Hamilton Beach 40715 User Guide

Espresso Maker

Machine à café espresso

Cafetera de espresso

English ...................... 2

Français .................. 15

Español .................. 28

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Questions? Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

¿Preguntas? Por favor llámenos – nuestros amables representantes están listos para ayudar. MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

Visit hamiltonbeach.com for delicious recipes, tips, and to register your product online!

Consultez hamiltonbeach.ca pour de délicieuses recettes, des conseils pratiques et pour enregistrer votre produit !

¡Visite hamiltonbeach.com.mx para recetas deliciosas, consejos, y para registrar su producto en línea!

Questions ? N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN: 1.800.267.2826

OTHER CONSUMER SAFETY INFORMATION

This product is intended for household use only. WARNING! Shock Hazard: This appliance has a polarized plug (one

wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

IMPORTANT SAFEGUARDS

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs. Care must be

taken, as burns can occur from touching hot parts or from spilled, hot liquid.

3. To protect against electric shock, do not place cord, plug, or

appliance in water or other liquid.

4. Close supervision is necessary when any appliance is used by or

near children.

5. Unplug from outlet when the espresso maker is not in use and

before cleaning. Unplug and allow to cool before putting on or taking off parts and before cleaning the appliance.

6. Appliance must be operated on a flat surface away from the edge

of counter to prevent accidental tipping.

7. Do not operate any appliance with a damaged cord or plug, or

after the appliance malfunctions or is dropped or damaged in any manner. Call our toll-free customer service number for information on examination, repair, or adjustment.

8. The use of accessory attachments not recommended by the

appliance manufacturer may result in fire, electrical shock, or personal injury.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter or touch hot

surfaces, including stove.

11. Be certain filter holder is securely in place when brewing espresso.

Scalding may occur if the filter holder is removed during the brewing cycle.

12. Do not place appliance on or near a hot gas or electric burner or

in a heated oven.

13. Always plug cord into the wall outlet before turning on any

controls. To disconnect appliance, turn controls to OFF and then remove plug from wall outlet.

14. WARNING: To reduce the risk of fire or electric shock, do not

remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

15. Do not use appliance for other than intended use.

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

SAVE THESE INSTRUCTIONS!

Parts and Features

Brew Head

Espresso Filter Holder

Measuring Scoop with Tamping Tool

Frothing Nozzle and Cover

Espresso/Pod Filter Holder

Ground Espresso/ Pod Filter Holder

Removable Cup Rest

Removable Water Reservoir

Removable Drip Tray

ON/OFF Button

Temperature Selection

Pump Button (dispenses coffee)

Steam Control Dial

Frothing Nozzle Wrench

2 3

Make sure all three buttons are in the OFF position (not pushed in) and that the steam control dial is turned fully clockwise to NO STEAM .

Plug in the unit and press ON/OFF button to turn unit on.

Wash all removable parts in warm, soapy water. No parts may be washed in a dishwasher. The water pump must be “primed” before first use to work properly. Operating without water in the reservoir can permanently damage the appliance.

Fill the removable water reservoir to the MAX fill line with cold water and replace securely on the back of unit.

When unit is ready, the light next to the temperature control button will glow green. Place an empty container under frothing nozzle so that nozzle is completely inside container.

Turn the steam control dial counterclockwise to STEAM . Press pump button to pump hot water out of frothing wand for cleaning purposes.

Press pump button again to turn frothing nozzle off; then turn steam control dial clockwise to NO STEAM .

Fill the container about halfway full. NOTE: The green light next to temperature selection button will turn off once pump button is pushed.

Place a container under brew head–it should be wide enough to catch water from both spouts. Press pump button and dispense any remaining water from reservoir.

Before First Use

(Priming the Pump)

Before First Use (cont.)

Press ON/OFF button to turn the unit off. The light next to the button will turn off. Unplug the unit.

Wash all parts again with warm, soapy water and dry thoroughly. WARNING! Shock Hazard. Do not immerse machine, cord, or plug in water or any other liquid. See Cleaning section on page 11 for full instructions.

Press pump button again to turn off.

Align raised dimple on the exterior of espresso/pod filter holder with cutout notch on inside of filter holder. Rotate expresso/pod filter holder 180º to secure in base.

Place ground espresso holder into filter holder. Add one tablespoon of ground espresso for each cup being made. Use shallow holder for 1 cup and deep holder for 2 cups. Press grounds firmly into holder with tamping tool.

Place pod into filter holder. When using single-serve pod, always use the shallower espresso/ pod filter holder. Never put two pods in either filter holder at one time.

Fill the removable water reservoir with desired amount of cold water and replace securely on the back of unit.

How to Use

Holding handle securely, insert filter holder into brew head with handle pointing left. Ensure no grounds are on rim of filter holder.

Rotate the filter holder to the right until it is firmly locked into place.

Plug in and press ON/OFF button to turn unit on. When ready, the light next to the temperature control button will glow green.

Place one or two cups under brew head spouts. If using one cup, use one wide enough to catch espresso from both spouts.

Make sure all three buttons are in the OFF position (not pushed in) and that the steam control dial is turned fully clockwise to NO STEAM .

Wait about 1 minute before removing filter holder from machine to allow espresso grounds and excess water still flowing through the pump to finish. NOTE: Some water may continue to drip intermittently from brew head. This is normal and a result of product operation.

Press pump button to begin the flow of espresso; press pump button again to stop the flow. As espresso dispenses, it will gradually look lighter in color. Allow espresso to drip from filter holder for 15-20 seconds before removing cup(s).

To empty espresso grounds and/or an espresso pod from the filter holder, flip the plastic lever located on the handle of the filter holder and hold the lever open.

How to Use (cont.)

Keeping thumb on handle lever, dispose of espresso grounds and/or pod filter.

Ensure filter holder is cool. Align raised dimple on espresso/pod filter holder with cutout notch in filter holder base; then remove.

Clean filter holder and brew head after each use. See Cleaning instructions on page 11. DO NOT allow grounds to remain in filter holder; this can clog filter holder and cause unit to malfunction.

Ensure there is water in the removable water reservoir and move the frothing nozzle to the right of the unit.

Press the temperature selection button.

Plug unit in; press ON/OFF button to begin heating water. When heated, the light next to temperature selection button will glow.

Turn the steam control dial to NO STEAM position .

How to Steam Milk

Fill a metal or ceramic cup 1/3 full with cold milk. A stainless steel cup and skim milk are recommended.

Turn steam control dial counterclockwise to open steam valve. Milk is steamed when cup becomes warm. NOTE: After each time steaming and to prevent clogging nozzle, hold a cup with water under nozzle and “steam” into the cup to clean.

Hold cup underneath frothing nozzle, leaving about 1/4 to 1/2 inch between the nozzle and the bottom of the cup.

Turn steam control dial to NO STEAM . Press ON/OFF button (light will go out); then press temperature selection button again to turn off steam temperature. Unplug unit from outlet. Clean the frothing nozzle after each use.

Burn Hazard. Vapor and water emitted from frothing nozzle are hot.

w WARNING

Ensure there is water in the removable water reservoir and move the frothing nozzle to the right of the unit.

Press the temperature selection button.

Plug unit in; press ON/OFF button to begin heating water. When heated, the light next to temperature selection button will glow.

Turn the steam control dial clockwise to NO STEAM .

Hold cup underneath frothing nozzle, leaving about 1/4 to 1/2 inch between the nozzle and the bottom of the cup.

Rotate steam control dial about 3/4 turn toward steam. Hold cup under frothing nozzle until desired consistency is reached. Froth should be stiff and scoopable with a spoon.

How to Froth Milk

Fill a metal or ceramic cup 1/3 full with cold milk. A stainless steel cup and skim milk are recommended.

Recipes

Espresso

Cappuccino

Latte

Iced espresso, cappuccino, or latte

Mocha

Brew one or two cups at a time following directions. Optional: Add sugar to taste.

Mix 1/3 espresso, 1/3 steamed milk, and 1/3 frothed milk. Top with ground nutmeg, ground cinnamon, powdered chocolate, or vanilla to taste.

Mix 1/2 espresso with 1/2 steamed milk. Top with ground nutmeg, ground cinnamon, powdered chocolate, or vanilla to taste.

Mix beverage as described above; then pour over ice.

Mix 1 ounce thick chocolate syrup with 1/3 espresso. Fill with frothed or steamed milk.

Visit hamiltonbeach.com for delicious recipes, tips, and to register your product online!

Cleaning

Turn steam dial to STEAM and empty any remaining liquid from frothing nozzle into container/cup of water.

Place a container under brew head–it should be wide enough to catch water from both spouts. Press pump button and dispense at least 1 cup of water for best results.

Electrical Shock Hazard.

Disconnect power before wiping exterior of unit or brew head. Do not immerse cord, plug, or base in any liquid.

w WARNING

Turn steam control knob clockwise to NO STEAM .

Wipe nozzle. Every other use: Remove nozzle tip with wrench on tamping tool and wash in warm, soapy water.

Press ON/OFF button to turn the unit off. The light next to the button will turn off. Unplug the unit.

Wipe exterior and brew head with warm water and damp cloth carefully—nozzle may still be hot.

Wash all parts with warm, soapy water and dry thoroughly. DO NOT wash any parts in a dishwasher.

Tips for Making Espresso

• For best results, use fresh-ground, dark, espresso roast coffee.

• If espresso preground coffee is used, store the unused portion in an

airtight container and keep in a cool, dark area for up to one week.

• The grind of the coffee will affect the taste of the coffee and how the appliance works. If the grind is too coarse, water will flow too fast through the coffee and result in a weaker flavor

. If the grind is too fine, the flavor may be too strong or bitter, and the grounds may clog the filter.

• For hotter espresso, preheat the filter holder, the ground espresso filter, and the pod filter by first brewing water into the cups for a few seconds and then emptying the brewed water. CAUTION: The filter holder, ground espresso filter, and pod filter are hot.

• Espresso beans may be ground in a coffee grinder. For best results, use the Hamilton Beach Custom Grind™ coffee grinder on the espresso setting. If grinding espresso in a store or using a burr mill, then use a setting that is one to two notches coarser than the espresso setting.

• Grind your espresso so that it looks gritty, like salt or sand. It is too fine if it looks like powder and feels like flour. If the coffee is ground too fine, then the water will not flow through the coffee.

• Espresso pods make it even easier to brew a great cup of espresso and cleanup is as easy as throwing out the used pod. Pods can be purchased at many local coffee houses and specialty housewares stores. A Web search for “coffee pods” will also connect you with many coffee pod suppliers.

• Always use cold water to make coffee. Warm water or other liquids could cause damage to the appliance.

POTENTIAL PROBLEM

Espresso will not flow out.

Machine is noisy when operating.

Espresso is too weak.

Espresso is too strong or bitter.

Difficult to froth milk.

Steam runs out too quickly.

PROBABLE CAUSE

• Is the water reservoir empty?

• Is the water reservoir properly fitted into position?

• Make sure that the coffee grounds are not overpacked in the filter.

• Is filter holder properly fitted into the espresso maker?

• Clean the filter, filter holder, and brew head.

• Is the water reservoir empty?

• Is the water reservoir properly fitted into position?

• Is the filter holder properly fitted into position?

• Always use fresh espresso ground coffee and tamp the ground coffee down firmly.

• The longer the brew time, the weaker the espresso (1 serving = 1 to 1-1/2 ounces).

• Be sure there is sufficient ground coffee in the filter.

• Coffee grounds are too coarse.

• Try a different brand or roast of coffee.

• Ensure steam control dial is OFF. If the steam control dial was left on, the water may have been too hot. Rotate steam control dial counterclockwise to release steam into a frothing cup or pitcher and allow appliance to cool. Then repeat steps in the section How to Use.

• Too much espresso ground was used.

• Grounds were too fine.

• Brew longer before pressing espresso button to OFF.

• Try different a different brand or roast of coffee.

•

Use the Hamilton Beach Custom Grind™coffee grinder.

• Always use fresh, cold milk (skim milk is recommended).

• Use a cold, stainless steel cup and move the cup slightly up and down while frothing.

• Clean the frothing nozzle.

• Make sure that the steam button is depressed and that the temperature/ready light is on.

• Trying to froth too much milk; reduce amount of milk in cup.

• Reprime the pump. See Before First Use on page 4.

Troubleshooting

Limited Warranty

This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use.

We exclude all claims for special, incidental and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability

or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary

depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.
