Hamilton Beach 53600, 53603 User Guide

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online.

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils.

Visite www.hamiltonbeach.com ( o

www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos.

Questions Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

Preguntas Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

EE. UU.)

Blender

Mélangeur

Licuadora

English ...................... 2

Français .................. 15

Español ................... 28

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used

by or near children. Children should be supervised to ensure that they do not play with the appliance.

4. To protect against risk of electrical shock, do not put cord,

plug, base, or motor in water or other liquid.

5. Unplug cord from outlet when not in use, before putting on

or taking off parts, and before cleaning.

6. Flashing light indicates ready to operate. Avoid any contact

with blades or moveable parts.

7. Do not operate any appliance with a damaged supply cord or

plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Call the provided customer service number for information on examination, repair, or adjustment.

8. The use of attachments, including canning jars, not

recommended or sold by the appliance manufacturer may cause a risk of injury to persons.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter or touch

hot surfaces, including stove.

11. Do not place on or near a hot gas or electric burner, or in a

heated oven.

12. Keep hands and utensils out of the jar and away from the

cutting blade, while blending or chopping food, to reduce the risk of severe personal injury and/or damage to the blender (attachments may not be provided with blender). A rubber spatula may be used but only when blender is not running.

13. Blades are sharp; handle carefully—especially when

assembling, disassembling, or cleaning inside blender jar.

14. Do not use a broken, chipped, or cracked blender jar.

15. To reduce the risk of injury, never place cutting blade

assembly on base without blending jar or personal jar attached.

16. Do not blend hot liquids in the personal jar.

17. Do not use broken, cracked, or loose cutting blade assembly.

18. Always operate blender with lid in place. Open vent area only

for adding ingredients.

19. Be careful if hot liquid is poured into blender as it can be

ejected out of appliance due to sudden steaming.

20. When blending hot liquids, open the center vent lid and close

any edge cover opening intended for pouring. To prevent possible burns: Do not exceed the 3-cup (710-ml) level. Hot liquids may push off lid during blending; therefore, with the protection of an oven mitt or thick towel, place one hand on top of the lid, keep exposed skin away from the lid, and start blending at lowest speed.

21. Ensure collar on base of blending jar and personal jar

are tight and secure. Injury can result if moving blades accidentally become exposed.

22. If the jar should twist or rotate when motor is switched ON,

switch OFF ( ) immediately and tighten jar in collar or on blender base.

23. Do not leave blender unattended while it is operating.

24. To disconnect cord, switch to OFF ( ). Then remove plug

from wall outlet.

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information

This product is intended for household use only. Use for food or liquid only.

w WARNING

provided with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension

The wattage/ampere rating of the blender is determined by an Underwriters Laboratory test and is based on available cutting blade assembly, jar combinations, and attachments that may not be provided with your unit, but are available as replacement parts. This is a measure of input wattage/amperes after 30 seconds of operation. The blender as provided may draw significantly less power.

Electrical Shock Hazard: This appliance is

Wattage/Peak Power Information

25. Do not use appliance for other than intended purpose.

26. CAUTION! In order to avoid a hazard due to inadvertent

resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.

cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

If the cutting blade assembly locks and will not move, it will damage the motor. Do not use. Call the toll-free customer service number for information.

Do not place blender jar in the freezer filled with food or liquid. This can result in damage to the cutting blade assembly, jar, blender, and possibly result in personal injury.

Peak power is the measure of the motor wattage during the first seconds of operation. This is when a blender requires the most power to crush ice, frozen fruit, etc. This is a better measure of what a blender motor can consume when power is needed most.

Parts and Features

*To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826 Mexico: 01 800 71 16 100

Two-Piece Removable Quiet Shield*

Pour Spout

BEFORE FIRST USE: After unpacking blender, wash everything except blender base in hot, soapy water. Dry thoroughly. Wipe blender base with a damp cloth or sponge. DO NOT IMMERSE BASE IN WATER. Care should be taken when cleaning inside of blender jar as cutting blade assembly is very sharp.

Vent

Lid*

Glass Blender Jar*

Handle

Personal Blender Jar

(optional accessory

on select models)

Drinking Lid*

Cutting Blade Assembly*

Jar Collar*

Sound-Absorbing Jar Pad

Shield Locking Button

Base

PULSE Button

Shield Locking Button

ON(I)/OFF( ) (Power) Switch

3 Speed Buttons

CANCEL Button

20-oz. Personal Jar*

Parts and Features (cont.)

Lid: The lid is easy to put on, take off, and clean. Always use lid when machine is in operation and to pour.

Blender Jar: Ounces, cups, and milliliters are clearly marked. ON(I)/OFF( ) (Power) Switch: The ON(I)/OFF( )

(power) switch is located on right-hand side of blender base. This lighted switch controls power to blender.

3 Speed Buttons: There are three speeds: LOW, MED, and HIGH.

PULSE Button: Press and hold down PULSE button to blend at high speed setting.

CANCEL Button: Stops blender at any time. Quiet Shield: The quiet shield reduces amount of

noise from your blender. When placed over blender jar, it muffles the sound that your blender produces.

Personal Blender Jar: The personal blender jar makes it easier to make beverages to take on the go.

Base: Contains motor. DO NOT IMMERSE BASE IN WATER.

Preparing Blender: After unpacking blender, wash everything except

blender base in hot, soapy water. Dry thoroughly. Wipe blender base with a damp cloth or sponge. DO NOT IMMERSE BASE IN WATER. Care should be taken when handling cutting blade assembly since it is very sharp. Refer to care recommendations on page 11.

IMPORTANT: Blender jar and cutting blade assembly are subject to wear during normal use. Always inspect jar for nicks, chips, or cracks. Always inspect cutting blade assembly for broken, cracked, or loose blades. If jar or cutting blade assembly is damaged, do not use. Call our customer care center to obtain replacement parts.

w WARNING

Burn Hazard. Metal parts under blending jar get hot after use. Do not touch.

Using Your Blender

1. Make sure blender is

unplugged. Place blender base on clean, dry surface. Place cutting blade assembly, blade side up, through opening in blending jar before twisting collar onto bottom of jar. Add Ingredients.

4. Plug into outlet. Press ON(I)/OFF( ) switch to turn on power to the blender. The control panel will flash and CANCEL button will continue to flash, indicating blender is ready for blending. Press ON(I)/OFF( ) switch to OFF ( ) position anytime machine is left unattended.

IMPORTANT: The blender jar and cutting blade assembly are subject to wear during normal use. Always inspect jar for nicks, chips, or cracks. Always inspect cutting blade assembly for broken, cracked, or loose blades. If jar or cutting blade assembly is damaged, do not use. Call tollfree customer service number to obtain replacement parts.

2. Place lid on jar. Place blender

jar on base.

3. Close quiet shield.

Using Your Blender (cont.)

5. Select speed and push

button.

6. Press a different speed button

during blending to increase or decrease blending speed. If using PULSE, blender will run at high speed only when PULSE button is held down.

OPTIONAL

w WARNING

7. Hazard. Do not fill blender jar

with hot liquid beyond 3-cup (710-ml) level. With protection of an oven mitt or thick towel, place one hand on top of lid. Keep exposed skin away from lid. Start blending at lowest speed.

Burn

8. At the end of blending cycle,

press CANCEL button to stop blending. Turn off blender with the ON(I)/OFF( ) switch on right side of base. Unplug.

9. Lift quiet shield.

w WARNING

10. Remove blender jar. 11. Pour with lid on.

Burn Hazard.

Metal parts under blending jar get hot after extended use.

Using Personal Jar (optional)

w WARNING

Do not blend hot ingredients. Pressure may build, causing jar to pop off and hot ingredients to erupt.

w WARNING

Handle blade carefully; it is very sharp. Make sure unit is turned OFF ( ) and is unplugged.

4. Unplug. Remove personal jar

from base. Turn bottom up; remove collar and cutting blade assembly from jar.

Burn Hazard.

Laceration Hazard.

1. Add ingredients. Carefully

place cutting blade assembly and collar onto personal jar.

5. Hand-tighten drinking lid onto

personal jar.

2. Turn personal jar upside down and shake. Place onto base.

3. Lift quiet shield and plug

blender into outlet. Push desired speed button. When using PULSE button, blender will only run when the PULSE button is held down. Place hand on top of jar to hold while blending. Press CANCEL button to stop blending.

Blender Tips

Blender Jar Tips

• ALWAYS place liquid in blender jar first, then remaining ingredients.

• For best performance, minimum amount of liquid needed per recipe is 1 cup (8 ounces/237 ml). Add more liquid if food is not blending properly. The amount of liquid needed will vary based on other ingredients required for blending.

• If blending action stops during blending or ingredients stick to sides of jar, stop blending and try pulsing or add more liquid to blender jar.

• Do not store food or liquids in blender jar.

Personal Jar Tips

• If blending action does not start, stops during blending, or ingredients stick to sides of the jar, press STOP button. Remove jar, shake contents, and return to blending.

• For best performance in the 20-oz. (591-ml) personal jar, minimum amount of liquid needed per recipe is 3/4 cup (6 ounces/177 ml).

• When filling jar, place frozen ingredients or ice into jar first. When turned upside down to blend, frozen items will be on top.

• Avoid bumping or dropping blender when in operation or at any time.

• Cutting large whole fruits and vegetables may allow them to blend more quickly.

• Do not fill blender jar past highest graduation marking.

• If ice or frozen fruit pieces are not blending, stop blender and pulse a few times.

• Do not allow ice to stand or freeze in jar. Immediately crush ice after placing in jar.

• Keep lid on for easy pouring.

• Do not chop or process hard foods such as cheese, crackers, or

meat.

• Avoid bumping or dropping blender.

• Do not blend hot liquids in personal jar.

• Do not fill personal jar above MAX fill line.

How to Remove and Replace Quiet Shield

1. TO REMOVE: Start with front

shield; separate front shield from back at rubber hinges.

1. TO REPLACE: Press both

shield locking buttons in while sliding back shield around the base.

2. Press tabs on both sides of

blender while moving back shield back with your thumbs.

2. To secure, press back shield

and blender base together.

3. Slide back shield away from

blender base.

3. Pull front shield around rear

shield.

4. Secure round hinges of front

shield around rubber hinges.

w WARNING

Cleaning Your Blender

1. Unplug.

2. Remove quiet shield.

3. Remove blender jar and lid. Rotate collar counterclockwise until

collar and cutting blade assembly come apart from blender jar.

3. Remove personal jar from base. Rotate collar counterclockwise

until collar and cutting blade assembly come apart from personal jar.

CLEANING BLENDER JAR:

• Add 5 cups (1.2 L) warm water and add two drops of dish soap. Press LOW speed button and blend for 30 seconds. Rinse and dry thoroughly.

• To clean after blending oily foods, sprinkle baking soda in blender. Add 1 cup (237 ml) white vinegar. Mixture will bubble. When bubbling subsides, add 1 1/2 cups (355 ml) water and blend on LOW speed for 30 seconds. Wash any remaining residue with dish soap and water. Rinse and dry thoroughly.

4. Wipe blender base, control panel, and cord with a damp cloth

or sponge. To remove stubborn spots, use a mild, nonabrasive cleanser.

5. Clean quiet shield with hot, soapy water. Dry thoroughly.

6. Blender jar, personal blender jar, lid, jar collar, and cutting blade

assembly are dishwasher-safe.

7. DO NOT use “SANI” setting when washing in the dishwasher.

“SANI” cycle temperatures could damage your product. Parts may also be washed with hot, soapy water. Rinse and dry thoroughly. Do not soak.

Disconnect power before cleaning. Do not immerse cord, plug, base, or motor in water or other liquid.

w WARNING

Metal parts under blending jar get hot after extended use.

Electrical Shock Hazard.

Burn Hazard.

Troubleshooting

All program buttons are flashing.

• The motor is not rotating and is experiencing a locked rotor

condition. Turn power switch to OFF ( ) and remove the blender jar. Turn power switch to ON (I), run blender without jar in place on HI for 30 seconds to 1 minute, and resume normal operation. NOTE: Buttons start flashing 2–3 seconds after a problem has occurred.

Blender fails to start.

• Make sure main power ON(I)/OFF( ) switch is in the ON (I)

position.

• Check to see if unit is securely plugged into an electrical outlet of

proper voltage and frequency.

• Check to see if fuse for electrical outlet has blown or if a circuit

breaker has tripped.

Ingredients will not mix properly.

• Check to see if enough liquid has been added to ingredients.

Mixture should be fluid and free-running at all times.

• Solid pieces are too large.

• Container is too full. Do not fill past highest (6.5 cups/1.5 L)

graduation marking.

• Cutting blade assembly blades are not sharp or are damaged.

Inspect container and cutting blade assembly daily.

• Select speed to create a fluid blend.

Blender smells like it is burning.

• Turn off blender and allow unit to cool.

• Although motors are tested during the manufacturing process, heavy use may cause curing of motor windings. The smell may quickly dissipate after a few heavy uses.

• If smell continues after additional heavy uses, call our customer care center.

There is grease around bottom of blender jar or on counter top.

• Monitor problem and source. This may indicate an issue with jar bearings.

• Call our customer care center if condition persists.
