SPECIFICATION DRAWING
Collection:
GEM
OAH ADJUSTABLE
VIA CORD SUSPENSION
FROM 25" TO 72"
.8
Product #:
BRAIDED FABRIC
CORD TO
MATCH FINISH
BLOWN
GLASS
GEMS
CHB0039-0F
18.0
**NOTE**
DRIVER TO BE INSTALLED IN J-BOX.
MINIMUM SIZE OF J-BOX REQUIRED IS
4" L x 4" W x 1.5" H
Visit
hammertonstudio.com
Mounting Packet:
UL Location:
Finish:
Top Diffuser:
Bottom Diffuser:
All fixtures created by Hammerton are handcrafted by artisans. Dimensions may vary up to 7/8".
© Copyright 2017. All rights in design, detail or invention of this drawing are reserved as the property of
Hammerton. Any imitation or adaptation without written consent is strictly prohibited.
Hammerton Inc. 217 Wright Brothers Dr. Salt Lake City, UT 84116 (801)973-8095
DRY
SEE WEB SITE FOR OPTIONS
CLOSED METAL
Weight(lbs.):
Y
CLOSED GLASS
for product options and specifications.
20
Electrical Type:
Elec. Qty:
Source Lumens:
Dimmable:
CRI:
LED
Wattage:
6
Ambient:
Forward/Reverse Phase To 1%
93+
Power Factor:
CCT:
16
Voltage:
1075
2700 K
>0.9
3 MEDIUM GEMS
3 LARGE GEMS
Mounting Detail
120
GEM COUNT
6.6
6.2
7.8
7.6
4/5/2017
6.0
2.75
MOUNTS DIRECTLY TO J-BOX
A
