Hamilton Beach 68010 User Manual

Râpe-glace

840116700

Ice Shaver

English........................................ 2

USA: 1-800-851-8900

Français...................................... 9

Canada : 1-800-267-2826

840116700 Ev00.qxd 6/17/03 10:35 AM Page 1

2

This appliance is intended for household use only.

This appliance is equipped with a polarized plug. This type of plug
has one blade wider than the other. The plug will fit into an electrical
outlet only one way. This is a safety feature intended to help reduce
the risk of electrical shock. If you are unable to insert the plug into
the outlet, try reversing the plug. If the plug should still fail to fit,
contact a qualified electrician to replace the obsolete outlet.
Do not attempt to defeat the safety purpose of the polarized plug
by modifying the plug in any way.

The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping over a longer
cord. If a longer cord is necessary an approved extension cord may
be used. The electrical rating of the extension cord must be equal to
or greater than the rating of the ice shaver. Care must be taken to
arrange the extension cord so that it will not drape over the counter­top or tabletop where it can be pulled on by children or accidentally
tripped over.

When using electrical appliances, basic safety precautions should
always be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not immerse motor

housing, cord, or plug in water or other liquid.

3. Close supervision is necessary when any appliance used by or
near children.

4. Unplug cord from outlet when not in use, before putting on or
taking off parts, and before cleaning.

5. Avoid contacting moving parts. Keep fingers out of discharge
opening.

6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions or is dropped or damaged in
any manner. Call our toll-free customer service number for
information on examination, repair or electrical or mechanical
adjustment.

7. The use of attachments not recommended or sold by Hamilton
Beach/ Proctor-Silex, Inc. may cause fire, electric shock, or
injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot

surfaces.

10. The blade is sharp. Handle carefully. Store out of reach of children.

11. Do not attempt to defeat the interlock mechanism.

12. Never place fingers or other utensils into discharge areas.

13. Check ice chamber for presence of foreign objects before using.

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

CONSUMER SAFETY INFORMATION

3

Ice Choices

• Fill Freezer Containers with desired liquid 24 hours before

use. Let freeze before using.

• Empty Freezer Containers and place ice rounds in plastic
storage bags to build up a selection of flavored ice.

• Ice can also be made in ice cube trays with water or other
beverage.

• Any form of ice can be used for plain shaved ice:
automatic ice maker, ice from trays, bagged ice, or the
Freezer Container rounds; however, the Freezer Container
rounds will work best.

840116700 Ev00.qxd 6/17/03 10:35 AM Page 2

5

Parts and Features

1. Motor Housing

2. Ice Chamber with

Shaving Blade

3. Base

4. 2 Freezer Containers

4

Before First Use: Wash Ice Chamber and Freezer

Containers in hot, soapy water. Rinse and dry.

1. Unplug Motor Housing from outlet.

2. To remove the Motor Housing for

cleaning, turn upside down. Then,
using a cloth to protect your hands,
grasp the metal disc and turn
counter-clockwise as shown.

3. Wash metal disc and nut in hot, soapy
water. Rinse and dry. Wipe the bottom
of the Motor Housing with damp, soapy cloth, then wipe
dry with a clean cloth.

4. Reattach the metal disc by placing it back onto the motor
housing. Using a cloth to protect your hands, turn the disc
clockwise. Do not immerse Motor Housing in water or
other liquid.

5. Wash Base, Ice Chamber, and Freezer Containers in hot,
soapy water. Rinse and dry.

Cleaning Your Ice Shaver

wWARNING

To reduce risk of personal injury and/or damage to your
ice shaver:

• Never wash ice chamber with shaving blade, or any part of
this appliance, or other removable parts in a dishwasher.

• Always inspect ice chamber with shaving blade before
each use.

• Do not use a cracked, bent or damaged ice chamber.

How to Use Your Ice Shaver

1. Have your preferred ice rounds or ice cubes available.

2. Place Base on countertop. Place bowl, cup, or other

container onto Base platform to hold shaved ice.

3. Fit Ice Chamber into Base by lining up flat sides.

4. Place ice into Ice Chamber. Do not overfill.

5. Place Motor Housing on top of Ice Chamber. Plug into outlet.

6. Push top of Motor Housing to start shaving. Release to

stop shaving. Some ice pieces will remain in Ice Chamber.

7. When finished, unplug ice shaver and clean according to
directions in “Cleaning Your Ice Shaver.”

840116700 Ev00.qxd 6/17/03 10:35 AM Page 4
