Hamilton Beach 04384 User Guide

TrueAir

Air Purifier

Épurateur d’air

Purificador de aire

English ...................... 2

Francais .................... 9

Espanol .................. 16

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Questions? Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

¿Preguntas? Por favor llámenos – nuestros amables representantes están listos para ayudar. MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

Visit hamiltonbeach.com for delicious recipes, tips, and to register your product online!

Consultez hamiltonbeach.ca pour de délicieuses recettes, des conseils pratiques et pour enregistrer votre produit !

¡Visite hamiltonbeach.com.mx para recetas deliciosas, consejos, y para registrar su producto en línea!

Questions ? N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 1

IMPORTANT SAFEGUARDS

1. Read all instructions before using this air purifier. Save these

instructions for reference.

2. Do not immerse this product in water or splash water on it.

An electrical short may result in shock or fire.

3. Do not handle the plug with wet hands; electrical shock may

occur, resulting in injury or death.

4. Never attempt to disassemble or alter the product in any way not

instructed by this manual. Shock, fire, or bodily injury may occur. Contact Hamilton Beach at 1-800-851-8900 (U.S.) or 1-800-267-2826 (Canada) for assistance.

5. Do not operate this product in any greasy environment, such as

in the kitchen. This product is not intended to filter oil or grease from the air.

6. Do not operate this product near an open fire. It may ignite and

cause fire, resulting in bodily injury or property damage.

7. Do not operate this product in a garage or other area with oil or

chemicals such as solvents or insecticides.

8. Always unplug the power cord from the receptacle when the air

purifier is not in use, before cleaning, when replacing parts, or before moving to another location.

9. Do not insert foreign objects into the product for any reason.

Bodily injury or property damage may occur.

10. Do not use this product outdoors. It is intended for indoor use only.

11. Do not use air purifier in unheated areas such as a garage or porch.

12. Do not operate this air purifier without the outlet grille in place or

if the outlet grille is broken or damaged.

13. WARNING: To reduce the risk of fire or electric shock, do not use

this air purifier with any solid-state speed control device.

In order to prevent the risk of fire, electric shock, personal injury, or damage to property, follow these instructions carefully. When using electric appliances, basic safety precautions should be followed, including the following:

SAVE THESE INSTRUCTIONS!

OTHER CONSUMER SAFETY INFORMATION

This appliance is intended for household use only. WARNING! Shock Hazard: This appliance has a polarized plug

(one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another highwattage appliance on the same circuit with this appliance.

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 2

HOW THE AIR PURIFIER WORKS

The air purifier functions as an air cleaner by helping to remove particulates (such as pet dander, dust, pollen, mold and mildew spores) from the air.

The air is cleaned in four stages:

1. A fan draws air through the sides of the front panel.

2. The permanent prefilter captures large particles (such as dog or cat hair), while the two carbon filters assist in removing odors.

The HEPA-grade filter then removes particles as small as 3 microns from the air at 99% effectiveness.

3. The ionizer (on select models) then releases negative ions into the air which attract positively charged particles.

4. The purified air is then released through the back of the unit.

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 3

Control Knob

Filter Holder

Replaceable Carbon Filters

Front Panel

Permanent Prefilter

(located on inside

front panel)

Control Knob – Turn the control knob to the desired setting. There are five settings:

• Off

• WhisperClean

– Use for quiet, nighttime operation or for

constant low-speed filtration.

• Medium – Provides a higher fan speed; use to quickly filter dust, pollen, etc., from a room.

• QuickClean

– Provides cleaning during acute needs.

• Ionizer – On select models, the ionizer will activate for fresher, cleaner air. Also illuminated with a soft blue ambient light (on select models).

Parts and Features

Air Outlet Grille

Ionizer/Light On/Off Button

(on select models)

Opening Tab

Timestrip Holder

Removable Base

(can be removed when used in console mode)

Air Intake

Adhesive Feet

Four adhesive feet are provided to use the air purifier in console mode as shown on the front cover. Adhere the feet to indentations as shown in the illustration.

How to Replace the Timestrip Cartridge:

1. Press firmly on foil bubble on the cartridge

to activate. A red line will appear a few moments later on the left side of the holder to indicate it has been correctly activated.

2. Slide activated cartridge into the plastic

holder on unit.

3. The activated cartridge will “count down”

for 3 months, indicating that it is time to replace the filter.

How to Install and Replace

the Carbon Filters and

Filter Holder

HEPA-Grade Filter

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 4

Selecting a Location

DO NOT

• Place the air purifier on a flat, stable surface.

• Place the air purifier near an electrical outlet where it is out of the way. Make sure that the air purifier and the cord do not present tripping hazards.

• Select a central location with adequate air circulation.

• Turn off and unplug the air purifier before moving or servicing it, or if it will not be used for several days.

• Route the electrical cord clear of furniture to prevent damage from pinching.

The air purifier is designed for easy use and maintenance. Make sure to remove all packing materials and properly install the permanent filter before use.

Remember to remove the plastic bag around filters before using.

• Do not stand, sit, or place any objects on the air purifier. It is not designed to support additional weight.

• Do not block the air intake and outlet grilles with drapes, curtains, or blinds. This may cause reduced performance.

• Do not use in a kitchen, garage, or area with grease, oil, or chemicals such as solvents or insecticides.

• Do not place on or near heat sources such as stoves, radiators, or heaters, or in direct sunlight.

• To reduce electrical noise and interference, do not place on or near, or plug into the same outlet as TVs, baby monitors, or cordless phones.

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 5

Cleaning

Electrical Shock Hazard.

Disconnect power before cleaning. Do not immerse unit in any liquid. Remember to activate a new timestrip cartridge when replacing the carbon filters.

w WARNING

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 6

PROBLEM

Unit will not turn on.

Reduced airflow or poor filtering.

PROBABLE CAUSE

• Is the unit plugged in?

• Is the control knob turned on?

• The air intake or air outlet grille may be blocked. Make sure nothing is in front of or directly behind the unit.

• The filter may be clogged. Clean the filter with a vacuum if needed.

• The permanent prefilter may be clogged. We recommend vacuuming the permanent prefilter every 1–3 months, depending on usage conditions.

• Replace carbon filters every 90 days, or sooner, depending on usage. Remember to replace your timestrip cartridge when doing so. See “How to Replace the Timestrip Cartridge” in the Parts and Features section.

Troubleshooting

Cleaning

(cont.)

Filters should last up to 3 months, depending on use. Always discard used filters. Timestrip cartridges are included with

new filters and should be replaced along with filters. Filters may be purchased through www.hamiltonbeach.com or through Consumer Affairs 1.800.851.8900.

Use only Hamilton Beach Brands, Inc., filters.

3-Pack Filters

04234_ Pet

Single-Pack Filters

04294_ Pet

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 7

Limited Warranty

This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use.

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition

of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may

have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.

840156702 ENv04.qxd:Layout 1 11/13/09 2:37 PM Page 8
