Hamilton Beach 42884, 840155200 User Manual
Coffeemaker
840155200
English ................................................ 2
USA: 1-800-851-8900
Français ............................................ 10
Canada: 1-800-267-2826
Español .............................................. 19
México: 01 800 71 16 100
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
Cafetière
Cafetera
READ BEFORE USE
LIRE AVANT L’UTILISATION
LEA ANTES DE USAR
840155200 ENv01 7/7/06 1:53 PM Page 1
2
Other Consumer Safety Information
IMPORTANT SAFEGUARDS
When using electrical appliances, basic
safety precautions should always be followed to reduce the risk of fire, electric
shock, and/or injury to persons, including
the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles
or knobs. Care must be taken, as burns
can occur from touching hot parts or
from spilled, hot liquid.
3. To protect against electric shock, do not
place cord, plug or coffeemaker in water
or other liquid.
4. Close supervision is necessary when any
appliance is used by or near children.
5. Unplug from outlet when either the coffeemaker or clock is not in use and
before cleaning. Allow to cool before
putting on or taking off parts and before
cleaning the appliance.
6. Coffeemaker must be operated on a flat
surface away from the edge of counter to
prevent accidental tipping.
7. Do not operate any appliance with a
damaged cord or plug, or after the appliance malfunctions or is dropped or
damaged in any manner. Call our toll-free
customer service number for information
on examination, repair, or adjustment.
8. The use of accessory attachments not
recommended by Hamilton Beach/
Proctor-Silex, Inc. may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table
or counter or touch hot surfaces, including stove.
11. The carafe is designed for use with this
coffeemaker. It must never be used on
a range top or in a microwave oven.
12. Do not set a hot carafe on a wet or cold
surface.
13. Do not use a cracked carafe or one with
loose or weakened handle.
14. Do not clean carafe or hot plate with
cleansers, steel wool pads, or other
abrasive material.
15. Be certain carafe lid is securely in place
during brew cycle and when pouring coffee. Do not use force when placing lid on
carafe.
16. To disconnect coffeemaker, turn controls
to OFF, then remove plug from wall outlet.
17. Do not place coffeemaker on or near a
hot gas or electric burner or in a heated
oven.
18. Warning: To reduce the risk of fire or
electric shock, do not remove the bottom
cover. No user serviceable parts are
inside. Repair should be done by authorized service personnel only.
19. Do not use appliance for other than
intended use.
SAVE THESE INSTRUCTIONS
This appliance is intended for household
use only.
The length of the cord used on this appliance was selected to reduce the hazards of
becoming tangled in, or tripping over a
longer cord. If a longer cord is necessary an
approved extension cord may be used. The
electrical rating of the extension cord must
be equal to or greater than the rating of the
coffeemaker. Care must be taken to arrange
the extension cord so that it will not drape
over the countertop or tabletop where it can
be pulled on by children or accidentally
tripped over.
To avoid an electrical circuit overload, do
not use another high wattage appliance on
the same circuit with your coffeemaker.
wWARNING
Shock Hazard
• Do not immerse this appliance in water or other liquid.
• This appliance has a polarized plug (one wide blade) that reduces the risk of electrical
shock. The plug fits only one way into a polarized outlet. Do not defeat the safety
purpose of the plug by modifying the plug in any way or using an adaptor. If the plug
does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet.
840155200 ENv01 7/7/06 1:53 PM Page 2
3
1. Reservoir
2. Swivel Shower Head
3. Filter Basket
4. Carafe
5. Nonstick Keep-Hot Plate
6. Lift Tab
7. Cord Storage
Features 2-hour Automatic Shutoff
Parts and Features
840155200 ENv01 7/7/06 1:53 PM Page 3
4
1. Plug in Coffeemaker and set Clock.
See “To Set the Clock and Program
Automatic Brew” on page 5.
2. Before first use, wash Carafe. See
“To Clean the Coffeemaker Parts”
on page 7. Then run one full Carafe
of clean water through a complete
cycle by following steps 6 through
10.
3. To make coffee, lift Cover to access
Filter Basket.
Move Shower
Head into a
position over
the Reservoir.
Place disposable paper
filter in Filter
Basket. Use a
good quality
cupcake (basket) style filter, 8 to 12
cup size. A permanent filter may also
be used.
4. For each cup of coffee being made,
place one level measuring tablespoon of ground coffee into filter.
5. After adding ground coffee into filter,
move Shower Head back into position over Filter Basket.
6. Fill Carafe with the desired amount
of cold water, and pour into
Reservoir. Flip Cover down to close.
NOTE: If Shower Head is positioned
over Reservoir when Cover is
closed, it will automatically be
swiveled into position over Filter
Basket when the Cover is closed.
7. Place Carafe with Carafe Lid
attached on Keep-Hot Plate.
8. Press ON/OFF button once to
turn the
Coffeemaker
on. The button
will glow red
when in use.
9. When finished, press the ON/OFF
button once and unplug.
10. If storing Coffeemaker, the Cord can
be pushed into a special cord storage area in the back of the unit.
NOTE: If the Coffeemaker is not
turned off manually, it will automatically shut off in two hours.
CAUTION
Overflowing coffee and hot water are a burn hazard. To avoid overflows of the Filter
Basket or Pause ‘N Serve:
• Use one level tablespoon of ground coffee per cup. Excessive amounts of coffee
grinds will clog the Filter Basket.
• Do not grind coffee too finely. This will clog the filter.
• Use a good quality “cupcake” or basket-style filter. The sides of the filter should be
upright against the sides of the Filter Basket to avoid filter collapsing. Paper filters
are less likely to clog than permanent filters.
• Return Carafe to the Keep-Hot Plate within 20 seconds if you are using the Pause
‘N Serve feature. Hot water continues to flow into the Filter Basket when this feature is used and it may overflow unless carafe is returned within 20 seconds.
• Make sure Carafe is fully seated on the Keep-Hot Plate.
Using Your Coffeemaker
How to Make Coffee
840155200 ENv01 7/7/06 1:53 PM Page 4
5
Hour
Minute
Program/
Automatic Brew
ON/OFF Button
Indicator Light
The Automatic Shutoff feature
shuts off the Keep-Hot Plate 2 hours
after brew cycle begins. Always turn
Coffeemaker OFF and unplug
when finished.
This feature allows you to pour a cup
of coffee before the entire brew cycle
has completed. By removing the
Carafe, the flow of coffee from the
bottom of the Filter Basket will stop.
CAUTION: Return carafe to Keep-Hot
Plate within 20 seconds. Hot water
continues to flow into the Filter Basket
when this feature is used. Overflowing
coffee and hot water are burn hazards.
1. Plug in Coffeemaker. The numbers
on the Clock will flash until the time
is set.
2. Press the H button until the current
hour is displayed. AM or PM will
appear on display. Press the M button until the current minute is
displayed. The Clock is now set.
3. To program Coffeemaker to auto-
matically begin brewing, press and
hold the Prog/Auto button for two
seconds to enter the setting mode.
While still pressing Prog/Auto, press
the
H button to set hours and then
press
the M button to set minutes
until the desired brew time is displayed.
4. To have Coffeemaker automatically
begin brewing at a preset time, press
Prog/Auto button momentarily. The
Prog/Auto button will glow green to
indicate Automatic Brew is set and
coffeemaker is ready to begin brewing. “Auto” will appear in the display.
5. The Coffeemaker will shut off two
hours after brewing begins.
NOTES:
• The Automatic Brew feature must be programmed each time it is used.
• Make sure you have placed the desired amount of water and coffee in the unit
before using the Automatic Brew feature.
Control Panel (for clock models)
Additional Features
Pause ’N Serve
Automatic Shutoff
To Set the Clock and Program Automatic Brew
840155200 ENv01 7/7/06 1:53 PM Page 5
6
1. Place empty Carafe on Keep-Hot
Plate. Lift cover.
2. Pour one pint of plain white vinegar
into the Reservoir.
3. Plug in Coffeemaker and turn ON.
4. After 30 seconds turn OFF.
5. Wait 30 minutes to allow the vinegar
to clean. Then turn ON again. When
the brew cycle is finished, turn OFF.
6. Empty Carafe and rinse. Pour one
Carafe of cold tap water intothe
Reservoir. Place carafe on Keep-Hot
Plate.
7. Turn ON. When the brew cycle is
finished, empty the Carafe. Repeat
this process with one more Carafe
of cold tap water.
8. Turn OFF when complete.
9. Wash Carafe and Filter Basket.
Quality coffee comes from quality
ingredients. For the best coffee, you
should start with freshly ground cof-
fee from freshly roasted beans. The
beans can be purchased and stored in
an airtight container. Just prior to
brewing, remove the amount needed
and grind the beans. Once the bean is
broken, the intense, rich flavor begins
to deteriorate.
If using a blade-type coffee grinder,
shake it occasionally during grinding to
redistribute the whole beans for a more
uniform grind. Experiment to find the
right grind for your coffeemaker and
taste. If the beans are ground too finely, it will produce a bitter taste. If
ground too coarsely the coffee will
taste weak and watery.
Some specialty coffees recommend
using more than one tablespoon of
ground coffee per cup. Your new
coffeemaker is designed to brew good
quality coffee using less amounts of
ground coffee. One level tablespoon of
ground coffee per cup is recommended. Of course, the amount of ground
coffee used depends upon your
personal preference.
The quality of your drinking water will
affect the flavor of your coffee. If you
do not drink water straight from the
tap, do not use it to make coffee. If
your water has an off-taste or smell, or
if you have extremely hard water, use
bottled drinking water or filtered water
to make coffee. If the water is from the
tap, it should be freshly drawn and
cold for the best coffee flavor.
The amount of coffee to water
depends
upon personal preference. One
tablespoon of ground coffee per cup is
recommended.
Automatic coffeemakers generally use
a 5-ounce cup size. The coffeemak-
er’s Carafe and Reservoir are marked
in “cups” for easy measuring.
Try different flavored coffees and
flavored creamers available at supermarkets
or specialty coffee stores. Regular
coffee can be flavored at home. Add a
sprinkle of cinnamon* or a drop of a
pure extract–like almond, vanilla, or
mint–to the ground coffee before brewing. For a mocha flavor, stir a spoon of
chocolate syrup or instant cocoa mix
to each cup of brewed coffee.
* (Too much cinnamon may clog the
filter causing Filter Basket overflow.)
Tips to Brew Good Coffee
To Clean the Inside of the Coffeemaker
Cleaning
840155200 ENv01 7/7/06 1:53 PM Page 6
7
1. Unplug Coffeemaker and allow to
cool before cleaning.
2. Wipe Keep-Hot Plate with a clean,
damp cloth. Do not use abrasives.
3. Occasionally wipe the Shower Head
located above the Filter Basket, with
a clean, damp cloth.
4. To remove the Carafe Lid, push the
hinge part of the Lid to one side,
then twist and lift the other side.
The pin will release from the hinge.
Then remove Lid.
5. Carafe is not dishwasher safe.
Wash the Carafe, Carafe Lid, and
removable Filter Basket in hot,
soapy water. Rinse and dry.
6. To remove stains on the Carafe,
scrub with baking soda or a mild
cleanser. For hard-to-remove stains,
fill the Carafe with hot tap water and
add 2 tablespoons of automatic
dishwasher detergent. Let this sit
overnight; then wash and rinse.
7. All other outside surfaces of the
Coffeemaker can be cleaned with
a clean, damp cloth.
To Clean the Coffeemaker Parts
Carafe Safety Precautions
This symbol reminds you that glass is fragile and can break which
could result in personal injury.
This symbol alerts you to the potential danger for personal injury if
you fail to read and follow these safety precautions.
• Do not use a cracked carafe or a
carafe having a loose or weakened
handle.
• This carafe is designed to be used
only on the Keep-Hot Plate of your
coffeemaker. Do not use on a gas or
electric rangetop, or in a microwave
or conventional oven.
• To avoid breakage, handle carafe
with care. Avoid impact. Glass will
break as a result of impact. Use care
when filling with water to avoid hitting
faucet.
• Do not place hot carafe on cool or
wet surface. Allow to cool before
washing or adding liquids.
• Do not set empty carafe on a hot
heating surface.
• Do not clean with steel wool pads,
abrasive cleanser, or any other materials that may scratch.
• Do not place hands inside carafe.
When handling, be careful if wearing
any hand jewelry, especially diamond
rings. Jewelry can scratch the glass,
which increases possibility of breakage.
• Do not bump, scratch, or boil dry.
• Discard carafe if it is cracked,
scratched, or heated while empty for
an extended period of time.
• To avoid accidents, do not pour in
the direction of people.
• If stirring in the carafe, use only
wooden, plastic, or rubber utensils.
Do not use metal utensils.
• Follow the above safety precautions
carefully to avoid serious burn injuries
which may result if breakage occurs
while carafe holds heated liquids.
840155200 ENv01 7/7/06 1:53 PM Page 7
8
Most questions you may have about your new Coffeemaker can be easily
answered. This handy guide lists some common Coffeemaker problems and tells
you how to correct them. If you need further assistance, please call our toll-free
customer assistance number listed on the front cover of this booklet and found
on the back of the Coffeemaker.
Doesn’t brew or
won’t heat.
Filter Basket or
Pause ’N Serve
overflows.
To Correct Problem
Longer than
normal brew time.
Problem
• Check to be sure power cord is firmly plugged into a
live power outlet.
• The Automatic Shutoff feature turns the Coffeemaker
off two hours after making the coffee. Turn Coffeemaker
OFF then back ON.
• For clock models, if power has been interrupted the
automatic brew time must be reset.
• Excessive amounts of ground coffee will clog the filter basket. One level tablespoon of ground coffee per
cup is recommended.
• Make sure coffee is not ground too finely. This will
clog the filter. Permanent filters are more likely to
clog than paper filters.
• Be sure to use a good quality cupcake or basketstyle filter. The sides of the filter should be upright
against side of Filter Basket to avoid filter collapsing.
• When using Pause ’N Serve, hot water continues to
flow into Filter Basket and may overflow if Carafe is
not returned to Keep-Hot Plate within 20 seconds.
•
Make sure that Carafe is fully seated on the Keep-Hot
Plate.
• Mineral deposits can build up in the pump of your
Coffeemaker. Periodic cleaning of the inside of your
Coffeemaker is recommended. More frequent cleaning
may be necessary, depending upon the hardness of
your water. See “Cleaning” for more information.
NOTE: Do not disassemble the unit.
Troubleshooting
840155200 ENv01 7/7/06 1:53 PM Page 8
9
If you have a claim under this warranty, please call our Customer Service Number.
For faster service please have model, series, and type numbers ready for operator
to assist you. These numbers can be found on the bottom of your appliance.
MODEL: _______________ TYPE: ________________ SERIES: _________________
Customer Service
This warranty applies to products purchased in the U.S. or Canada.
LIMITED WARRANTY
This product is warranted to be free from defects in material and workmanship for a period
of one (1) year for Hamilton Beach products or one hundred eighty (180) days for ProctorSilex and Traditions products from the date of original purchase, except as noted below.
During this period, we will repair or replace this product, at our option, at no cost. THE
FOREGOING WARRANTY IS IN LIEU OF ANY OTHER WARRANTY OR CONDITION,
WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL INCLUDING, WITHOUT
LIMITATION, ANY STATUTORY WARRANTY OR CONDITION OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. ANY LIABILITY IS EXPRESSLY LIMITED
TO AN AMOUNT EQUAL TO THE PURCHASE PRICE PAID, AND ALL CLAIMS FOR
SPECIAL, INCIDENTAL AND CONSEQUENTIAL DAMAGES ARE HEREBY EXCLUDED.
There is no warranty with respect to the following, which may be supplied with this
product, including without limitation: glass parts, glass containers, cutter/strainers, blades,
seals, gaskets, clutches, motor brushes, and/or agitators, etc. This warranty extends only
to the original consumer purchaser and does not cover a defect resulting from abuse,
misuse, neglect including failure to clean product regularly in accordance with
manufacturer’s instructions, use for commercial purposes, or any use not in conformity
with the printed directions. This warranty gives you specific legal rights, and you may also
have other legal rights which vary from state to state, or province to province. Some states
or provinces do not allow limitations on implied warranties or special, incidental or
consequential damages, so the foregoing limitations may not apply to you.
If you have a claim under this warranty, DO NOT RETURN THE APPLIANCE TO THE
STORE! Please call our CUSTOMER SERVICE NUMBER. (For faster service please have
model, series, and type numbers ready for operator to assist you.)
CUSTOMER SERVICE NUMBERS
In the U.S. 1-800-851-8900
In Canada 1-800-267-2826
hamiltonbeach.com or proctorsilex.com
KEEP THESE NUMBERS FOR FUTURE REFERENCE!
840155200 ENv01 7/7/06 1:53 PM Page 9
Loading...
