Table of Contents
1. Warranty and Service ................................................... 3
2. Preface ......................................................................... 4
3. Description of Warning Symbols..................................... 5
4. Safety Notices ............................................................... 6
5. Regulatory Information ................................................ 14
6. Introducing the TV ....................................................... 16
Features.................................................................. 16
7. Checking Package Contents ........................................ 17
8. Getting to Know Your TV ............................................. 18
Front View ............................................................... 18
Input and Output Ports ............................................. 19
9. Getting Started ............................................................ 20
Connecting to an Antenna or Cable TV ..................... 20
Connecting to AV Devices ........................................ 21
Connecting to a VCR/VCD/DVD Player ................ 21
Connecting to a Video Camera ............................ 22
Connecting to a Game Device ............................. 23
Connecting External Speakers or Headphones.......... 24
Connecting the Power Adapter ................................. 25
10. Using the TV .............................................................. 26
Using the Remote Control ........................................ 26
Turning the TV On and Off ....................................... 27
Selecting Channels .................................................. 27
Switching Source Signals ......................................... 28
Adjusting the Volume ............................................... 28
1
Page 3
Table of Contents
11. Adjusting On-Screen Display (OSD) Settings ............... 29
Brightness ............................................................... 30
Contrast .................................................................. 31
Video Setting ........................................................... 32
Hue .................................................................... 33
Saturation ........................................................... 34
Sharpness .......................................................... 35
Color Temperature .............................................. 36
Audio Setting ........................................................... 37
Treble................................................................. 38
Bass ................................................................... 39
Balance .............................................................. 40
TV Setting ............................................................... 41
TV/CATV ............................................................ 42
MTS ................................................................... 43
Auto Program...................................................... 44
Manual Program.................................................. 45
Channel Add/Erase ............................................. 46
Miscellaneous Setting .............................................. 47
OSD Position ...................................................... 48
Language ........................................................... 49
Sleep Timer ........................................................ 50
OSD Display ....................................................... 51
Reset ................................................................. 52
12. Taking Care of Your TV .............................................. 53
13. Troubleshooting .......................................................... 54
14. Specifications ............................................................. 56
15. Glossary .................................................................... 57
2
Page 4
1
Warranty and Service
The instructions on this manual are for the model(s) listed on the front
cover. Before you start reading, check your product number by looking
at the rear of your TV.
Thank you for purchasing our Liquid Crystal Display Television (LCD
TV). With this product, you will be able to enjoy superior audio and
video while enriching your lifestyle with advanced technology.
The Hannspree TV is warranted for one year limited service from the
date of product is received (as shown on the Warranty and Service Manual); please refer to the "Warranty and Service Manual" for the detailed
warranty information.
Hannspree provides complete service information in the included "Warranty and Service Manual", or directly from Hannspree global customer
service center. Our service representatives will be very happy to serve
you to your satisfaction.
Hannspree global customer service center telephone number:
From Taiwan please call 0800-008-800
The Hannspree e-mail Address:
service@hannspree.com
3
Page 5
2
Preface
This manual is designed to assist users in setting up and using the LCD
TV. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents.
The information in this document is subject to change without notice.
Copyright
© Copyright 2003 Hannspree, Inc.
All rights reserved. This product and related documentation are protected by copyright and are distributed under licenses restricting their
use, copying, and distribution. No part of this documentation may be
reproduced in any form by any means without prior written authorization
of Hannspree, Inc., and its licensors, if any.
4
Page 6
3
Description of Warning Symbols
Warning
This symbol is used to remind
users to pay attention to
important descriptions regarding usage and maintenance
(repair) or additional important information related to this
product.
This symbol is used to remind
users to pay attention to the
danger of electric shocks due
to dangerous internal noninsulated components.
Caution
Electric Power Notice
Electric power may cause personal injury and mechanical damage if it is
misused. Although safety has been taken into consideration during the
design and production of this product, electric shock or fire can result
when the product is misused. To prevent potential danger, follow the
instructions below when installing, operating and cleaning the product.
In addition, read the following “Safety Notices” carefully before using the
product to ensure that your TV is safe and long-lasting.
5
Page 7
4
Safety Notices
Power Supply Safety Notes
1. To avoid electric shocks, do not use an extended power cord or
an outlet that does not match this product's plug or leaves the
plug exposed.
2. This product has a 3-pin grounded plug. The third pin connects
to ground; do not remove it.
3. If the power cord or plug is damaged or worn, unplug it immediately and contact a qualified service technician for maintenance.
4. To avoid fire or electric shocks, do not overload electric power
outlets.
Installation Safety Notes
Antenna
We suggest that you use an outdoor antenna to get the best signal
possible unless you have cable TV or a centralized indoor antenna
system. You may, however, use an antenna indoors if it is placed in
a location free from interference.
Location
Avoid allowing the TV to get prolonged exposure to sunlight or
other strong sources of heat. Leave sufficient distance between the
TV and the wall to provide enough space for the emission of heat.
6
Page 8
Before You Proceed
1. Read the Safety Notices and the User’s Manual carefully
before turning the product on.
2. Keep your User’s Manual in a safe place for future reference.
Keep the box and packaging in case the product needs to be
shipped in the future.
3. Follow the product and warning label instructions.
4. Any changes or modifications that do not follow the instructions
in this manual will void this product's warranty.
Warning
To reduce the risk of fire or electric shock, do not expose this
product to rain or moisture.
Power
To avoid danger of fires or electric shock, make sure that you use a
proper adapter. The TV is compatible with the following adapters:
• EDAC POWER ELECTRONICS CO., LTD.: EA 1050E-120
• LI SHIN INTERNATIONAL ENTERPRISE CORP.: 0217B1240
7
Page 9
Optimal Viewing Distance
8
Page 10
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug: A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
9
Page 11
10. Protect the power cord from being walked on
or pinched particularly at the plug, convenience receptacles, and the point where they
exit from the apparatus.
11. Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
12. Only use attachments/accessories specified
by the manufacturer.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
if the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
10
Page 12
Personal Safety
To avoid overloading the power supply, do not
plug too many electrical devices into an outlet or
extension cable.
Dangerous high-voltage electric power components are located inside the TV. To avoid electric
shock, do not disassemble the casing.
Do not place or drop metals, small objects, or
flammable materials in the vent to avoid an electric shock or a fire.
If the TV is dropped, falls down, or is otherwise
damaged, unplug the power cord immediately
and notify a qualified service technician.
If any fluid is sprayed or dropped into the TV,
remove the power plug immediately and notify a
qualified service technician.
The screen of the TV is made of glass, be careful to avoid hitting or scraping it. If the screen is
broken, avoid cutting yourself on the broken
glass.
Do not allow children to use the TV unattended
to avoid accidents caused by improper operation.
11
Page 13
Installation
To avoid damage to power circuits, do not place
the TV in locations where there is excessive
steam or dust.
Do not place the TV on a bed, sofa, carpet, or in
a sealed cabinet to avoid blocking the product's
vents.
Install the outdoor antenna far from power transmission lines to avoid possible danger.
Remove the power cord and antenna connector
when there is a storm or when the TV is not in
use for a long period to avoid electric shock from
lightning.
This product is classified as an electrical appliance. Any violent shocks or movements, other
than lifting or moving, may affect its components,
causing a dangerous situation.
12
Page 14
Operation
V
Maintenance
This product is designed for power sources as
labeled on the casing. Avoid using any other
power accessories to avoid electric shock or
other damage.
The plug can be inserted into an outlet in only
one direction. Notify a qualified service technician if you cannot plug it in correctly.
If there is any problem that cannot be resolved
according to the instructions given in this manual, notify a qualified service technician immediately. Do not attempt any methods not covered in
this manual.
Do not attempt to repair the TV by yourself.
Notify a qualified service technician. Ask the service technician to complete a safety inspection
before switching the power on after completing
any maintenance.
13
Page 15
5
Regulatory Information
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
1
Warning: A shielded-type power cord is required in order to meet FCC
emission limits and also to prevent interference to nearby radio and television reception. It is essential that only the supplied power cord be
used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your
authority to operate the equipment.
1. applies only to products purchased in the United States of America
14
Page 16
DOC Compliance Notice
1
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulations of the Canadian Department of Communications.This
device complies with Canada ICES-003 Class B.
CE Conformity Statement
2
This device complies with the requirements set out in the Council Directive on the approximation of the Laws of the Member States relating to
Electromagnetic Compatibility (89/336/EEC) and the Amendment Directive (92/31/EEC), Low-Voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC).
1. applies only to products purchased in Canada
2. applies only to products purchased in the European Union
15
Page 17
6
Introducing the TV
Thank you for purchasing this Liquid Crystal Display TV. Your LCD TV is designed to
be safe, versatile, and easy to use.
The evening purse design makes it a fun
addition to any room.
You can watch broadcast or cable televi-
sion channels, and easily connect a VCR,
VCD, or DVD player or a game device to
the standard RCA and S-Video input ports
that are included in the 4-IN-1 cable.
Convenient control buttons located on the
top of the product let you change channels, adjust volume, and
change display settings through an easy-to-use on-screen menu sys-
tem. The built-in stereo speakers provide full, rich sound and a convenient audio output port lets you connect to an external audio
system or headphones.
Features
• 9.6-inch color TFT LCD TV
• Safe and sturdy construction
• Built-in TV tuner
•4-IN-1 cable
• On-Screen Display (OSD) menu system
• Built-in 3W+3W speakers
16
Page 18
G
W
A
1
8
3
0
0
V
8
0
C
V
W
-
1
E
7
7
8
7
4
7
Checking Package Contents
Make sure the following components are included in the box. Contact
your vendor immediately if anything is missing or damaged.
TV
User’s Manual Quick Start Guide Warranty and
Service Manual
User's Manual
Q
uick Start
G
uide
W
Wire Material Package
Power Cord Power Adapter 4-IN-1 Cable
RCA Jack x 3
S Jack X 1
a
r
ra
n
ty
a
n
d
s
e
rv
ic
e
m
a
n
u
a
l
17
Page 19
8
Getting to Know Your TV
Front View
12 3 4 5
MENU CH VOL SOURCE
Signal sensor
7
Description Function
1 Menu
2 Select channel
3 Power Turns the TV on and off.
4 Adjust volume
5 Source
6 Power LED Green LED indicates power on.
7 Stereo speakers Play audio content.
Turns the On-Screen Display (OSD)
menus on and off.
Changes channels. Press CH to
increase the channel number. Press CH
to decrease the channel number.
Press VOL+ to increases the volume.
VOL– to decreases the volume.
Press
Selects the input source to be displayed
(TV/CATV, AV, or S-Video).
18
6
7
Page 20
Input and Output Ports
ANT AV In HEADPHONE DC-IN
1234
Description Function
1 ANT
2 AV In
3 HEADPHONE
4 DC-IN
Connects to an antenna or CATV
cable television line.
Connects to VCR/VCD/DVD player
CVBS RCA cables or a game
device.
Connects to headphones or other
audio device.
Connects to the included power
adapter.
19
Page 21
9
Getting Started
Connecting to an Antenna or Cable TV
1 Connect one end of the UHF or CATV cable to the ANT Jack
(VHF/UHF IN Jack) on the back of the TV.
2 Connect the other end of the VHF/UHF (Antenna) or CATV cable to
the antenna socket or CATV cable.
Antenna
ANT AV In HEADPHONE DC-IN
ANT jack
(VHF/UHF IN jack)
Antenna/CATV
coaxial cable
Note
If you cannot receive channels after connecting to an antenna or cable TV
line, try scanning for channels. See “Auto Program” on page 44.
Antenna/CATV
socket
20
Page 22
Connecting to AV Devices
Connect external devices such as a VCR, VCD or DVD player, or
video game to the TV using the 4-IN-1 cable.
Connecting to a VCR/VCD/DVD Player
The illustration presented here shows how to connect the TV to a
VCR and VCD or DVD player. Actual connections may vary accord-
ing to the make and model of the device. Refer to the user’s manual
included with the device for more detailed instructions.
VCR
VCD
DVD
ANT AV In HEADPHONE DC-IN
4-IN-1 jack
4-IN-1 cable
Note
The cables are color-coded (black, red, white, yellow). Connect each colorcoded cable to the appropriate connector on your device.
S-Video
connector
BRWY
AV
connectors
21
Page 23
Connecting to a Video Camera
The instructions presented here are a general guide to connecting
the TV to a camcorder or other type of digital camera. Actual connec-
tions may vary according to the make and model of the device. Refer
to the user’s manual included with the camcorder or camera for more
detailed instructions.
S
WB
ANT AV In HEADPHONE DC-IN
S-Video
connector
4-IN-1 jack
B
R
W
Y
4-IN-1 cable
AV connectors
Note
The cables are color-coded (black, red, white, yellow). Connect each colorcoded cable to the appropriate connector on your device.
22
Page 24
Connecting to a Game Device
The instructions presented here are a general guide to connecting
the TV to a game device using the RCA Jacks provided (some game
devices may require a unique adapter that is not provided). Actual
connections may vary according to the make and model of the game
device. Refer to the user’s manual included with the game device for
more detailed instructions.
ANT AV In HEADPHONE DC-IN
4-IN-1 jack
4-IN-1 cable
Notes
• Connect the 4-IN-1 cable connectors to the corresponding connectors on
your game device adapter.
• If the 4-IN-1 cable does not fit the game device, then insert the included
RCA jack between the 4-IN-1 cable and the game device.
S-Video
connector
4-IN-1 cable
BRWY
AV
connectors
23
Page 25
Connecting External Speakers or Headphones
External speakers or headphones may be used to listen to the TV
rather than using the built-in speakers. Connect external speakers or
headphones to the headphone line out port as illustrated.
Headphones
ANT AV In HEADPHONE DC-IN
Speakers
Speaker/Headphone
line out port
Notes
• External speakers or headphones are not included with the product.
• The internal TV speakers will not output sound when headphones are
plugged in.
• Use external speakers with amplifiers only.
24
Page 26
Connecting the Power Adapter
1 Connect the power cord to the power adapter as illustrated.
2 Plug the power adapter connector into the DC-IN input jack on the
rear panel of the TV.
3 Insert the three-pronged plug at the other end of the power cord into
a power outlet.
Power outlet
Three-pronged
plug
Power cord
ANT AV In HEADPHONE DC-IN
DC-IN
Power adapter
25
Page 27
10
Using the TV
Using the Remote Control
For best results, use the remote control within a distance of 5 meters
from the front of the TV’s signal sensor. Do not exceed an angle of 30
degrees when pointing at the signal sensor. Refer to the following
illustration.
26
3m
3m
30
30
5m
Page 28
Turning the TV On and Off
1 Press the POWER button on
the remote control (or control
panel). The power LED
changes from dark to green,
indicating that the power has
been turned on.
2 Press the POWER button
again; the power LED
changes from green to dark,
indicating that the TV is in off
mode.
Selecting Channels
Press the CH and CH
button on the control panel to
select the channel or enter the
specific channel number by
pressing the number buttons on
the remote control.
Power Button
MENU CH VOL SOURCE
TV:10
Power LED
Channel up
Channel down
MENU CH VOL SOURCE
TV:10
27
Page 29
Switching Source Signals
Current Source setting
Press the SOURCE button on
MENU CH VOL SOURCE
the remote control or control
panel to select the incoming
source signal.
TV:10
The current source setting
(TV/CATV, S-Video, or AV)
appears on the top left corner of
the screen.
Note
The TV supports S-Video input in addition to normal video and audio sig-
nals.
Adjusting the Volume
Press the VOL
+ button to
increase the volume. Press the
– button to decrease the
VOL
Vol u m e u p
Volume down
MENU CH VOL SOURCE
volume. The volume level is dis-
played on the TV.
Press the MUTE button on the
remote control to turn the sound
off. Press the MUTE button on
the remote control or press the
VOL UP/VOL DOWN button to
turn the sound on.
28
48
Volume level
Page 30
ETO
11
Adjusting On-Screen Display (OSD)
Settings
The On-Screen Display (OSD) menu system provides a quick and
simple method to adjust your TV’s settings. This chapter describes
how to change each of the available settings.
The OSD can be used with either the remote control or the front control panel.
Button Descriptions Control Panel
MENU MENU
CH UP CH
CH DOWN
ENTER MENU
The following sections explain how to adjust settings in the OSD
menus using the remote control.
OSD Setting Menu
CH
Main Menu
ETO
MENU CH
Press the MENU button to enter
Video Setting
ENTER
The Main Menu appears
the OSD menus.
Note
To exit the OSD menus at any time, press the CH UP button or the CH
DOWN
Also, after you finish setting OSD parameters, follow these instructions to
exit the OSD menus; alternatively, wait 15 seconds for the OSD to close
automatically.
button to select Exit . Then press MENU to exit the OSD menus.
29
Page 31
Brightness
ETO
Main Menu
Brightness
ENTER
1 Press MENU to enter the OSD
menus.
ETO
2 Press the CH UP button or the CH
DOWN button to select Brightness.
50
3 Press MENU. The brightness slide
bar appears.
4 Press the CH UP button to increase
the brightness.
5 Press the CH DOWN button to
decrease the brightness.
6 Press MENU to confirm the setting
and return to the Main menu.
Notes
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
30
BRIGHTNESS 100 50 0
Page 32
Contrast
ETO
ENTER
Contrast
Main Menu
1 Press MENU to enter the OSD
ETO
menus.
2 Press the CH UP button or the CH
50
DOWN button to select Contrast.
3 Press MENU. The contrast slide
bar appears.
4 Press the CH UP button to increase
the contrast.
5 Press the CH DOWN button to
decrease the contrast.
6 Press MENU to confirm the setting
and return to the Main menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
CONTRAST 100 50 0
31
Page 33
Video Setting
ETO
MENU CH
Main Menu
ETO
Video Setting
ENTER
Press the MENU button to enter
the OSD menus.
1 Press the CH UP button or the
CH DOWN button
Video Setting.
to select
2 Press MENU to enter the
Video Setting menu.
32
Page 34
Hue
Video Setting
G
B
R
Hue
GR
50
ENTER
1 Press the CH UP button or the CH
DOWN button to select Hue.
2 Press MENU to enter the Hue
menu.
3 Press the CH UP button to increase
the hue towards the red spectrum.
The image becomes more red.
4 Press the CH DOWN button to
decrease the hue towards the
green spectrum. The image
becomes more green.
5 Press MENU to confirm the setting
and return to the Video Setting
menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
HUE 100 50 0
33
Page 35
Saturation
ENTER
Video Setting
G
R
B
Saturation
1 Press the CH UP button or the CH
DOWN button to select Saturation.
2 Press MENU to enter the
50
Saturation menu.
3 Press the CH UP button to increase
the saturation. The screen image
becomes more vibrant.
4 Press the CH DOWN button to
decrease the saturation. The
screen image becomes less
vibrant.
5 Press MENU to confirm the setting
and return to the Video Setting
menu.
Note
The new setting is confirmed automatically when the OSD times out.
MAX MID MIN
34
SATURATION 100 50 0
Page 36
Sharpness
R
G
B
ENTER
Video Setting
Sharpness
1 Press the CH UP button or the CH
DOWN button to select Sharpness.
2 Press MENU to enter the
50
Sharpness menu.
3 Press the CH UP button to increase
the sharpness.
4 Press the CH DOWN button to
decrease the sharpness.
5 Press MENU again to confirm the
setting and return to the Video Set
ting menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
SHARPNESS 100 50 0
-
35
Page 37
Color Temperature
R
G
B
ENTER
Video Setting
Color
1 Press the CH UP button or the CH
DOWN button to select Color.
2 Press MENU to enter the Color
menu. The following three color
temperatures are available.
Standard Color
Press the CH UP button or the CH
DOWN button to select Standard, then
press MENU.
Warm Color
Press the CH UP button or the CH
DOWN button to select Warm, then
press MENU.
Cold Color
Press the CH UP button or the CH
DOWN button to select Cold, then press
MENU.
36
Page 38
Audio Setting
ETO
Ma in men u
EN TER
MENU CH
ETO
Audio Setting
Press the MENU button to enter
the OSD menus.
1 Press the CH UP button or the
CH DOWN button
Audio Setting.
to select
2 Press MENU to enter the
Audio Setting menu.
37
Page 39
Treble
EN TER
Au di o Se ttin g
Treble
1 Press the CH UP button or the CH
DOWN button to select Treble.
2 Press MENU to enter the Treble
48
menu.
3 Press the CH UP button to increase
the treble.
4 Press the CH DOWN button to
decrease the treble.
5 Press MENU to confirm the setting
and return to the Audio Setting
menu.
Note
The new setting is confirmed automatically when the OSD times out.
MAX MID MIN
Treble 100 50 0
38
Page 40
Bass
EN TER
Au di o Se ttin g
Bass
1 Press the CH UP button or the CH
DOWN button to select Bass.
2 Press MENU to enter the Bass
48
menu.
3 Press the CH UP button to increase
the bass.
4 Press the CH DOWN button to
decrease the bass.
5 Press MENU to confirm the setting
and return to the Audio Setting
menu.
Note
The new setting is confirmed automatically when the OSD times out.
MAX MID MIN
Bass 100 50 0
39
Page 41
Balance
EN TER
Au di o Se ttin g
LR
Balance
50
1 Press the CH UP button or the CH
DOWN button to select Balance.
2 Press MENU to enter the Balance
menu.
3 Press the CH DOWN button to shift
the balance to the left speaker.
4 Press the CH UP button to shift the
balance to the right speaker.
5 Press MENU to confirm the setting
and return to the Audio Setting
menu.
Note
The new setting is confirmed automatically
when the OSD times out.
MAX MID MIN
Balance R (100) 50 L (0)
40
Page 42
TV Setting
ETO
MENU CH
Main Menu
ETO
TV Setting
ENTER
Press the MENU button to enter
the OSD menus.
1 Press the CH UP button or the
CH DOWN button
Setting.
to select TV
2 Press MENU to enter the TV
Setting menu.
41
Page 43
TV/CATV
ENTER
ENTER
ENTER
TV
TV/CATV
TV
TV
TV/CATV
TV
TV
TV/CATV
TV
AUTO
SET
AUTO
SET
AUTO
SET
Setting
MENU
SET
CATV
Setting
MENU
SET
CATV
Setting
MENU
SET
CATV
1 Press the CH UP button or the CH
Channel
-
+
DOWN button to select TV/CATV.
2 Press MENU to enter the TV/CATV
menu. The following choices are
available.
Receiving Broadcast TV
Channel
-
+
Press the CH UP button or the CH
DOWN button to select TV, then press
MENU.
Receiving Cable TV
Channel
-
+
Press the CH UP button or the CH
DOWN button to select CATV (default),
then press MENU.
42
Page 44
MTS
EN TER
TV
SA P DU AL
AUTO
SET
MENU
SET
Se tt ing
Channe l
+
-
MA IN
MTS
1 Press the CH UP button or the CH
DOWN button to select MTS.
2 Press MENU to enter the MTS
menu.
ENTER
ENTER
ENTER
MAIN
1 Press the CH UP button or the CH
DOWN button to select MAIN
(default). MAIN is highlighted in
red.
2 Press MENU again to confirm the
MAIN
TV
MTS
Setting
AUTO
MENU
Channel
SET
SET
SAP DUAL
-
+
selection.
TV
Setting
AUTO
MENU
Channel
-
+
SET
SET
MTS
SAP DUAL
MAIN
TV
Setting
AUTO
MENU
Channel
-
SET
SET
+
MTS
SAP DUAL
MAIN
SAP
1 Press the CH UP button or the CH
DOWN button to select SAP. SAP is
highlighted in red.
2 Press MENU again to confirm the
selection.
DUAL
1 Press the CH UP button or the CH
DOWN button to select DUAL.
DUAL is highlighted in red.
2 Press MENU to confirm the selec-
tion.
43
Page 45
Auto Program
+
ENTER
TV
Setting
AUTO
MENU
SET
SET
Program
AUTO
YES
Channel Indicator
TV:10
1 Press the CH UP button or the CH
Channel
-
NO
DOWN button to select
Auto Pro-
gram.
2 Press MENU to enter the Auto Pro-
gram menu.
3 Press the CH UP button or the CH
DOWN button to select Yes
or No.
4 Press MENU.
The screen goes blank and the chan-
nel indicator values range from 2 to
69 (antenna connection) or from 1 to
125 (CATV cable connection).
The screen displays the first channel
that is successfully found after scan-
ning is complete.
44
Page 46
Manual Program
This function allows you to locate channels for adding to or erasing
from preset channels.
ENTER
TV
Manual
DOWN
AUTO
SET
Setting
MENU
Channel
SET
Program
Up
3
1 Press the CH UP button or the CH
-
+
DOWN button to select Manual
Program.
2 Press MENU to enter the Manual
Program menu.
3 Press the CH UP button and CH
DOWN button to find the channel
you want to add.
4 When you have found the channel,
press MENU.
45
Page 47
Channel Add/Erase
Channel to be added or erased must be selected from Manual
program.
ENTER
Erase
TV
Setting
AUTO
MENU
SET
SET
CH.Add/Erase
3
1 Press the CH UP button or the CH
Channel
-
+
DOWN button to select
CH. Add/Erase.
2 Press MENU to enter the CH.
Add
Add/Erase menu. Select one of the
following options.
Add Channel
1 Press the CH UP button to select
Add.
2 Press the MENU to add the
selected channel.
Erase Channel
1 Press the CH DOWN button to
select Erase.
2 Press MENU to delete the selected
channel.
When you return to the normal TV
screen and use the
DOWN
buttons to browse channels,
the deleted channel (for example,
Channel 3) is skipped automatically.
CH UP / CH
46
Note
You can still access the deleted channel
by entering the channel number using
the number buttons on the remote control.
Page 48
Miscellaneous Setting
MENU CH
Main Menu
ETO
Miscellaneous
ENTER
Press the MENU button to enter
the OSD menus.
1 Press the CH UP button or the
CH DOWN button
Miscellaneous.
to select
2 Press MENU to enter the Mis-
cellaneous menu.
47
Page 49
OSD Position
EN TER
OS D Posi tio n
OSD
OSD
50
H -P o si t io n
ENTE R
OSD Pos itio n
OSD
ENTE R
OSD Pos itio n
OSD
OSD Position
H-Position
OSD
H-Position
OSD
V-Position
1 Press the CH UP button or the CH
DOWN button to select OSD
Position.
50
2 Press MENU to enter the OSD
Position menu.
The following options are available.
Horizontal Position
1 Press the CH UP button or the CH
DOWN button to select H
48
2 Press MENU.
-Position.
3 Press the CH DOWN button to
move the OSD screen to the left.
Press the CH
UP button to move
the OSD screen to the right.
4 Press MENU to confirm the setting.
Vertical Position
1 Press the CH UP button or the CH
DOWN button to select V
48
2 Press MENU.
-Position.
48
3 Press the CH DOWN button to
move the OSD screen downward.
Press the CH
UP button move the
OSD screen upward.
4 Press MENU to confirm the setting.
Page 50
Language
OSD
Z
Z
Z
CH
OSD
Z
Z
Z
CH
ENTER
ENTER
Miscellaneous
Language
English
Miscellaneous
Language
English
ᕷᥟύЎ
ᕷᥟύЎ
1 Press the CH UP button or the CH
DOWN
button to select Language.
2 Press MENU to enter the Language
menu.
The screen displays the available
OSD languages: English and
T-Chinese (Traditional Chinese).
3 Press the CH UP button or the CH
DOWN button to select a language.
4 Press MENU to confirm your
choice.
Note
The default language setting is
Tranditional Chinese.
49
Page 51
Sleep Timer
OSD
CH
EN TER
Mi sc ella neo us
OSD
CH
OF F
60
90
12 0
The sleep timer turns the TV off automatically after a set period of
time.
ENTER
Miscellaneous
Sleep
OFF
Sleep
1 Press the CH UP button or the CH
Z
Z
Z
DOWN button to select Sleep.
2 Press MENU to enter the Sleep
30
90
120
60
menu.
3 The screen displays the available
sleep timer setting:
–Off
– 30 minutes
– 60 minutes
– 90 minutes
– 120 minutes
4 Press the CH UP button or the CH
Z
Z
Z
DOWN button to select a setting.
5 Press MENU to confirm your
30
choice.
50
Page 52
OSD Display
OSD
Z
Z
Z
This setting allows you to set whether information such as the
selected channel is shown on the TV screen when the DISPLAY but-
ton is pressed.
ENTER
Miscellaneous
OSD
On
CH
Display
Off
1 Press the CH UP button or the CH
DOWN button to select OSD
Display.
2 Press MENU to enter the OSD
Display menu.
3 Press the CH UP button or the CH
DOWN button to select On or Off.
4 Press MENU to confirm your
choice.
51
Page 53
Reset
OSD
Z
Z
Z
CH
The Reset function returns all of your TV’s user settings to their factory defaults.
Warning:
The reset function will erase all of your custom and favorite channel
settings, and will reset all display settings (such as contrast, brightness, etc.) to the factory default values. The reset function cannot be
reversed once it begins.
Miscellaneous
1 Press the CH UP button or the CH
DOWN button to select Reset.
Yes
Reset
No
2 Press MENU to enter the Reset
menu.
3 Press the CH UP button or the CH
ENTER
DOWN button to select Yes or No.
By default, No is already selected
(highlighted in red).
4 Press MENU to confirm your
choice.
52
Page 54
12
Taking Care of Your TV
Turn the power off before you begin cleaning the
TV.
For best results, use a clean lens cloth to
remove dust and fingerprints from the screen.
Do not wipe the shell of the TV with alcohol,
GAS
OIL
methanol, gasoline or oil products to avoid damaging the finish. Wipe the shell with a dry soft
cloth and use neutral cleaning fluids.
If your model has leather components, wipe the
leather parts with a dry cloth and keep the area
dry. Place the TV far from sources of steam to
avoid making the leather wet.
Be careful to remove the power plug correctly.
Hold the plug instead of pulling the power cord.
Arrange the power cord with other cords to avoid
knotting or bending which may cause fire due to
damage or electric leakage.
53
Page 55
13
Troubleshooting
Situation Solution
• Connect the power cord properly.
• Press the POWER button on the control
panel or remote control.
• Press the SOURCE button to cycle through
No picture and sound.
No picture, or poor picture, sound is
OK.
Picture is not in color.
Picture is OK, no sound.
One of the speakers has no sound.
Can’t receive some TV channels using
cable TV.
Want to reset TV settings. • Use the Reset function in the OSD menu.
Cannot operate menus.
No image but have sound.
connected video sources.
• Press the CHANNEL UP or CHANNEL
DOWN button to switch to other TV stations.
• Check the TV/CATV OSD settings. See
“TV/CATV” on page 42.
• Make sure all cables are connected properly.
• Check the antenna and cable connections.
• Adjust the brightness in the OSD menus. See
“Brightness” on page 30.
• Adjust the saturation in the OSD menus. See
“Saturation” on page 34.
• Press the VOL UP button on the control panel
or remote control.
• Make sure the MTS option is set to Main or
Dual. See “MTS” on page 43.
• Adjust the balance in the OSD menus. See
“Balance” on page 40.
• Try the Auto Program function in the OSD “TV
Setting” menu. See “Auto Program” on
page 44.
• If OSD items are colored light blue, the system is in a state such that those settings are
not available. For example, video setting is
available in TV mode.
• Make sure the video signal cable is connected properly.
54
Page 56
Situation Solution
No sound but have image.
Screen image turns over.
Snow appears on the screen.
Blurred or overlapped images.
• Make sure the source device is functioning
properly.
• Set the volume to a higher level.
• Make sure the audio cable is connected
securely.
• Turn the mute off.
• Make sure the video signal cable is connected properly.
• Adjust the location of the antenna, placing it
far from roads or sources of interference.
• Check the antenna and the video signal line
connections.
• Readjust the sharpness setting.
• Choose programs with high quality signals.
• Adjust the direction of the antenna or change
the video signal cable.
55
Page 57
14
Specifications
F660-10A1
LCD Panel Size 9.6-inch TFT
Aspect Ratio 4:3
Best Resolution 800 (horizontal) x 600 (vertical)
Maximum Display Area 194.4 mm (H) x 145.8 mm (W)
TV System NTSC
Video System
Audio System
Built-in Speakers 3W + 3W
Power Supply 100-240V, 50/60 Hz, 12V DC
Power Consumption 42W Maximum
Power Consumption (Standby) 0.9W Maximum
Optional Accessories External Speakers
Weight (including base) 2.5 kg
Dimensions (including base) 325 mm (H) x 313 mm (W) x 48 mm (D)
S-Video Input and Composite Video Input (through the
4-IN-1 cable)
Input: RCA Jack (L/R Audio Input through the 4-IN-1
cable)
Output: 3.5mm ø headphone jack x 1
56
Page 58
15
Glossary
Aspect Ratio The ratio of width to height of a film, image or display screen.
Broadcast TV Broadcasting video signals using high-frequency electromagnetic
waves to distribute television channels to viewers (standard TV broadcast).
CATV Community Antenna Television, the original name for cable TV. A television
distribution system that uses coaxial cable instead of the traditional radio broadcasting (over-the-air) method to deliver television, FM radio, and other services to
consumers.
Color Temperature Adjusting the color temperature enables you to set the inten-
sity of white light. Color temperature is measured in Kelvin (K). Higher color temperatures result in a blue tint. Lower temperatures result in a red tint.
DUAL Used with SAP and NTSC, enables broadcast of the main broadcast signal
on one speaker, and the alternate audio speaker on the other speaker.
Hue Colors in a color system are measured by hue, saturation and luminance.
Hue indicates the predominant color.
LCD Liquid Crystal Display. A display technology that uses rod-shaped molecules
(liquid crystals) that flow like liquid and bend light.
Main is the default audio signal belonging to a particular channel.
MTS Multi-channel Television Sound. Enables reception of audio other than the
primary (MAIN) audio signal. DUAL enables reception of a stereo audio signal,
while SAP (Second Audio Program) enables reception of a separate channel that
may be a different language or completely different information such as the news.
RCA connector An RCA or phono connector is a plug and socket for a two-wire
(signal and ground) coaxial cable that is widely used to connect audio and video
components. RCA sockets are commonly found at the rear of audiovisual equipment.
RCA jack An RCA jack enables you to attach the 4-IN-1 cable to a device socket.
Refer to “Checking Package Contents” on page 17 and “Connecting to a Game
Device” on page 23.
SAP (Secondary Audio Program) is an audio channel used with the NTSC TV
standard for auxiliary transmission of such items as foreign language broadcasting
or teletext.
Saturation Chromatic purity indicating the amount of white contained in a color.
Fully saturated colors are pure colors; less saturated colors appear as pastel
shades.
57
Page 59
S-Video Super-video, a video cabling standard used to transmit video by keeping
brightness (Y) and color information (C) on separate channels. Most often used
with camcorders, VCRs, and quality receivers and amplifiers to provide sharper pictures.
VCD A compact disk format developed in 1993 by Sony and Philips to capture full-
motion video. A standard Video CD can hold 74 minutes of near VHS-quality video
and CD-quality sound.
58
Loading...
