Hamilton Beach 49983 User Guide

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online!

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils !

¡Visite www.hamiltonbeach.com ( o

www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos!

EE. UU.)

2-Way FlexBrew®

Coffee Maker

Questions? Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions ? N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

¿Preguntas? Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

Cafetière à double

usage FlexBrew

Cafetera Doble

FlexBrew

English ....................... 2

Français .................... 21

Español .................... 41

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used by

or near children. Children should be supervised to ensure that they do not play with the appliance.

4. Do not touch hot surfaces. Use handles or knobs. Care

must be taken, as burns can occur from touching hot parts or from spilled, hot liquid.

5. To protect against electric shock, do not place cord, plug,

or coffee maker in water or other liquid.

6. Unplug from outlet when either the coffee maker or clock is not

in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

7. Coffee maker must be operated on a flat surface away from the

edge of counter to prevent accidental tipping.

8. Do not operate any appliance with a damaged supply cord or

plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Call the provided customer service number for information on examination, repair, or adjustment.

9. The use of accessory attachments not recommended

by the appliance manufacturer may cause injuries.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or counter or touch hot

surfaces, including stove.

12. Do not place coffee maker on or near a hot gas or electric

burner or in a heated oven.

13. The carafe is designed for use with this coffee maker. It must

never be used on a range top or in a microwave oven.

14. Do not set a hot carafe on a wet or cold surface.

15. Do not use a cracked carafe or one with loose or weakened

handle.

16. Do not clean carafe with cleansers, steel wool pads, or other

abrasive materials.

17. Be certain carafe lid is securely in place during brew cycle and

when pouring coffee. Do not use force when placing lid on carafe.

18. To disconnect coffee maker, turn controls to OFF ( ) and then

remove plug from wall outlet.

19. WARNING! To reduce the risk of fire or electric shock, do not

remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

20. Do not use appliance for other than intended use.

21. CAUTION! Cut Hazard: Removable single-serve pack holder

contains a sharp blade. Use caution when handling.

22. CAUTION! Cut Hazard: Piercing nozzle is sharp. Use caution

when cleaning.

SAVE THESE INSTRUCTIONS!

Other Consumer Safety Information

This appliance is intended for household use only.

w WARNING

with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.

Electrical Shock Hazard: This appliance is provided

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another highwattage appliance on the same circuit with this appliance.

Parts and Features

*To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826 Mexico:

01 800 71 16 100

Brew Basket*

Carafe*

Display

Water Reservoir

BEFORE FIRST USE: Wash all removable parts in hot, soapy water. Rinse and dry. Brew one cycle with water on each side and discard water.

Removable Single-Serve Pack Holder* (punches hole on bottom of pack)

Single-Serve Brew Basket With Hinged Lid (for ground

Brew Selector Dial

Control Panel

Water Window

Piercing Nozzle

(punches hole in top of

single-serve pack)

coffee)

Brew Basket*

Brew Basket Handle

Water Window

Warming Plate

HOT Indicator (turns red when hot)

Multilevel Cup Rest*

Cord Stuff Storage

How to Use Single-Serve Side –

Brewing Single-Serve Packs

w CAUTION

To avoid contact with hot coffee or water:

• DO NOT use more than 10 oz. (296 ml) of water for single-serve pack or 14 oz. (414 ml) for grounds. Too much water causes ERR message

and long beep. SOLUTION: Place carafe on warming plate. Turn brew selector dial to Carafe ( ). Press l/ button to remove water. Turn brew selector dial to single-serve side ( ). Add correct amount of water to water reservoir. Start brew process.

• Fill reservoir with cup or travel mug of water into which the coffee will be brewed.

• Fully insert cup or travel mug under brew basket.

• For best results, use K-Cup®* packs.

NOTES:

• The unit will only brew on one side at a time.

• For Hotter Coffee: Rinse the mug with hot water before brewing.

• The Brew Mode selection will stay in the last mode used, unless unplugged.

• Coffee may continue to drip after brewing is complete (after 3 beeps) when using finely ground coffee.

• Programming mode cannot be used on Single-Serve side.

Burn Hazard.

*K-Cup is a registered trademark of Keurig, Inc. Use of the K-Cup trademark does not imply any affiliation with or endorsement by Keurig, Inc.

Fill reservoir with cup or travel mug into which the coffee will be brewed (maximum 10 oz. [296 ml] water).

Plug in coffee maker. Rotate brew selector dial to the right to select Single-Serve ( ).

How to Use Single-Serve Side –

Brewing Single-Serve Packs (cont.)

Remove brew basket. Place a pack into the single-serve pack holder.

Press BREW OPTIONS button to select .

w CAUTION

serve pack holder has a sharp blade. Handle with care.

Cut Hazard. Single-

w CAUTION

Warming plate is hot even when brewing on Single-Serve side.

Burn Hazard.

Press down on edge of the pack until the pack snaps into place and hole is punched in the bottom. Do not remove foil.

Press down on brew basket handle to lock and puncture the

foil lid on the pack.

9 9

Ensure the multilevel/flip cup rest is firmly secured and snapped into place.

How to Use Single-Serve Side –

Brewing Single-Serve Packs (cont.)

For removal of cup rest: Push up cup rest; tilt up. Push down to release.

After brewing, pull up on brew basket handle to unlock and remove.

1110

Coffee maker will shut off automatically and light will go off when brew cycle is completed (3 beeps will sound).

Allow 2 minutes to cool in between brews.

Brew basket and single-serve pack holder should be rinsed after every use.

w CAUTION

Warming plate is hot even when brewing on Single-Serve side.

Press ON/OFF (I/ ) button. The blue power ON indicator light will light up to show that the coffee maker is on.

Burn Hazard.

How to Use Single-Serve Side –

Brewing Coffee Grounds

w CAUTION

To avoid contact with hot coffee or water:

• DO NOT use more than 10 oz. (296 ml) of water for single-serve pack or 14 oz. (414 ml) for grounds. Too much water causes ERR message and long beep. SOLUTION: Place carafe on warming plate. Turn brew selector dial to Carafe ( ). Press l/ button to remove water. Turn brew selector dial to single-serve side ( ). Add correct amount of water to water reservoir. Start brew process.

• Fill reservoir with cup or travel mug of water into which the coffee will be brewed.

• Fully insert cup or travel mug under brew basket.

• Remove single-serve pack holder before adding coffee grounds to brew basket.

• To avoid overflow, keep ground coffee below MAX fill line.

NOTE: It can take up to 2 minutes before brewed coffee starts dispensing into your cup or travel mug.

Burn Hazard.

1 3

Fill reservoir with cup or travel mug into which the coffee will be brewed (maximum 14 oz. [414 ml] water).

Plug in coffee maker. Rotate brew selector dial to the right to select Single-Serve ( ).

How to Use Single-Serve Side –

Brewing Coffee Grounds (cont.)

w CAUTION

Warming plate is hot even when brewing on Single-Serve side.

Burn Hazard.

Press BREW OPTIONS button to select GROUND mode.

To remove single-serve pack holder, grasp the single-serve pack holder cup; slide towards the back and then lift out.

w CAUTION

sharp blade. Handle with care.

Cut Hazard. Removable single-serve pack holder has a

Add ground coffee (3 tablespoons [44 ml] is the MAX amount of ground coffee for brew basket).

109

How to Use Single-Serve Side –

Brewing Coffee Grounds (cont.)

w CAUTION

Warming plate is hot even when brewing on Single-Serve side.

Burn Hazard.

Ensure the multilevel/flip cup rest is firmly secured and snapped into place.

11 12

Press ON/OFF (I/ ) button. The blue power ON indicator light will light up to show that the coffee maker is on.

Coffee maker will shut off automatically and light will go off when brew cycle is completed (3 beeps will sound).

Press the ON/OFF (I/ ) button again to STOP brewing midcycle.

Allow 2 minutes to cool in between brews.

Brew basket should be rinsed after every use.

How to Use Carafe Side

AUTOMATIC SHUTOFF: The coffee maker will automatically shut off 2 hours after brew cycle is complete. NOTE: The unit will only brew on one side at a time.

Plug in coffee maker. Rotate dial to the left to select carafe ( ).

For each cup of coffee being made, place one level tablespoon (15 ml) of coffee into filter.

Press BREW OPTIONS button to select REGULAR or BOLD modes. REGULAR is the default.

Place a cupcake-style paper filter in brew basket. A permanent filter may also be used.

7 8

How to Use Carafe Side (cont.)

Place carafe, with carafe lid attached, on warming plate.

PAUSE AND SERVE:

To serve coffee during the brewing cycle, remove carafe and pour a cup. By removing the carafe, the flow of coffee from the bottom of the filter basket will stop.

w CAUTION

20 seconds of being removed to prevent overflow. NOTES:

• If the coffee maker is not turned off manually, it will automatically shut off in 2 hours.

• BOLD mode will require additional time to complete a brewing cycle. Coffee maker remembers last brew option selected. If unplugged, coffee maker defaults to REGULAR.

Burn Hazard. The carafe must be replaced within

For enhanced full/strong-flavored coffee, press BREW OPTIONS button until BOLD is displayed.

Press I/ (ON/OFF) button to start. Press I/ (ON/OFF) button again to turn off.

How to Use Carafe Side (cont.)

Tips for Best-Tasting Coffee

• All coffees are made from either arabica beans or robusta beans, or some combination of both. Arabica beans are slightly more expensive, but tend to produce better-tasting coffee.

• Ground coffee will become stale much faster than whole beans. If buying preground coffee, choose a package with the latest expiration date or a smaller quantity.

• If grinding whole beans, set your coffee grinder on a fine/medium grind. This will yield the best-tasting grounds. Try to use freshly ground coffee within about a week of grinding.

• Using a water filter, filtered water, or bottled water will yield bettertasting coffee than tap water.

• Use approximately 1 tablespoon (15 ml) of grounds for each cup of coffee being made. To avoid overflow, use slightly less grounds (3/4 tablespoon [11.3 ml]) when brewing decaf or flavored coffees. Also, be aware that using coffee that is ground too finely may also cause the filter basket to overflow.

• Make sure your coffee maker is clean. See “Care and Cleaning” sections.

Programming – For Carafe Side Only

NOTE: The unit will only brew on one side at a time. Single-Serve side cannot be used while Carafe side is programmed.

Rotate dial to the left to select carafe ( ).

21 4

Press HOUR and then MINUTE to set clock.

Press PROGRAM to activate automatic brewing. Green program light will illuminate to indicate the unit is programmed and will begin brewing at the selected start time.

Hold PROGRAM until clock flashes.

Continue holding PROGRAM button, press HOUR and MINUTE until the desired brewing start time is reached, and then release PROGRAM button.

Care and Cleaning

All coffee makers should be cleaned at least once a month (once a week for areas with hard water).

w WARNING

Do not immerse cord, plug, or coffee maker in any liquid.

w WARNING

Failure to allow coffee maker to cool down may cause hot water or coffee to spray from the piercing nozzle. Use caution when cleaning.

w CAUTION

Piercing nozzle is sharp. Use caution when cleaning.

Shock Hazard.

Burn Hazard.

Cut Hazard.

2 3

Routine cleaning of the piercing nozzle: The nozzle is located in the lid of the coffee maker. Bend a small paper clip as shown; insert the tip of the paper clip through the holes of the piercing nozzle and up into the piercing nozzle to ensure grounds have been removed. Brew 2 or 3 times with cold water to make sure grounds have been removed from the piercing nozzle.

DISHWASHER-SAFE

DO NOT use the “SANI” setting when washing in the dishwasher. “SANI” cycle temperatures could damage your product.

Care and Cleaning (cont.)

Press I (ON) button. Press (OFF) button after 30 seconds and wait 30 minutes. Press I (ON) button. Press (OFF) button when finished.

Rotate dial to the left to select carafe ( ).

Pour 1/2 cup (118 ml) of plain white vinegar and 1/2 cup (118 ml) of cold water into water reservoir.

131211

Run 2–3 more brew cycles with CLEAN WATER only. Allow to cool between cycles. Turn dial to ( ). Repeat process for single-serve side.

Troubleshooting – Single-Serve Side

PROBLEM PROBABLE CAUSE/SOLUTION

Err message on display.

K-CUP

Weak coffee. • Not enough ground coffee used. See “How to Use Single-Serve Side.”

Coffee overflows from brew basket, travel mug, or regular mug.

Coffee tastes bad. • Coffee maker needs cleaning. See Care and Cleaning on page 15.

Water exits carafe side. • Make sure selector dial is set to Single-Serve side. Auto-start feature does not

work with Single-Serve side. Clear water when brewing

with single-serve pack. Steam flows up across

control panel.

Coffee maker will not brew. • Piercing nozzle is clogged. Follow cleaning piercing nozzle instructions on page 15.

• Set option to BOLD.

• Excessive amount of water in reservoir. Use travel mug or mug into which coffee will be brewed to fill reservoir. Use slightly less grounds when brewing decaffeinated, flavored, or finely ground coffee. Or use medium ground coffee.

• Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.

• Poor coffee quality and freshness.

• Poor water quality. Use filtered or bottled water.

• Auto-start feature is not designed to work with Single-Serve side. Program mode is for Carafe side only.

• Forgot to lock handle down, which pierces top foil of single-serve packs.

• When brewing ground coffee with single-serve pack holder assembly removed, steam will travel up across the control panel if the basket handle is pressed down. Leave the handle up for ground coffee.

• Do not exceed MAX water level for single-serve pack brewing.

Troubleshooting – Carafe Side

PROBLEM PROBABLE CAUSE/SOLUTION

Brew basket overflows or coffee brews slowly.

Coffee leaks onto base. • Carafe removed from warming plate for more than 20 seconds during the brewing cycle. Coffee tastes bad. • Coffee maker needs cleaning. See Care and Cleaning on page 15.

• Excessive amounts of ground coffee.

• Decaffeinated and/or coffee ground too finely can cause overflow. Use slightly less grounds when brewing decafeinated, flavored, or finely ground coffee. Or use medium ground coffee.

• Coffee maker needs cleaning. See Care and Cleaning on page 15.

If using a paper filter:

• Coffee grounds between paper filter and brew basket.

• Paper filter not open and in proper position.

• Rinse brew basket before inserting paper filter so the edges will remain pressed against the sides of the basket.

• Poor-quality paper filter.

• Coffee ground too coarsely or too finely. Use medium ground coffee.

• Coffee-to-water ratio unbalanced. Adjust for personal preference.

• Poor coffee quality and freshness.

• Poor water quality. Use filtered or bottled water.

+ 42 hidden pages
