Hamilton Beach 52147H User Guide

English ...................... 2

Français .................. 12

Español .................. 22

Dual Wave™Blender

Mélangeur

Licudora

READ BEFORE USE LIRE AVANT D’UTILISER LEA ANTES DE USAR

Questions? Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

¿Preguntas? Por favor llámenos – nuestros amables representantes están listos para ayudar. MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

Visit hamiltonbeach.com for delicious recipes, tips, and to register your product online!

Consulter hamiltonbeach.ca pour les recettes délicieuses, conseils pratiques, et pour enregistrer votre produit!

Visite hamiltonbeach.com.mx para recetas deliciosas, consejos, y para registrar su producto en línea.

Questions? N'hésitez pas à nous appeler – nos associés s'empresseront de vous aider. CAN: 1.800.267.2826

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 1

SAVE THESE INSTRUCTIONS!

IMPORTANT SAFEGUARDS

1. Read all instructions.

2. To protect against risk of electrical shock, do not put cord, plug, base, or motor in water or other liquid.

3. Close supervision is necessary when any appliance is used by or near children.

4. Unplug cord from outlet when not in use, before putting on or taking off parts, and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug, or after appliance malfunctions, or is dropped or damaged in any manner. Call our toll-free customer service number for information on examination, repair or electrical or mechanical adjustment.

7. The use of attachments, including canning jars, not recommended or sold by the appliance manufacturer may cause a risk of injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces, including the stove.

10. Keep hands and utensils out of jar while blending to reduce the risk of severe injury to persons or damage to the blender. A rubber spatula may be used but must be used only when blender is not running.

11. Blades are sharp; handle carefully–especially when assembling, disassembling or cleaning inside blender jar.

12. Do not use a broken, chipped, or cracked blender jar.

13. Do not use broken, cracked, or loose cutting blades.

14. To reduce the risk of injury, never place cutting assembly blades on base without jar properly attached.

15. Always operate blender with lid in place.

16. Only blend hot liquids in large-capacity 80-ounce jar. Remove center-piece of two-piece lid. Hot liquids may push lid off jar during blending. To prevent possible burns: do not fill 80ounce jar beyond the 6 cup (1500 ml) level. With the protection of an oven mitt or thick towel, place one hand on top of lid. Keep exposed skin away from lid. Start blending at lowest speed.

17. Do not blend hot liquids in the small capacity Stay or Go™ Personal Blending Jars.

18. Screw on cutting assembly firmly. Injury can result if moving blades accidentally become exposed.

19. If the jar should turn when the motor is switched ON, switch OFF immediately and tighten jar onto cutting assembly.

20. Do not leave blender unattended while it is operating.

21. To disconnect cord, turn the control to OFF. Then remove plug from wall outlet.

22. Do not use appliance for other than intended purpose.

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 2

OTHER CONSUMER SAFETY INFORMATION

This appliance is intended for household use only. Use for food or liquids only.

WARNING! Shock Hazard: This appliance has a polarized plug

(one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or using an adaptor. If the plug does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in, or tripping over, a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

Do not place blender jar in the freezer filled with food or liquid. The contents may freeze and may result in damage to the cutting blades, jar, blender and possibly result in personal injury. If cutting blades lock and do not move, it will damage the motor. Do not use. Call the toll-free customer service number for information.

Wattage/Peak Power Information: The wattage/ampere

rating of the blender is determined by an Underwriter’s Laboratory test. This rating is based on the 80-ounce blending jar. Use of the accessory personal blending jar may draw significantly less power. This is a measure of input wattage/ amperes after 30 seconds of operation.

Peak power is the measure of the motor wattage during the first seconds of operation. This is when a blender requires the most power to crush ice, frozen fruit, etc. This is a better measure of what a blender motor can consume when power is needed most. The blender as provided may draw significantly less power.

Optional Accessory: Stay or Go™ Personal Blending Jar

(AC16) may be used with this appliance. Two blending jars are included with the blender. Additional blending jars may be purchased separately.

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 3

Parts and Features

Lid

Base

Control Knobs (2)

Cutting Assemblies

(to be used with 80-oz Jar and Personal Blending Jars)

Dispenser Spout Cap

Filler Cap

Dispenser

Dispenser Spout

80-Ounce Blender Jar

Dispenser

Stay or Go™

Personal Blending Jars

Bottom Lid

Jar

Top Lid

Dispenser Lever

Dispenser Spout Cap

Storage Feature

(stored on bottom of blender base)

Cord Storage

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 4

Using the Blender

1 2 3 4

5 6

When using 80-ounce jar, only use ONE control knob to run BOTH blades: 1 (Low), 2 (High), or P (Pulse).

NOTES:

• A minimum of 16 ounces (500 ml) is recommended for 80-ounce jar.

• The international OFF symbol (O) is provided to clearly indicate the OFF position.

Run blender on 2 (High) while dispensing.

Cutting assemblies must be securely tightened to blender jar before placing on base.

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 5

Using the Stay or Go™ Personal Blending Jar

Cutting assemblies should be removed from 80-ounce jar and used with Personal Blending Jar.

Hold jar in place while blending. When blending with a single personal jar, avoid DUAL BLADE ACTUATOR, second motor may turn on.

3 4

DUAL BLADE

ACTUATOR

Hold jars in place while blending.

AVOID CONTACT

Place cup on base. Turn slightly clockwise to lock in place.

Turn slightly counterclockwise to unlock and remove.

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 6

8 9

Using the Stay or Go™ Personal Blending Jar (cont.)

Personal Blending Jar Storage Feature

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 7

Cleaning the Blender

DISHWASHER SAFE

Wipe blender base, control panel, and cord with a damp cloth or sponge. To remove stubborn spots, use a mild, non-abrasive cleanser.

Electrical Shock Hazard.

Disconnect power before cleaning. Do not immerse cord, plug or base in any liquid.

w WARNING

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 8

Troubleshooting

PROBLEM

Blender leaks.

Ice not crushed. Does not blend well.

Does not dispense or dispenses slowly.

Dispenser leaks.

Cannot remove cutting assembly.

Blender jar won’t fit on base.

Personal Blending Jar leaks.

PROBABLE CAUSE/SOLUTION

• Tighten cutting assembly on jar.

• Make sure lid with filler cap is pushed down tightly on jar.

• Make sure gasket is not damaged, twisted, or missing. If damaged, please call our toll-free customer service number to order a replacement.

• See Blending Tips.

• Make sure enough liquid has been added. If mixture is too thick, continue to add liquid until mixture is blended to desired consistency. A minimum of 16 ounces (500 ml) is recommended for 80-ounce jar.

• Do not try to mash potatoes, mix stiff dough, whip egg whites, grind raw meat, or extract juices from fruits and vegetables. The blender is not made to perform these tasks.

• Make sure blender is ON and dispenser lever is in the DOWN position.

• If solid food or ultra-thick beverage will not dispense, pour from jar.

• Make sure seal rings are in place on dispenser lever and spout.

• Make sure dispenser lever is in the UP position.

• Loosen cutting assembly by holding jar and turning cutting assembly counterclockwise.

• Make sure cutting assemblies are securely tightened to blender jar. If difficult to tighten, dampen cutting assemblies first, then securely tighten to blender jar.

• Tighten top lid and cutting assembly securely before placing on blender base.

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 9

Crushing Ice

For best performance, when a recipe calls for liquid, place the liquid in blender jar followed by the ice cubes. Ensure ice cubes are separated. When only crushed ice is desired, add 2 cups (500 ml) of ice cubes to jar. Place lid on blender jar then Pulse. Allow blades to come to a complete stop between pulses. Continue until ice is crushed to desired consistency. For best results always crush ice immediately after removing from freezer.

Blending Tips Optional Accessories

Stay or Go™ Personal Blending Jar (AC16) may be used with this appliance. Two blending jars are included with the blender. Additional blending jars may be purchased separately.

To Order Call:

1.800.851.8900 (U.S.)

1.800.267.2826 (Canada)

01.800.71.16.100 (Mexico) or visit hamiltonbeach.com

840171704 ENnv01.qxd 7/8/08 2:14 PM Page 10
