Hamilton Beach 11550 User Guide

READ BEFORE USE
By Neil Iwan at 3:19 pm, Nov 12, 2014
LIRE AVANT UTILISATION LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online!
¡Visite www.hamiltonbeach.com ( o
www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos!
Questions? Please call us – our friendly associates are ready to help. USA: 1.800.851.8900
Questions ? N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826
¿Preguntas? Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.
EE. UU.)
Garment Steamer
Presseur de vêtements
à la vapeur
Vaporera para
Prendas
English ...................... 2
Français .................. 10
Español ................... 18
840188403 ENv02.indd 1840188403 ENv02.indd 1 11/12/14 2:08 PM11/12/14 2:08 PM
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they do not play with the appliance.
4. Do not leave appliance unattended while connected.
5. To reduce the risk of contact with hot water emitting from steam
vents, check appliance before each use by holding it away from body and operating steam button.
6. Use appliance only for its intended use.
7. To reduce the risk of electric shock, do not immerse the
appliance in water or other liquids.
8. Never yank cord to disconnect from outlet; instead, grasp plug
and pull to disconnect.
9. Do not allow cord to touch hot surfaces. Let appliance cool
completely before putting away. Loop cord loosely around appliance when storing.
10. Always disconnect appliance from electrical outlet when filling
with water or emptying, and when not in use.
11.
Do not operate appliance with a damaged cord, or if the appliance has been dropped or damaged. To reduce the risk of electric shock, do not disassemble or attempt to repair the appliance, take it to a qualified service person for examination and repair. Incorrect reassembly or repair could cause a risk of fire, electric shock, or injury to persons when the appliance is used.
12. Burns could occur from touching hot metal parts, hot water,
or steam. Use care when you turn a steam appliance upside down—there may be hot water in the reservoir.
13. To avoid a circuit overload, do not operate another high-wattage
appliance on the same circuit.
14. If an extension cord is absolutely necessary, a 15-ampere cord
should be used. Cords rated for less amperage may overheat. Care should be taken to arrange the cord so that it cannot be pulled or tripped over.
SAVE THESE INSTRUCTIONS!
Other Consumer Safety Information
IMPORTANT SAFETY INSTRUCTIONS
This product is intended for household use only.
w WARNING
with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.
2
Electrical Shock Hazard: This product is provided
Direct steam at clothing only. Directing steam toward any other surface may damage that surface.
• Do not steam clothes that are being worn.
• Do not use steam in the direction of people or pets.
840188403 ENv02.indd 2840188403 ENv02.indd 2 11/12/14 2:08 PM11/12/14 2:08 PM
Parts and Features
Steam Nozzle/ Handle
Brush Attachment*
Creasing Attachment*
Steam Nozzle Holder
Retractable Pole Levers
Integrated Garment Hanger
Retractable Pole*
Optional Accessories
on Select Models
*To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826
Mexico:
01 800 71 16 100
Flexible Steam Hose*
ON/OFF Switch
Steam Hose Attachment Opening
Water Tank With Handle*
Brush Attachment
Snap onto steam nozzle.
Creasing Attachment
Power Cord
Rolling Caster Feet
840188403 ENv02.indd 3840188403 ENv02.indd 3 11/12/14 2:08 PM11/12/14 2:08 PM
Slide onto steam nozzle
until it locks into place.
3
Assembly Instructions
materials from garment steamer.
1 2 3
Before First Use: Remove ALL packing
Unpack all pieces from carton and remove any packing materials. Assemble steam nozzle holder by pushing it onto the tube end of the retractable pole.
NOTE: Brush and Creasing Attachments are optional accessories on select models.
Insert base of retractable pole into opening on top of the steamer, lining up the cutout notches; then slide the ridged collar down over the opening.
Holding ridged collar on base of pole, turn clockwise until tightened and secure.
4
Assemble steam nozzle holder by pushing it onto the tube end of the retractable pole. To extend the retractable pole, flip each lever on the pole to the open position.
4
840188403 ENv02.indd 4840188403 ENv02.indd 4 11/12/14 2:08 PM11/12/14 2:08 PM
5
Extend the pole up to full height; then flip levers closed to secure. Firmly grasp base of flexible steam hose and push in tabs on both sides. Insert into opening on steamer. CAUTION! Burn Hazard: Escaping steam is hot. Ensure base of hose is fully inserted as directed. If steam is leaking around base of hose, turn off and allow to cool before attempting to adjust the base of hose.
6
7
Hang steam nozzle/handle on steam nozzle holder.
How to Steam
NOTE: Do not install or remove steaming attachments when the unit is ON.
1
Unscrew the ridged cap on bottom of water tank.
5
Plug unit into electrical outlet.
840188403 ENv02.indd 5840188403 ENv02.indd 5 11/12/14 2:08 PM11/12/14 2:08 PM
2
Fill the tank with cool water.
6
Turn ON/OFF switch to the ON ( I ) position. Wait at least one minute for the steam to start flowing from the steam nozzle. Begin steaming at top of garment. Slowly move steam nozzle vertically up and down to cover entire garment. CAUTION! Burn Hazard: Steam is hot. Always point nozzle away from yourself and others. Never steam clothes while they are being worn.
3
Replace cap.
7
4
Place water tank back onto steamer.
8
When finished, turn power switch
O ) and unplug unit.
OFF (
5
Garment Steamer Tips
NOTICE: To avoid garment damage, check garment label for fabric composition and any steaming instructions such as this symbol:
Do not use steam
• The retractable pole should be fully extended during operation to ensure the free flow of steam through the flexible steam hose.
• Inserting the retractable pole so that the integrated garment hanger faces the rear of the unit will ensure stability while steaming clothing.
• Do not operate without water in the water tank. To add water during operation, first switch steamer OFF ( O ) and then remove water tank and refill.
• Use caution when hanging clothing from the integrated garment hanger. Too much weight or pulling on the garment hanger may cause the unit to tip over.
• The integrated garment hanger is not intended for hanging multiple garments at one time or for garment storage.
• When steaming, touching fabrics lightly with the steam nozzle/ handle will assist in wrinkle removal. It is important to make contact with the garment and/or fabric.
• For more difficult wrinkles, try steaming from the underside of the fabric. This allows the fibers in the material to relax.
• Pants are more easily steamed upside down, holding the cuffs.
• Your garment steamer is also ideal for steaming curtains, upholstery, and other fabric items that are difficult or unable to be ironed.
Using the Brush/Creasing Attachments
NOTE: Attachments are optional accessories on select models. Make sure unit is OFF when assembling attachments.
Brush Attachment
Use the Brush Attachment to:
• Steam upholstery, pillows, and other fabrics
• Freshen clothing and fabrics that have become “matted” over time
• Assist with lint removal while steaming
Creasing Attachment
Use the Creasing Attachment to:
• Steam creases into pants, shirt cuffs, and collars
6
840188403 ENv02.indd 6840188403 ENv02.indd 6 11/12/14 2:08 PM11/12/14 2:08 PM
Brush Attachment
Creasing Attachment
Care and Cleaning
Follow this procedure monthly to avoid mineral deposits and buildup, which can affect the steaming performance of the unit.
1 Cup
(237 ml)
White
1
Make sure unit is unplugged.
5
Turn the unit ON ( I ) and let the liquid solution steam out of the steam handle/nozzle.
840188403 ENv02.indd 7840188403 ENv02.indd 7 11/12/14 2:08 PM11/12/14 2:08 PM
Vinegar
2
Mix a solution of one cup white vinegar and one cup water.
6
Repeat this process with clean water until vinegar odor is no lon­ger present.
1 Cup
(237 ml)
Water
3
Slowly pour the solution into the water tank and replace the cap.
7
Reassemble steamer for storage. Wrap cord around the cord wrap
on bottom of steamer.
4
Replace water tank onto steamer.
7
Troubleshooting
PROBLEM
Unit won’t steam. Not enough steam.
Flexible steam hose drips and/or leaks.
Steamer leaves water spots on clothing.
Flexible steam hose emits a gurgling noise.
PROBABLE CAUSE
•
Make sure there is water in the water tank and unit is plugged in and switched to ON ( I ) position.
• Do not hold the steam handle/nozzle too low for too long, or steam will condense into water inside the hose and may block normal steam flow. Periodically lift steam nozzle/handle as high as possible to let any condensation in flexible steam hose drain back into unit.
• Extend retractable pole until it is fully open. Do not allow kinks in the flexible steam hose.
• Allow enough time (approximately one minute) for steamer to preheat before use.
• Periodically lift steam nozzle/handle as high as possible to let any condensation in flexible steam hose drain back into unit.
• Fully extend flexible steam hose to allow steam to flow freely.
8
840188403 ENv02.indd 8840188403 ENv02.indd 8 11/12/14 2:08 PM11/12/14 2:08 PM
Limited Warranty
This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.
This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.
This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the rating label (e.g., 120V ~ 60 Hz).
We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition
of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have
other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.
To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.
9
840188403 ENv02.indd 9840188403 ENv02.indd 9 11/12/14 2:08 PM11/12/14 2:08 PM
