Hamilton Electronics HA-661-4 Specification Sheet

HA-661-4 & HA-661-8

HA-661-4 & HA-661-8

Portable Cassette Recorder/Players

Portable Cassette Recorder/Players

Our Most Popular Recorder!

This conventional 2 watt portable cassette recorder/player
has all the basic features you need for years of reliable
operation. The automatic recording level control function
ensures a steady sound level without having to adjust
volume. In addition, the HA-661's built-in condenser micro­phone faithfully captures every word and sound. Other out­standing features include high-quality 3" round speaker, LED
recording/power indicator, separate jacks for remote control
and external microphone, four ¼" headphone jacks (HA-661­8 has eight) and a convenient cord wrap.

• ¼" Headphone Jacks - HA-661-4: Four, HA-661-8: Eight

• 2 Watt Amplifier

• Built-In Condenser Microphone

• Automatic Level Control

• 3" Round Speaker

• Convenient Cord Wrap

• Operates on AC with attached 5' Cord or 4 "C" Cell
Batteries (not included)

• UL and CSA Listed

HA-661-4

HA-661-8

HA-661-8 Rear Panel

CASSETTE RECORDER/PLAYER SPECIFICATIONS

Power Output 2 Watts
Frequency Response 63-10kHz
Wow & Flutter <0.35%
S/N Ratio 40dB
Speaker 3" Round
FF/Rewind Time 120 sec. (C-60)
Microphone Built-in Electret
Record Level Control ALC
Mechanism Auto Stop
Controls Record, Play, Cue, Review, Rewind, FF,

Stop/Eject,Pause, Volume

Output Jacks ¼" Headphone: HA-661-4: Four,

HA-661-8: Eight
Input Jacks 3.5mm, Microphone, 2.5mm Remote
Tape Counter 2x, 3-Digit
Power Requirements 120V AC, 50-60Hz or 4 "C" Cell Batteries
Dimensions 12¾"L x 6"W x 2½"H
Weight 4 lbs. without batteries
Safety Compliance UL and CSA Listed
Warranty 1 Year From Date of Original Purchase
