Page 1
12.1” Ultra-Mobile Laptop PC
Ideal for on-the-road, business, school and home use.
Equipped With
Dual Core Processor Inside
HannsBook
SN12E2 Series
Available in 2 Colors:
Pearl Red
12.1” LED HD Widescreen Display with HDMI Output
SRS Premium Sound
Close to 1” Thick and Weighs Less than 3 lbs. with Battery
Footprint Slightly Bigger than a Letter-size Paper
Battery Life Over 6 Hours with a Single Charge
Multi-touch Mouse Pad
2GB Memory / 320GB SATA Hard Drive
Intel® Pentium™ SU4100 Processor Dual Core 1.3 GHz
Windows® 7 Home Premium Operating System
Wireless 802.11b/g/draft n
802.11b/g/n
L E D
12” LCD with
LED Backlight 320GB SATA HDD 3-in-1 Card Reader
Wireless LAN
MULTI-TOUCH PAD
(SN12E238UP212)
& Pearl Black
(SN12E23BUP212)
Full-function
Keyboard
www.hannspree.com/us
Full Webpage
Viewing
Quick Charging
6-Cell Battery
RoHS
Compliant
Webcam & Mic
For Video Conferencing
Page 2
Technical Specications:
HannsBook
SN12E2 Series
1. Models
2. Processor / Cache / FSB
3. Operating System
4. Resolution (H x V)
5. Display Size
6. Chipset
7. Graphics & Video Module
8. System Memory
9. Hard Disk Drive
10. Battery
11. Audio
12. I/O Terminal
13. Card Reader
14. Touch Pad
15. Webcam
16. Networking
17. AC Adapter
18. Kensington Slot
19. Net Dimensions
20. Gross Dimensions
21. Net Weight
22. Gross Weight
23. Weight w/o Battery
24. Certications
25. Package Contents
26. UPC Codes
27. Warranty
Pearl Black (SN12E23BUP212) / Pearl Red (SN12E238UP212)
Intel Pentium SU4100 Dual Core 1.3GHz / 2MB LS Cache / 800MHz FSB
Windows 7 Home Premium
1366 x 768 White LED
12.1” LED HD Widescreen (16:9 diagonal) Color Active Matrix TFT (Anti-Glare)
GS45+ICH9M-SFF
Intel GMA4500MHD
2GB DDRII 800MHz
320GB (SATA)
6-Cell Battery (2600mAh); >6 Hours
2 Speakers, 1W x 2 (SRS Premium Sound)
HDMI Port, 3x USB 2.0 Ports, VGA Port, RJ-45, Headphone-Out, Mic-In
3-in-1 Card Reader: SD/MMC/MS
Multi-Touch Function
1.3MP
10/100/1000 LAN, 802.11b/g/draft n
Input: 100-240V (2.0A) 50~60Hz/Output: 65W, 19.0V/3.42A
Yes
11.7” (W) x 8.5” (H) x 1.25” (D) with Battery
13.5” (W) x 11.6” (H) x 3.9” (D)
3.4 lbs.
6.9 lbs.
2.7 lbs.
FCC Class B Certied, UL, CSA (CUL), RF Module Certicate, RoHS, Windows 7, Linux FoxOS
HannsBook, Power Cable (1.8m), AC Adapter, Warranty Card, Quick Guide, Carry Bag, Cleaning Cloth,
Driver DVD (Manual + Win 7 Drivers + APs (SRS Premium Sound, Adobe Reader, WinRAR and
Symantec NIS)
842651005337 (Pearl Black); 842651005344 (Pearl Red)
1-Year Limited (1-Year Parts/Labor, 1-Year LCD/Backlight)/6-Month Limited Battery & Power Supply
Beverly Hills Store 420 N. Beverly Drive, Beverly Hills, CA 90210 310.288.0208
San Francisco Store 400 Sutter Street, San Francisco, CA 94108 415.986.3300
Customer Service 1.888.808.6789 (Toll Free) / Email: [email protected]
©2010 Hannspree North America, Inc. Specifications and design are subject to change without notice. Non-metric weights and measurements are approximate.
All brand, product, service names and logos are trademarks and/or registered trademarks of their respective manufacturers and companies. Screen shot is simulated.
RoHS
Compliant
Version 03262010
