Page 1
2F, No.362, Jui-Kuang Rd., Neihu District,
Taipei City 114, Taiwan, R.O.C.
TEL: 886-2-87520000
FAX: 886-2-87527092
www.hannspree.com
NTSCTVTWEN1203
MAC-001029
12.1" Liquid Crystal Display
Television
ST48-12A1
User's Manual
Page 2
Table of Contents
1. Warranty and Service .................................................... 3
2. Preface......................................................................... 4
3. Description of Warning Symbols ..................................... 5
4. Safety Notices............................................................... 6
5. Regulatory Information ................ ................................ 14
6. Introducing the TV..................................... .................. 16
Features.................................................................. 16
7. Checking Package Contents ........................................ 17
8. Getting to Know Your TV .......................................... ... 18
Front View................. .............................................. 18
Input and Output Ports............................................. 20
9. Getting Started............................................................ 22
Connecting to an Antenna or Cable TV ... .................. 22
Connecting to AV Devices........................................ 23
Connecting to a VCR, VCD or DVD Player ........... 23
Connecting to a Video Camera ............................ 24
Connecting Headphones .......................................... 25
Connecting the Power Adapter ................................. 26
10. Using the TV .............................................................. 27
Using the Remote Control ........................................ 27
Turning the TV On and Off ....................................... 28
Selecting Channels.................................................. 28
Switching Source Signals......................................... 29
Adjusting the Volume ............................................... 29
1
Page 3
Table of Contents
11. Adjusting On-Screen Display (OSD) Settings ............... 30
OSD Setting Menu ................... ................................ 30
Picture Setting...................................................... ... 31
Brightness .......................... ................................ 32
Contrast ............... .............................................. 33
Sharpness ....................................................... ... 34
Hue .................................................................... 35
Saturation........................................................ ... 36
Color .................................................................. 37
Preset .... ............................................................ 38
Audio Setting........................................................ ... 39
Treble ................... .............................................. 40
Bass..................... .............................................. 41
Balance .............................................................. 42
Enhance ............................................................. 43
Preset .... ............................................................ 43
TV Setting ............................................................... 44
TV/CATV .......................................... .................. 45
Channel Add/Erase ............................................. 46
Auto Program ...................................................... 47
Customize Setting .................................................... 48
Sleep Timer .......... .............................................. 49
OSD Timeout ...................... ................................ 50
Language ........................................................... 50
12. Taking Care of Your TV .............. ................................ 51
13. Troubleshooting.......................................................... 52
14. Specifications............................................................. 54
15. Glossary .................................................................... 55
2
Page 4
1
Warranty and Service
The instructions on this manual are for the model (s) listed on the front
cover. Before you start reading, check your produt number by looking at
the rear of your TV.
Thank you for purchasing our Liquid Crystal Display Television (LCD
TV). With this product, you will be able to enjoy superior audio and
video while enriching your lifestyle with advanced technology.
The Hannspree TV is warranted for one year limited service from the
date the product is received (as shown on the Warranty and Service
Manual); please refer to the "Warranty and Service Manual" for the
detailed warranty information.
Hannspree provides complete service information in the included "Warranty and Service Manual", or directly from Hannspree global customer
service center . Our service representatives will be very happy to serve
you to your satisfaction.
Hannspree global customer service center telephone number:
From Taiwan please call 0800-008-800
The Hannspree E-mail Address:
service@hannspree.com
3
Page 5
2
Preface
This manual is designed to assist users in setting up and using the LCD
TV. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents.
The information in this document is subject to change without notice.
Copyright
© Copyright 2003 Hannspree, Inc.
All rights reserved. This product and related documentation are pro-
tected by copyright and are distributed under licenses restricting their
use, copying, and distribution. No part of this documentation may be
reproduced in any form by any means without prior written authorization
of Hannspree, Inc., and its licensors, if any.
4
Page 6
3
Description of Warning Symbols
Warning
This symbol is used to remind
users to pay attention to
important descriptions regarding usage and maintenance
(repair) or additional important information related to this
product.
This symbol is used to remind
users to pay attention to the
danger of electric shocks due
to dangerous internal noninsulated components.
Caution
Electric Power Notice
Electric power may cause personal injury and mechanical damage if it is
misused. Although safety has been taken into consideration during the
design and production of this product, electric shock or fire can result
when the product is misused. To prevent potential danger, follow the
instructions below when installing, operating and cleaning the product.
In addition, read the following “Safety Notices” carefully before using the
product to ensure that your TV is safe and long-lasting.
5
Page 7
4
Safety Notices
Power Supply Safety Notes
1. To avoid electric shocks, do not use an extended powe r cord or
an outlet that does not match this product's plug or leaves the
plug exposed.
2. This product has a 3-pin grounded plug. The third pin connects
to ground; do not remove it.
3. If the power cord or plug is damaged or worn, unplug it immediately and contact a qualified service technician for maintenance.
4. To avoid fire or electric shocks, do not overload electric power
outlets.
Installation Safety Notes
Antenna
We suggest that you use an outdoor antenna to get the best signal
possible unless you have cable TV or a centralized indoor antenna
system. You may, however , use an antenna indoors if it is placed in
a location free from interference.
Location
Avoid allowing the TV to get prolonged exposure to sunlight or
other strong sources of heat. Leave sufficient distance between the
TV and the wall to provide enough space for the emission of heat.
6
Page 8
Before You Proceed
1. Read the Safety Notices and the User’s Manual carefully
before turning the product on.
2. Keep your User’s Manual in a safe place for future reference.
Keep the box and packaging in case the product needs to be
shipped in the future.
3. Follow the product and warning label instructions.
4. Any changes or modifications that do not follow the instructions
in this manual will void this product's warranty.
Warning
To reduce the risk of fire or electric shock, do not expose this
product to rain or moisture.
Power
To avoid danger of fires or electric shock, make sure that you use a
proper adapter. The TV is compatible with the following adapters:
• EDAC POWER ELECTRONICS CO., LTD.: EA1050E-120
• LI SHIN INTERNATIONAL ENTERPRISE CORP.: 0217B1240
7
Page 9
Optimal Viewing Area
128 cm
8
Page 10
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug: A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
9
Page 11
10. Protect the power cord from being walked on
or pinched particularly at the plug, convenience receptacles, and the point where they
exit from the apparatus.
11. U se only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
12. Only use attachments/accessories specified
by the manufacturer.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way , such as
if the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
10
Page 12
Personal Safety
To avoid overloading the power supply, do not
plug too many electrical devices into an outlet or
extension cable.
Dangerous high-voltage electric power components are located inside the TV. To avoid electric
shock, do not disassemble the casing.
Do not place or drop metals, small objects, or
flammable materials in the vent to avoid an electric shock or a fire.
If the TV is dropped, falls down, or is otherwise
damaged, unplug the power cord immediately
and notify a qualified service technician.
If any fluid is sprayed or dropped into the TV,
remove the power plug immediately and notify a
qualified service technician.
The screen of the TV is made of glass, be careful to avoid hitting or scraping it. If the screen is
broken, avoid cutting yourself on the broken
glass.
Do not allow children to use the TV unattended
to avoid accidents caused by improper operation.
11
Page 13
Installation
To avoid damage to power circuits, do not place
the TV in locations where there is excessive
steam or dust.
Do not place the TV on a bed, sofa, carpet, or in
a sealed cabinet to avoid blocking the product's
vents.
Install the outdoor antenna far from power transmission lines to avoid possible danger.
Remove the power cord and antenna connector
when there is a storm or when the TV is not in
use for a long period to avoid electric shock from
lightning.
12
Page 14
Operation
V
Maintenance
J.
This product is designed for power sources as
labeled on the casing. Avoid using any other
power accessories to avoid electric shock or
other damage.
The plug can be inserted into an outlet in only
one direction. Notify a qualified service technician if you cannot plug it in correctly.
If there is any problem that cannot be resolved
according to the instructions given in this manual, notify a qualified service technician immediately . Do not attempt any methods not covered in
this manual.
Do not attempt to repair the TV by yourself.
Notify a qualified service technician. Ask the service technician to complete a safety inspection
before switching the power on after completing
any maintenance.
13
Page 15
5
Regulatory Information
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
1
Warning: A shielded-type power cord is required in order to meet FCC
emission limits and also to prevent interference to nearby radio and television reception. It is essential that only the supplied power cord be
used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your
authority to operate the equipment.
1. applies only to products purchased in the United States of America
14
Page 16
DOC Compliance Notice
1
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulations of the Canadian Department of Communications.This
device complies with Canada ICES-003 Class B.
CE Conformity Statement
2
This device complies with the requirements set out in the Council Directive on the approximation of the Laws of the Member States relating to
Electromagnetic Compatibility (89/336/EEC) and the Amendment Directive (92/31/EEC), Low-Voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC).
1. applies only to products purchased in Canada
2. applies only to products purchased in the European Union
15
Page 17
6
Introducing the TV
Thank you for purchasing this Liquid
Crystal Display TV. Your TV is designed
to be safe, versatile, and easy to use.
The Skewer design makes it a fun
addition to any room.
You can watch standard NTSC
television channels, and easily connect
a VCR, VCD, or DVD player to the
standard CVBS and S-Video input ports
located at the rear of the unit.
Convenient control buttons located on
the front panel let you change channels, adjust the volume, and
change display settings through an easy-to-use on-screen menu
system. The TV speakers provide full, rich stereo sound and a
convenient audio output port lets you connect to an external audio
system or headphones.
Features
• 12.1-inch color TFT LCD TV
• Safe, sturdy construction
• Built-in TV tuner
• Audio/video support:
– Stereo audio inputs
– Composite video inputs
– S-Video input
• On-screen display (OSD) menu system
• Multi-channel Television So unds (MTS) Stereo with SAP
• Built-in 2W+2W stereo audio amplifier
16
Page 18
G
W
A
1
8
3
0
0
V
8
0
C
V
W
-
1
E
7
7
8
7
4
7
Checking Pac kage Contents
Make sure the following components are included in the box. Contact
your vendor immediately if anything is missing or damaged.
TV
User’s Manual Quick Start Guide Warranty and Service
Manual
User's Manual
Quick Start
Guide
Warranty and service
manual
Wire Material Package
Power Cord Power Adapter 4-in-1 Cable
17
Page 19
8
Getting to Know Your TV
Front View
88
Signal sensor
34 5
2617
Description Function
1 Headphone line out Connects to headphones.
2 Menu
3 Source
Turns the on-screen display (OSD)
menus on and off.
Selects the input source to be displayed
( TV, AV1 , or AV2 ).
18
Page 20
Description Function
4 Select channel
Channel up(S): Increase the channel number.
Channel down(T) : Decrease the channel
number.
5 Adjust volume
Volume down (-) : Decreases the volume.
6 Power Turns the TV on and off.
7 Power LED Green LED indicates power on.
8 Speakers Output audio content.
Volume up (+): Increases the volume.
19
Page 21
Input and Output Ports
1234
1 AV2
20
Description Function
Use the included 4-in-1 Audio/Video
cable to connect external devices, such
as a VCR, VCD, or DVD player.
Audio Input: AV connectors white and
red audio cables.
Video Input: AV connector video (yellow) or S-Video cables.
Page 22
Description Function
Use the A V1 input to connect an external
device, such as a VCR, VCD, or DVD
player.
2 AV1
Audio Input: AV connector white and
red audio cables.
Video Input: AV connector video
(yellow) cable.
3 DC-IN Connects to the included power adapter.
Antenna/cable TV
4
line in
Connects to an antenna or CATV cable
television line.
21
Page 23
9
Getting Started
Connecting to an Antenna or Cable TV
1
Connect one end of the VHF/UHF (Antenna) or CATV cable to the
ANT Jack (VHF/UHF IN Jack) on the back of the TV.
2 Connect the other end of the VHF/UHF (Antenna) or CATV cable to
the Antenna or CATV socket.
Antenna
AV1
ANT
DC-IN
AV2
R L VIDEO
AV1
DC-IN
AV2
R L VIDEO
ANT
Antenna/CATV
socket
ANT jack
(VHF/UHF IN jack)
Antenna/CATV
coaxial cable
Note
If you cannot receive channels after connecting to an antenna or cable TV
line, try scanning for channels. See “Auto Program” on page 47.
22
Page 24
Connecting to AV Devices
Connect external devices such as VCD/DVD players or VCRs to the
TV using the AV1 and AV2 ports on the back of the TV.
Connecting to a VCR, VCD or DVD Player
The illustration presented here shows you how to connect your TV to
a VCR, VCD or DVD player. Actual connections may vary according
to the make and model of your device. Refer to the user’s manual
included with the AV device for more detailed instructions.
VCR
VCD
AV1
DC-IN
R L VIDEO
ANT
DVD
AV2
AV2
AV1
R L VIDEO
AV2
DC-IN
ANT
4-in-1 cable
BRWY
S-Video
connector connectors
AV
Cables and connectors are colorcoded (black, red, white, yellow).
23
Page 25
Connecting to a Video Camera
The following illustration shows you how to connect the TV to a
camcorder. Actual connections may vary according to the make and
model of the device. Refer to the user’s manual included with the
camcorder for more detailed instructions.
S
WB
AV1
ANT
DC-IN
AV2
R L VIDEO
AV1
DC-IN
AV2
R L VIDEO
AV2
ANT
S-Video
connector
B
4-in-1 cable
Note: When connecting the S-Video
connector and AV connectors at the
same time, the priority is given to the
S-Video connector.
24
R
W
Y
AV connectors
Cables and connectors are
color-coded (black, red,
white, yellow).
Page 26
Connecting Headphones
Headphones may be used to listen to the TV instead of using the
built-in speakers. Connect headphones to the headphone line out
port as illustrated.
Headphones
Headphone
line out port
Notes
• Headphones are not included with the product.
• The intern al TV speakers will not output sound when headphones are
plugged in.
25
Page 27
Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2 Plug the power adapter connector into the DC-IN on the rear panel of
the TV.
3 Plug the three-pronged plug at the other end of the power cord into a
power outlet.
Power Outlet
AV1
ANT
DC-IN
AV2
R L VIDEO
Three-pronged
plug
26
AV2
AV1
R L VIDEO
DC-IN
DC-IN
ANT
Power cord
Power adapter
Page 28
10
Using the TV
Using the Remote Control
For best results, use the remote control within a dist ance of 5 me ters
(16 feet) from the front of the TV’s signal sensor. Do not exceed an
angle of 30 degrees when pointing at the signal sensor. Refer to the
following illustration.
3m
3m
30
30
5m
27
Page 29
Turning the TV On and Off
1
Press the
remote control or on the TV control
panel. The power LED indicator on the
front of the TV changes from red to
green, indicating that the power is on.
POWER
button on the
CH 33
2 Press the POWER button again. The
power LED changes from green to red,
indicating that the TV is in standby (off)
mode.
Selecting Channels
1
Press the
channel number by one.
CH UP
button to increase the
2 Press the CH DOWN button to
decrease the channel number by one.
3 Enter the specific channel number by
pressing the number buttons on the
remote control. The channel is
displayed on the LCD panel.
Power button
Power LED
CH 33
Channel up
Channel down
28
Page 30
Switching Source Signals
Press the SOURCE button to select
different source signals.
CH, AV1, and AV2 appear on the top
right corner of the screen in that order.
Note
The TV supports S-Video input in addition
to normal video and audio signals. The TV
detects the signal type automatically and
gives priority to S-video when two signals
are detected at the same time.
Adjusting the Volume
1
Press the
VOL UP
button to increase
the volume.
2 Press the VOL DOWN button to
decrease the volume.
3 Press the MUTE button. The word
“MUTE” appears on the top right
corner of the screen and sound is
turned off.
CH 33
Source
MUTE
Volume down
Vo lume up
4 Press the MUTE button again to
restore the original volume.
29
Page 31
SEL
ENTER
MENU
11
Adjusting On-Screen Display (OSD) Settings
The On-Screen Display (OSD) menu system provides a quick and
simple method to adjust your TV's settings. This chapter describes
how to change each of the available settings. The OSD can be used
with either the front control panel or remote control.
Button Descriptions Front Panel Control
Menu MENU
CH UP S
CH DOWN T
VOL UP +
VOL DOWN –
The following sections explain how to adjust settings in the OSD
menus using the front panel control. You can also use the arrow
buttons on the remote control to adjust settings
OSD Setting Menus
MAIN
MENU
AUDIO
TV
CUSTOMIZE
MENU
ENTER
SEL
Press MENU to enter the OSD
The Main Menu appears.
Main Menu screen.
Note
Press the MENU button to exit the OSD menus and submenus at any time.
Repeatedly press the MENU button to exit the OSD menus and submenus
and return to TV mode.
30
Page 32
Picture Setting
SEL
ENTER
MENU
MAIN
MENU
AUDIO
TV
CUSTOMIZE
ENTER
SEL
MENU
Press MENU to enter the OSD
Main Menu screen.
Press the VOL UP button to
enter the PICTURE Menu.
Note
You can operate the OSD with either the remote control or the front panel
control.
31
Page 33
Brightness
BRIGHTNESS
BRIGHTNESS
BRIGHTNESS
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
BRIGHTNESS
+12
BRIGHTNESS
-12
NEUTRAL
ENTERENTER
30
MENUMENU
1 Press the VOL UP button. The
0
0
0
0
brightness slide bar appears.
2 Press the VOL UP button to
increase the brightness.
3 Press the VOL DOWN button to
decrease the brightness.
4 Press MENU to c onfirm the setting
and return to the Picture Menu.
Note
The new setting is confirmed automaticall y
when the OSD times out.
MAX MID MIN
BRIGHTNESS +12 0 -12
32
Page 34
Contrast
SELSEL
ENTERENTER
MENUMENU
CONTRAST
CONTRAST
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
CONTRAST
30
CONTRAST
15
NEUTRAL
ENTERENTER
30
MENUMENU
1
Press the
0
0
0
0
CONTRAST.
2 Press the VOL UP button. The
contrast slide bar appears.
CH DOWN
button to select
3 Press the VOL UP button to
increase the contrast.
4 Press the VOL DOWN button to
decrease the contrast.
5 Press MENU to confirm the setting
and return to
Note
The new setting is confirmed automatically
when the OSD times out.
the Picture Menu.
MAX MID MIN
CONTRAST 30 15 1
33
Page 35
Sharpness
SELSEL
ENTERENTER
MENUMENU
SHARPNESS
SHARPNESS
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
NEUTRAL
ENTERENTER
30
MENUMENU
1
Press the
0
0
0
0
SHARPNESS.
2 Press the VOL UP button. The
sharpness slide bar appears.
CH DOWN
button to select
SHARPNESS
+8
SHARPNESS
-8
3 Press the VOL UP button
to
increase the sharpness.
4 Press the VOL DOWN button to
decrease the sharpness.
5 Press MENU to confirm the setting
and return to the Picture Menu.
Note
The new setting is confirmed automatically when the OSD times out.
MAX MID MIN
SHARPNESS +8 0 -8
34
Page 36
Hue
SELSEL
ENTERENTER
MENUMENU
HUE
HUE
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
HUE
+24
HUE
-24
NEUTRAL
ENTERENTER
30
MENUMENU
1
Press the
0
0
0
0
HUE.
2 Press the VOL UP button. The hue
slide bar appears.
CH DOWN
button to select
3 Press the VOL UP button to
increase the hue toward the green
end of the spectrum. The image
becomes more green.
4 Press the VOL DOWN button to
decrease the hue toward the red end
of the spectrum. The image
becomes more red.
5 Press MENU to confirm the setting
and return to the Picture Menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
HUE +24 0 -24
35
Page 37
Saturation
SEL
ENTERENTER
MENUMENU
SATURATION
SATURATION
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
SATURATION
+24
SATURATION
-24
NEUTRAL
ENTERENTER
30
MENUMENU
1
Press the
0
0
0
0
SATURATION.
2 Press the VOL UP button. The
saturation slide bar appears.
CH DOWN
button to select
3 Press the VOL UP button to
increase the saturation.
4 Press the VOL DOWN button to
decrease the saturation.
5 Press MENU to confirm the setting
and return to the Picture Menu.
Note
The new setting is confirmed automatically
when the OSD times out.
36
MAX MID MIN
SATURATION +24 0 -24
Page 38
Color
ADJADJ
MENUMENU
SELSEL
ENTERENTER
MENUMENU
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
ADJADJ
30
NEUTRAL
MENUMENU
1
Press the
0
0
0
0
select COLOR.
2 Press the VOL UP button. The
current setting appears blinking in
CH DOWN
button to
the brackets.
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
ADJADJ
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
ADJADJ
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
NEUTRAL
ENTERENTER
30
MENUMENU
30
WARM
MENUMENU
30
COLD
MENUMENU
Neutral Color
0
0
0
0
Press the VOL UP button to select
NEUTRAL, then press MENU.
“NEUTRAL” appears in the brackets.
Warm Color
0
0
0
0
Press the VOL UP button to select
WARM, then press MENU. “WARM”
appears in the brackets.
Cold Color
0
0
0
0
Press the VOL UP button to select
COLD, then press MENU. “COLD”
appears in the brackets.
Note
The default color temperature is NEUTRAL.
37
Page 39
Preset
SELSEL
ENTERENTER
MENUMENU
PICTURE MENU
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
SATURATION
COLOR
PRESET
SELSEL
NEUTRAL
ENTERENTER
30
OK
MENUMENU
1
Press the
0
0
0
0
select PRESET.
2 Press the VOL UP button. “OK”
appears in the brackets. All picture
CH DOWN
button to
settings are returned to the factoryset default values.
Note
The preset function erases all of your
custom picture settings.
38
Page 40
Audio Setting
SELSEL
ENTERENTER
MENUMENU
MAIN
MENU
AUDIO
TV
CUSTOMIZE
ENTERENTER
MENUMENU
SELSEL
1
Press MENU to enter the OSD
Main Menu screen.
Press the
buttons to select AUDIO.
2 Press the VOL UP button to
CH UP / DOWN
enter the Audio Menu.
Note
You can operate the OSD with either the remote control or the front panel
control.
39
Page 41
Treble
SELSEL
ENTERENTER
MENUMENU
TREBLE
TREBLE
AUDIO MENU
TREBLE
BASS
BALANCE
ENHANCE
PRESET
SELSEL
ENTERENTER
ON
MENUMENU
1 Press the VOL UP button. The
0
0
0
treble slide bar appears.
TREBLE
+24
TREBLE
-24
2 Press the VOL UP button to
increase the treble.
3 Press the VOL DOWN button to
decrease the treble.
4 Press MENU to confirm the setting
and return to the Audio Menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
Treble +24 0 -24
40
Page 42
Bass
SELSEL
ENTERENTER
MENUMENU
BASS
BASS
AUDIO MENU
TREBLE
BASS
BALANCE
ENHANCE
PRESET
SELSEL
ENTERENTER
ON
MENUMENU
1
Press the
CH DOWN
button to select
BASS.
0
0
0
2 Press the VOL UP button. The bass
slide bar appears.
BASS
+24
BASS
-24
3 Press the VOL UP button to
increase the bass.
4 Press the VOL DOWN button to
decrease the bass.
5 Press MENU to confirm the setting
and return to the Audio Menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
Bass +240-24
41
Page 43
Balance
SELSEL
ENTERENTER
MENUMENU
BALANCE
BALANCE
AUDIO MENU
TREBLE
BASS
BALANCE
ENHANCE
PRESET
SELSEL
ENTERENTER
ON
MENUMENU
1
Press the
0
0
0
BALANCE.
2 Press the VOL UP button. The
CH DOWN
button to select
balance slide bar appears.
BALANCE
-24
BALANCE
+24
3 Press the VOL DOWN button to shift
the balance to the left speaker.
4 Press the VOL UP button
to shift the
balance to the right speaker.
5 Press MENU to confirm the setting
and return to the Audio Menu.
Note
The new setting is confirmed automatically
when the OSD times out.
LEFT MID RIGHT
Balance -24 0 +24
42
Page 44
Enhance
SELSEL
ENTERENTER
MENUMENU
SELSEL
ENTERENTER
MENUMENU
AUDIO MENU
TREBLE
BASS
BALANCE
ENHANCE
PRESET
SELSEL
Preset
AUDIO MENU
TREBLE
BASS
BALANCE
ENHANCE
PRESET
SELSEL
ENTERENTER
ENTERENTER
ON
MENUMENU
ON
OK
MENUMENU
1
Press the
CH DOWN
button to select
ENHANCE.
0
0
0
2 Press the VOL UP button
setting field.
3 Press the VOL UP button
to enter the
to turn
enhance on or off.
4 Press MENU to confirm your choice.
Note
Turning Enhance on boosts the volume;
however, if the input signal is over
specification, audio distortion may occur.
1
Press the
0
0
0
select PRESET.
2 Press the VOL UP button. “OK”
appears in the brackets. All audio
settings are returned to the factoryset default values.
CH DOWN
button to
Note
The preset function erases all of your
custom audio settings.
43
Page 45
TV Setting
SEL
ENTER
MENU
MAIN
MENU
AUDIO
TV
CUSTOMIZE
MENU
ENTER
SEL
1
Press the
Press MENU to enter the OSD
Main Menu screen.
buttons to select TV.
2 Press the VOL UP button to
enter the TV Menu.
Note
You can operate the OSD with either the remote control or the front panel
control.
CH UP
/
DOWN
44
Page 46
TV/CATV
SEL
ENTER
MENU
+ADJ
MENU
+ADJ
MENU
TV
MENU
TV/CATV
CH
ADD/ERASE
AUTO PROGRAM
SEL
ENTER
CATV
MENU
1
Press the
VOL UP
button. The
current setting appears flashing in
the brackets.
TV
MENU
TV/CATV
CH
ADD/ERASE
AUTO PROGRAM
+ADJ
TV
MENU
TV/CATV
CH
ADD/ERASE
AUTO PROGRAM
+ADJ
CATV
MENU
TV
MENU
Receiving Cable TV
Press the VOL UP button to select
CATV, then press MENU. “CATV”
appears in the brackets.
Receiving Broadcast TV
Press the VOL UP button to select TV,
then press MENU. “TV” appears in the
brackets.
Note
The default TV setting is “CATV”.
45
Page 47
Channel Add/Erase
SEL
ENTER
MENU
MENU
TV
MENU
TV/CATV
CH
ADD/ERASE
AUTO PROGRAM
SEL
ENTER
43
TV
CH UP/DOWN
-ERASE ADD+
MENU
CATV
MENU
1 Press
the CH DOWN button to
select CH ADD/ERASE.
2 Press the VOL UP button. The OSD
menu display switches to the
following screen.
Press the CH UP/ DOWN on the front
panel to select a channel.
Add Channel
Then press the VOL UP button on the
front panel to add the selected channel.
The channel number changes from
yellow into green after adding the
channel.
Erase Channel
Then press the VOL DOWN button on
the front panel to erase the selected
channel. The channel number changes
from green into yellow after erasing the
channel.
Note
You can still access the erased channel
by entering the channel number using
the number buttons on the remote
control. Add the channel again if it was
erased accidentally.
46
Page 48
Auto Program
SEL
ENTER
MENU
TV
MENU
TV/CATV
CH
ADD/ERASE
AUTO PROGRAM
SEL
AUTO PROGRAM
ENTER
TV 44
CATV
MENU
1
Press the
CH DOWN
button to
select AUTO PROGRAM.
2 Press the VOL UP button to begin
auto programming. The screen
displays channels incrementally as
the TV scans for available
channels.
Note
The screen displays the first channel that
is successfully found after scanning is
completed.
47
Page 49
Customize Setting
SELSEL
ENTERENTER
MENUMENU
MAIN
MENU
AUDIO
TV
CUSTOMIZE
ENTERENTER
MENUMENU
SELSEL
1
Press MENU to enter the OSD
Main Menu screen.
Press the
buttons to select CUSTOMIZE.
2 Press the VOL UP button to
CH UP / DOWN
enter the Customize Menu.
Note
You can operate the OSD with either the remote control or the front panel
control.
48
Page 50
Sleep Timer
SEL
ENTER
MENU
+ADJ
MENU
30SLEEP
60SLEEP
90SLEEP
120SLEEP
The sleep timer turns the TV off automatically after a set time.
1 Press the VOL UP button to select
TIMER
ENTER
MENU
20
ENGLISH
MENU
OFF
SEC
a value: OFF, 30, 60, 90, or 120
minutes.
CUSTOMIZE
SLEEP
TIMEOUT
OSD
LANGUAGE
SEL
2 Press MENU to confirm your
TIMER
MENU
30
20
ENGLISH
MENU
MIN
SEC
choice.
You can also press SLEEP on the
remote control to select 30, 60, 90 or
120 minutes. The setting appears on
the TV screen.
CUSTOMIZE
SLEEP
TIMEOUT
OSD
LANGUAGE
+ADJ
The remaining time is updated every
10 minutes on the display. During the
last minute, the sleep timer flashes.
49
Page 51
OSD Timeout
+ADJ
MENU
SEL
ENTER
MENU
MENU
This setting allows you to set the length of time the OSD menus
appear on the screen when a button is not pressed.
1
CUSTOMIZE
TIMER
SLEEP
TIMEOUT
OSD
LANGUAGE
+ADJ
MENU
20
ENGLISH
MENU
OFF
SEC
Press the
select OSD TIMEOUT.
2 Press the VOL UP button. The
current setting appears flashing in
CH DOWN
button to
the brackets.
3 Press the VOL UP button to select
a value: 20, 40, or 60 seconds.
4 Press MENU to confirm your
choice.
Language
1
CUSTOMIZE
TIMER
SLEEP
TIMEOUT
OSD
LANGUAGE
SEL
ENTER
MENU
20
ENGLISH
MENU
OFF
SEC
Press the
select LANGUAGE.
2 Press the VOL UP button. The
current setting appears flashing in
the brackets.
CH DOWN
button to
3 Press the VOL UP button to select
ENGLISH or CHINESE.
4 Press MENU to confirm your
MENU
Note
The default language setting is Traditional Chinese.
choice.
50
Page 52
12
T aking Care of Y our TV
Turn the power of f before you begin cleaning the
TV.
For best results, use a clean lens cloth to
remove dust and fingerprints from the screen.
Do not wipe the shell of the TV with alcohol,
methanol, gasoline or oil products to avoid
GAS
OIL
damaging the finish. Wipe the shell with a dry
soft cloth and use neutral cleaning fluids.
If your model has leather components, wipe the
leather parts with a dry cloth and keep the area
dry. Place the TV far from sources of steam to
avoid making the leather wet.
Be careful to remove the power plug correctly.
Hold the plug instead of pulling the power cord.
Arrange the power cord with other cords to avoid
knotting or bending which may cause fire due to
damage or electric leakage.
51
Page 53
13
Troubleshooting
Situation Solution
No picture and sound.
No picture, or poor picture,
sound is OK.
• Connect the power cord properly.
• Press the POWER button on the control panel or remote control.
• Press the SOURCE button to cycle
through connected video sources.
• Press the CH UP or CH DOWN button to switch to other TV stations.
• Check the TV/CATV OSD settings.
See “TV/CATV” on page 45.
• Make sure all cables ar e con n ec te d
properly.
• Check the antenna and cable connections.
• Adjust the brightness in the OSD
menus. See “Brightness” on page 32.
Picture is not in color.
Picture is OK, no sound.
One of the speakers has no
sound.
Can’t receive some TV channels using cable TV.
Want to reset TV settings.
52
• Adjust the saturation in the OSD
menus. See “Saturation” on page 36.
• Press the VOL UP button on the control panel or remote control.
• Make sure the MTS optio n is set to
MAIN or MONO.
• Adjust the balance in the OSD
menus. See “Balance” on page 42.
• Try the Auto Program function in the
OSD “TV Setting” menu. See “Auto
Program” on page 47.
• Use the Preset function in the OSD
Picture and Audio menu.
Page 54
Situation Solution
Cannot operate menus.
• If OSD items are colored light blue,
the system is in a state such that
those settings are not available. For
example, video setting is available in
TV mode.
No image but have sound.
No sound but have image.
Screen image turns over.
Snow appears on the screen.
Blurred or overlapped
images.
• Make sure the video signal cable is
connected properly.
• Make sure the source device is functioning properly.
• Set the volume to a higher level.
• Make sure the audi o cab le is connected securely.
• Turn the mute off.
• Make sure the video signal cable is
connected properly.
• Adjust the location of the antenna,
placing it far from roads or sources of
interference.
• Check the antenna and the video signal line connections.
• Readjust the sharpness setting.
• Choose programs with high quality
signals.
• Adjust the direction of the antenna or
change the video signal cable.
53
Page 55
14
Specifications
ST48-12A1
LCD Panel Size 12.1-inch TFT
Aspect Ratio 4:3
Best Resolution 800 (horizontal) x 600 (vertical)
Maximum Display Area 246.0 mm (H) x 184.5 mm (V)
TV System NTSC
AV1: Composite Video (RCA Jack; Yellow)
Video System
Audio System
AV2: mini-DIN 10-pin (Composite + SVideo)
AV1: L/R RCA jacks (audio input)
AV2: mini-DIN 10-pin L/R RCA jacks (audio
input)
3.5 mm headphone jack (audio output)
Built-in stereo audio
amplifier
Power Supply 100~240V, 50/60 Hz, 12V DC
Power Consumption
Weight (including base) 2.9 KG
Dimensions (including
base)
2W + 2W
40W (Max.)
281 mm (H) x 366 mm (W) x 177 mm (D)
54
Page 56
15
Glossary
Aspect Ratio The ratio of width to height of a film, image or display screen.
Broadcast TV Broadcasting video signals using high-frequency electromagnetic
waves to distribute television channels to viewers (standard TV broadcast).
CATV Community Antenna Television, the original name for cable TV. A television
distribution system that uses coaxial cable instead of the traditional radio broadcasting (over-the-air) method to deliver television, FM radio, and other services to
consumers.
Color Temperature Adjusting the color temperature enables you to set the inten-
sity of white light. Color temperature is measured in Kelvin (K). Higher color temperatures result in a blue tint. Lower temperatures result in a red tint.
Hue Colors in a color system are measured by hue, saturation and luminance.
Hue indicates the predominant color.
LCD Liquid Crystal Display. A display technology that uses rod-shaped molecules
(liquid crystals) that flow like liquid and bend light.
MAIN is the default audio signal belonging to a particular channel.
MTS Multi-channel Television Sound. Enables reception of audio other than the
primary (MAIN) audio signal. SAP (Second Audio Program) enables reception of a
separate channel that may be a different language or completely different information such as the news.
RCA connector An RCA or phono connector is a plug and socket for a two-wire
(signal and ground) coaxial cable that is widely used to connect audio and video
components. RCA sockets are commonly found at the rear of A/V equipment.
Saturation Chromatic purity indicating the amount of white contained in a color.
Fully saturated colors are pure colors; less saturated colors appear as pastel
shades.
S-Video Super-video, a video cabling standard used to transmit video by keeping
brightness (Y) and color information (C) on separate channels. Most often used
with camcorders, VCRs, and quality receivers and amplifiers to provide sharper pictures.
55
Loading...
