Hangshi Technology S29 User Manual

Product list

Weraring Method

Headphone introduction

Pairing

S29

User Manual

Right

Headphone

Left

LED indicator

1. Identify the left and right earbuds and ear-fins.

earphones.

3. Insert the assembled earphones into to your ears like shown in the lower left corner images.

4. Adjust the positioning to get a snug

PLEASE NOTE: Using appropriate size

maximum external noise isolation and a

the eartips and ear-fins one size at a time to find the best fit for each side.

Redial last calling

Short

Double

Short

Double

Key 3 sec.

Key

KeyShort

Key

Indicator flashes blue, then flashes red

Indicator keeps red for 1 sec, then goes off

2 times.

turns on.

Pairing with one smartphone

· Long press Power button on the earphone for 3 seconds , do not lose your finger

· You will hear “Power ON” voice prompt from the earphone, keep pressing Power button until you hear “Pairing” voice prompt.

·Select S29 from the dvice list, click S29 and wait for a moment;

·You will hear “connected” from the earphone after successful connecting.

Headphone charging

1. Low battery status: Red light flashes every 5 seconds, you will hear “Battery low” voice prompt from the earphone evry 3 minutes;

2. Charging status: Red light keeps on.

3. Fully charge status: Blue light keeps on.

Specification Cleaning and maintenance Caution

Model

Audio decode

The noise reduction

Bluetooth version

Main control chipset

Support agreement

Response frequency

System compatibility

Bluetooth distance

Working time

Charging time

Standby time

Battery capacity

Speaker unit

Waterproof level IPX4

S29

APT-X

CVC 6.0

Bluetooth 4.1

CSR 8645

HFP/HSP/A2DP/AVRCP

20Hz-20KHz

iOS/Android/Windows

≥10M

14H

1.5-2H

≥360H

3.7V , 100mAhx2

φ8.2MM

1. Do not disassemble or modify the headphone in any reason.Otherwise headphone can be malfunctioned orburnt.In this case the headphone is out of warranty coverage.

2. Keep it away from any corrosive liquid.Otherwise it could cause serious damage to headphone.Any damage caused by touching corrosive liquid is not in warranty of manufacturer.

3. Do not use it in thunderstorm weather.Thunderstormcan cause headphone doesn't work properly and increase the risk of electric shock.

4. When pulling out the plug,please be sure to hold Micro USB port cable of headphone.

5. Do not overly oppress headphone cable,it may cause interruption or

destroy to circuit.

6. For the cleanness and hygiene of headphone,please often disassemble

silicone earphone tips and use mild detergent to clean.Keey headphone dry and clean when not in use.

Please read safety instructions carefully before using.

1.Please do not use corrosive liquid to clean headphone.

2.Please keep headphone away from high temperature flame or fire.

3.Please avoid headphone falling from a height.

4.Please do not let headphone get touch with corrosive liquid.

5.Please do not charge headphone long-time over charging time.

6.Please do not disassemble headphone unauthorizedly.

Warm reminder

To avoid damage to your hearing, please ensure that your music volume is small when wearing headphone. After wearing well,Please adjust to an appropriate volume.In case of hearing damage,please do not long-time use loud volume to listen to music.Please be responsible for your hearing.

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
