Page 1
SPECIFICATION DRAWING
Collection:
24.3
TEXTURED GLASS
24.3
.8
Product #:
CHB00XX-23
GLASS TEXTURE
RIMELIGHT
STRATA
LATTICE
GRANITE
IVORY WISP
PART NUMBER
CHB0011-23
CHB0015-23
CHB0016-23
CHB0017-23
CHB0034-23
OAH ADJUSTABLE
IN 3" INCREMENTS
FROM 12.4" TO 66.4"
TEXTURED GLASS
5.8
CHB00XX-23-XX-XX-XXX-E2
CHB00XX-23-XX-XX-XXX-G2
Product #
Bulbs Not Included
Mounting Packet:
Approximate lbs.:
Finish:
Top Diffuser:
Bottom Diffuser:
© Copyright 2016. All rights in design, detail or invention of this drawing are reserved as the property of
SEE WEB SITE FOR OPTIONS
OPEN
All fixtures created by Hammerton are handcrafted by artisans. Dimensions may vary up to 7/8".
Hammerton. Any imitation or adaptation without written consent is strictly prohibited.
Hammerton Inc. 217 Wright Brothers Dr. Salt Lake City, UT 84116 (801)973-8095
Electrical Type
Incandescent
Flourescent
Visit
hammertonstudio.com
Y
20
FROSTED ACRYLIC
Bulb Type
A19
CFL/LED RETRO
Electrical Type:
Bulb Qty:
Wattage:
Socket Type:
UL Location:
Wattage
75
13
for product options and specifications.
SEE TABLE
4
Bulb Type:
SEE TABLE
SEE TABLE
DRY
Socket Type
Medium E26
GU-24
SEE TABLE
Voltage:
Mounting Detail
120
3/30/2016
6.0
2.75
MOUNTS DIRECTLY TO J-BOX
B
