SV28LMMB SV32LMNB SV42LMNB

DISPLAY

Aspect Ratio 16:9 16:9 16:9 16:10 16:9 16:9

Resolution 1366 x 768 1920 x 1080 1920 x 1080 1920 x 1200 1920 x 1080 1920 x 1080

Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonia, Finnish, French,

OSD Language

Sound Output
(RMS Watts)

Sound Mode

Picture Format Auto, Normal, Zoom1, Zoom2, Full Screen

Picture Mode Standard, Vivid, Movie, Eco, Personal

Rear Connector

Side Connector

Product
Dimensions (mm)
W x H x D (with
stand)

Net Weight 3.74 kg 4.41 kg 6 kg 8.035 kg 13 kg 19 kg

Operation (Max.) 26 W 30 W 36 W 55 W 95 W 120 W

Standby < 0.5 W

Main Power

Ambient
Temperature

German, Greek, Hungarian, Italian, Irish, Latvian, Lithuanian, Norwegian, Polish,
Portuguese, Romanian, Russian, Serbian, Slovak, Slovenian, Spanish, Swedish,
Turkish, Ukrainian

ENHANCEMENT

3 W 3 W 5 W5 W10 W10 W

Personal, Music, Speech

CONNECTION

Tuner Input (75
Input

SCART 1
SPDIF
HDMI 1

Common Interface, USB, Earphone, AV In (Composite Audio/Video)

HDMI 2 HDMI 2 HDMI 2 HDMI 2 HDMI 3 HDMI 3

467.01 x 3 41.44
x 148

Ω), PC IN: D-SUB and PC Audio, Component Video and L/R Audio

SCART 1
SPDIF
HDMI 1

WEIGHT & DIMENSIONS

533.81 x 379.31
x 148

SCART 1
SPDIF
HDMI 1

609.35 x 443 x
210

POWER

SCART 1
SPDIF
HDMI 1

672.91 x 527.11
x 220

AC 220~240V

50~60 Hz

5ºC ~ 35ºC

SCART 1
SCART 2
SPDIF
HDMI 1
HDMI 2

790.18 x 571.43
x 240

SCART 1
SCART 2
SPDIF
HDMI 1
HDMI 2

1021.1 x 705.8
x 270

36

8

Dissembling the stand base

1 Disconnect all the cables and cords from the TV to prevent breakage.
2 Carefully place the TV face down on a soft and flat surface (blanket, foam, cloth,

etc) to prevent any damage to the TV.
3 Remove the screws so that the stand base can be removed.
4 Gently remove the stand base.

English

19”/22”

(For reference only)

25”/28”/32”/42”

Wall mounting the TV:

Model Name

SV19LMMB 100x100 mm 4 Metric 4 x 10 mm 15 kg
SV22LMMB 100x100 mm 4 Metric 4 x 10 mm 18 kg
SV25LMMB 100x100 mm 4 Metric 4 x 10 mm 24 kg
SV28LMMB 100x100 mm 4 Metric 4 x 10 mm 30 kg
SV32LMNB 200x200 mm 4 Metric 4 x 14 mm 36 kg
SV42LMNB 200x200 mm 4 Metric 6 x 12 mm 72 kg

VESA-compatible
wall bracket (WxH)

Mount holes
number

Screw type Maximum loading

1 Purchase a VESA compatible wall bracket

(please refer to the table above).
2 Locate your ideal TV position on the wall.
3 Fix the wall bracket firmly on the wall.
4 Secure the TV to the bracket using the 4

mount holes on the back and center of the TV.

Note:

• Please read the instructions of your specific wall bracket to properly wall mount
the TV.

• The TV stand base can be screwed on a table or a hard surface using the hole
on the back of the stand base.

*Installing the LED-LCD HDTV requires special skill that should only be performed by qualified service

personnel. Customers should not attempt to do the work themselves. Hannspree bears no responsibility for
improper mounting or mounting that results in accident or injury. You can ask a qualified service personnel
about using an optional bracket to mount the TV to the wall.

37

English

9

Using the Cable Organizer

Route the cables through the cable clamp as shown:

38
