MV9700
Portable DVD with TV/USB/SD/MMC
INSTRUCTION MANUAL
Components or manufacturing process may be subject
to change within the specification for improving purpose.
Thank you for buying this product.
1 Head unit
1) ON/OFF: Turns on/off DVDplayer.
2) MODE: Press to switch between the following mode: TV IN--FM--AV IN--DVD.
3) VOLUME: Increase or decrease the volume.
4) PLAY / PAUSE: Press to switch sequentially between playback and pause.
5) PREVIOUS : Press to return to the previous tracker (chapter).
NEXT : Press to go to the next tracker (chapter).
6) LCD Display
7) Power LED
8) GAME 1: Game 1 jack.
9) AV IN: Audio/video input jack.
10) AV OUT: Audio/video output jack.
11) USB: USB jack.
12) SD/MMC: SD/MMC jack.
13) PHONE: Headphone jack.
14) GAME 2: Game 2 jack.
15) IR
16) ANT: Ant jack.
17) OPEN: Opens/closes the disc cover.
18) DC IN: Power supply socket, DC 12 V.
2.Remote control
1) POWER : Power on or power off.
2) LCD ON/OFF : Turns on/off LCD monitor.
3) PROG
4) MUTE : Switch between mute on or mute off.
5) 0-10 buttons : Press to directly select the desired track, preset tuning or disc.
6) ZOOM : 1/4, 1/3, 1/2, 2, 3, 4
7) Direction & Enter : Navigates menus.
8) AUDIO : Press to change the audio language during DVD playback.
9) VOLUME : Press to increase or decrease the volume.
10) PREVIOUS : Press to return to the previous tracker (chapter).
NEXT : Press to go to the next tracker (chapter).
11) PLAY / PAUSE : Press to switch sequentially between playback and pause.
12) REVERSE : Press to perform fast reverse..
FORWARD : Press to perform fast forward.
13) STOP : Press to stop playback.
15)SETUR
16) RETURN : Press to display the PBC menu during PBC playback..
17) PBC : During Playing SVCD,VCD 2.0 with PBC function .you can enjoy a simple PBC
interactive function.
18) SLOW : Each time you press, it changes the speed in four steps in the following
order: 1/2--1/4--1/8--1/16.
19) MENU : Enter the menu display
20) OSD : Show the title and chapter currently playing.
Show the elapsed playing time of the current chapter.
21) SUBTITLE : Press to change the subtitle language during DVD playback.
Press to copy the music from CD to USB flash disk.
22) ANGLE : Select DVD camera angle.
23) TITLE : Show the title currently playing.
24) REPEAT :
There are three repeat play ranges for the DVD playback: all, chapter and title .
For TV, press to return to the previous display.
25) A-B button
26) MODE : Press to switch between the following mode: TV IN--FM--AV IN--DVD.
27) USB/GAME : Press to switch between DVD, USB and SD card.
3 Source
DVD USB1
Media
SD
4.1 General Setup Page
Press SETUP button to General Setup Page when dvd is playing.
TV Display
For TV display mode, you can choose Normal / Ps, Normal / Lb or Wide mode.
Angle Mark
Select on or off.
General Setup Page
Go to general setup page
TV Display
Angle Mark
Osd Lang
Capti ons
Screen Saver
Last Memory
Ps
Off
Eng
On
On
On
OSD menu languages
For OSD menu languages, you can choose English, Chinese, French, German, Spanish,
Italian, Portuguese or Russian.
Captions
Select on or off.
Screen Saver
Select on or off.
Last Memory
Select the last memory state on or off.
4.2 Audio Setup Page
Speaker Setup Page
Set downmix mode
Downmix Str Lt / Rt
Stereo
V Surr
Speaker Setup
Downmix
For downmix, you can choose Lt / Rt, Stereo or V Surr mode.
Equal izer Page
Set equal izer type
Eq Type None None
Rock
Pop
Li ve
Dance
Techno
Classic
Soft
Equalizer
Eq Type
For equalizer type, you can choose rock, pop, live, dance, techno, classic or soft mode.
4.3 Dolby Digital Setup
Dolby Digital Setup
Dual mono (1+1) setup
Dual Mono
Dynami c
Stereo
L-Mono
R-Mono
Mix-Mono
Dual Mono
For dual mono, you can choose Stereo, L-Mono, R-Mono or Mix-Mono mode.
Dolby Digital Setup
Set drc to full
Dual Mono
Dynamic
FULL
3 / 4
1 / 2
1 / 4
OFF
Dynamic
There are eight levels of dynamic for choose.
FULL--7 / 8--3 / 4--1 / 2-- 3 / 8--1 / 4 -- 1 / 8 -- OFF
4.5 Panel Quality Setup
Panel Qual i ty Setup
Sharpness
Sharpness
Brightness
Contrast
Hue
Saturati on
Mid
00
00
00
00
Hi gh
Medium
Low
Sharpness : You can choose high, medium or low mode.
Brightness : Adjust screen brightness from -16 to +16.
Contrast : Adjust screen contrast from-16 to +16
Hue : Adjust screen hue from-9 to +9
Saturation : Adjust screen saturation from-9 to +9
4.5 ATV Setup
Press MODE button to switch the TV IN and then press SETUP button to ATV setup page.
ATV Setup
Go to ATV setup page
Auto Search
Manu Search
Fine Tune
ATV Audio Mode
Start
Start
Start
PAL_I
Auto Search
250.25 6VH F
Manu Search
Press ENTER key to save.
Press STOP key to abandon.
Press LEFT key to down scan.
45.25
Press EN TER KEY To Save
Press STOP KEY To Abandon
Press LEFT KEY To D ow n Scan
0VHF
Fine Tune
001 PAL I
ATV Audio Mode
There are night mode of audio for choose.
Please to choose the local audio system you need.
4.6. Preference Page
Press SETUP button to Preference Page when disc cover is open.
Preference Page
Go to preference page
Tv Type
Audio
Subti tl e
Disc Menu
Parental
Password
Defaul t
PAL
Eng
Eng
Eng
TV Type : Select TV standard.
PAL,AUTO,NTSC.
Audio : Select audio language.
Subtitle : Select subtitle language.
Disc Menu : Select menu language.
Parental : Select parental control.
1 Kid Saf ，2 G ，3 Pg ，4 Pg_13 ，5 Pgr ，6 R ，7 Nc17 ，8 Adult .
Password
Password Mode : Select on or off.
Input the password and press OK button if you want to change it.
The default password is 0000.
Password
OK
Password
Input the old password and new password, then press OK button if you want to change the
password.
New Password
Old P as swor d
Confir m
OK
Default
Reset the system and load the factory setting.
5 FM Setup
Press MODE button to FM .
Press , button to select a band.
Press , button to adjust value.
Press GO TO button to auto research.
005 102.85M H Z
6 Game
1) Press USB/GAME button on remote controller to switch game mode.
2) Insert the game controller into the plugs.
7 CD RIP
Press SUBTITLE button on remote controller to switch CD RIP mode.
CD RIP
OPTIONS TRACK
SUMMARY
Speed Normal
Bit rate 128kbps
Create ID3 Yes
Device USB1
tra c k 01 03: 40
tra c k 02 04: 19
tra c k 03 03: 44
tra c k 04 05: 13
tra c k 05 03: 59
tra c k 06 03: 51
tra c k 07 04: 20
Selec t ed Track 1
Selected Tim e 03:40
Start Exit Select All Select None
8 Product information
Power supply
Power consumption
Operating temperature range
Laser w avelength
Video output
Format
Output level
Load impedance
Audio line out
Audio out (analog audio)
Load impedance
Audio distortion + noise
F reque nc y respons e
Signal/noise ratio
Channel separation
D ynam ic range
Input : 100-240V~50/60Hz
Output : DC 12V 1.5A
<15W
0-45 C
650 nm
PA L , N T S C , AU TO
1Vp - p
75Ω
Output level : 2V
°
± 2 0%
±
≦
±
≧
≧
≧
10%
-80 (1 KH z )
20Hz-20KHz 1dB
80 d B
80 d B
80 d B
10K Ω
