Hamilton Beach 31117 User Manual
English ........................................................................................ 2
USA: 1-800-851-8900
Visit proctorsilex.com for delicious recipes and to register your product online!
Français .................................................................................... 11
Canada : 1-800-267-2826
Consulter proctorsilex.ca pour les recettes
délicieuses et pour enregistrer votre produit !
Español ...................................................................................... 21
En México: 01-800-71-16-100
Visite proctorsilex.com para recetas deliciosas y para
registro de su producto en línea.
Toaster Oven
Four grille-pain
Horno eléctrico
840164600
READ BEFORE USE
À LIRE AVANT UTILISATION
LEA ANTES DE USAR
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
840164600 ENv02.qxd 3/22/07 1:53 PM Page 1
3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plug,
or toaster oven in water or other liquid.
4. Close supervision is necessary when any appliance is used by
or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to
cool before cleaning appliance and putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or plug, or
after the appliance malfunctions or is dropped or damaged in
any manner. Call our toll-free customer service number for
information on examination, repair or electrical or mechanical
adjustment.
7. The use of accessory attachments not recommended by
Hamilton Beach/Proctor-Silex, Inc. may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
2
SAVE THESE INSTRUCTIONS!
10. Do not place on or near a hot gas or electric burner, or in a
heated oven.
11. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids. Be sure to allow hot oil
or liquids to cool before moving appliance.
12. To disconnect, turn all controls to Off ( O ), then remove plug
from wall outlet.
13. Use extreme caution when removing tray or disposing of hot
grease.
14. Do not clean with metal scouring pads. Pieces can break off the
pad and touch electrical parts, creating a risk of electrical shock.
15. Oversize foods or metal utensils must not be inserted in a
toaster oven as they may create a fire or risk of electric shock.
16. A fire may occur if the toaster oven is covered, touching or near
flammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any item on top of the
appliance when in operation, or before the appliance cools down.
17. Extreme caution should be exercised when using containers
constructed of materials other than metal or glass.
18. Do not store any materials, other than Hamilton Beach/
Proctor-Silex, Inc. recommended accessories, in this oven.
19. Do not place any of the following materials in the oven: paper,
cardboard, plastic, and the like.
20. Do not cover crumb tray or any part of the oven with metal foil.
This will cause overheating of the oven.
21. To turn oven off, turn ON/OFF Control Dial to Off ( O ) position.
See “Parts and Features” section.
22. Do not place eyes or face in close proximity with tempered
safety glass door, in the event that the safety glass breaks.
23. Always use appliance with crumb tray securely in place.
24. Do not use appliance for other than intended use.
25. Clean oven interior carefully. Do not scratch or damage heating
element tube.
wWARNING
Fire Hazard
• If contents ignite, do not open oven door. Unplug oven and allow
contents to stop burning and cool before opening door.
• Do not operate unattended while in Toast or Broil modes.
• Do not use with oven cooking bags.
• Always allow at least one inch between food and heating element.
• Always unplug toaster oven when not in use.
• Regular cleaning reduces risk of fire hazard.
840164600 ENv02.qxd 3/22/07 1:53 PM Page 2
5
4
This appliance is intended for household use only.
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping over a longer
cord. If a longer cord is necessary an approved extension cord may
be used. The electrical rating of the extension cord must be equal
to or greater than the rating of the toaster oven. Care must be
taken to arrange the extension cord so that it will not drape over
the countertop or tabletop where it can be pulled on by children or
accidentally tripped over.
This appliance is equipped with a fully tempered safety glass door.
The tempered glass is four times stronger than ordinary glass and
more resistant to breakage. Tempered glass can break, however it
breaks into pieces with no sharp edges. Care must be taken to
avoid scratching door surface or nicking edges. If the door has a
scratch or nick, call our toll-free customer service number.
Always unplug your toaster oven from the outlet when not in use.
Before First Use
Most heating appliances produce an odor and/or smoke when
used for the first time. Plug the toaster oven into an outlet. Turn
the Function/Temperature Knob to 450°F (220ºC). Heat at this
temperature for 10 minutes. The odor should not be present after
this initial preheating. Wash baking pan and oven rack before
using.
OTHER CONSUMER SAFETY INFORMATION
PPaarrttss aanndd FFeeaattuurreess
1. Function/Temperature Knob – To select the Oven
Temperature, Broil , or Toast .
2. ON / OFF ( O ) / Toast Shade Selector/Timer
3. Indicator Light – Lit when oven is on or when toasting.
4. Baking Pan
5. Crumb Tray
6. Oven Rack
Do not leave appliance unattended when in operation.
840164600 ENv02.qxd 3/22/07 1:53 PM Page 4
7
6
TTooaassttiinngg TTiippss
THIS OVEN RETAINS HEAT VERY WELL. WHEN MAKING
MORE THAN ONE BATCH OF TOAST, THE TOAST SHADE
SELECTOR SHOULD BE SET TO A LIGHTER COLOR ON
THE SECOND BATCH TO GET THE SAME SHADE OF
TOAST AS THE FIRST.
• If bottom surface of the toast is too light, place bread
near back of oven. This toasts top and bottom more evenly
than if placed in center of oven.
• To toast regular toaster pastry, frozen pastry, or waffles,
select a light color and toast directly on oven rack. If pastry
has a glaze of frosting, use baking pan.
• The number of slices of bread, bread freshness, and
starting temperature of oven will affect toast color. If oven
is already hot, select a lighter shade of toast than normal.
Adjust Toast Shade Selector to achieve desired color.
TToo BBaakkee
TToo TTooaasstt
IMPORTANT! Function/Temperature Knob
must be in TOAST position or unit will not
toast properly.
1. Place toast on oven rack.
2. Set Function/Temperature Knob to TOAST.
3. Rotate Toast Shade Selector/Timer Knob
past 5 then set to desired toast color.
4. The bell will sound at the end of the toast
cycle. To stop cycle, turn Toast Shade
Selector/Timer knob to OFF.
Fire Hazard
• Keep one inch between food and heating element.
• Do not use oven cooking bags.
• Do not heat foods in plastic containers.
• Follow food manufacturers instructions.
w WARNING
1. Select temperature then set Timer to 5 and
let preheat for five minutes before beginning
to bake.
2. Set Timer to desired time or ON. The
indicator light will come on and oven
will begin baking.
3. When finished, turn OFF. Unplug from outlet.
Baking Tips:
• Most foods should be baked according to package or recipe
directions. Watch carefully and adjust the time or temperature
if necessary.
• For baked potatoes, bake at 425ºF (220ºC) for 1 hour or until
done.
Fire Hazard
Do not leave oven unattended during toasting.
w WARNING
840164600 ENv02.qxd 3/22/07 1:53 PM Page 6
9
8
TToo BBrrooiill
1. Place baking pan on the oven rack.
2. Set the Function Selector Knob to Broil.
3. Set Timer to desired time or ON. The Indicator Light will
come on. Only the
top heating element will come on during the Broil Function.
4. Halfway through cooking time, or when food has browned,
turn food over to brown and cook other side.
5. When finished turn OFF; unplug from outlet.
BROILING TIPS:
• For best results, do not preheat when broiling.
• Always allow at least one inch between the food and the
heating element.
• Single-serving meats are broiled to doneness in approximately 15 to 20 minutes.
CClleeaanniinngg tthhee OOvveenn
For best performance and long life, clean toaster oven regularly.
1. Unplug oven and allow to cool.
2. Wash oven rack and baking pan in hot, soapy water. Rinse
and dry. Do not use abrasive cleansers or steel wool.
3. To clean the inside of the oven, wipe oven walls, bottom
of oven, and glass door with a damp, soapy cloth. Repeat
with a damp, clean cloth.
4. For stubborn stains, use a plastic scouring pad.
5. To clean the outside of the oven, wipe with a damp cloth.
Do not use abrasive cleansers.
The toaster oven will not heat.
Make sure electrical outlet is working and oven is plugged in.
Next turn Function/Temperature Knob to 350°F (175ºC). Turn
ON/OFF Knob to ON. The Indicator Light should now be lit.
The toaster oven will not toast.
Make sure outlet is working and the oven is plugged in.
1. Set Function/Temperature Knob to TOAST.
2. Select toast color.
The Indicator Light should now be lit. The oven will not toast
properly unless the ON/OFF Knob is set to TOAST.
TTrroouubblleesshhoooottiinngg
Fire Hazard
• Keep one inch between food and heating element.
• Do not use oven cooking bags.
• Do not heat foods in plastic containers.
• Follow food manufacturers instructions.
w WARNING
• Failure to clean the oven interior regularly may result in
fire hazard.
• Do not clean with metal scouring pads. Pieces can break off
pad and touch electrical parts, causing a risk of electric shock.
w WARNING
840164600 ENv02.qxd 3/22/07 1:53 PM Page 8
10
This warranty applies to product purchased in the U.S.
or Canada.
LIMITED WARRANTY
This product is warranted to be free from defects in material and
workmanship for a period of one hundred eighty (180) days from the date of
original purchase, except as noted below. During this period, we will repair
or replace this product, at our option, at no cost. THE FOREGOING
WARRANTY IS IN LIEU OF ANY OTHER WARRANTY OR CONDITION,
WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL INCLUDING,
WITHOUT LIMITATION, ANY STATUTORY WARRANTY OR CONDITION OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ANY
LIABILITY IS EXPRESSLY LIMITED TO AN AMOUNT EQUAL TO THE
PURCHASE PRICE PAID, AND ALL CLAIMS FOR SPECIAL, INCIDENTAL
AND CONSEQUENTIAL DAMAGES ARE HEREBY EXCLUDED. There is no
warranty with respect to the following, which may be supplied with this
product, including without limitation: glass parts, glass containers,
cutter/strainers, blades, seals, gaskets, clutches, motor brushes, and/or
agitators, etc. This warranty extends only to the original consumer
purchaser and does not cover a defect resulting from abuse, misuse,
neglect including failure to clean product regularly in accordance with
manufacturer’s instructions, use for commercial purposes, or any use not in
conformity with the printed directions. This warranty gives you specific legal
rights, and you may also have other legal rights which vary from state to
state, or province to province. Some states or provinces do not allow
limitations on implied warranties or special, incidental or consequential
damages, so the foregoing limitations may not apply to you.
If you have a claim under this warranty, DO NOT RETURN THE
APPLIANCE TO THE STORE! Please call our CUSTOMER SERVICE
NUMBER. (For faster service please have model, series, and type numbers
ready for operator to assist you.)
CUSTOMER SERVICE NUMBERS
In the U.S. 1-800-851-8900
In Canada 1-800-267-2826
proctorsilex.com
KEEP THESE NUMBERS FOR FUTURE REFERENCE!
840164600 ENv02.qxd 3/22/07 1:53 PM Page 10
Loading...
