GHOST-CHARGER
12/24V USB Car Charger
USER MANUAL
XPW1224U_FC
www.hamletcom.com
Dear Customer,
thanks for choosing an Hamlet product. Please carefully
follow the instructions for its use and maintenance and,
once this item has run its life span, we kindly ask You to
dispose of it in an environmentally friendly way, by
putting it in the separate bins for electrical/electronic
waste, or to bring it back to your retailer who will collect it for free.
We inform You this product is manufactured with materials and
components in compliance with RoHS Directive 2002/95/CE; with
WEEE Directive 2002/96/CE, 2003/108/CE Italian Legislative
Decree 2005/151 and EMC Directive 2004/108/EC for the following
standards: EN 55022: 2006+A1: 2007, EN 55024: 1998+A1:
2002+A2: 2003.
The complete CE declaration of conformity of the product can be
obtained by contacting Hamlet at info@hamletcom.com.
The information on the importer for your country can be found in the
“About Us” section of the Hamlet website at www.hamletcom.com.
Trademarks and changes
All trademarks and company names mentioned in this manual are
used for description purpose only and remain property of their
respective owners.
The material in this document is for information only and subject to
change without notice.
Description and use
Exagerate Ghost-Charger with USB Power Port plugs into any
cigarette lighter to power mobile phones, PDA, tablets, MP3 players
and other compatible USB-powered devices. Please refer to the
manual of your product for correct recharge. Connect to the USB
port of the product the peripheral to charge.
Technical specifications
• Input Voltage: 12~24V DC
• Input Current: 0.55A (12V DC), 0.30A (24V DC)
• Operating temperature: -40 ~ +65 °C, humidity: 10%~85%
• Storage temperature: -40 ~ +85 °C, humidity: 10%~85%
• Output Voltage: 5V ± 0.1V DC
• Output Current: 2100mA
• Output Voltage Accuracy: ± 5%
• Output Normal Rated Power: 6W
• Dimension: 45×32 mm
• Weight: 15 g
