00
183377
Wireless CarCharger
“FC-10CFlex”
Kabelloses KFZ-Ladegerät
Operating Instructions
Bedienungsanleitung
GB
D
A
1
2
4
3
B
G Operating instruction
Controls and Displays
1. Micro-USB input
2. Status LED
3. Adjustment lever
4. Ventilation grille mount
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please keep
these instructions in asafe place for futurereference. If you sell the device, please pass these
operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to
specichazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• ‘FC-10C Flex’ Wireless Car Charger for smartphones
• Ventilation grille mount
• 1x Micro-USB cable
• These operating instructions
3. Safety Notes
• The product is intended for private, non-commercial use only.
• Protect the product from dirt, moistureand overheating, and only use it in adry
environment.
• Do not drop the product and do not expose it to any major shocks.
• Do not operate the product outside the power limits given in the specications.
• Do not open the device or continue to operate it if it becomes damaged.
• Do not use the product in areas wherethe use of electronic devices is not permitted.
• In order to prevent damage caused by overheating, make surethe product is not covered
by textiles, metal or other objects.
• Dispose of packaging material immediately according to locally applicable regulations.
• Do not modify the product in any way.Doing so voids the warranty.
2
Do not put any bank cards or similar cards with magnetic strips,
or other magnetically sensitive objects, on the product.
The data on the cards could be damaged or deleted.
Warning
Ensurethat thereare no metal parts (for example, metal plate for magnetic holder) on the
back of your terminal device. Metal may heat up signicantly in the eld of the induction
charger,causing damage to your terminal device and/or the charger.
4. Getting Started and Operation
Note
• To be able to charge your terminal device using the wireless charger,your terminal
device must be compatible with inductive charging technology.Please read the
operating instructions of your device.
• Note that the presence of mobile phone cases, covers or other materials between the
wireless charger and the back of your terminal device can interferewith charging or
even prevent it.
• Attach the wireless vehicle charger to your vehicle’sventilation grille using the included
ventilation grille mount (4).
• Connect the included Micro-USB cable to the Micro-USB input (1) on the inductive
charger and to asuitable USB vehicle charger.Please refer to the operating instructions for
the USB vehicle charger used.
• When the power supply is active, the status LED (2) lights up blue.
• Adjust the holding brackets to the size of your smartphone using the adjustment lever
(3). Youcan easily move the lever by pressing it to release the locking mechanism.
• To adjust the holding brackets to your smartphone’ssize, rst set them to the maximum
open position.
• Then insert your smartphone into the charger and push the holding brackets together using
the adjustment lever until the smartphone is rmly seated in the holder.
• Release the lever to lock the holding arms in position.
• Thanks to the exible holding arms, you can now easily secureyour smartphone in the
charger at any time, and take it out again. The holding arms always remain in the position
you have previously set.
3
Warning
• Only use suitable charging devices or USBconnections for charging.
• As arule, do not use charging devices or USB connections that aredefective and do not
try to repairthem yourself.
• Now insert your terminal device withits back to the wirelesscharger (B).
• Chargingstarts as soon as an effective induction eld has been generated. The status
LED (2) begins topulse in red. The current charging status appears on your terminal
device.
• If no connection can be established through induction, you mayhave to changethe
position of yourterminaldevice (B).
• Chargingstops automatically onceyour device’sbattery is fully charged. The statusLED
(2) is now steadily lit in red.
• Remove your terminal device from the wireless charger and disconnect the chargerfrom
the power supply.
• If there aremetal or magnetic objects on the charger,the statusLED (2)will ash
steadily in blue.
5. Care and Maintenance
Only clean this productwith aslightly damp,lint-free cloth anddonot use aggressive
cleaning agents.
6. Warranty Disclaimer
Hama GmbH &CoKG assumes no liability and providesnowarranty for damage resulting
from improper installation/mounting, improper use of the product or from failuretoobserve
the operating instructions and/orsafety notes.
7. Service and Support
Please contact Hama Product Consulting if you have any questionsabout this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here: www.hama.com
4
8. Technical Data
Wireless CarCharger
max.2.0 A
Input
Output
(under optimized conditions)
Dimensions 85 –98x50x35mm
5V
9V max.1.67 A
max. 10 W
9. Recycling Information
Note on environmental protection:
After the implementation of theEuropean Directive 2012/19/EU and2006/66/EU
in the national legal system, the following applies: Electric and electronicdevices
as well as batteriesmust not be disposed of with household waste. Consumers
are obligedbylaw to return electrical and electronic devices as well as batteries
at the end of their service lives to the public collecting points set up for this
purposeorpoint of sale.Details to this are defined by the national law of therespective
country. This symbol on the product, the instructionmanual or thepackage indicates that a
product is subject to these regulations. By recycling, reusing thematerials or other forms of
utilising old devices/Batteries, you are makinganimportant contribution to protecting our
environment.
10. Declaration of Conformity
Hereby,Hama GmbH &CoKGdeclares thatthe radio equipment type [00183377]
is in compliance withDirective 2014/53/EU.The full text of theEUdeclarationof
conformity is available at the following internetaddress:
www.hama.com-> 00183377 -> Downloads.
Frequency band(s) 125kHz
Maximum radio-frequency
power transmitted
0.0006mW (-32.46 dBm) EIRP
5
D Bedienungsanleitung
Bedienungselemente und Anzeigen
1. Micro-USB-Eingang
2. Status-LED
3. Justierhebel
4. Lüftungsgitter-Befestigung
Vielen Dank, dass Sie sich für ein Hama Produkt entschieden haben!
Nehmen Sie sich Zeit und lesen Sie die folgenden Anweisungen und Hinweise zunächst ganz
durch. Bewahren Sie diese Bedienungsanleitung anschließend an einem sicheren Ort auf,um
bei Bedarf darin nachschlagen zu können. Sollten Sie das Gerät veräußern, geben Sie diese
Bedienungsanleitung an den neuen Eigentümer weiter.
1. Erklärung von Warnsymbolen und Hinweisen
Warnung
Wirdverwendet, um Sicherheitshinweise zu kennzeichnen oder um Aufmerksamkeit auf
besondereGefahren und Risiken zu lenken.
Hinweis
Wirdverwendet, um zusätzlich Informationen oder wichtige Hinweise zu kennzeichnen.
2. Packungsinhalt
• Kabelloses KFZ-Ladegerät „FC-10C Flex“ für Smartphones
• Lüftungsgitter-Halterung
• 1x Micro-USB-Kabel
• diese Bedienungsanleitung
3. Sicherheitshinweise
• Das Produkt ist für den privaten, nicht-gewerblichen Haushaltsgebrauch vorgesehen.
• Schützen Sie das Produkt vor Schmutz, Feuchtigkeit und Überhitzung und verwenden Sie es
nur in trockenen Umgebungen.
• Lassen Sie das Produkt nicht fallen und setzen Sie es keinen heftigen Erschütterungen aus.
• Betreiben Sie das Produkt nicht außerhalb seiner in den technischen Daten angegebenen
Leistungsgrenzen.
• Öffnen Sie das Produkt nicht und betreiben Sie es bei Beschädigungen nicht weiter.
• Benutzen Sie das Produkt nicht in Bereichen, in denen elektronische Produkte nicht erlaubt
sind.
• Achten Sie darauf,dass das Produkt nicht durch Textilien, Metall- oder sonstige
6
