MAK-000002
15" Liquid Crystal Display
Television
User's Manual
Table of Contents
1. Regulatory Information................................................... 3
2. Description of Warning Symbols ..................................... 5
3. Safety Notices ............................................................... 6
4. Preface ....................................................................... 13
5. Introducing the TV ....................................................... 15
Features.................................................................. 15
6. Checking Package Contents......................................... 16
7. Getting Started ............................................................ 17
Control Panel .......................................................... 17
Input and Output Jacks ............................................ 18
Remote Control ....................................................... 19
Inserting the Remote Control Battery/Batteries.......... 21
8. Making Connections .................................................... 24
Connecting to an Antenna or Cable TV ..................... 24
Connecting to AV Devices ........................................ 25
Connecting to a VCR/VCD/DVD Player ................ 25
Connecting to a Video Camera ............................ 26
Connecting to a Video Game Console .................. 27
Connecting External Speakers or Headphones.......... 28
Connecting to a PC .................................................. 29
Connecting the Power Adapter ................................. 30
9. Using the TV ............................................................... 31
Using the Remote Control ........................................ 31
Turning the TV On and Off ....................................... 31
Selecting Channels .................................................. 31
Switching Source Signals ......................................... 31
Adjusting the Volume ............................................... 31
10.Adjusting On-Screen Display (OSD) Settings ................ 32
OSD Setting Menu ................................................... 33
Brightness .......................................................... 34
Contrast ............................................................. 35
Audio Setting ........................................................... 36
Treble................................................................. 37
Bass ................................................................... 38
1
Table of Contents
Balance .............................................................. 39
SRS ................................................................... 40
Mute ................................................................... 41
Video Setting ........................................................... 42
Hue .................................................................... 43
Saturation ........................................................... 44
Sharpness .......................................................... 45
Color Temperature .............................................. 46
TV Setting ............................................................... 47
TV/CATV ............................................................ 48
MTS ................................................................... 49
Auto Program...................................................... 50
Manual Program.................................................. 51
Channel Add/Erase ............................................. 52
Favorite Channel................................................. 53
PC Setting ............................................................... 54
Horizontal Position .............................................. 55
Vertical Position .................................................. 56
Phase ................................................................. 57
Clock .................................................................. 58
DOS Mode .......................................................... 59
Color Temperature .............................................. 60
Miscellaneous Setting .............................................. 62
Language ........................................................... 63
Sleeper............................................................... 64
OSD Display ....................................................... 65
Time Setting ....................................................... 66
More Option ........................................................ 67
11.Taking Care of Your TV & Remote Control .................... 77
12.Troubleshooting ........................................................... 78
13.Warranty and Service .................................................. 80
14.Specifications .............................................................. 81
15.Glossary ..................................................................... 82
2
1
Regulatory Information
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
1
Additional Information
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Warning: You are cautioned that changes or modifications not
expressly approved by the party responsible for compliance could void
your authority to operate the equipment.
1. applies only to products purchased in the United States of America
3
DOC Compliance Notice
1
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulations of the Canadian Department of Communications.This
device complies with Canada ICES-003 Class B.
CE Conformity Statement
2
This device complies with the requirements set out in the Council
Directive on the approximation of the Laws of the Member States
relating to Electromagnetic Compatibility (89/336/EEC) and the
Amendment Directive (92/31/EEC), Low-Voltage Directive (73/23/EEC)
and the Amendment Directive (93/68/EEC).
1. applies only to products purchased in Canada
2. applies only to products purchased in the European Union
4
2
Description of Warning Symbols
Before You Proceed
1. Read all Safety Notices in Section 2 of this manual and
instructions in the User’s Manual carefully before either plugging
in or turning the TV on.
2. Keep this User’s Manual in a safe place for future reference.
Keep the box and packaging in case the TV needs to be shipped
in the future.
3. Follow the TV and warning label instructions.
4. Any uses, operations, changes, alterations or modifications of
the TV that do not follow the instructions in this manual will void
this TV’s warranty.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
This symbol is used to alert
users to pay attention to
important descriptions
regarding usage, maintenance
(repair), and additional
important information related
to this TV.
CAUTION
This symbol is used to alert
users to the risk of electric
shocks due to dangerous and
uninsulated components.
5
3
Safety Notices
Electric Power Notice
Electric power may cause personal injury and mechanical damage if
misused. Although safety has been taken into consideration during the
design and production of this TV, electric shock or fire can result if the
TV is misused. To prevent potential danger, read and follow the
instructions and warnings contained in this manual when setting up,
operating or cleaning the TV. In addition, please read all “Safety
Notices” contained in this manual carefully before using the TV.
Power Supply Safety Notes
1. To avoid electric shocks, do not use an extended power cord or
an outlet that does not match this TV's plug or leaves the plug
exposed.
2. This TV has a 3-pin grounded plug. The third pin connects to
ground; do not remove it or alter it in anyway.
3. If the power cord or plug is damaged or worn, unplug it
immediately and contact an authorized service technician for
maintenance.
4. To avoid fire or electric shocks, do not overload electric power
outlets.
6
Installation Safety Notes
Antenna
We suggest that you use an outdoor antenna to get the best signal
possible unless you have cable TV or a centralized indoor antenna
system. You may, however, use an antenna indoors if it is placed in a
location free from interference.
Location
Avoid prolonged exposure to sunlight or other strong sources of heat.
Leave sufficient distance between the TV and the wall to provide
enough space for the emission of heat.
WARNING
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
Power
To avoid danger of fires or electric shock, only use those adapters
listed below, which are compatible with this TV.
• EDAC POWER ELECTRONICS CO., LTD.: EA1050A-120
• LI SHIN INTERNATIONAL ENTERPRISE CORP.: 0218B1260
7
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install
in accordance with manufacturer’s
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding-type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on
or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11 Only use attachments/accessories specified
by the manufacturer.
12 Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14 Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
CAUTION
These servicing instructions are for use by
qualified service personnel only.To reduce
the risk of electric shock, do not perform any
servicing other than that contained in the
operating instructions unless you are
qualified to do so.
9
Personal Safety
To avoid overloading the power supply, never
plug too many electrical devices into an outlet,
power strip, or extension cable.
Dangerous high-voltage electric power
components are located inside the TV. To avoid
electric shock, do not disassemble the TV in any
way.
Do not place or drop metals, small objects, or
flammable materials into the vent of the TV.
If the TV is dropped, falls down, or is otherwise
damaged, unplug the power cord immediately
and contact an authorized service technician.
If any fluid is sprayed or dropped into the TV,
contact an authorized service technician.
10
The screen of the TV is made of glass. Avoid
hitting or scraping it. If the screen is broken, do
not touch the broken glass.
Do not allow children to use the TV unattended.
Installation
Do not place the TV in locations where there is
excessive steam or dust.
Avoid blocking the TV's vents, do not place the
TV on a bed, sofa, carpet, or in a sealed cabinet.
Install the outdoor antenna (not included) away
from power transmission lines to avoid possible
danger.
Unplug the power cord and antenna connector
when there is a storm or when the TV is not in
use for long periods to avoid electric shock from
lightning.
11
Operation
V
Maintenance
This TV is designed for home power sources as
labeled on the casing. Avoid using any other
power accessories to avoid electric shock or
other damage.
The plug can be inserted into an outlet in only
one direction as shown to the left. Do not alter
the plug. Contact an authorized service
technician if you cannot plug it in correctly.
If there is any problem that cannot be resolved
according to the instructions given in this
manual, contact an authorized service technician
immediately. Do not attempt any methods not
covered in this manual.
Do not attempt to repair the TV by yourself.
Contact an authorized service technician. Ask
the service technician to complete a safety
inspection before switching the power on after
completing any maintenance.
12
4
Preface
Thank you for purchasing a Hannspree Liquid Crystal Display Television
(LCD TV). Your new TV will allow you to enjoy superior audio and video
while enriching your lifestyle with advanced technology.
Please carefully read this manual in its entirety before setting up, using
or operating your TV. To ensure the safe and correct installation and
operations of the TV, it is important that the safety and operation
instructions in this manual are followed.
This instruction manual is designed to assist you in setting up and using
the TV. The information in this manual has been carefully checked for
accuracy; however, no guarantee is given to the correctness of the
contents. The information in this manual is subject to change without
notice.
To the extent allowed by applicable law, Hannspree California Inc.
(“Hannspree”) shall not be liable for direct, indirect, special, exemplary,
incidental or consequential damages arising from any defect or
omission in this manual, even if advised of the possibility of such
damages in advance.
13
Copyright
© Copyright 2004 Hannspree California Inc.
All rights reserved. This manual is protected by copyright and
distributed under licenses restricting its use, copying and distribution.
No part of this manual may be reproduced in any form by any means
without the prior written authorization of Hannspree. The TV described
in this manual may include copyrighted software of Hannspree (or other
third parties). Hannspree (or other third parties) preserves the exclusive
rights for copyrighted software, such as the right to distribute or
reproduce the copyrighted software. Accordingly, and to the extent
allowed by applicable law, any copyrighted software contained in the
product described herein shall not be distributed, modified, reverse
engineered, or reproduced in any manner without the prior written
authorization of Hannspree (or of other third parties).
The Hannspree logos presented herein are trademarks of Hannspree.
All other product names, trademarks or logos mentioned herein are
used for identification purpose only, and may be the trademarks or
registered trademarks of their respective owners.
The purchase of the product described herein shall not be deemed to
grant, either directly or by implication, estoppel or otherwise, any
license under the copyrights, patents, patent applications or trademarks
of Hannspree, except for the normal, non-exclusive use that arises by
operation of law in the sale of a product.
14
5
Introducing the TV
Thank you for purchasing this LCD TV. Your LCD TV is designed to be safe,
versatile, and easy to use. The design makes it a fun addition to any room.
You can watch broadcast or cable television channels, and easily connect a
VCR, VCD, DVD player or a game device to the standard RCA and S-Video
input ports that are included in the 4-IN-1 A/V cable. You can also connect
your TV to a PC and use the TV as an external monitor.
Convenient control buttons located on the TV and a handy remote control let
you change channels, adjust the volume, and change display settings
through an easy-to-use on-screen display menu system. The built-in stereo
speakers provide full rich sound and a convenient audio output port lets you
connect to an external audio system or headphones.
Features
• Built-in TV tuner
• 4-IN-1 A/V cable
• On-Screen Display (OSD) menu system
• Built-in stereo speakers
• 3D Comb Filter
• Advanced de-interlacing
15
6
Checking Package Contents
Make sure the following components are included in the box. Please contact
Hannspree Customer Service immediately if anything is missing or
damaged.
•TV
• User’s manual
• Quick start guide
• Warranty and service manual
• Power cord
• Power adapter
• 4-IN-1 A/V cable
• Remote control and battery/batteries
• RCA jack x 3
• VGA cable
• Stop Card
16
7
f
A
Getting Started
Control Panel
Description Icon Function
Power
/
0
Of
On
Turns the TV on and off.
Power LED
Mute (Auto)
Source
Menu
Select
channel
Adjust
volume
MUTE
AUTO
MUTE
0
UTO
0
SOURCE/S/
MENU/M/
channel up
/ / S)
(
channel down
( / / T)
volume up
00
A
( / / + / S)
volume down
( / / – / T)
Indicates power status.
In TV/AV mode, press this button to
mute the audio. Automatically
adjusts the screen parameter in PC
mode.
Selects the input source to be
displayed
(TV/CATV, AV, AV1,AV2 or PC).
Turns the On-Screen Display (OSD)
menu on and off.
Changes channels. Press channel up
to increase the channel number.
Press channel down to decrease the
channel number. In PC or AV mode,
press either button to return to TV
mode.
Press volume up to increase the
audio volume. Press volume down to
decrease the audio volume.
17
Input and Output Jacks
Description Connector Function
AV1 (R-AUDIO/
L-AUDIO/VIDEO)
(Selected models
only)
AV2 (AV, AV IN)
ANT
DC-IN (DC-12V)
VGA/PC-IN
Connects to a right audio (red)
or left audio (white) cable, or
video (yellow) cable.
Use the included 4-IN-1 A/V
cable to connect external
devices, such as a VCR, VCD,
DVD player
cables or a game device.
Audio Input: AV connector
audio (white and red) cables.
Video Input: AV connector
video (yellow) or S-Video
cable.
Connects to an antenna or
CATV cable television line.
Connects to the included
power adapter.
Connects to a PC.
, CVBS RCA
LINE IN
LINE OUT
Headphone jack
18
()
Connects to a PC's audio lineout.
Connects to external stereo
speakers.
Connects to headphones or
external speakers
Remote Control
T
Description Icon Function
Menu
Arrow
Number
Recall/Last
Caption/CC
MTS
MENU
MENU
M
/
ENTER
/
S / T / W / X /
< / >
123
456
789
0
RECALL / LAS
CC
MTS
Press this button to activate the OSD
menu system and to adjust various
settings and personal preferences.
PressS / T / W and X to scroll
through the on-screen display
menus.
Favorite channels can be selected
using the
W and X buttons on the
remote control.
Use to select a channel directly.
Press 0-9 to enter the channel
number (press 1 and 0 for channel
10).
Press this button to return to the last
channel selected.
Press this button to enable the
closed captions/subtitles (Only
available in the United States of
America).
Press this button to enable the
bilingual function when the program
has stereo/SAP/MONO capabilities.
Power Turns the TV power on or off.
Adjust volume
-VOL VOL+
>VOL VOL<
VOL VOL
VOL VOL
Press volume up to increase the
audio volume. Press volume down to
decrease the audio volume.
19
Description Icon Function
T
Press this button to eliminate sound.
Mute
MUTE
Press mute again or press the
volume adjust buttons to restore
sound.
Changes channels. Press channel
Select channel
CH CH
CH CH
CH CH+
>
CH CH
up to increase the channel number.
Press channel down to decrease the
channel number. In PC or AV mode,
>
press either button to return to TV
mode.
Press this button to cycle the video
Source
SOURCE
input sources. The source is
displayed on the screen.
Auto (selected
models only)
Reset (selected
models only)
V-Chip (selected
models only)
AUTO
RESE
V-CHIP
Press this button to automatically
adjust the screen parameters in PC
mode.
Press this button to reset the TV.
This button allows you to change
v-chip settings.
Sleep (selected
models only)
Display (selected
models only)
20
SLEEP
DISPLAY
Press this button repeatedly to set
the length of time until the TV turns
off.
Press this button to show messages
on the screen, such as the channel
number and other. Press this button
again to show the real-time clock.
Press this button again to close the
display message.
Inserting the Remote Control Battery/Batteries
Lithium battery/batteries
1
Open the battery compartment cover at the
back of the remote control (A).
A
2 Slide the battery/batteries, with the positive
(+) side facing up, underneath the shorter set
of metal contacts (B).
3 Press the battery/batteries firmly into place
in the battery compartment (C)
4 Replace the battery compartment cover (D).
Note
Your remote control may have either AAA type batteries or CR2032 lithium
battery/batteries.
B
C
D
21
AAA battery/batteries
1
Open the battery compartment cover at the
back of the remote control (A).
A
2 Insert the battery/ batteries paying
attention to the polarity markings inside
the battery compartment (B).
B
3 Replace the battery compartment cover
(C).
Note
Your remote control may have either AAA type batteries or lithium
battery/batteries.
C
22
CAUTION
• If the remote control is not used for a long period, remove the batteries
and store them separately.
• Handle damaged or leaking batteries carefully, and wash hands after
such handling.
• If your remote control has two batteries, do not mix new and old
batteries because the life of the new batteries will be shortened.
Chemical fluids may leak from the old batteries.
• Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the equipment
manufacturer. Discard used batteries according to manufacturer’s
instructions.
• Refer to your local recycling or waste disposal rules and contact a local
waste disposal vendor to dispose of used batteries.
• The remote control may have a magnet in it, so do not place magnetic
sensitive items such as watches, credit cards, or flash media close to
the cover.
• Do not use force when pulling the remote control cover open; you may
damage the hinge.
23
8
Making Connections
Connecting to an Antenna or Cable TV
1
Connect one end of the VHF/UHF (Antenna) or CATV cable to ANT
Jack (VHF/UHF IN Jack) on the back of the TV.
2 Connect the other end of the VHF/UHF (Antenna) or CATV cable to
the antenna socket or CATV cable.
Antenna
ANT
ANT jack
(VHF/UHF IN jack)
Antenna/CATV
socket
Antenna/CATV
coaxial cable
Note
If you cannot receive channels after connecting to an antenna or cable TV
line, try scanning for channels. See “Auto Program” on page 50.
24
Connecting to AV Devices
Connect external devices such as a VCR, VCD or DVD player, or video
game console to the TV using the supplied 4-IN-1 A/V cable.
Connecting to a VCR/VCD/DVD Player
The illustration presented here shows how to connect the TV to a VCR,
VCD or DVD player. Actual connections may vary according to the make
and model of the device. Refer to the user’s manual included with the device
for more detailed instructions.
VCR
DVD
VCD
AV2
4-IN-1 A/V jack
BRWY
S-Video
connector
4-IN-1 A/V cable
Note
• The cables are color-coded (black, red, white, yellow). Connect each
color-coded cable to the appropriate connector on your device.
• When connecting the S-Video connector and AV connector at the same
time, the priority is given to the S-Video connector.
AV
connectors
25
Connecting to a Video Camera
The instructions presented here are a general guide to connecting the TV to
a camcorder or other type of digital camera. Actual connections may vary
according to the make and model of the device. Refer to the user’s manual
included with the camcorder or camera for more detailed instructions.
S
WB
AV2
4-IN-1 A/V jack
S-Video
connector
B
R
W
4-IN-1 A/V cable
AV connectors
Note
The cables are color-coded (black, red, white, yellow). Connect each colorcoded cable to the appropriate connector on your device.
Y
26
Connecting to a Video Game Console
The instructions presented here are a general guide to connecting the TV to
a game console using the RCA Jacks (some game devices may require a
unique adapter that is not provided). Actual connections may vary according
to the make and model of the game device. Refer to the user’s manual
included with the game console for more detailed instructions.
AV2
4-IN-1 A/V jack
BRWY
S-Video
connector
4-IN-1 A/V cable
AV
connectors
Notes
• Connect the 4-IN-1 A/V cable connectors to the corresponding
connectors on your game device adapter.
• If the 4-IN-1 A/V cable does not fit the game device, then insert RCA jack
between the 4-IN-1 A/V cable and game device.
27
Connecting External Speakers or Headphones
External speakers or headphones may be used to listen to the TV rather
than using the built-in speakers. Connect external speakers to the speaker
line out port or headphones to the headphone port as illustrated.
Headphones
Headphone
Speaker line
out port
Notes
• External speakers or headphones are not included with the TV.
• The internal TV speakers will not output sound when headphones are
plugged in.
• Use external speakers with built-in amplifiers only.
HEADPHONE/
jack
LINE OUT
Speakers
28
Connecting to a PC
You can connect the TV to a PC and use it as an external monitor. Connect
the TV’s VGA/PC-IN port to the PC’s VGA port. Connect the TV’s line in port
to the PC’s line out port to listen to the PC’s audio output on the TV’s
speakers. Refer to the following illustration.
VGA
PC-IN
PC link cable
Note
You can connect the line out port of a CD-ROM player, stereo, or other
device to the TV’s line in port to listen to the devices audio output.
LINE IN
Line out
VGA cable
VGA port
Line out
VGA port
29
Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2 Plug the power adapter connector into the DC-IN input jack on the
rear panel of the TV.
3 Insert the three-pronged plug at the other end of the power cord into
a power outlet.
Three-pronged
plug
30
DC-IN
DC-IN
DC-IN input jack
Power adapter
Power outlet
Power cord
9
f
f
Using the TV
Using the Remote Control
For best results, use the remote control within a distance of 16 feet
(5 meters) from the front of the TV. Do not exceed an angle of 30 degrees
when pointing at the TV.
Notes
• The operational distance may be shortened when the signal sensor is
directly exposed to strong light.
• Aim the transmitter on the remote control at the signal sensor and
ensure that there are no obstacles between them.
Turning the TV On and Off
/
0
Of
1
Press power on the remote control or control panel to turn
on the TV.
2 Press power
Selecting Channels
Press channel up or channel down on the control panel to select the
channel or enter the specific channel number by pressing the number
buttons on the remote control.
On
/
0
On
again; the TV is in off mode.
Of
Switching Source Signals
Press source to select the incoming source signal.
The current source setting (TV/CATV, AV, AV1,AV2 or PC ) appears on the
upper left corner of the screen.
Adjusting the Volume
Press volume up to increase the volume. Press volume down to decrease
the volume. The volume level is displayed on the screen.
31
10 Adjusting On-Screen Display (OSD)
Settings
The On-Screen Display (OSD) menu system provides a quick and simple
method to adjust your TV’s settings. This chapter describes how to change
each of the available settings.
The OSD can be used with either the remote control or the control panel.
Function Control Panel Icon Button Remote Control Icon
Menu Menu Menu MENU/ENTER, M
Channel
up
Channel
down
Enter Menu Enter MENU/ENTER, M
Note
The following sections explain how to adjust settings in the OSD menus
using the control panel.
CH ( / / + /
CH ( / / – /
S)
T)
Right arrow
Left arrow
/ X
W
/
32
OSD Setting Menu
PC
Brightness&Contrast
Press menu to enter the OSD
Brightness
Contrast
menus. The Main Menu appears.
Return
Select
Note
To exit the OSD menus, press channel up or channel down to select Exit
. Then press menu to exit the OSD menus. Also, after you finish setting
OSD parameters, follow these instructions to exit the OSD menus.
Menu OK
30
30
33
Brightness
Brightness&Contrast
Brightness
Contrast
Return
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press menu again to enter the
PC
Brightness & Contrast menu.
3 Press channel up to increase the
2
55
brightness. Press channel down to
decrease the brightness.
4 Press menu to select Return.
5 Press channel down to exit the
Brightness & Contrast menu.
Note
The new setting is confirmed
automatically when the OSD times out.
34
Contrast
Brightness&Contrast
Brightness
Contrast
Return
Adjust
Menu Next
1
PC
Press menu to enter the OSD menus.
2 Press menu again to enter the
2
55
Brightness & Contrast menu.
3 Press menu to select Contrast.
4 Press channel up to increase the
contrast. Press channel down to
decrease the contrast.
5 Press menu to select Return.
6 Press channel down to exit the
Brightness & Contrast menu.
Note
The new setting is confirmed
automatically when the OSD times out.
35
Audio Setting
Press menu to enter the OSD
menus.
1
Press channel up or channel
down to select Audio Setting.
2 Press menu to enter the Audio
Setting menu.
PC
Audio Setting
Treble
Bass
Balance
SRS ON OFF
Mute
Return
LR
ON OFF
Select
Menu OK
36
Treble
PC
Audio Setting
Treble
Bass
Balance
SRS On Off
Mute
Return
LR
On Off
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Audio Setting.
3 Press menu to enter the Audio
Setting menu.
4 Press channel up to increase the
treble. Press channel down to
decrease the treble.
5 Press menu to select Return.
6 Press channel down to exit the Audio
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
37
Bass
PC
Audio Setting
Treble
Bass
Balance
SRS On Off
Mute
Return
LR
On Off
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Audio Setting.
3 Press menu to enter the Audio
Setting menu.
4 Press menu to select Bass.
5 Press channel up to increase the
bass. Press channel down to
decrease the bass.
6 Press menu to select Return.
7 Press channel down to exit the Audio
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
38
Balance
PC
Audio Setting
Treble
Bass
Balance
SRS On Off
Mute
Return
LR
On Off
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Audio Setting.
3 Press menu to enter the Audio
Setting menu.
4 Press menu to select Balance.
5 Press channel up to change the
balance to the right speaker. Press
channel down to change the balance
to the left speaker.
6 Press menu to select Return.
7 Press channel down to exit the Audio
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
39
SRS
This option enables the 3D Surround Sound feature.
PC
Audio Setting
Treble
Bass
Balance
SRS On Off
Mute
Return
LR
On Off
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Audio Setting.
3 Press menu to enter the Audio
Setting menu.
4 Press menu to select SRS.
5 Press channel down to turn the SRS
on. Press channel up to turn the SRS
off.
6 Press menu to select Return.
7 Press channel down to exit the Audio
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
40
Mute
PC
Audio Setting
Treble
Bass
Balance
SRS On Off
Mute
Return
LR
On Off
Adjust
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Audio Setting.
3 Press menu to enter the Audio
Setting menu.
4 Press menu to select Mute.
5 Press channel down to turn the mute
on. Press channel up to turn the
mute off.
6 Press menu to select Return.
7 Press channel down to exit the Audio
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
41
Video Setting
Press menu to enter the OSD
menus.
1
Press channel up or channel
down to select Video Setting.
2 Press menu to enter the Video
Setting menu.
Hue
Saturation
Sharpness
Color Temp
Return
Select
PC
Video Setting
GR
Standard
Menu OK
42
Hue
Video Setting
Hue
Saturation
Sharpness
Color Temp Standard
Return
GR
Adjust
Menu OK
1
PC
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Video Setting.
3 Press menu to enter the Video
Setting menu.
4 Press channel down to increase the
red hue. The image becomes more
red. Press channel up to increase
the
green hue. The image becomes
more green.
5 Press menu to select Return.
6 Press channel down to exit the Video
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
43
Saturation
Video Setting
Hue
Saturation
Sharpness
Color Temp Standard
Return
GR
Adjust
Menu Next
1
PC
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Video Setting.
3 Press menu to enter the Video
Setting menu.
4 Press menu to select Saturation.
5 Press channel up to increase the
saturation. The screen image
becomes more vibrant. Press
channel down to decrease the
saturation. The screen image
becomes less vibrant.
6 Press menu to select Return.
7 Press channel down to exit the Video
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
44
Sharpness
Video Setting
Hue
Saturation
Sharpness
Color Temp Cold
Return
GR
Adjust
Menu Next
PC
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Video Setting.
3 Press menu to enter the Video
Setting menu.
4 Press menu to select Sharpness.
5 Press channel up to increase the
sharpness. Press channel down to
decrease the sharpness.
6 Press menu to select Return.
7 Press channel down to exit the Video
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
45
Color Temperature
Hue
Saturation
Sharpness
Color Temp
Return
Adjust
PC
Video Setting
GR
Cold
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Video Setting.
3 Press menu to enter the Video
Setting menu.
4 Press menu to select Color Temp.
The following choices are available.
Warm
Press channel up or channel down to
select Warm.
Standard
Press channel up or channel down to
select Standard.
Cold
Press channel up or channel down to
select Cold.
5 Press menu to select Return.
6 Press channel down to exit the Video
Setting menu.
46
Note
The new setting is confirmed
automatically when the OSD times out.
TV Setting
Press menu to enter OSD
menus.
1
Press channel up or channel
down to select TV Setting.
2 Press menu to enter the TV
Setting menu.
TV/CATV
TV Setting
MTS
Auto Program
Manual Program
Favorite Channel
Return
Select
CATV
Stereo
Yes
Menu OK
PC
No
47
TV/CATV
TV/CATV
MTS
Auto Program
Manual Program
Favorite Channel
Return
TV Setting
Adjust
TV
Stereo
Yes
Menu Next
PC
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
No
select TV Setting.
3 Press menu to enter the TV Setting
menu.
4 Select one of the following.
Receiving Broadcast TV
Press channel up or channel down to
select TV when using an antenna to
receive TV.
Receiving Cable TV
Press channel up or channel down to
select CATV STD when connected to
cable.
5 Press menu to select Return.
6 Press channel down to exit the TV
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
48
MTS
TV/CATV
MTS
Auto Program
Manual Program
Favorite Channel
Return
Adjust
PC
TV Setting
CATV
Stereo
Yes
Menu Next
No
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select TV Setting.
3 Press menu to enter the TV Setting
menu.
4 Press menu to select MTS. The
following choices are available.
STEREO
Press channel up or channel down to
select Stereo (default), the default
audio signal belonging to a particular
channel.
SAP
Press channel up or channel down to
select SAP (Secondary Audio
Program), an audio channel used
with the NTSC TV standard for
auxiliary transmission of such items
as foreign language broadcasting.
This option may not be available in
your local area.
MONO
Press channel up or channel down to
select Mono, which outputs sound
through a single channel.
5 Press menu to select Return.
6 Press channel down to exit the TV
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
49
Auto Program
TV Setting
TV/CATV
MTS
Auto Program
Manual Program
Favorite Channel
Return
Adjust
CATV
Stereo
Yes
Menu Next
1
PC
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select TV Setting.
No
3 Press menu to enter the TV Setting
menu.
4 Press menu to select Auto Program.
5 Press channel down to select Yes.
Channel indicator values range from 2
to 69 (antenna connection) or from 1 to
125 (CATV cable connection).
50
Manual Program
This function allows you to search preset channels or to erase previously
preset channels.
TV Setting
TV/CATV
MTS
Auto Program
Manual Program
Favorite Channel
Return
Adjust
CATV
Stereo
Yes
Manual Program 2
Manual Program
Add/Erase
Return
Adjust
Down Up
Add
Menu Next
Menu Next
PC
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
No
select TV Setting.
3 Press menu to enter the TV Setting
menu.
4 Press menu to select Manual
Program.
PC
Erase
5 Press channel up to enter the
Manual Program menu.
6 Press channel up or channel down to
find the channel you want to add.
When you have found the channel,
see the next section “Channel
Add/Erase” to add or erase the
channel.
51
Channel Add/Erase
After you found a channel using Manual Program, follow the following
instruction to add or erase the channel.
Manual Program 2
Manual Program
Add/Erase
Return
Adjust
Down Up
Add
Menu Next
PC
Up
Erase
Erase
1
Press menu to select Add/Erase.
2 Select one of the following option.
Add Channel
Press channel down to select Add.
The channel is added to the channel
list.
Erase Channel
Press channel up to select Erase.
The channel is erased from the
channel list.
When you return to the normal TV
screen and use channel up and
channel down to browse channels,
an erased channel (for example,
Channel 3) is skipped automatically.
Note
You can still access the erased channel
by entering the channel number using the
number keys on the remote control.
52
Favorite Channel
Use the Favorite Channel function to save up to four channels for quick
access.(Only available in the United States of America)
TV/CATV
MTS
Auto Program
Manual Program
Favorite Channel
Return
M1 2
M2 2
M3 2
M4 2
Return
TV Setting
Adjust
Favorite Channel
Adjust
CATV
Stereo
Yes
Menu Next
Menu Next
PC
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
No
select TV Setting.
3 Press menu to enter the TV Setting
menu.
4 Press menu to select Favorite
Channel.
5 Press channel up to enter the
Favorite Channel menu.
PC
6 Press menu to select (M1, M2, M3,
or M4) from the list.
7 Press channel up or channel down to
select a channel number.
8 Press menu to select Return.
9 Press channel down to return to the
previous menu.
Note
Favorite channels can be selected using
theW and X buttons on the remote
control.
53
PC Setting
1
Connect TV to a PC.
2 Press source to select PC.
3 Press menu to enter the OSD
menus.
4 Press channel up or channel
down to select PC.
5 Press menu to enter the PC
menu.
H.Position
V.Position
Phase
Clock
More Option
Return
Select
PC
PC Setting
50
16
0
1688
Menu OK
54
Horizontal Position
H.Position
V.Position
Phase
Clock
More Option
Return
Adjust
PC
PC Setting
Menu Next
50
16
0
1688
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press channel up to move the display
to the right. Press channel down to
move the display to the left.
5 Press menu to select Return.
6 Press channel down to exit the PC
Setting
Note
The new setting is confirmed
automatically when the OSD times out.
menu.
55
Vertical Position
H.Position
V.Position
Phase
Clock
More Option
Return
Adjust
PC
PC Setting
Menu Next
50
16
0
1688
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press menu to select V.Position.
5 Press channel up to move the display
up. Press channel down to move the
display down.
6 Press menu to select Return.
7 Press channel down to exit the PC
Setting
Note
The new setting is confirmed
automatically when the OSD times out.
menu.
56
Phase
H.Position
V.Position
Phase
Clock
More Option
Return
Adjust
PC
PC Setting
Menu Next
50
16
0
1688
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press menu to select Phase.
5 Press channel up to increase the
phase. Press channel down to
decrease the phase.
6 Press menu to select Return.
7 Press channel down to exit the PC
Setting
Note
The new setting is confirmed
automatically when the OSD times out.
menu.
57
Clock
H.Position
V.Position
Phase
Clock
More Option
Return
Adjust
PC
PC Setting
Menu Next
50
16
0
1688
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press menu to select Clock.
5 Press channel up to increase the
clock. Press channel down to
decrease the clock.
6 Press menu to select Return.
7 Press channel down to exit the PC
Setting
Note
The new setting is confirmed
automatically when the OSD times out.
menu.
58
DOS Mode
PC Setting
H.Position
V.Position
Phase
Clock
More option
Return
Adjust
DOS Mode Tex t
Color Temp
User R :
User G :
User B :
Return
More Option
User
Adjust Menu Next
Menu Next
1
PC
Press menu to enter the OSD menus.
2 Press channel up or channel down to
50
16
0
1688
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press menu to select the More
PC
Option.
5 Press channel up to enter more
option.
30
30
30
6 Press channel up or channel down to
select Text or Graphics mode.
59
Color Temperature
PC Setting
H.Position
V.Position
Phase
Clock
More option
Return
Adjust
DOS Mode Text
Return
More Option
StandardColor Temp
Adjust
Menu Next
Menu Next
PC
50
16
0
1688
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select PC Setting.
3 Press menu to enter the PC Setting
menu.
4 Press menu to select the More
Option.
PC
5 Press channel up to enter More
Option.
6 Press menu to select Color Temp.
Warm
Press channel up or channel down to
select Warm.
Standard
Press channel up or channel down to
select Standard.
Cold
Press channel up or channel down to
select Cold.
60
DOS Mode Tex t
Color Temp
User R :
User G :
User B :
Return
More Option
User
Adjust Menu Next
PC
User
The User option enables users to
make their own color settings.
30
30
30
Press channel up or channel down to
select User. The user menu appears.
– Press menu to select User R, User
G, or User B.
– Press channel up or channel down
to increase or decrease the
selected color temperature.
7 Press menu to select Return.
8 Press channel down to exit the More
Option
Note
The new setting is confirmed
automatically when the OSD times out.
menu.
61
Miscellaneous Setting
Press menu to enter the OSD
menus.
1
Press channel up or channel
down to select Miscellaneous.
2
Press menu to enter the
Miscellaneous menu.
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Select
PC
Miscellaneous
English
OFF
ON OFF
Menu OK
62
Language
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
PC
Miscellaneous
English
Off
On Off
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press channel up or channel down
to select a language.
5 Press menu to select Return.
6 Press channel down to exit the
Miscellaneous menu.
63
Sleeper
The Sleeper turns the TV off automatically after a set period of time.
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press menu to select Sleeper.
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
PC
Miscellaneous
English
Off
On
Menu Next
Off
5 Press channel up or channel down to
select a power off time:
–OFF
– 30 minutes
– 60 minutes
– 90 minutes
– 120 minutes
6 Press menu to select Return.
7 Press channel down to exit the
Miscellaneous menu.
64
OSD Display
When set to Off, the OSD display (source data on top left corner of the TV
screen) turns off after approximately 5 seconds. When set to On, the OSD
does not turn off automatically.
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
PC
Miscellaneous
English
Off
On Off
Menu Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press menu to select OSD Display.
5 Press channel down to select On.
Press channel up to select Off.
6 Press menu to select Return.
7 Press channel down to exit the
Miscellaneous menu.
65
Time Setting
This setting allows you to set the TV clock.
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
Hour :
Minute :
Return
PC
Miscellaneous
English
Off
On Off
Menu Next
PC
Time Setting
-12-AM
-12-
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press menu to select Time Setting.
5 Press channel up to enter the Time
Setting menu.
6 Press menu to select the Hour or
Minute.
7 Press channel up or channel down to
decrease or increase the time.
8 Press menu to select Return.
9 Press channel down to exit the Time
Setting menu.
Note
The new setting is confirmed
automatically when the OSD times out.
66
More Option
This setting allows you to set the OSD background, closed caption function,
parental control features, and reset the TV.
Miscellaneous
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
Menu Next
More Option
OSD Background
C . Caption
Parental
Reset Yes
Return
Adjust
Menu
PC
English
Off
On Off
PC
Off
No
Next
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press menu to select More Option
setting.
5 Press channel up to enter the More
Option menu.
6 Press menu to select OSD
Background, C.Caption, Parental,
Reset, or Return.
67
OSD Background
This setting allows you to make the OSD background transparent or
opaque.
OSD Background
C . Caption
Parental
Reset Yes
Return
More Option
Adjust
Menu
Off
Next
PC
1
Enter the More Option menu.
2 Press channel down to make the
background transparent. Press
channel up to make the background
No
opaque.
3 Press menu to select Return.
4 Press channel down to exit the More
Option menu.
Note
The new setting is confirmed
automatically when the OSD times out.
68
C. Caption (Closed Caption)
This setting allows you to select closed caption subtitles or text information
broadcast with the program
1
.
OSD Background
C . Caption
Parental
Reset Yes
Return
More Option
Adjust
Menu Next
Off
PC
1
Enter the More Option menu.
2 Press menu to select C.Caption.
3 Press channel up to select CC1,
CC2, CC3, CC4, Text1, Text2,
No
Text3, Te x t 4 , or Off .
4 Press menu to select Return.
5 Press channel down to exit the More
Option menu.
1. Closed Caption is only available in the United States of America.
69
Parental
The Parental Control Function (V-CHIP) is used to block program viewing
based on the ratings sent by the broadcast stations
1
. The United States has
two rating systems for viewing contents, TV Parental Guidelines, and movie
ratings. The TV Parental Guidelines work in conjunction with the V-CHIP to
help parents screen out inappropriate television programs from their
children. Movie ratings are used for original movies rated by the Motion
Picture Association of America (MPAA) as watched on cable TV and not
edited for television. The V-CHIP can also be set to block MPAA-rated
movies.
OSD Background
C . Caption
Parental
Reset Yes
Return
Adjust
Off
Menu Next
Enter Password
More Option
Submit
Return
Adjust
Menu Next
Parental
V - Chip
MPAA Rating
TV Rating
Change Password
Return
Adjust
Off
Menu Next
PC
No
PC
PC
1
Enter the More Option menu.
2 Press menu to select Parental.
3 Enter the password number using the
remote control keypad.
4 Press X (on the remote control) to
submit the password.
The Parental submenu appears.
Note
To use parental control functions, a
password must be entered. The default
password is 0000. The password may only
be entered using the remote control. If the
wrong password is entered, “Wrong
Password” is displayed. See “Change
Password” on page 75.
1. Parental functions are only available in the United States of America and
is contingent upon the availability of the TV network programming.
70
V-Chip
This setting allows you to turn the V-chip functions on or off.
V - Chip
MPAA Rating
TV Rating
Change Password
Return
Parental
Adjust
Off
Menu Next
PC
1
Enter the More Option menu.
2 Press menu to select Parental.
3 Enter the password number using
the remote control keypad.
4 Press menu to select Submit.
5 Press X (on the remote control) to
submit the password.
The Parental submenu appears.
6 Press the menu button to select
V-Chip.
7 Press channel up to toggle the
V-chip function on or off.
8 Press menu to select Return.
9 Press channel down to return to the
More Option menu.
71
MPAA Rating
The MPAA rating menu allows you to block or unblock broadcast programs
based on their movie rating.
G - Allow -
PG - Allow -
PG13 - Allow -
R - Allow -
NC17 - Allow -
X - Allow -
Return
MPAA Rating
Adjust
Menu Next
PC
1
Enter the More Option menu.
2 Press menu to select Parental.
3 Enter the password number using
the remote control keypad
4 Press menu to select Submit.
5 Press X (on the remote control) to
submit the password.
The Parental submenu appears.
6 Press menu to select MPAA Rating.
7 Press channel up to display the
MPAA submenu.
8 Press menu to select a rating to
change.
9 Press channel up to allow or block
the selected rating.
10Press menu to select Return.
11 Press channel down to return to the
Parental menu.
72
TV Rating
The TV Rating menu allows you to block or unblock broadcast programs
based on their TV rating.
Adjust
TV Rating
Menu Next
TV - Y - Allow -
TV - Y7 - Allow -
TV - G - Allow -
TV - PG - Allow -
TV - 14 - Allow -
TV - MA - Allow -
Return
PC
1
Enter the More Option menu.
2 Press menu to select Parental.
3 Enter the password number using
the remote control keypad.
4 Press menu to select Submit.
5 Press channel up to submit the
password.
The Parental submenu appears.
6 Press menu to select TV Rating.
7 Press channel up to display the TV
Rating submenu.
8 Press menu to select a rating to
change.
9 Press channel up to allow or block
the selected rating. The Blocked
Content menu will display.
10Press menu to select Return.
11 Press channel down to return to the
Parental menu.
73
Ratings
MPAA Ratings
G – Suitable for a general audience, all children
PG – Parental guidance suggested
PG-13 – Parental guidance for children under 13 suggested
R – Restricted viewing. Parental guidance suggested for children
under 17
NC-17 – No-one under 17 allowed to view
X – Adults only
TV Ratings
Age based
TV-Y – Suitable for a general audience, all children
TV-Y7 – Directed at children aged 7 and older
TV-G – General audience
TV-PG – Parental guidance suggested
TV-14 – Parents strongly cautioned
TV-MA – Mature audience only
Content based
FV – Fantasy violence
D – Suggestive dialogue
L – Strong language
S – Sexual situations
V – Violence
Note
More information about the ratings system can be found by visiting these
web sites:
http://www.mpaa.org
http://www.tvguidelines.org
74
Change Password
The Change Password function enables you to change the password
needed to access Parental Control features.
Change Password
New
Confirm
Submit
Return
Adjust
Menu Next
PC
1
Enter the More Option menu.
2 Press menu to select Parental.
3 Enter the password number using
the remote control keypad.
4 Press menu to select Submit.
5 Press channel up to submit
password.
6 The Parental submenu appears.
7 Press menu to select Change
Password.
8 Press channel up to display the
Change Password screen.
9 Enter the new password using the
keypad on the remote control.
10Enter the new password again to
confirm.
11 Press channel up to submit the new
password.
12Press menu to select Return.
13Press channel down to return to the
Parental menu.
Notes
• If the two passwords entered do not
match, the message “Wrong
Password” is displayed.
• Your password is required to access
any parental control feature in the
future. If you forget your password,
refer to “Troubleshooting” on page
79.
75
Reset
The Reset function returns all of your TV’s user settings to their factory
defaults.
Warning:
The reset function will erase all of your custom and favorite channel
settings, and will reset all display settings (such as contrast,
brightness, etc.) to the factory default values. The reset function
cannot be reversed once it begins.
Miscellaneous
Language
Sleeper
OSD Display
Time Setting
More Option
Return
Adjust
OSD Background
C . Caption
Parental
Reset Yes
Return
Adjust
Menu Next
More Option
Menu Next
PC
English
Off
On Off
PC
Off
No
1
Press menu to enter the OSD menus.
2 Press channel up or channel down to
select Miscellaneous.
3 Press menu to enter the
Miscellaneous menu.
4 Press menu to select More Option.
5 Press channel up to enter the More
Option menu.
6 Press menu to select Reset.
7 Press channel down to reset the
OSD settings.
By default, No is already selected
(highlighted in yellow). The TV
immediately resets when Yes is
selected and you see the message on
the screen.
76
11 Taking Care of Your TV & Remote
Control
Turn the power off before you begin cleaning the
TV.
For best results, use a clean lens cloth to
remove dust and fingerprints from the screen.
Do not wipe the shell of the TV with alcohol,
GAS
OIL
methanol, gasoline or oil products to avoid
damaging the finish. Wipe the shell with a dry
soft cloth and use neutral cleaning fluids.
If your model has leather components, wipe the
leather parts with a dry cloth and keep the area
dry. Place the TV far from sources of steam to
avoid making the leather wet.
Be careful to disconnect the power plug
correctly. Hold the plug. Do not attempt to
disconnect the plug by pulling on the power cord.
Arrange and store the power cord neatly as
shown to the left to avoid knotting or bending
which may cause fire due to damage or electric
leakage.
Note
Protect the remote control from shock or vibration to avoid damage.
Do not place the remote control in hot or humid locations.
77
12
Troubleshooting
Situation Solution
No picture and sound.
No picture, or poor picture, sound is OK.
Picture is not in color.
Picture is OK, no sound.
One of the speakers has no sound.
Cannot receive some TV channels using
cable TV.
Want to reset TV settings.
• Connect the power cord properly.
• Check if the power LED is on or not.
• Press power on the control panel or remote
control.
• Press source to cycle through connected
video sources.
• Press channel up or channel down to
switch to other TV stations.
• Check the TV/CATV OSD settings. See
“TV/CATV” on page 48.
• Make sure all cables are connected
properly.
• Check the antenna and cable connections.
• Adjust the brightness in the OSD menus.
See “Brightness” on page 34.
• Adjust the saturation in the OSD menus.
See “Saturation” on page 44.
• Make sure all cables are connected
properly.
• Make sure the source device is functioning
properly.
• Make sure the audio cable is connected
securely.
• Turn the mute off.
• Press volume up on the control panel or
remote control.
• Make sure the MTS option is set to Stereo,
SAP, or Mono. See “MTS” on page 49.
• Adjust the balance in the OSD menus. See
“Balance” on page 39.
• Make sure the audio cable is connected
securely.
• Try the Auto Program function in the OSD
“TV Setting” menu. See “Auto Program” on
page 50.
• Use the Reset function in the OSD menu.
See “Reset” on page 76.
78
Situation Solution
Cannot operate menus.
Forgot parental control password. • Use the master password 0928
Screen image turns over.
Snow appears on the screen.
Blurred or overlapped images.
Remote control doesn’t work.
• If OSD items are colored in light blue, the
system is in a state such that those settings
are not available.
• Make sure the video signal cable is
connected properly.
• Adjust the location of the antenna, placing it
far from roads or sources of interference.
• Check the antenna and the video signal line
connections.
• Readjust the sharpness setting.
• Choose programs with high quality signals.
• Adjust the direction of the antenna or
change the video signal cable.
• Make sure the battery is inserted correctly.
• Replace the battery with a new one.
• Make sure the TV power cord is plugged in.
• Make sure the path between the remote
control and the sensor is clear.
• Try operating the remote control at a closer
distance to the TV. Refer to “Using the
Remote Control” on page 31.
79
13
Warranty and Service
For complete warranty service information, please refer to the “Warranty
and Service Manual” enclosed with your TV.
80
14
Specifications
15-inch LCD TV
LCD Panel Size 15-inch TFT
Aspect Ratio 4:3
Display Resolution 1024 (horizontal) x 768 (vertical)
TV System NTSC
Video System
Audio System
Built-in Speakers 2W + 2W / 3W + 3W
Power Supply 100-240V, 50/60 Hz, 12V DC
Power Consumption 60 W Maximum
Optional Accessories External Speakers
PC Mode Support Timing
VGA input (15 pin D-SUB / PC link cable), S-Video
Input and Composite Video Input (through the 4-IN-1
A/V cable)
Line in
10-pin mini-DIN (Audio Input with 4-IN-1 A/V cable)
3.5 mm ø headphone port x 1 (Audio Output)
Pixel Format Hor. Freq. (kH z) Hor. Polari ty Ver. Freq. (Hz) V ertical Polari ty Standard
1 640*400 31.47 - 70 + DO S_Graphi c
2 720*400 31.47 - 70 + DO S_Text
3 640*480 31.47 - 60 - V ESA
4 640*480 37.861 - 72 - V ESA
5 640*480 37.5 - 75 - V ESA
6 800*600 35.156 + 56 + V ESA
7 800*600 37.879 + 60 + V ESA
8 800*600 48.077 + 72 + V ESA
9 800*600 46.875 + 75 + V ESA
10 1024*768 48.363 - 60 - V ESA
11 1024*768 56.476 - 70 - V ESA
12 1024*768 60.023 + 75 + V ESA
13 832*624 49.7 - 75 - MAC
14 1024*768 60.2 - 75 - MAC
15 640*480 35 - 67 - M A C
81
15
Glossary
Aspect Ratio: The ratio of width to height of a film, image or display
screen.
Broadcast TV: Broadcasting video signals using high-frequency
electromagnetic waves to distribute television channels to viewers
(standard TV broadcast).
CATV: Community Antenna Television, the original name for cable
TV. A television distribution system that uses coaxial cable instead of
the traditional radio broadcasting (over-the-air) method to deliver
television, FM radio, and other services to consumers.
Color Temperature: Adjusting the color temperature enables you to
set the intensity of white light. Color temperature is measured in
Kelvin (K). Higher color temperatures result in a blue tint. Lower
temperatures result in a red tint.
Hue: Colors in a color system are measured by hue, saturation and
luminance. Hue indicates the predominant color.
LCD (Liquid Crystal Display): A display technology that uses rod-
shaped molecules (liquid crystals) that flow like liquid and bend light.
MTS: Multi-channel Television Sound. Enables reception of audio
other than the primary (stereo) audio signal. SAP (Second Audio
Program) enables reception of a separate channel that may be a
different language or completely different information such as the
news.
OSD (On-Screen Display): A control panel on the television screen that
allows you to select viewing options.
Saturation: Chromatic purity indicating the amount of white contained
in a color. Fully saturated colors are pure colors; less saturated
colors appear as pastel shades.
Stereo: is the default audio signal belonging to a particular channel.
S-Video: Separate video, a video cabling standard used to transmit
video by keeping brightness (Y) and color information (C) on
82
separate channels. Most often used with camcorders, VCRs, and
quality receivers and amplifiers to provide sharper pictures.
83
is a trademark of
SRS Labs, Inc.
SRS technology is incorporated under license from SRS
Labs, Inc.
Loading...
