ASSEMBLY INSTRUCTIONS
Abbot Chandelier (Item#: FB150-1160)
Important Safety Instructions:
• We recommend you contact a professional electrician to install any hardwired lighting. Incorrect
installation can lead to fires.
• These instructions are provided for your safety. It is very important that they are read carefully and completely
before assembling fixture.
• This fixture has been rated for up to (1) 60-watt maximum TYPE B bulbs (not included) or (1) 9-watt compact
fluorescent light bulbs (not included). To avoid the risk of fire, do not exceed the recommended wattage.
Pre-assembly:
Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or
hardware.
Remove all parts and hardware from box along with any plastic protective packaging.
Parts Enclosed: Hardware Included:
Item Description QTY
A Mounting plate 1
B Canopy 1
C Lock ring 2
D Ring 1
E Lamp Shade 1
To install you will need: Screwdriver/Electrical tape
item Description QTY
a Plastic wire connectors 3
b Mounting sc rews 2
To Adjust the Suspension Length of t he Fix t ure:
The adjustment or shortening of the lighting fixture’s suspension length is only needed if the factory set
length is not appropriate for your installation. We recommend that you adjust the lighting fixtur e to the
proper desired length before cutting the electrical cord.
Determine the lighting fixture suspension length from the ceiling for the product installation, allowing the
extra cord length for the outlet junction box wire connections. If needed, cut off the extra power cord
length on the 3 wire cords so that they all at least 6 inches (152.4mm) long within the outlet junction
box.(J-box)
Assembly Instructi on:
Step1.
Step2.
Step3.
Step
Step
Attach mounting plate (A) to Canopy (B).
Screw Lock Ring (C) onto Canopy (B).
Attach Lock Ring (C) to chain. Attach chain to Ring (D)
4. Screw Ring (D) into Lamp Shade (E).
5. Assembly is completed.
Care instructions:
• Wipe with soft dry cloth only
• Always avoid the use of harsh chemicals or abrasive as they may damage to the finish.
Thank you for your purchase
