Hamilton Beach 31195 User Manual

840119500

Countertop Oven with Convection

English ................................................ 2

USA: 1-800-851-8900

Français ............................................ 14

Canada : 1-800-267-2826

Español .............................................. 26

México: 01 800 71 16 100

Le invitamos a leer cuidadosamente este

instructivo antes de usar su aparato.

Four à convection de comptoir

Horno de convección para mostrador

840119500 ENv02.qxd 12/5/03 2:26 PM Page 1

2

Consumer Safety Information

IMPORTANT SAFEGUARDS

When using electric appliances, basic safety
precautions should always be followed, including
the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock do not
immerse cord, plug, or oven in water or other
liquid.

4. Close supervision is necessary when any appli­ance is used by or near children.

5. Unplug from outlet when not in use and before
cleaning. Allow to cool before cleaning appliance
and putting on or taking off parts.

6. Do not operate any appliance with a damaged
cord or plug, or after the appliance malfunctions
or is dropped or damaged in any manner. Call
our toll-free customer service number for
information on examination, repair or adjustment.

7. The use of accessory attachments not recom­mended by the manufacturer may cause
injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or
counter, or touch hot surfaces, including the stove.

10. Do not place on or near a hot gas or electric
burner, or in a heated oven.

11. Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
Be sure to allow hot oil or liquids to cool before
moving appliance.

12. To disconnect, turn any control to Off, then
remove plug from wall outlet.

13. Use extreme caution when removing tray or dis­posing of hot grease.

14. Do not clean with metal scouring pads. Pieces
can break off the pad and touch electrical parts,
creating a risk of electrical shock.

15. Oversize foods or metal utensils must not be
inserted in a oven as they may create a fire or
risk of electric shock.

16. A fire may occur if the oven is covered, touching
or near flammable material, including curtains,
draperies, walls, and the like, when in operation.
Do not store any item on top of the appliance
when in operation, or before the appliance cools
down.

17. Extreme caution should be exercised when
using containers constructed of other than metal
or glass.

18. Do not store any materials, other than manufac­turer-recommended accessories, in this oven.

19. Do not place any of the following materials in
the oven: paper, cardboard, plastic, and the like.

20. Do not cover crumb tray or any part of the oven
with metal foil. This will cause overheating of the
oven.

21. To turn oven off, turn Timer to OFF position. See
“Parts and Features” section.

22. Do not place eyes or face in close proximity with
tempered safety glass door, in the event that the
safety glass breaks.

23. Always use appliance with crumb tray securely
in place.

24. Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

This appliance is intended for household use only.

This appliance is equipped with a polarized plug. This type
of plug has one blade wider than the other. The plug will fit
into an electrical outlet only one way.This is a safety fea­ture intended to help reduce the risk of electrical shock. If
you are unable to insert the plug into the outlet, try revers­ing the plug. If the plug should still fail to fit, contact a quali­fied electrician to replace the obsolete outlet. Do not
attempt to defeat the safety purpose of the polarized plug
by modifying the plug in any way.

The length of the cord used on this appliance was selected
to reduce the hazards of becoming tangled in, or tripping
over a longer cord. If a longer cord is necessary an
approved extension cord may be used. The electrical rating
of the extension cord must be equal to or greater than the
rating of the oven. Care must be taken to arrange the
extension cord so that it will not drape over the countertop
or tabletop where it can be pulled on by children or acci­dentally tripped over.

This appliance is equipped with a fully tempered safety
glass door.The tempered glass is four times stronger than
ordinary glass and more resistant to breakage. Tempered
glass can break, however it breaks into pieces with no
sharp edges. Care must be taken to avoid scratching door
surface or nicking edges. If the door has a scratch or nick,
call our toll-free customer service number.

Always unplug your oven from the outlet when not in use.

Before First Use

Most heating appliances produce an odor and/or smoke
when used for the first time. Plug the oven into an outlet.
Turn the Temperature Knob to 450°F (230ºC). Heat at this
temperature for 10 minutes. The odor should not be pre­sent after this initial preheating. Wash all accessories
before using.

840119500 ENv02.qxd 12/5/03 2:26 PM Page 2

3

Parts and Features

1. Power Indicator Light

2. Temperature Knob

3. Function Knob

4. ON/OFF ( O ) Oven Control/Timer

5. Oven Rack (2)

6. Slide-Out Tray

7. Rotisserie Forks on Rotisserie Rod

(Rotisserie Skewer)

8. Rotisserie Lift

9. Pizza Pan

*optional feature on certain models

Broiler Rack

Bake Pan

Rotisserie Forks on Rotisserie Rod*

(Rotisserie Skewer)

Rotisserie Lift

Pizza Pan

840119500 ENv02.qxd 12/5/03 2:27 PM Page 3

4

How to Use Your Oven

1. Place oven rack in middle or low
position depending on
food to be cooked.

When cooking pizza, place pizza

pan on top of rack
with pizza pan
legs aligned to
drop into oven
rack slots.

2. Set Temperature Knob to desired
temperature.

3. Set Function Knob to BAKE.

4. Set Timer to 10 minutes or Stay On

to preheat oven for 10 minutes.

5. Place food to be baked into oven.

6. Set Timer to desired time or to Stay

On.

7. When finished, turn OFF. Unplug
from outlet.

Baking and Traditional Cooking

Warming and Reheating Tips

• Do not totally enclose foods in alu­minum foil. Foil can insulate foods
and slow down heating.

• To reheat rolls or biscuits, place
on baking pan and heat at 300ºF
(150ºC) for 10 minutes.

• Reheat leftover roasts or casseroles
at 350ºF (180ºC) for 20 to 30 minutes
or until heated through.

Pan Sizes

The following pans should fit your oven. To be sure, place the pan in the oven to
check the fit before preparing the recipe.

6-cup muffin pan
2 8 x 4-inch (20 x 10 cm) loaf pans
9 x 5-inch (23 x 13 cm) loaf pans
2 8-inch (20 cm) round or square baking pans
Most 1 to 11⁄2 quart (1 to 11⁄2 L) casserole dishes

Baking Tips

• The convection method cooks up to
one-third faster than traditional baking.

• When first using, check to determine
if time or temperature should be
adjusted.

• Cooking time will vary considerably
depending on the meat's thickness.
Cook until thermometer inserted in
the center of the meat registers
desired doneness.

wWARNING

Fire Hazard

To reduce risk of fire, do not use oven
cooking bags in this oven.

840119500 ENv02.qxd 12/5/03 2:27 PM Page 4

5

Broiling

1. Place oven rack in high or middle

position. Place food on broil rack in
the bake pan and place in oven.
Do not preheat oven.

2. Set Temperature Knob to 500ºF

(260ºC).

3. Set Function Knob to Broil.

4. Set Timer between 5 and 15 minutes

or to Stay On.

5. Halfway through cooking time, or
when food has browned, turn food
over to brown and cook other side.

6. When finished, turn OFF. Unplug
from outlet.

Broiling Tips

• For best results, do not preheat oven
when broiling.

• Always allow at least one inch
between the food and the heating
element.

• Use oven rack in high position for
faster broiling times. Use low position
for foods needing longer broiling
times, like chicken.

These cooking times are an average and should be adjusted to individual
preferences. Turn foods halfway through cooking time.

Broiling Chart

APPROXIMATE TIME

20 minutes
15 minutes
15 to 20 minutes

15 minutes

FOOD

Hamburgers
Hot Dogs

Sausage Links or Patties
(pierce casings before cooking)

Fish

Optional Features (available on certain models)

Convection Cooking

NOTE: Most food items will bake up to one-third faster in convection mode than

traditional bake mode.

1. Place oven rack in middle or low
position depending on
food to be cooked.

2. Set Temperature Knob to desired
temperature.

3. Set Function Knob to Convection.

4. Set Timer to 10 minutes or Stay On

to preheat 10 minutes before begin­ning to bake.

5. Place food to be baked into oven.

6. Set Timer between 5 and 15 minutes

or to Stay On.

7. When finished, turn OFF. Unplug
from outlet.

840119500 ENv02.qxd 12/5/03 2:27 PM Page 5

6

Optional Features (cont.)

1. Place oven rack in lowest position
then place bake pan on rack.

2. Preheat oven to desired temperature.
NOTE: The bottom heating elements

will not come on during rotisserie
cooking.

3. Insert Rotisserie Rod into center of

meat.

NOTE: Chicken and large pieces of

meat must be
tied with cotton
string. Chicken
wings and legs
must be tied
tightly to pre­vent them from
hitting the bake

pan. The oven
can accommodate up to a 5-pound
chicken if centered and tied properly.

4. Place Rotisserie Forks on Rod with
Forks inserted
into the bottom
side of the
chicken.
Center meat
lengthwise on
rod.

5. Tighten the screws on the Rotisserie

Forks after the meat is centered on
the Rod.

6. Turn oven to OFF; use Rotisserie Lift
to insert the Rod
into oven with
the pointed end
of Rod inserted
into the right
side of oven. Lift
Rod above
bracket on left
side of oven and

rest Rod on the bracket. Place bake
pan under meat.

7. Turn Function Knob to the Rotisserie

setting.
NOTE: Always turn oven to OFF to
check meat temperature or to
remove meat from oven.

8. To remove cooked meat from oven,

place the Rotisserie Lift with the
hooks under the Rotisserie Rod. Lift
and slide the Rotisserie Rod to the
left and remove from the oven.

9. Place meat on a clean surface and

use a pot holder to unscrew the
Rotisserie Forks from Rotisserie Rod.
Slide meat onto a serving tray or cut­ting surface.

Rotisserie Cooking

840119500 ENv02.qxd 12/5/03 2:27 PM Page 6

7

Cleaning Your Oven

Your oven’s slide out tray should be
cleaned regularly for best performance
and long life.

1. Unplug oven and allow to cool.

2. Wash oven rack and baking pan in

hot, soapy water. Rinse and dry.

3. To clean the crumb tray, slide out
and wipe crumb tray with a damp
cloth. Slide back into position.

4. To clean the oven interior walls and
outside of oven, wipe with a damp
cloth. Do not use abrasive cleansers.
Do not clean with metal scouring
pads. Pieces can break off metal
scouring pad and touch electrical
parts, causing a risk of electric shock.

Troubleshooting

The oven will not heat.

Check to make sure the outlet is working and the oven is plugged in. Next turn
Temperature Knob to 350°F (180ºC), turn Function Knob to Bake, and turn Timer to
Stay On.

An odor and smoke comes from the oven.

Smoke and odor is normal during the first use of most heating appliances. This will
not be present after the initial heating period.

Some foods burn and some are not done.

Use oven rack position to center food in the oven. Adjust oven temperature or
cooking time for best results with your recipes.

Baking Recipes

Roast Chicken

To roast a whole chicken in the oven, it must be 7 pounds or smaller.

Baked Potatoes

4 medium baking potatoes, about 10-ounces each
To preheat oven, set Temperature Control Knob to 425ºF (220ºC); set Function

Knob to Bake. Wash potatoes then pierce skin with a fork. Place potatoes on bak­ing pan and put in oven. Bake for 1 hour or until done. Do not wrap in aluminum
foil as this may increase cooking time.

Hot Mexican Bean Dip

15-ounce (425 g) can black beans,

well drained

1 teaspoon (5 ml) hot pepper sauce

1

⁄3 cup (80 ml) sour cream

To preheat oven, set Temperature Control Knob to 350ºF (180ºC); set Function
Knob to Bake. Mash black beans. Add hot pepper sauce, sour cream, salsa and
half of the cheese. Spoon into shallow casserole dish. Sprinkle remaining cheese
on top. Bake for about 10 minutes, or until bubbly. Serve with tortilla chips.

Makes 3 cups.

1

⁄3 cup (80 ml) salsa

4 ounces (115 g) Monterey Jack cheese,

grated

840119500 ENv02.qxd 12/5/03 2:27 PM Page 7

8

Baking Recipes

Mini Meat Loaves

1 pound (450 g) lean ground beef
1 small onion, finely chopped

3

⁄

4 cup (175 ml) fresh bread crumbs

1 egg, beaten
1 tablespoon (15 ml) Parmesan cheese,

grated

To preheat oven, set Temperature Control Knob to 350ºF (180ºC); set Function
Knob to Bake. Combine all ingredients and mix well. Divide mixture in a 6-cup
muffin pan. Bake for 30 minutes or until done. Makes 4 to 6 servings.

Minute Muffins

1 cup (250 ml) self-rising flour

1

⁄2 cup (125 ml) milk

2 tablespoons (30 ml) mayonnaise or sour cream
To preheat oven, set Temperature Control Knob to 450ºF (230ºC); set Function

Knob to Bake. Stir together ingredients. Spoon into greased 6 cup muffin pan.
Bake for 12 minutes or until done. Makes 6 muffins.

5 Minute Pizza

English muffins, split in half and
slightly toasted
Pizza or spaghetti sauce

To preheat oven, set Temperature Control Knob to 450ºF (230ºC); set Function
Knob to Bake. Place muffin halves on baking pan cut side up. Spread some sauce
on top of each muffin. Sprinkle with cheese then top with pepperoni. Place pan in
oven and bake for about 5 minutes or until cheese melts.

Raspberry-Pepper Glazed Ham

1 9 to 10-pound (4050 g – 4500 g)

cooked bone-in spiral-cut ham

1 12-ounce (350 g) jar raspberry

preserves

2 tablespoons (30 ml) white vinegar
To preheat oven, set Temperature Control Knob to 350ºF (180ºC); set Function

Knob to Bake.
Place oven rack in lowest position. Assemble broil rack in baking pan and place

ham on rack. Prepare and heat ham according to package directions.
In a saucepan, combine raspberry preserves, white vinegar, garlic, black pepper,

and raspberry liqueur, (optional). Cook on medium until small bubbles appear
around edge. Brush half of glaze over ham 30 minutes before it is done. Bake for
final 30 minutes. Reheat remaining glaze. Remove glazed ham from oven. Spoon
remaining glaze over ham just before serving. Makes 20 servings.

1 tablespoon (15 ml) fresh parsley,

finely chopped

1

⁄4 teaspoon (1.25 ml) salt

1

⁄

4 teaspoon (1.25 ml) pepper

Grated mozzarella cheese
Pepperoni slices

1 tablespoon (15 ml) garlic, minced
1 tablespoon (15 ml) black pepper
2 tablespoons (30 ml) raspberry

liqueur, optional

840119500 ENv02.qxd 12/5/03 2:27 PM Page 8

9

Honey Bun Cake

1

⁄2 cup (125 ml) packed brown sugar

1

⁄2 cup (125 ml) white sugar

1

⁄3 cup (80 ml) chopped pecans (optional)
2 teaspoons (10 ml) ground cinnamon
1 package 18.25 ounce (517g)

yellow cake mix

To preheat oven, set Temperature Control Knob to 350ºF (180ºC); set Function
Knob to Bake.

Grease bottom and sides of a bunt pan with shortening; lightly flour. In a small
bowl, mix brown sugar, white sugar, pecans (optional), and cinnamon until well
blended; set aside. In a large bowl, beat cake mix, oil, eggs, and yogurt with an
electric mixer on medium speed for 2 minutes. Spread half of the batter in the
pan. Evenly spread cinnamon mixture over the batter. Spread remaining batter
over the cinnamon layer. Bake about 55 minutes or until toothpick inserted in to
the center comes out clean. Allow cake to cool 10 minutes and turn on to plate.

Makes 12 servings.

Honey Bun Cake Glaze

1 cup (250 ml) powered sugar
2 teaspoons (10 ml) milk

1

⁄2 teaspoon (2.5 ml) vanilla or desired extract
In a small bowl, mix powered sugar, milk, and extract until smooth. Prick top of

cake with fork and drizzle glaze over cake while slightly warm.

Easy Banana Bread

1 package 18.25 ounce (517g)

white cake mix

1 cup (250 ml) ripe banana

(about 2 medium), mashed

To preheat the oven, set Temperature Control Knob to 350ºF (180ºC); set Function
Knob to Bake. Grease bottom and sides of two 9x5x3 inch (23 x 13 x 6 cm) loaf
pans with shortening; lightly flour.

In a large bowl, beat cake mix, bananas, buttermilk, oil, and eggs with electric mixer
on medium speed for 2 minutes. Stir in nuts if desired. Pour into prepared pans. Bake
for 40 minutes or until toothpick inserted into the center comes out clean. Allow cake
to cool 10 minutes before removing from pan. Repeat for second loaf. Makes 16

servings.

Cranberry Pork Roast with Sweet Potatoes

3 sweet potatoes, peeled and quartered
1 2-pound (900 g) boneless pork roast
14-ounce (400 g) can whole berry

cranberry sauce

To preheat the oven, set Temperature Control Knob to 400ºF (205ºC); set Function
Knob to Bake.

Place sweet potatoes in the bottom of roasting pan. Wash roast and place on top
of the potatoes. In a medium bowl, mash cranberry sauce; stir in sugar, cloves,
and salt. Pour over roast and potatoes. Bake until thermometer inserted in the
canter of the roast registers 160ºF (71ºC), 45 to 60 minutes. Makes 4 servings.

2

⁄3 cup (150 ml) vegetable oil
4 eggs
8 ounces (225 g) plain yogurt

1

⁄2 cup (125 ml) buttermilk

1

⁄3 cup (80 ml) vegetable oil
3 eggs, beaten
1 cup (250 ml) chopped nuts, (optional)

1

⁄2 cup (125 ml) sugar

1

⁄4 teaspoon (1.25 ml) ground cloves

Salt to taste

840119500 ENv02.qxd 12/5/03 2:27 PM Page 9

10

Pumpkin Cookies

1 package 18.25 ounce (517g) white

cake mix
2 teaspoons (10 ml) pumpkin pie spice
1 cup (250 ml) canned pumpkin

To preheat the oven, set Temperature Control Knob to 375ºF (190ºC); set Function
Knob to Convection. Lightly spray cookie sheet with nonstick cooking spray.

Beat cake mix, pumpkin pie spice, pumpkin, and butter with electric mixer on
medium speed for 2 minutes. Stir in raisins, (optional). Scoop out 1 tablespoon
(15 ml) of dough, and place on prepared cookie sheet. Repeat with the remaining
dough, placing scoops 2 inches (5 cm) apart. Bake for 10 to 12 minutes or until
lightly browned around edges. Allow to sit on cookie sheet and cool 1 to 2 min­utes before transferring to cooling rack. Makes 24 servings.

Double Corn Bread

1

⁄4 cup (60 ml) milk

1 egg

1

⁄4 cup (60 ml) vegetable oil

To preheat the oven, set Temperature Control Knob to 425ºF (220ºC); set Function
Knob to Convection. Grease a 6-muffin tin.

In a large bowl, stir egg, milk, and oil together. Add cream corn and cornmeal mix;
stir until cornmeal is just dampened. Pour batter into muffin tins. Bake for 20 min­utes or until golden brown. Makes 6 servings.

Herb Roasted Turkey Breast

1 7 pound (3150 g) turkey breast,

fresh or frozen, thawed
1 teaspoon (5 ml) ground thyme
1 teaspoon (5 ml) rosemary leaves,

crushed
To preheat the oven, set Temperature Control Knob to 400ºF (205ºC); set Function

Knob to Convection.
Assemble broiler rack in back pan and spray with nonstick cooking spray. Wash

turkey breast and pat dry with paper towel. Place turkey breast on rack breast
side up. In small bowl mix thyme, rosemary, garlic, butter, salt, and pepper; rub
mixture evenly on turkey breast. Roast turkey breast 21⁄2 hours or until internal
temperature reaches 180ºF (82ºC). Remove from oven, cover and allow to rest for
15 minutes before carving. Makes 8 servings.

1

⁄4

cup (60 ml) butter or margarine,
softened

1

⁄2 cup (125 ml) raisins, (optional)

Convection Recipes

1 8-ounce (225 g) can corn, cream style
2 cups (500 ml) self-rising corn meal mix

1

⁄2 teaspoon (2.5 ml) garlic, minced

1

⁄2 cup (125 ml) butter, softened

Salt and pepper to taste

840119500 ENv02.qxd 12/5/03 2:27 PM Page 10

11

Sage Pork Roast with Apple

1 2-pound (450 – 900 g) pork roast
1 teaspoon (5 ml) dried sage

1

⁄2 teaspoon (2.5 ml) black pepper
1 tablespoon (15 ml) garlic, minced
Salt to taste

To preheat the oven, set Temperature Control Knob to 450ºF (230ºC); set Function
Knob to Bake.

Place oven rack on lowest setting. Place roast on rotisserie assembly following
instructions on page 6. In a small bowl combine sage, pepper, garlic and salt. Rub
mixture on roast, place bacon slices across top of roast prior to tying. Tie the roast
and place in oven. Put apples and onions in the baking pan and place on oven
rack under roast. Roast for 1 to 11⁄2 hours or until meat thermometer registers
160ºF (71ºC). Stir apples and onions to coat with pan juices. Makes 6 servings.

Herb-Rubbed Chicken

1 tablespoon (15 ml) dried sage leaves
1 teaspoon (5 ml) dried ground thyme
1 teaspoon (5 ml) black pepper

1

⁄4 teaspoon (1.25 ml) celery salt
To preheat the oven, set Temperature Control Knob to 400ºF (205ºC); set Function

Knob to Bake.
Wash chicken and pat dry with paper towels. Place chicken on rotisserie assembly

following instructions on page 6.
In a small bowl, combine sage, thyme, pepper, celery salt, and paprika. Brush

chicken with olive oil. Rub herb mixture over entire chicken. Roast for 2 hours or
until thermometer registers 180ºF (82ºC). Makes 4 to 5 servings.

Rotisserie Recipes

4 slices bacon
3 medium cooking apples, cored and

sliced

1 large onion, pealed and quarter

1

⁄2 teaspoon (2.5 ml) paprika
1 4-pound (1800 g) chicken
Olive oil

840119500 ENv02.qxd 12/5/03 2:27 PM Page 11
