Page 1
Parts and Accesories Diagram
Revision Description:
Update Lid and Container Complete part numbers.
Request Number:
DOC6943
Revision Date:
07/25/2016
Approved by:
DOC6943
Issue Code(s):
Page:
1 of 4
Document #:
540090000
Rev:
B
VFD Board with
Touch Pad
1
Foot (1 each)
990036100
TRIAC Board
990071700
Fan
990071900
Transfer
Board
0182200
Main Board
0
Lower Housing
30
Touch Pad
54840
Stiffener Plate
990151200
USB Board
990072000
USB Cover
990071400
Upper Housing
with
9901
Switch
990114100
Jar Pad
990071300
Jar Sensor
990084400
RFI Board
990078800
Post Kit
990
Replacement Parts
Cordset
990069800
Model HBH850-CE
PROPRIETARY RIGH TS NO TIC E This document and all information contained within i t is the prop erty of Hamilton Beach Br ands, Inc. ( HB B). It is confidential an d proprietary
and has been pr ovided to you for a limited purpose. It must be retur ned or destroyed upon request. Disclosure, reproduction or use of this document and any informat ion
contained within it, in full or in part, for any purpose is forbidden without the prior written consent of HBB. No photographs may be taken of any article fabric at ed or assem bl e d
from this document without the prior wr itten consent of HBB.
9901
Touchpad
54810
99018550
99014280
99
9901548
078900
4421 Waterfront Dri ve
Glen Allen, VA 23060
ENG-FRM-RIC-4.32, Rev. E
Page 2
Parts and Accesories Diagram
Revision Description:
Update Lid and Container Complete part numbers.
Request Number:
DOC6943
Revision Date:
07/25/2016
Approved by:
DOC6943
Issue Code(s):
Page:
2 of 4
Document #:
540090000
Rev:
B
Quiet Shield
QS850
Motor,
Complete
990069700
Motor Seal
990060800
Drive Coupling
99006
Motor Brush Kit
s)
75300
Thumb Screw Kit
098900
Thumb Screw
0072700
Quiet Shield Shock
Absorbers
990201700
RFI Kit
990148000
Model HBH850-CE
PROPRIETARY RIGH TS NO TIC E This document and all information contained within i t is the prop erty of Hamilton Beach Br ands, Inc. ( HB B). It is confidential an d proprietary
and has been pr ovided to you for a limited purpose. It must be retur ned or destroyed upon request. Disclosure, reproduction or use of this document and any informat ion
contained within it, in full or in part, for any purpose is forbidden without the prior written consent of HBB. No photographs may be taken of any article fabric at ed or assem bl e d
from this document without the prior wr itten consent of HBB.
99
990
0700
4421 Waterfront Dri ve
Glen Allen, VA 23060
ENG-FRM-RIC-4.32, Rev. E
(2 piece
9900
Page 3
Parts and Accesories Diagram
Revision Description:
Update Lid and Container Complete part numbers.
Request Number:
DOC6943
Revision Date:
07/25/2016
Approved by:
DOC6943
Issue Code(s):
Page:
3 of 4
Document #:
540090000
Rev:
B
Filler Cap
Lid
Cutter Assembly **
Container (Magnetic)
64oz.
Model HBH850-CE
PROPRIETARY RIGH TS NO TIC E This document and all information contained within i t is the prop erty of Hamilton Beach Br ands, Inc. ( HB B). It is confidential an d proprietary
and has been pr ovided to you for a limited purpose. It must be retur ned or destroyed upon request. Disclosure, reproduction or use of this document and any informat ion
contained within it, in full or in part, for any purpose is forbidden without the prior written consent of HBB. No photographs may be taken of any article fabric at ed or assem bl e d
from this document without the prior wr itten consent of HBB.
990084000
990105800
Container,
Complete
6126-650-CE
990075400
98650
Notes:
*Complete Container Includes: Cutter Assembly, Container, Lid and Filler Cap
**Cutter Assembly Includes: Blade, Lock Washer, Hex Nut, Drive Coupling Attachment and Cutter Bearing
Assembly.
4421 Waterfront Dri ve
Glen Allen, VA 23060
ENG-FRM-RIC-4.32, Rev. E
Page 4
Parts and Accesories Diagram
Revision Description:
Update Lid and Container Complete part numbers.
Request Number:
DOC6943
Revision Date:
07/25/2016
Approved by:
DOC6943
Issue Code(s):
Page:
4 of 4
Document #:
540090000
Rev:
B
48oz Container Complete*
Container Washer
Model HBH850-CE
PROPRIETARY RIGH TS NO TIC E This document and all information contained within i t is the prop erty of Hamilton Beach Br ands, Inc. ( HB B). It is confidential an d proprietary
and has been pr ovided to you for a limited purpose. It must be retur ned or destroyed upon request. Disclosure, reproduction or use of this document and any informat ion
contained within it, in full or in part, for any purpose is forbidden without the prior written consent of HBB. No photographs may be taken of any article fabric at ed or assem bl e d
from this document without the prior wr itten consent of HBB.
Accessories
6126-600
BCR100
4421 Waterfront Dri ve
Glen Allen, VA 23060
ENG-FRM-RIC-4.32, Rev. E
