Hama 00137423 Operating Instructions Manual

Page 1
00
137423
Bluetooth-Headset
F
D
PL
GB
Bedienungsanleitung
Mode d‘emploi
Instrucciones de uso
Instrukcja obsługi
“MyVoice3000”
E
Page 2
4
B
A
C D
3
4
5
2
6
1
Page 3
2
Controls and Displays
1. Multi-Function Key
2. Status LED
3. Volume Control (-)
4. Lautstärkeregler (+)
5.
Charging Socket
6. Microphone
Thank you for choosing a Hama product. Take your time and read the following instructions and information completely. Please keep these instructions in a safe place for future reference. If you sell the device, please pass these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic hazardås and risks.
Note
This symbol is used to indicate additional information or important notes.
G Operating instruction
Page 4
3
2. Package Contents
•1x MyVoice3000 Bluetooth headset
•1x USB charging Cable (B)
•1x Ear Hook (C)
•3x Ear pads (D)
•These operating instructions
3. Safety Notes
•The product is intended for private, non-commercial use only.
Protect the product from dirt, moisture and overheating, and only use it in a dry environment.
•Do not allow yourself to be distracted by the product, for example when driving a vehicle or operating sports equipment. Always pay attention to the surrounding trac and your environment.
•Do not drop the product and do not expose it to any major shocks.
Do not operate the product outside the power limits given in the
specications.
Do not open the device or continue to operate it if it becomes damaged.
Since the battery is integrated and cannot be removed, you will need to dispose of the product as a whole. Do this in compliance with the legal requirements.
•Dispose of packaging material immediately according to locally
applicable regulation.
•Do not modify the product in any way. Doing so voids the warranty.
Page 5
4
Warning – Rechargeable battery
•Only use suitable charging devices or USB connections for charging.
•As a rule, do not charge devices or USB connections that are defective and do not try to repair them yourself.
•Do not overcharge the product or allow the battery to completely discharge.
•Avoid storing, charging or using batteries in extreme temperatures.
•We suggest to fully charge the item for at least one time in two months
4. Getting Started
•The headset is equipped with a rechargeable battery. The battery must be fully charged before using the device for the rst time.
•Ensure that the headset is switched off before charging it.
•Begin charging by connecting the included USB charging cable to the charging socket (5) as well as to the USB connection of a PC/laptop.
•Alternatively, you can charge the headset using a suitable USB charger. Please refer to the operating instructions for the USB charger used.
•The status LED (2) lights up constantly in red during the charging process.
•Charging the battery fully may take up to 2 hours.
Page 6
5
Warning
Do not use the headset while it is charging.
•When the battery is fully charged, the status LED (2) remains lit blue.
•Disconnect all cable and mains connections after use.
Note
If you have not used the item for a few month, it may take 15-30 minutes for the status LED (3) to red when charging.
5. Operation
Switching the headset on/off
Turn On: With the device off, press and hold the multifunction button (1) for 3 seconds until you hear a voice. The status LED (2) ashes in blue three times. The voice announces the battery charge by the amount of talking time remaining.
Remaining talking time Voice announcement
> 3,75 h„Battery high“
3,75 h – 0,75 h„Battery medium“
< 0,75 h„Battery low“
Page 7
6
Turn Off: With the device on, press and hold the multifunction button (1) for 5 seconds. The status LED (2) ashes red twice before the device turns off.
The rst time the device is turned on, pairing is automatically started – see 5.1 Bluetooth pairing.
5.1. Bluetooth pairing
Note – Pairing
•Make sure that your Bluetooth-capable terminal device is on and Bluetooth is activated.
•For more information, please refer to the operating instructions of your terminal device.
•The headset and the terminal device should not be any further than 1 metre away from each other. The smaller the distance, the better.
•Ensure the headset is off.
•Press and hold the multifunction button (1) for approx. 8 seconds until the status LED (2) begins to alternate red and blue. The headset is searching for a Bluetooth connection.
•Open the Bluetooth settings on your terminal device and wait until MyVoice3000 appears in the list of Bluetooth devices found.
•Bluetooth devices found.
•Select MyVoice3000 and wait until the headset is listed as connected in the Bluetooth settings on your terminal device.
Page 8
7
Note – Bluetooth password
If your terminal device requests a password to establish the connection, enter 0000.
Note
If pairing was successful, the status LED (2) lights up in blue for about 2 seconds. A short signal tone sounds and a voice says, “Your phone is connected”.
•You can now use the headset.
5.2. Automatic Bluetooth connection
(after successful pairing)
Note
•Make sure that your Bluetooth-capable terminal device is on and Bluetooth is activated.
•For more information, please refer to the operating instructions of your terminal device.
•Make sure that the headset is switched on.
•After the headset and terminal device have been paired, a connection is established automatically.
•You can now use the headset.
Page 9
8
Note
•If pairing was successful, the status LED (2) lights up in blue for about 2 seconds. A short signal tone sounds and a voice says, “Your phone is connected”.
•It may be necessary to change the settings on your terminal device to enable it to automatically connect to the paired headset.
Hinweis - Connection impaired
After the headset and terminal device have been paired, a connection is established automatically. If the Bluetooth connection is not established automatically, check the following:
•Check the Bluetooth settings of your terminal device to see whether MyVoice3000 is connected. If not, repeat the steps listed under 5.1 Bluetooth pairing.
•Check whether obstacles are impairing the range. If so, move the devices closer together.
•The performance can also be affected by a weak battery.
5.3. Multi-pairing
•The headset can be paired with two terminal devices at once so that, for example, you can use a private and a business mobile phone simultaneously.
•To begin with, activate Bluetooth only on the rst terminal device that you wish to pair.
•Pair the rst terminal device with the headset as described in 5.1 Bluetooth Pairing.
Page 10
9
•Switch off the headset as described in 5 Operation (Switching off).
•Activate Bluetooth on the second terminal device.
•Press and hold the multifunction button (1) for approx. 8 seconds until the status LED (2) begins to alternate red and blue. The headset is searching for a Bluetooth connection.
•Continue as decribed in 5.1 Bluetooth Pairing.
•Once the second terminal device is connected, open the Bluetooth settings on the rst terminal device and select MyVoice3000.
•Now both terminal devices are connected to the headset.
5.4. Hands-free function
Note
•Note that support for certain key functions may vary depending on your terminal device.
•For more information, please refer to the operating instructions of your terminal device.
Making a call
•Dial the number directly on your terminal device to make a call.
Voice-activated dialing
•Please check if your mobile phone supports voice dialing function.
•Press and hold the multifunction button (1) for approx. 3 seconds
•The mobile phone’s voice control will be activated.
•Start a call as described in your mobile phone’s operating instructions.
•Say the name of person you wish to call.
•If the voice tags are paired to the related phone number stored in your mobile phone, the number will be dialed.
Page 11
10
Accepting calls
•Press the multifunction button (1) once to answer an incoming call.
Rejecting an incoming call
•Press and hold the multifunction button (1) for approx. 3 seconds to reject an incoming call. You will hear a short tone.
Ending a call
•During a call, press the multifunction button (1) once to end the call.
Redial
•Briey press the multifunction button (1) twice to call the last number.
•You will hear a short beep.
Forwarding a call
•During the call, press and hold the multifunction button (1) for approx. 3 seconds to forward the call from the headset to the terminal device or from the terminal device to the headset. You will hear a short tone.
5.5. Volume control and mute function
•Press the volume control (-) (3) to reduce the volume.
•Press the volume control (+) (4) to increase the volume.
5.6. Disconnecting the headset
•Switch the headset off.
•Disconnect the headset via the Bluetooth settings on your terminal device.
Page 12
11
5.7. Battery level
•If the battery level is low, the headset beeps and the status LED (2) starts ashing red.
•Charge the headset as described in 4. Getting Started.
Note
However, the talk and standby times may vary when used with different mobile phones or other compatible Bluetooth devices, usage settings, usage styles and environments.
•When the headset is switched off, press the multifunction button (1) for approx. 1 second to nd out the current charge level of the battery.
•When the headset is switched on, press and hold both volume control buttons (+/–, 3/4) to nd out the current charge level of the battery. The voice announces the battery charge by the amount of talking time remaining.
Verfügbare Gesprächszeit
Sprachinformation
Status-LED (2)
> 3,75 h„Battery high“ Blue
3 seconds
3,75 h – 0,75 h„Battery medium“ Blue
3x ashing
< 0,75 h„Battery low“ Rot 3x ashing
Page 13
12
6. Care and Maintenance
Only clean this product with a slightly damp, lint-free cloth and do not use aggressive cleaning agents. Make sure that water does not get into the product.
7. Warranty Disclaimer
Hama GmbH & Co. KG assumes no liability and provides no warranty for damage resulting from improper installation/mounting, improper use of the product or from failure to observe the operating instructions and/or safety notes.
8. Service and Support
Please contact Hama Product Consulting if you have any questions about this product. Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com
Page 14
13
9. Technical Data
Bluetooth headset
Bluetooth technology Bluetooth v3.0
Supported proles HSP, HFP, A2DP,
Frequency of Bluetooth
transmissions
2,402 GHz – 2,480 GHz
Range < 10 m
Battery
Type
3.7V lithium polymer 80 mAh
Charging time ~ 2h
Page 15
14
10. Recycling Information Note on environmental protection:
After the implementation of the European Directive 2012/19/EU and 2006/66/EU in the national legal system, the following applies: Electric and electronic devices as well as batteries must not be disposed of with
household waste. Consumers are obliged by law to return electrical and electronic devices as well as batteries at the end of their service lives to the public collecting points set up for this purpose or point of sale. Details to this are dened by the national law of the respective country. This symbol on the product, the instruction manual or the package indicates that a product is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices/Batteries, you are making an important contribution to protecting our environment.
11. Declaration of Conformity
Hama GmbH 8 Co. KG hereby declares that the device
complies with the essential requirements and other
relevant provisions of Directive 2014/53/EU. See www. hama.com for the declaration of conformity with the relevant directive.
Page 16
15
Bedienungselemente und Anzeigen
1. Multifunktionstaste
2.
Status-LED
3.
Lautstärkeregler (-)
4.
Lautstärkeregler (+)
5.
Ladebuchse
6.
Mikrofon
Vielen Dank, dass Sie sich für ein Hama Produkt entschieden haben! Nehmen Sie sich Zeit und lesen Sie die folgenden Anweisungen und Hinweise zunächst ganz durch. Bewahren Sie diese Bedienungsanleitung anschließen an einem sicheren Ort auf, um bei Bedarf darin nachschlagen zu können. Sollten Sie das Gerät veräußern, geben Sie diese Bedienungsanleitung an den neuen Eigentümer weiter.
1.
Erklärung von Warnsymbolen und Hinweisen
Warnung
Wird verwendet, um Sicherheitshinweise zu kennzeichnen oder um Aufmerksamkeit auf besondere Gefahren und Risiken zu lenken.
Hinweis
Wird verwendet, um zusätzlich Informationen oder wichtige Hinweise zu kennzeichnen.
D Bedienungsanleitung
Page 17
16
2. Packungsinhalt
•1x Bluetooth-Headset MyVoice3000
•1x USB-Ladekabel (B)
•1x Ohrbügel (C)
•3x Ohrpolster (D)
•diese Bedienungsanleitung
3. Sicherheitshinweise
•Das Produkt ist für den privaten, nicht-gewerblichen
Haushaltsgebrauch vorgesehen.
•Schützen Sie das Produkt vor Schmutz, Feuchtigkeit und
Überhitzung und verwenden Sie es nur in trockenen Umgebungen.
•Lassen Sie sich auf der Fahrt mit einem Kraftfahrzug oder
Sportgerät nicht durch Ihr Produkt ablenken und achten Sie auf die Verkehrslage und Ihre Umgebung.
•Lassen Sie das Produkt nicht fallen und setzen Sie es keinen
heftigen Erschütterungen aus.
•Betreiben Sie das Produkt nicht außerhalb seiner in den
technischen Daten angegebenen Leistungsgrenzen.
•Öffnen Sie das Produkt nicht und betreiben Sie es bei
Beschädigungen nicht weiter.
•Der Akku ist fest eingebaut und kann nicht entfernt werden,
entsorgen Sie das Produkt als Ganzes gemäß den gesetzlichen Bestimmungen.
•Entsorgen Sie das Verpackungsmaterial sofort gemäß den örtlich
gültigen Entsorgungsvorschriften.
•Nehmen Sie keine Veränderungen am Gerät vor. Dadurch verlieren
sie jegliche Gewährleistungsansprüche.
Page 18
17
Warnung – Akku
•Verwenden Sie nur geeignete Ladegeräte oder USB­Anschlüsse zum Auaden.
•Verwenden Sie defekte Ladegeräte oder USB-Anschlüsse generell nicht mehr und versuchen Sie nicht, diese zu reparieren.
•Überladen oder tiefentladen Sie das Produkt nicht.
•Vermeiden Sie Lagerung, Laden und Benutzung bei extremen Temperaturen.
•Laden Sie bei längerer Lagerung regelmäßig (mind. vierteljährig) nach.
4. Inbetriebnahme
•Das Headset verfügt über einen wieder auadbaren Akku. Vor der ersten Anwendung muss der Akku vollständig aufgeladen werden.
•Stellen Sie sicher, dass das Headset vor dem Auaden ausgeschaltet ist.
•Starten Sie den Ladevorgang, indem Sie das beiliegende USB­Ladekabel an die Ladebuchse (5) und an den USB-Anschluss eines PCs/Notebooks anschließen. Alternativ können Sie das Headset über ein geeignetes USB-Ladegerät laden. Beachten Sie hierzu die Bedienungsanleitung des verwendeten USB-Ladegeräts.
•Die Status-LED (2) leuchtet während des Ladevorgangs dauerhaft rot.
•Es kann bis Zu 2 Stunden dauern, bis der Akku vollständig geladen ist.
Page 19
18
Warnung
Verwenden Sie das Headset nicht während des Ladevorgangs!
•Ist der Akku vollständig geladen, leuchtet die Status-LED (2) dauerhaft blau.
•Trennen Sie anschließend alle Kabel- und Netzverbindungen.
Hinweis
Wenn Sie das Gerät einige Monate lang nicht verwendet haben, kann es 15-30 Minuten dauern, bis die Status-LED (3) beim Ladevorgang rot leuchtet.
5. Betrieb
Ein-/ Ausschalten des Headsets
Einschalten: Halten Sie im ausgeschalteten Zustand die Multifunktionstaste (1) 3 Sekunden lang gedrückt, bis Sie eine Sprachinformation hören. Die Status-LED (2) blinkt dreimal blau auf. Die Sprachinformation richtet sich nach der Akkukapazität, gemessen an der noch verfügbaren Gesprächszeit:
Verfügbare Gesprächszeit Sprachinformation
> 3,75 h„Battery high“
3,75 h – 0,75 h„Battery medium“
< 0,75 h„Battery low“
Page 20
19
Ausschalten: Halten Sie im eingeschalteten Zustand die Multifunktionstaste (1) 5 Sekunden lang gedrückt. Die Status-LED (2) blinkt zweimal rot auf, bevor sich das Gerät abschaltet
Beim ersten Einschalten wird automatisch das Pairing gestartet –
siehe 5.1. Bluetooth Erstverbindung (Pairing).
5.1. Bluetooth Erstverbindung (Pairing)
Hinweis – Pairing
•Stellen Sie sicher, dass Ihr Bluetooth-fähiges Endgerät eingeschaltet ist und dass Bluetooth aktiviert ist.
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
•Das Headset und das Endgerät sollten nicht weiter als 1 Meter voneinander entfernt sein. Je geringer der Abstand, desto besser.
•Vergewissern Sie sich, dass das Headset ausgeschaltet ist.
•Drücken Sie die Multifunktionstaste (1) ca. 8 Sekunden, bis die Status-LED (2) abwechselnd rot und blau aueuchtet. Das Headset sucht nach einer Bluetooth Verbindung.
•Öffnen Sie auf Ihrem Endgerät die Bluetooth Einstellungen und warten Sie bis in der Liste der gefundenen Bluetooth Geräte MyVoice3000 angezeigt wird.
•Wählen Sie MyVoice3000 aus und warten Sie bis das Headset als verbunden in den Bluetooth Einstellungen Ihres Endgerätes angezeigt wird.
Page 21
20
Hinweis – Bluetooth Passwort
Manche Endgeräte benötigen für die Einrichtung der Verbindung mit einem anderen Bluetooth Gerät ein Passwort.
•Geben Sie für die Verbindung das Passwort 0000 ein, wenn Sie zur Eingabe von Ihrem Endgerät aufgefordert werden.
Hinweis
Wenn die Kopplung erfolgreich war, leuchtet die Status-LED (2) ca. 2 Sekunden blau auf. Es ertönt ein kurzer Signalton und die Sprachinformation „Your phone is connected“.
•Sie können das Headset nun verwenden.
5.2. Automatische Bluetooth Verbindung (nach bereits erfolgtem Pairing)
Hinweis
•Stellen Sie sicher, dass Ihr Bluetooth-fähiges Endgerät eingeschaltet ist und dass Bluetooth aktiviert ist.
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
•Vergewissern Sie sich, dass das Headset eingeschaltet ist.
•Nach einer erfolgreichen Erstverbindung erfolgt die Verbindung automatisch.
•Sie können das Headset nun verwenden.
Page 22
21
Hinweis
•Wenn die Kopplung erfolgreich war, leuchtet die Status-LED (2) ca. 2 Sekunden blau auf. Es ertönt ein kurzer Signalton und die Sprachinformation „Your phone is connected“.
•Gegebenenfalls müssen Sie die Einstellung auf dem Endgerät vornehmen, um die automatische Verbindung mit dem gekoppelten Headset zuzulassen.
Hinweis - Verbindung beeinträchtigt
Nach einer erfolgreichen Erstverbindung erfolgt die Verbindung automatisch. Sollte sich die Bluetooth Verbindung nicht automatisch wiederherstellen, prüfen Sie die folgenden Punkte:
•Kontrollieren Sie in den Bluetooth Einstellungen des Endgerätes, ob MyVoice3000 verbunden ist. Wenn nicht, wiederholen Sie die unter 5.1. Bluetooth Erstverbindung genannten Schritte.
•Kontrollieren Sie, ob Hindernisse die Reichweite beeinträchtigen. Wenn ja, positionieren Sie die Geräte näher zueinander.
•Auch bei schwacher Batterie kann die Leistung beeinträchtigt sein.
5.3. Multipairing
•Sie können das Headset mit zwei Endgeräten gleichzeitig koppeln, um diese, z.B. privates und geschäftliches Mobiltelefon, parallel nutzen zu können.
•Aktivieren Sie Bluetooth zunächst nur am ersten Endgerät, das Sie koppeln möchten.
Page 23
22
•Koppeln Sie das erste Endgerät – wie in 5.1. Bluetooth Pairing (Erstverbindung) beschrieben – mit dem Headset.
•Schalten Sie das Headset – wie in 5. Betrieb (Ausschalten) beschrieben – aus.
•Aktivieren Sie auch beim zweiten Endgerät Bluetooth.
•Drücken und halten Sie die Multifunktionstaste (1) ca. 8 Sekunden, bis die Status-LED (2) abwechselnd rot und blau aueuchtet. Das Headset sucht nach einer Bluetooth Verbindung.
•Gehen Sie weiter wie in 5.1. Bluetooth Pairing (Erstverbindung) beschrieben, vor.
•Nach erfolgreicher Verbindung des zweiten Endgerätes öffnen Sie auf dem zuerst verbundenen Endgerät die Bluetooth Einstellungen und wählen Sie MyVoice3000 aus.
•Es sind beide Endgeräte mit dem Headset verbunden.
5.4. Freisprechfunktion
Hinweis
•Beachten Sie, dass die Unterstützung einiger Funktionen von Ihrem Endgerät abhängig ist.
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
Anruf tätigen
•Wählen Sie die Nummer direkt über Ihr Endgerät, um einen Anruf zu tätigen.
Sprachwahlfunktion
•Prüfen Sie, ob Ihr Mobiltelefon Sprachwahl unterstützt.
•Drücken und halten Sie die Multifunktionstaste (1) für ca. 3 Sekunden.
Page 24
23
•Auf Ihrem Mobiltelefon wird die Sprachsteuerung geöffnet.
•Um einen Anruf zu tätigen, gehen Sie wie in der Bedienungsanleitung Ihres Mobiltelefons beschrieben vor.
•Nennen Sie den Namen der Person, die Sie anrufen möchten.
•Wenn die Spracheinträge mit der zugehörigen Telefonnummer, die auf Ihrem Mobiltelefon gespeichert ist, gekoppelt sind, wird die Nummer gewählt.
Anruf entgegennehmen
•Drücken Sie einmal die Multifunktionstaste (1), um einen eingehenden Anruf anzunehmen.
Eingehenden Anruf abweisen
•Drücken und halten Sie die Multifunktionstaste (1) für ca. 3 Sekunden, um einen eingehenden Anruf abzuweisen. Es ertönt ein kurzer Signalton.
Gespräch beenden
•Drücken Sie während des Gesprächs einmal die
Multifunktionstaste (1), um den Anruf zu beenden.
Wahlwiederholung
•Drücken Sie zweimal kurz die Multifunktionstaste (1), um die Nummer des letzten Anrufs anzurufen.
•Sie hören einen kurzen Signalton.
Anruf weiterleiten
•Drücken und halten Sie die Multifunktionstaste (1) während des Anrufs für ca. 3 Sekunden, um den Anruf vom Headset an das Endgerät oder vom Endgerät an das Headset weiterzuleiten. Es ertönt ein kurzer Signalton.
Page 25
24
5.5. Lautstärkeregelung und Stummschaltung
•Drücken Sie den Lautstärkeregler (-) (3), um die Lautstärke zu reduzieren.
•Drücken Sie den Lautstärkeregler (+) (4), um die Lautstärke zu erhöhen.
5.6. Trennen des Headsets
•Schalten Sie das Headset aus.
•Trennen Sie das Headset über die Bluetooth Einstellungen Ihres Endgerätes.
5.7. Akkukapazität
•Bei geringer Akkukapazität piept das Headset und die Status­LED (2) beginnt rot zu blinken.
•Laden Sie das Headset – wie in 4. Inbetriebnahme beschrieben – auf.
Hinweis
Die verfügbare Gesprächs- bzw. Standby-Zeit hängt jedoch vom jeweils verwendeten Mobiltelefon oder sonstigen kompatiblen Bluetooth-Geräten sowie von den Benutzereinstellungen, Benutzerpräferenzen und jeweiligen Umgebungsbedingungen ab.
•Drücken Sie die Multifunktionstaste (1) ca. 1 Sekunde, um die aktuelle Kapazität des Akkus zu erfahren, wenn das Headset ausgeschalten ist.
•Drücken und Sie die halten Sie beide Lautstärkeregler (-)/ (+) (3/4), um die aktuelle Kapazität des Akkus zu erfahren, wenn das Headset eingeschalten ist. Die Sprachinformation richtet sich nach der Akkukapazität, gemessen an der noch verfügbaren Gesprächszeit:
Page 26
25
Verfügbare Gesprächszeit
Sprachinformation
Status-LED (2)
> 3,75 h„Battery high“
Blau 3 Sekunden
3,75 h – 0,75 h„Battery medium“
Blau 3x blinken
< 0,75 h„Battery low“
Rot 3x blinken
6. Wartung und Pflege
Reinigen Sie dieses Produkt nur mit einem fusselfreien, leicht feuchten Tuch und verwenden Sie keine aggressiven Reiniger. Achten Sie darauf, dass kein Wasser in das Produkt eindringt.
7. Haftungsausschluss
Die Hama GmbH & Co. KG übernimmt keinerlei Haftung oder Gewährleistung für Schäden, die aus unsachgemäßer Installation, Montage und unsachgemäßem Gebrauch des Produktes oder einer Nichtbeachtung der Bedienungsanleitung und/oder der Sicherheitshinweise resultieren.
8. Service und Support
Bitte wenden Sie sich bei Fragen zum Produkt gerne an die Hama­Produktberatung. Hotline: +49 9091 502-115 (Deu/Eng) Weitere Supportinformationen nden sie hier: www.hama.com
Page 27
26
9. Technische Daten
Bluetooth Headset
Bluetooth Technologie Bluetooth v3.0
Unterstützte Prole HSP, HFP, A2DP,
Frequenz für die Bluetooth-
Übertragugnen
2,402 GHz – 2,480 GHz
Reichweite < 10 m
Akku
Typ
3,7 V Lithium-Polymer
80 mAh
Auadezeit ~ 2h
Page 28
27
10. Entsorgungshinweise
Hinweis zum Umweltschutz:
Ab dem Zeitpunkt der Umsetzung der europäischen Richtlinien 2012/19/EU und 2006/66/EG in nationales Recht gilt folgendes: Elektrische und elektronische Geräte sowie Batterien dürfen nicht mit dem Hausmüll
entsorgt werden. Der Verbraucher ist gesetzlich verpichtet, elektrische und elektronische Geräte sowie Batterien am Ende ihrer Lebensdauer an den dafür eingerichteten, öffentlichen Sammelstellen oder an die Verkaufsstelle zurückzugeben. Einzelheiten dazu regelt das jeweilige Landesrecht. Das Symbol auf dem Produkt, der Gebrauchsanleitung oder der Verpackung weist auf diese Bestimmungen hin. Mit der Wiederverwertung, der stoichen Verwertung oder anderen Formen der Verwertung von Altgeräten/ Batterien leisten Sie einen wichtigen Beitrag zum Schutz unserer Umwelt.
11. Konformitätserklärung
Hiermit erklärt Hama GmbH 8 Co. KG, dass sich dieses
Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der Richtlinie 2014/53/EU bendet. Die Konformitätserklärung gemäß der entsprechenden Richtlinie nden Sie unter www.hama. com.
Page 29
28
Éléments de commande et d'affichage
1. Touche multifonction
2. LED d’état
3. Volume (-)
4. Volume (+)
5. Prise de charge
6. Microphone
Nous vous remercions d’avoir choisi un produit Hama. Veuillez prendre le temps de lire l‘ensemble des remarques et consignes suivantes. Veuillez conserver ce mode d‘emploi à portée de main an de pouvoir le consulter en cas de besoin. Transmettez-le au nouveau propriétaire avec l’appareil le cas échéant.
1. Explication des symboles d‘avertissement et des
remarques
Avertissement
Ce symbole est utilisé pour indiquer des consignes de sécurité ou pour attirer votre attention sur des dangers et risques particuliers.
Remarque
Ce symbole est utilisé pour indiquer des informations supplémentaires ou des remarques importantes.
F Mode d‘emploi
Page 30
29
2. Contenu de l‘emballage
•1micro-casque Bluetooth MyVoice3000
•1x Câble de charge USB (B)
•1x contour d‘oreille (C)
•3x Oreillettes (D)
•Mode d‘emploi
3. Consignes de sécurité
Ce produit est destiné à une installation domestique non
commerciale.
•Protégez le produit de toute saleté, humidité, surchauffe et
utilisez-le uniquement dans des locaux secs.
Ne laissez pas le produit capter votre attention lorsque vous
pilotez un véhicule ou un appareil de sport et veuillez concentrer toute votre attention à la circulation et à votre environnement.
Protégez le produit des secousses violentes et évitez tout choc
ou toute chute.
N‘utilisez pas le produit en dehors des limites de puissance
indiquées dans les caractéristiques techniques.
Ne tentez pas d‘ouvrir le produit en cas de détérioration et cessez
de l’utiliser.
La batterie est installée de façon permanente et ne peut pas être
retirée ; recyclez le produit en bloc conformément aux directives légales.
•Recyclez les matériaux d’emballage conformément aux
prescriptions locales en vigueur.
N’apportez aucune modication à l’appareil. Des modications
vous feraient perdre vos droits de garantie.
Page 31
30
Avertissement concernant les batteries
•Utilisez exclusivement un chargeur approprié ou une connexion USB lors de la recharge.
•Cessez d‘utiliser tout chargeur ou toute connexion USB défectueux et ne tentez pas de réparer ces derniers.
•Ne surchargez ou ne déchargez pas totalement le produit.
•Evitez un stockage, une charge ou une utilisation à des températures extrêmes.
•Nous vous recommandons de charger entièrement la batterie de l‘appareil une fois tous les deux mois.
4. Mise en service
•Le micro-casque dispose d’une batterie rechargeable. La batterie doit être totalement rechargée avant la première utilisation du micro-casque.
•Assurez-vous que le micro-casque est bien hors tension avant de commencer la charge de l’appareil.
•Démarrez le cycle de charge en branchant le câble USB fourni à la prise de charge (5) et au port USB d’un ordinateur (portable ou non). Vous pouvez également charger le micro-casque à l’aide d’un chargeur USB adapté. Veuillez, dans ce cas, également consulter le mode d’emploi du chargeur USB utilisé.
•Le voyant LED de charge (2) en rouge en permanence pendant la charge.
•La charge de la batterie est susceptible de durer 2 heures.
Avertissement
N’utilisez pas le micro-casque pendant la recharge !
Page 32
31
•La LED d’état (2) s’allume en bleu en permanence dès que la batterie est entièrement chargée.
•Débranchez tous les câbles et les connexions secteur.
Remarque
Il est possible que le témoin lumineux rouge s‘allume uniquement 15-30 minutes après avoir démarré la procédure de charge si voyant LED de charge (2) n‘avez pas utilisé votre appareil pendant quelques mois.
5. Fonctionnement
hors tension (ON / OFF)
Mise sous tension (ON): À l’état éteint, maintenez la touche multifonctions (1) enfoncée pendant 3 secondes jusqu’à ce que vous entendiez un message vocal. La LED d’état (2) clignote trois fois en bleu. Le message vocal est réglé sur la capacité de la batterie, laquelle est mesurée en fonction de l’autonomie en conversation encore disponible:
Autonomie en conversation disponible
Message vocal
> 3,75 h„Battery high“
3,75 h – 0,75 h„Battery medium“
< 0,75 h„Battery low“
Page 33
32
Mise hors tension (OFF): À l’état allumé, maintenez la touche multifonctions (1) enfoncée pendant 5 secondes. La LED d’état (2) clignote deux fois en rouge avant que l’appareil ne s’éteigne.
Lors de la première mise sous tension, le couplage démarre automatiquement - voir 5.1. Première connexion Bluetooth
(couplage).
5.1. Première connexion Bluetooth (couplage)
Remarque concernant le couplage
•Assurez-vous que votre appareil Bluetooth est bien sous tension et que sa fonction Bluetooth est bien activée.
•Veuillez également consulter le mode d’emploi de votre appareil.
•La distance entre le micro-casque Bluetooth et votre appareil ne devrait pas excéder un mètre. Plus la distance entre est petite, meilleure est la connexion.
•Assurez-vous que le casque est éteint.
•Appuyez sur la touche multifonctions (1) pendant environ 8 s jusqu‘à ce que la LED d’état (2) clignote alternativement en rouge/bleu. Le micro-casque recherche une connexion Bluetooth.
•Ouvrez le menu des paramètres Bluetooth sur votre appareil portable et attendez que l’appareil MyVoice3000 apparaisse dans la liste des appareils Bluetooth détectés.
•Sélectionnez l’appareil MyVoice3000, puis patientez jusqu’à ce que le micro-casque apparaisse en tant que connecté dans les réglages Bluetooth de votre appareil.
Page 34
33
Remarque concernant le mot de passe Bluetooth
Saisissez le mot de passe 0000, dans le cas où l’appareil exige la saisie d’un mot de passe.
Remarque
Lorsque le couplage a réussi, la LED d’état (2) s’allume pendant env. 2 secondes en bleu. Un bref signal acoustique retentit et vous entendez le message vocal « Your phone is connected ».
•Vous pouvez commencer à utiliser le kit mains libres.
5.2. Connexion Bluetooth automatique
(après un premier couplage réussi)
Remarque
•Assurez-vous que votre appareil compatible Bluetooth est sous tension et que la fonction Bluetooth est activée.
•Veuillez également consulter le mode d’emploi de votre appareil.
•Assurez-vous que le micro-casque est hors tension.
•Après une première connexion conforme, les connexions suivantes sont établies automatiquement.
•Vous pouvez commencer à utiliser le micro-casque.
Page 35
34
Remarque
•Lorsque le couplage a réussi, la LED d’état (2) s’allume pendant env. 2 secondes en bleu. Un bref signal acoustique retentit et vous entendez le message vocal « Your phone is connected ».
•Le cas échéant, vous devrez paramétrer votre appareil an d’autoriser la connexion automatique avec le micro-casque couplé.
Remarque concernant une mauvaise connexion
Après une première connexion conforme, les connexions suivantes sont établies automatiquement. Dans le cas où la connexion Bluetooth ne s’établit automatiquement, vériez les points suivants:
•Vériez, dans les paramètres Bluetooth de votre appareil portable, que MyVoice3000 est bien connecté. Si ce n’est pas le cas, répétez les étapes décrites dans le paragraphe 5.1. Première connexion Bluetooth.
•Vériez la présence d’obstacles susceptibles de réduire la portée. Si tel est le cas, rapprochez les appareils l’un de l’autre.
•Une pile faible est également susceptible d’inuencer négativement le fonctionnement du produit.
5.3. Multipairing
•Vous pouvez coupler le micro-casque à deux appareils en même temps, par ex. un téléphone portable privé et un téléphone portable de fonction, pour les utiliser en parallèle.
Page 36
35
•Activez d’abord la fonction Bluetooth sur le premier appareil que vous souhaitez coupler.
•Couplez le premier appareil – comme décrit au point 5.1. Couplage Bluetooth (première connexion) – au micro­casque.
•Mettez le micro-casque hors tension – comme décrit au point 5. Service (mise hors tension).
•Activez désormais la fonction Bluetooth sur le second appareil.
•Appuyez sur la touche multifonctions (1) pendant env. 8 secondes jusqu'à ce que la LED d’état (2) clignote alternativement en rouge/bleu. Le micro-casque recherche une connexion Bluetooth.
•Continuez comme décrit au point 5.1. Couplage Bluetooth (première connexion).
•Une fois le deuxième appareil connecté, ouvrez les réglages Bluetooth sur l’appareil connecté en premier, puis sélectionnez MyVoice3000.
•Les deux appareils sont connectés au micro-casque.
5.4. Fonction mains libres
Remarque
•Veuillez noter que la prise en charge de certaines fonctions dépend de votre appareil.
•Veuillez consulter le mode d’emploi de votre appareil à ce sujet.
Effectuer un appel
•Composez le numéro directement sur votre appareil an d’effectuer un appel.
Page 37
36
Numérotation vocale
•Vériez si votre téléphone portable supporte la numérotation vocale.
•Appuyez sur la touche multifonctions (1) pendant environ 3 s.
•Sur votre téléphone portable, la commande vocale s’ouvre.
•Pour passer un appel, procédez comme décrit dans le mode d’emploi de votre téléphone portable.
•Dites le nom de la personne que vous souhaitez appeler.
•Si les entrées vocales sont couplées au numéro de téléphone correspondant, enregistré dans votre téléphone portable, le numéro sera composé.
Recevoir un appel
•Appuyez une fois sur la touche multifonctions (1) an de répondre à un appel entrant.
Refuser un appel entrant
•Appuyez pendant env. 3 secondes sur la touche multifonctions (1) an de refuser un appel entrant. Un bref signal acoustique retentit.
Mettre fin à un appel
•Pendant une conversation, appuyez une fois sur la touche multifonctions (1) an de terminer un appel.
Rappel du dernier numéro composé
•Appuyez brièvement 2 fois sur la touche multifonctions (1) an d’appeler le numéro du dernier appel.
•Vous entendrez un bref bip.
Page 38
37
Transmettre un appel
•Appuyez, au cours de l’appel, sur la touche multifonctions (1) pendant environ 3 s an de transmettre l’appel du micro-casque vers votre téléphone ou de votre téléphone vers le micro-casque. Un bref signal acoustique retentit.
5.5. Réglage du volume et mise en sourdine
•Utilisez la touche de réglage du volume (-) (3) pour diminuer le volume.
•Utilisez la touche de réglage du volume (+) (4) pour augmenter le volume.
5.6. Déconnexion du micro-casque
•Mettez le micro-casque hors tension.
•Déconnectez le micro-casque à l’aide des paramètres Bluetooth de votre appareil.
5.7. Capacité de la batterie
•En cas de batterie faible, le micro-casque émet des bips et la LED d’état (2) se met à clignoter en rouge.
•Chargez alors le kit mains-libres – comme décrit au point 4. Mise en service.
Remarque
Il est possible que les temps de veille et de conversation indiqués diffèrent en fonction du type de téléphone portable ou d‘appareil Bluetooth utilisé, des paramètres d‘utilisation, du style d‘utilisation et de l‘environnement.
Page 39
38
•Appuyez sur la touche multifonctions (1) pendant env. 1 seconde pour connaître la capacité actuelle de la batterie lorsque le micro-casque est éteint.
•Appuyez sur les deux touches de réglage du volume (-)/ (+) (3/4) et maintenez-les enfoncées pour connaître la capacité actuelle de la batterie lorsque le micro-casque est allumé. Le message vocal est réglé sur la capacité de la batterie, laquelle est mesurée en fonction de l’autonomie en conversation encore disponible:
Autonomie en
conversation
disponible
Message vocal
LED d’état (2)
> 3,75 h„Battery high“ Bleu
3 secondes
3,75 h – 0,75 h„Battery medium“ Bleu clignote 3x
< 0,75 h„Battery low“
Rouge clignote 3x
6. Soins et entretien
Nettoyez ce produit uniquement à l’aide d’un chiffon non pelucheux légèrement humide ; évitez tout détergent agressif. Veillez à ce qu’aucun liquide ne pénètre dans le produit.
7. Exclusion de garantie
La société Hama GmbH & Co. KG décline toute responsabilité en cas de dommages provoqués par une installation, un montage ou une utilisation non conformes du produit ou encore provoqués par un non respect des consignes du mode d‘emploi et/ou des consignes de sécurité.
Page 40
39
8. Service et assistance
En cas de question concernant le produit, veuillez vous adresser au service de conseil produits de Hama. Ligne téléphonique directe : +49 9091 502-115 (allemand/anglais) Vous trouverez ici de plus amples informations concernant l‘assistance : www.hama.com
9. Caractéristiques techniques
Micro-casque Bluetooth
Technologie Bluetooth Bluetooth v3.0
Prols supportés HSP, HFP, A2DP
Fréquence pour les
transmissions Bluetooth
2,402 GHz – 2,480 GHz
Portée < 10 m
Batterie
Type
Lithium polymère 3,7 V
80 mAh
Temps de recharge ~ 2h
Page 41
40
10. Consignes de recyclage
Remarques concernant la protection de l’environnement:
Conformément à la directive européenne 2012/19/EU et 2006/66/CE, et an d‘atteindre un certain nombre d‘objectifs en matière de protection de l‘environnement, les règles suivantes doivent être appliquées: Les
appareils électriques et électroniques ainsi que les batteries ne doivent pas être éliminés avec les déchets ménagers. Le pictogramme “picto” présent sur le produit, son manuel d‘utilisation ou son emballage indique que le produit est soumis à cette réglementation. Le consommateur doit retourner le produit/la batterie usager aux points de collecte prévus à cet effet. Il peut aussi le remettre à un revendeur. En permettant enn le recyclage des produits ainsi que les batteries, le consommateur contribuera à la protection de notre environnement. C‘est un acte écologique.
11. Déclaration de conformité
La société Hama GmbH & Co. KG déclare par la présente
que cet appareil est conforme aux exigences essentielles
et aux autres dispositions de la directive 2014/53/UE. Voss trouverez la déclaration de conformité selon la directive correspondante sur notre site: www.hama.com.
Page 42
41
Elementos de manejo e indicadores
7. Tecla multifunción
8.
LED de estado
9.
Regulador de volumen (-)
10.
Regulador de volumen (+)
11.
Hembrilla de carga
12.
Micrófono
Le agradecemos que se haya decidido por un producto de Hama. Tómese tiempo y léase primero las siguientes instrucciones e indicaciones. Después, guarde estas instrucciones de manejo en un lugar seguro para poder consultarlas cuando sea necesario. Si vende el aparato, entregue estas instrucciones de manejo al nuevo propietario.
1.
Explicación de los símbolos de aviso y de las indicaciones
Aviso
Se utiliza para caracterizar las indicaciones de seguridad o para llamar la atención sobre peligros y riesgos especiales.
Nota
Se utiliza para caracterizar informaciones adicionales o indicaciones importantes.
E Instrucciones de uso
Page 43
42
2. Contenido del paquete
•1Headset Bluetooth MyVoice3000
•1cable de carga USB (B)
•1arco de oreja (C)
•3almohadillas (D)
•Estas instrucciones de manejo
3. Instrucciones de seguridad
•El producto es para el uso doméstico privado, no comercial.
•Proteja el producto de la suciedad, la humedad y el
sobrecalentamiento y utilícelo sólo en recintos secos.
Durante los desplazamientos con un vehículo o aparato deportivo,
no se distraiga con el producto y preste atención al tráco y a su entorno.
No deje caer el producto ni lo someta a sacudidas fuertes.
•No opere el producto fuera de los límites de potencia indicados
en los datos técnicos.
No abra el producto y no lo siga operando de presentar
deterioros.
La pila recargable está montada de forma ja y no se puede
retirar, deseche el producto como una unidad y en conformidad con los reglamentos locales.
Deseche el material de embalaje en conformidad con las
disposiciones locales sobre el desecho vigentes.
No realice cambios en el aparato. Esto conllevaría la pérdida de
todos los derechos de la garantía.
Page 44
43
Aviso – Batería
•Utilice solo cargadores adecuados o conexiones USB para cargar.
•No siga utilizando cargadores o conexiones USB defectuosos y no intente repararlos.
•No sobrecargue ni descargue en profundidad el producto.
•Evite almacenar, cargar y usar las pilas en condiciones de temperatura extrema.
•En caso de almacenamiento prolongado, cargue regularmente (mín. trimestralmente).
4. Puesta en funcionamiento
•El headset incorpora una batería recargable. La batería debe haberse cargado completamente antes del primer uso.
•Asegúrese de que el headset está apagado antes de proceder a su carga.
•Inicie el proceso de carga conectando el cable de carga USB adjunto a la hembrilla de carga (5) y al puerto USB de un PC/ ordenador portátil. Alternativamente, puede cargar el headset utilizando un cargador USB. Para ello, tenga en cuenta las instrucciones de manejo del cargador USB utilizado.
•El LED de estado (2) luce de color rojo de manera continua durante el proceso de carga.
•Pueden transcurrir hasta 2 horas hasta que la batería esté totalmente cargada.
Page 45
44
Aviso
No utilice el headset durante el proceso de carga!
•Una vez cargada completamente la batería, el LED de estado (2) se mantiene continuamente iluminado de color azul.
•Seguidamente, interrumpa todas las conexiones por cable y de red.
Nota
Si no ha utilizado el dispositivo durante varios meses, pueden transcurrir hasta 15-30 minutos hasta que el LED de estado (2) se encienda de color rojo durante el proceso de carga.
5. Funcionamiento
Conexión/desconexión del headset
Encendido: Con el dispositivo apagado, mantenga pulsada la tecla de multifunción (1) durante 3 segundos, hasta que oiga una información por voz. El LED de estado (2) parpadea tres veces de color azul. La información por voz está sujeta a la capacidad de la batería, medida según el tiempo en conversación disponible en ese momento:
Page 46
45
Tiempo en conversación disponible
Información por voz
> 3,75 h„Battery high“
3,75 h – 0,75 h„Battery medium“
< 0,75 h„Battery low“
Apagado: Con el dispositivo encendido, mantenga pulsada la tecla de multifunción (1) durante 5 segundos. El LED de estado (2) parpadea dos veces de color rojo antes de la desconexión del dispositivo.
Durante el primer encendido se inicia automáticamente el proceso de vinculación – véase 5.1. Conexión inicial Bluetooth
(vinculación)
5.1. Conexión inicial Bluetooth (vinculación)
Nota – Vinculación
•Asegúrese de que su terminal compatible con Bluetooth está encendido y de que se ha activado Bluetooth.
•Observe también las instrucciones de uso de su terminal.
•Entre el headset y el terminal no debería haber más de 1 metro de separación. Cuanto menor sea la distancia entre ellos, mejor.
•Cerciórese de que el headset está apagado.
•Pulse la tecla de multifunción (1) durante aprox. 8 segundos hasta que el LED de estado (2) se encienda alternando los colores rojo y azul. El headset busca una conexión Bluetooth.
Page 47
46
•En el terminal, abra la conguración Bluetooth y espere hasta que se muestre MyVoice3000 en la lista de los dispositivos Bluetooth encontrados.
•Seleccione MyVoice3000 y espere hasta que el headset se muestre como conectado en los ajustes de Bluetooth de su terminal.
Nota – Contraseña Bluetooth
Algunos terminales requieren una contraseña para la conguración de la conexión con otros dispositivos Bluetooth.
•Introduzca la contraseña 0000 para la conexión si el terminal lo requiriese.
Nota
Si la vinculación se ha realizado correctamente, el LED de estado (2) se encenderá durante aprox. 2 segundos, de color
azul. Se emite un breve tono de señal y la información por voz «Your phone is connected».
•Ahora puede utilizar el headset.
Page 48
47
5.2. Conexión Bluetooth automática (una vez realizada la vinculación)
Nota
•Asegúrese de que su terminal compatible con Bluetooth está encendido y de que se ha activado Bluetooth.
•Observe también las instrucciones de uso de su terminal.
•Cerciórese de que el headset está encendido.
•La conexión se establece de forma automática tras el establecimiento correcto de la conexión inicial.
•Ahora puede utilizar el headset
Nota
•Si la vinculación se ha realizado correctamente, el LED de estado (2) se encenderá durante aprox. 2 segundos, de color
azul. Se emite un breve tono de señal y la información por voz «Your phone is connected».
•De ser necesario, puede que deba efectuar los ajustes necesarios en el terminal para permitir la conexión automática con el headset vinculado.
Page 49
48
Nota - Fallo en la conexión
La conexión se establece de forma automática tras el establecimiento correcto de la conexión inicial. De no establecerse la conexión Bluetooth de forma automática, compruebe los siguientes puntos:
•Compruebe, en la conguración Bluetooth del terminal, si MyVoice3000 se ha conectado. De no ser así, repita los pasos nombrados en 5.1. Conexión inicial Bluetooth.
•Verique la presencia de obstáculos que puedan afectar al alcance. De haberlos, reduzca la separación entre los dispositivos.
•El rendimiento también puede verse afectado por una carga baja de la pila.
5.3. Multivinculación
•Puede vincular el headset simultáneamente con dos terminales, como pueden ser p. ej. un teléfono móvil de negocios y uno privado, para poder utilizar los dos de forma paralela.
•En primer lugar, active Bluetooth únicamente en el primer terminal que desee vincular.
•Vincule el primer terminal, como se describe en 5.1. Vinculación Bluetooth (conexión inicial), con el headset.
•Apague el headset, como se describe en 5. Funcionamiento (Apagado).
•Active Bluetooth ahora también en el segundo terminal.
•Pulse y mantenga pulsada la tecla de multifunción (1) durante aprox. 8 segundos hasta que el LED de estado (2) se encienda alternando los colores rojo y azul. El headset busca una conexión Bluetooth.
•Proceda como se describe en 5.1. Vinculación Bluetooth (conexión inicial).
Page 50
49
•Conectado correctamente el segundo terminal, abra los ajustes de Bluetooth en el terminal conectado en primer lugar y seleccione MyVoice3000.
•Ambos terminales quedan conectados con el headset.
5.4. Función de manos libres
Nota
•Tenga en cuenta que la compatibilidad con algunas de las funciones depende de su terminal.
•Observe también las instrucciones de uso de su terminal.
Realizar una llamada
•Marque el número directamente desde su terminal para realizar una llamada.
Función de marcación por voz
•Compruebe si su teléfono móvil es compatible con la marcación por voz.
•pulse y mantenga pulsada la tecla de multifunción (1) durante aprox. 3 segundos
•Se abrirá seguidamente el control por voz de su teléfono móvil.
•Para realizar una llamada, proceda como se describe en las instrucciones de uso de su teléfono móvil.
•Diga el nombre de la persona a la que desea llamar.
•Si la entrada de voz está correctamente vinculada con el número de teléfono correspondiente guardado en su teléfono móvil, procederá a marcarse el número.
Contestar una llamada
•Pulse una vez la tecla de multifunción (1) para aceptar una llamada entrante.
Page 51
50
Rechazar una llamada entrante
•Pulse y mantenga pulsada la tecla multifunción (1) durante aprox. 3 segundos para rechazar la llamada entrante. Se emite un breve tono de señal.
Finalizar una llamada
•Durante la conversación, pulse una vez la tecla de multifunción (1) para nalizar la llamada.
Rellamada
•Pulse dos veces la tecla de multifunción (1), brevemente, para llamar al número de la última llamada.
•Oirá un tono breve de señal.
Transferir una llamada
•Durante la llamada, pulse y mantenga pulsada la tecla de multifunción (1) durante aprox. 3 segundos para transferir
la llamada desde el headset al terminal o desde el terminal al headset. Se emite un breve tono de señal.
5.5. Regulación del volumen y silenciamiento
•Pulse el regulador de volumen (-) (3) para disminuir el volumen.
•Pulse el regulador de volumen (+) (4) para subir el volumen.
5.6. Desconexión del headset
•Apague el headset.
•Desconecte el headset mediante los ajustes de Bluetooth de su terminal.
5.5. Capacidad de la batería
•Cuando la capacidad de la batería es baja, el headset emite un pitido y el LED de estado (2) comienza a parpadear de color rojo.
Page 52
51
•Cargue el headset, como se describe en 4. Puesta en
funcionamiento.
Nota
El tiempo de conversación o en standby disponible depende, no obstante, del teléfono móvil o los dispositivos Bluetooth compatibles empleados, así como de los ajustes del usuario, las preferencias del usuario y las condiciones concretas del entorno
•Pulse la tecla multifunción (1) durante aprox. 1 segundo para conocer la capacidad actual de la batería si el headset está apagado.
•Pulse y mantenga pulsados ambos reguladores de volumen (-)/ (+) (3/4) para conocer la capacidad actual de la batería si el headset está encendido. La información por voz está sujeta a la capacidad de la batería, medida según el tiempo en conversación disponible en ese momento:
Tiempo en
conversación
disponible
Información
por voz
LED de estado
(2)
> 3,75 h„Battery high“
Azul 3 segundos
3,75 h – 0,75 h„Battery medium“
Azul 3 parpadeos
< 0,75 h„Battery low“
Rojo 3 parpadeos
Page 53
52
6. Mantenimiento y cuidado
Limpie este producto sólo con un paño ligeramente humedecido que no deje pelusas y no utilice detergentes agresivos. Asegúrese de que no entre agua en el producto.
7. Exclusión de responsabilidad
Hama GmbH & Co KG no se responsabiliza ni concede garantía por los daños que surjan por una instalación, montaje o manejo incorrectos del producto o por la no observación de las instrucciones de manejo y/o de las instrucciones de seguridad.
8. Servicio y soporte
Si tiene que hacer alguna consulta sobre el producto, diríjase al asesoramiento de productos Hama. Línea directa: +49 9091 502-115 (Alemán/Inglés) Encontrar más información de soporte aquí: www.hama.com
9. Datos técnicos
Headset Bluetooth
Tecnología Bluetooth Bluetooth v3.0
Perles soportados HSP, HFP, A2DP
Frecuencia para las
transmisiones Bluetooth
2,402 GHz – 2,480 GHz
Alcance < 10 m
Page 54
53
Batería
Tipo
3,7 V polímero de litio
80 mAh
Tiempo de carga ~ 2h
10. Instrucciones para desecho y reciclaje
Nota sobre la protección medioambiental:
Después de la puesta en marcha de la directiva Europea 2012/19/EU y 2006/66/EU en el sistema legislativo nacional, se aplicara lo siguiente: Los aparatos eléctricos y electrónicos, así como las baterías, no se deben
evacuar en la basura doméstica. El usuario está legalmente obligado a llevar los aparatos eléctricos y electrónicos, así como pilas y pilas recargables, al nal de su vida útil a los puntos de recogida comunales o a devolverlos al lugar donde los adquirió. Los detalles quedaran denidos por la ley de cada país. El símbolo en el producto, en las instrucciones de uso o en el embalaje hace referencia a ello. Gracias al reciclaje, al reciclaje del material o a otras formas de reciclaje de aparatos/pilas usados, contribuye Usted de forma importante a la protección de nuestro medio ambiente.
11. Declaración de conformidad
Madiante la presente, Hama GmbH & Co. KG delcara
que este aparato cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de la directiva 2014/53/UE. La declaración de conformidad conforme a la directiva correspondiente la encontrará en www.hama.com.
Page 55
54
Elementy obsługi i sygnalizacji
1. Przycisk wielofunkcyjny
2.
Dioda LED stanu
3.
Regulator głośności (-)
4.
Regulator głośności (+)
5.
Gniazdo ładujące
6.
Mikrofon
Dziękujemy za zakup naszego produktu! Przed pierwszym użyciem należy dokładnie przeczytać instrukcję obsługi. Instrukcję należy przechować, gdyż może być jeszcze potrzebna.
1. Objaśnienie symboli ostrzegawczych i wskazówek
Ostrzeżenie
Używane w celu zwrócenia uwagi na szczególne niebezpieczeństwo lub ryzyko.
Wskazówki
Używane w celu zwrócenia uwagi na szczególnie przydatne informacje.
P Instrukcja obsługi
Page 56
55
2. Zawartość opakowania
•1x zestaw słuchawkowy Bluetooth MyVoice3000
•1x kabel ładujący USB (B)
•1x pałąk zauszny (C)
•3x poduszki słuchawkowe (D)
•niniejsza instrukcja obsługi
3. Wskazówki bezpieczeństwa
Produkt jest przeznaczony do prywatnego, niekomercyjnego
użytku domowego.
•Chronić produkt przed zanieczyszczeniem, wilgocią i przegrzaniem
oraz stosować go tylko w suchym otoczeniu.
•Podczas jazdy pojazdem mechanicznym bądź używania przyrządu
sportowego nie dopuścić do odwrócenia uwagi przez produkt oraz stale obserwować otoczenie i sytuację w ruchu drogowym.
•Chronić produkt przed upadkiem i silnymi wstrząsami.
Nie stosować produktu poza zakresem mocy podanym w danych
technicznych.
•Nie otwierać produktu i nie używać go, gdy jest uszkodzony.
•Akumulator jest zamontowany na stałe i nie można go
usunąć, poddać cały produkt utylizacji zgodnie z ustawowymi postanowieniami.
•Materiały opakowaniowe należy natychmiast poddać utylizacji
zgodnie z obowiązującymi przepisami miejscowymi.
•Nie modykować urządzenia. Prowadzi to do utraty wszelkich
roszczeń z tytułu gwarancji.
Page 57
56
Ostrzeżenie – akumulator
•Używać do ładowania tylko odpowiednich ładowarek lub portów USB.
•Generalnie nie stosować uszkodzonych ładowarek lub portów USB ani nie próbować ich naprawiać.
•Chronić produkt przed przeładowaniem lub głębokim rozładowaniem.
•Unikać przechowywania, ładowania i stosowania w ekstremalnych temperaturach.
•Wprzypadku dłuższego przechowywania regularnie (przynajmniej co kwartał) doładowywać akumulator.
4. Uruchamianie
•Zestaw słuchawkowy posiada ładowalny akumulator. Przed pierwszym użyciem należy całkowicie naładować akumulator.
•Przed ładowaniem upewnić się, że zestaw słuchawkowy jest wyłączony.
•Rozpocząć proces ładowania, podłączając dołączony kabel ładujący USB do gniazda ładującego (5) i portu USB komputera/ notebooka. Alternatywnie zestaw słuchawkowy można też naładować za pomocą odpowiedniej ładowarki USB. Uwzględnić instrukcję obsługi stosowanej ładowarki USB.
•Podczas ładowania dioda LED stanu (2) świeci się ciągle na czerwono.
•Całkowite naładowanie akumulatora może trwać do 2 godzin.
Page 58
57
Ostrzeżenie
Nie używać zestawu słuchawkowego podczas procesu ładowania!
•Po całkowitym naładowaniu akumulatora dioda LED stanu (2) świeci się ciągle na niebiesko.
•Następnie odłączyć wszystkie połączenia kablowe i sieciowe.
Wskazówka
Jeżeli urządzenie nie jest używane przez kilka miesięcy, czas, po którym dioda LED stanu (2) zaświeci się na czerwono w trakcie procesu ładowania, może wynieść 15-30 minut.
5. Praca
Włączanie/ wyłączanie zestawu słuchawkowego
Włączanie: Przy wyłączonym urządzeniu trzymać wciśnięty przez 3 sekundy przycisk wielofunkcyjny (1), aż rozlegnie się komunikat głosowy. Dioda LED stanu (2) miga trzykrotnie na niebiesko. Komunikat głosowy zależy od pojemności akumulatora, czyli dostępnego jeszcze czasu rozmowy:
Page 59
58
Dostępny czas rozmowy Komunikat głosowy
> 3,75 h„Battery high“
3,75 h – 0,75 h„Battery medium“
< 0,75 h„Battery low“
Wyłączanie: Przy włączonym urządzeniu trzymać wciśnięty przez 5 sekundy przycisk wielofunkcyjny (1). Dioda LED stanu (2) miga dwukrotnie na czerwono, zanim urządzenie się wyłączy.
Po pierwszym włączeniu automatycznie uruchamiana jest funkcja parowania (pairing) - patrz rozdział 5.1. Pierwsze łączenie
Bluetooth (pairing).
5.1. Pierwsze łączenie Bluetooth (pairing)
Wskazówka – parowanie urządzeń (pairing)
•Urządzenie końcowe Bluetooth musi być włączone i łącze Bluetooth musi być aktywne.
•Uwzględnić instrukcję obsługi urządzenia końcowego.
•Zestaw słuchawkowy i urządzenie końcowe nie powinny znajdować się w odległości większej niż 1 m od siebie. Im mniejsza odległość, tym lepiej.
•Upewnić się, czy zestaw słuchawkowy jest wyłączony.
•Nacisnąć przycisk wielofunkcyjny (1) przez ok. 8 sekund, aż dioda LED stanu (2) zaświeci się na przemian na czerwono i niebiesko. Zestaw słuchawkowy szuka połączenia Bluetooth.
Page 60
59
•Otworzyć na urządzeniu końcowym ustawienia Bluetooth i poczekać, aż w liście znalezionych urządzeń Bluetooth pojawi się napis MyVoice3000.
•Wybrać MyVoice3000 i poczekać, aż zestaw słuchawkowy będzie wyświetlany jako połączony w ustawieniach Bluetooth urządzenia końcowego.
Wskazówka – hasło Bluetooth
Niektóre urządzenia końcowe wymagają podania hasła do konguracji połączenia z innym urządzeniem Bluetooth.
•Jeżeli na urządzeniu końcowym pojawi się wezwanie do podania hasła, wpisać hasło 0000 w celu połączenia.
Wskazówka
Jeżeli parowanie powiodło się, dioda LED stanu (2) świeci się na niebiesko przez ok. 2 sekundy. Rozlega się krótki sygnał dźwiękowy i komunikat głosowy „Your phone is connected“.
•Teraz zestaw słuchawkowy jest gotowy do użycia.
5.2. Automatyczne połączenie Bluetooth (po wcześniejszym sparowaniu urządzeń)
Wskazówka
•Urządzenie końcowe Bluetooth musi być włączone i łącze Bluetooth musi być aktywne.
•Uwzględnić instrukcję obsługi urządzenia końcowego.
Page 61
60
•Upewnić się, czy zestaw słuchawkowy jest włączony.
•Po pierwszym pomyślnym połączeniu kolejne łączenie odbywa się automatycznie.
•Teraz zestaw słuchawkowy jest gotowy do użycia.
Wskazówka
•Jeżeli parowanie powiodło się, dioda LED stanu (2) świeci się na niebiesko przez ok. 2 sekundy. Rozlega się krótki sygnał dźwiękowy i komunikat głosowy „Your phone is connected“.
•Ewentualnie należy skongurować urządzenie końcowe, aby zezwolić na automatyczne połączenie ze sparowanym zestawem słuchawkowym.
Wskazówka - zakłócone połączenie
Po pierwszym pomyślnym połączeniu kolejne łączenie odbywa się automatycznie. Jeżeli połączenie Bluetooth nie zostanie nawiązane automatycznie, sprawdzić następujące punkty:
•Sprawdzić w ustawieniach Bluetooth urządzenia końcowego, czy urządzenie MyVoice3000 jest połączone. Jeżeli nie, powtórzyć czynności opisane w rozdziale 5.1. Pierwsze
łączenie Bluetooth.
•Sprawdzić, czy zasięg działania nie jest ograniczony przez przeszkody. Ewentualnie przybliżyć urządzenia do siebie.
•Słaba bateria może także niekorzystnie wpływać na działanie urządzenia.
Page 62
61
5.3. Multipairing
•Zestaw słuchawkowy można jednocześnie połączyć z dwoma urządzeniami końcowymi, aby np. móc jednocześnie korzystać z telefonu komórkowego prywatnego i służbowego.
•Najpierw włączyć Bluetooth tylko na pierwszym urządzeniu, które ma być sparowane.
•Połączyć pierwsze urządzenie końcowe - zgodnie z opisem w rozdziale 5.1. Pierwsze łączenie Bluetooth (pairing) – z zestawem słuchawkowym.
•Wyłączyć zestaw słuchawkowy – zgodnie z opisem w rozdziale
5. Praca (wyłączanie).
•Włączyć Bluetooth także w drugim urządzeniu końcowym.
•Nacisnąć i trzymać wciśnięty przez ok. 8 sekund przycisk wielofunkcyjny (1), aż dioda LED stanu (2) zaświeci się na przemian na czerwono i niebiesko. Zestaw słuchawkowy szuka połączenia Bluetooth.
•Następnie postępować zgodnie z opisem w rozdziale
5.1. Pierwsze łączenie Bluetooth (pairing).
•Po pomyślnym połączeniu drugiego urządzenia końcowego, na pierwszym z połączonych urządzeń końcowych otwierają się ustawienia Bluetooth, należy wtedy wybrać MyVoice3000.
•Oba urządzenia końcowe są połączone z zestawem słuchawkowym.
5.4. Funkcja głośnomówiąca
Wskazówka
•Należy pamiętać, że obsługa niektórych funkcji jest zależna od urządzenia końcowego.
•Uwzględnić instrukcję obsługi urządzenia końcowego.
Page 63
62
Rozmowa telefoniczna
•Aby wykonać rozmowę telefoniczną, wybrać numer bezpośrednio za pomocą urządzenia końcowego.
Funkcja wyboru głosowego
•Sprawdzić, czy telefon komórkowy posiada funkcję wyboru głosowego.
•Nacisnąć i trzymać wciśnięty przez ok. 3 sekundy przycisk wielofunkcyjny (1).
•Wtelefonie komórkowym otwierana jest funkcja sterowania głosowego.
•Aby wykonać rozmowę telefoniczną, postępować zgodnie z opisem w instrukcji obsługi telefonu komórkowego.
•Wypowiedzieć nazwisko osoby, z którą chcemy rozmawiać przez telefon.
•Jeżeli komunikaty głosowe są połączone z numerem kontaktu zapisanym w telefonie komórkowym, numer ten jest wybierany.
Odbieranie rozmowy telefonicznej
•Jednokrotnie nacisnąć przycisk wielofunkcyjny (1), aby odebrać połączenie przychodzące.
Odrzucanie połączenia przychodzącego
•Nacisnąć i trzymać wciśnięty przez ok. 3 sekundy przycisk wielofunkcyjny (1), aby odrzucić połączenie przychodzące.
Rozlega się krótki sygnał dźwiękowy.
Kończenie rozmowy telefonicznej
•Podczas rozmowy jednokrotnie nacisnąć przycisk wielofunkcyjny (1), aby zakończyć połączenie.
Page 64
63
Ponowne wybieranie numeru
•Dwukrotnie nacisnąć przycisk wielofunkcyjny (1), aby wywołać ostatnio wybierany numer.
•Rozlega się krótki sygnał dźwiękowy.
Przekazywanie połączenia
•Podczas połączenia nacisnąć i trzymać wciśnięty przez ok. 3 sekundy przycisk wielofunkcyjny (1), aby przekazać połączenie z zestawu słuchawkowego na urządzenie końcowe lub z urządzenia końcowego na zestaw słuchawkowy. Rozlega się krótki sygnał dźwiękowy.
5.5. Regulacja głośności i wyciszanie
•Nacisnąć regulator głośności (-) (3), aby zmniejszyć poziom głośności.
•Nacisnąć regulator głośności (+) (4), aby zwiększyć poziom głośności.
5.6. Rozłączanie zestawu słuchawkowego
•Wyłączyć zestaw słuchawkowy.
•Odłączyć zestaw słuchawkowy poprzez ustawienia Bluetooth urządzenia końcowego.
5.7. Pojemność akumulatora
•Wprzypadku niskiej pojemności akumulatora zestaw słuchawkowy wydaje sygnał akustyczny, a dioda LED stanu (2) zaczyna migać na czerwono.
•Naładować zestaw słuchawkowy – zgodnie z opisem w rozdziale
4. Uruchamianie.
Page 65
64
Wskazówka
Dostępny czas rozmowy lub uśpienia (stand by) zależy zawsze od stosowanego telefonu komórkowego lub innych kompatybilnych urządzeń Bluetooth oraz ustawień i preferencji użytkownika, a także warunków otoczenia.
•Nacisnąć przez ok. 1 sekundę przycisk wielofunkcyjny (1), aby odczytać aktualną pojemność akumulatora, gdy zestaw słuchawkowy jest wyłączony.
•Nacisnąć i trzymać wciśnięte oba regulatory głośności (-)/ (+) (3/4), aby odczytać aktualną pojemność akumulatora, gdy zestaw słuchawkowy jest włączony. Komunikat głosowy zależy od pojemności akumulatora, czyli dostępnego jeszcze czasu rozmowy:
Dostępny czas
rozmowy
Komunikat
głosowy
Dioda LED
stanu (2)
> 3,75 h„Battery high“
Niebieska
3 sekundy
3,75 h – 0,75 h„Battery medium“
Niebieska
3x migają
< 0,75 h„Battery low“ Rot 3x migają
Page 66
65
6. Czyszczenie
Czyścić produkt tylko przy użyciu niestrzępiącej się, lekko zwilżonej szmatki i nie stosować agresywnych detergentów. Uważać, aby do wnętrza produktu nie wniknęła woda.
7. Wyłączenie odpowiedzialności
Hama GmbH & Co. KG nie udziela gwarancji ani nie odpowiada za szkody wskutek niewłaściwej instalacji, montażu oraz nieprawidłowego stosowania produktu lub nieprzestrzegania instrukcji obsługi i/lub wskazówek bezpieczeństwa.
8. Serwis i pomoc techniczna
W razie pytań dotyczących produktu prosimy zwrócić się do infolinii Hama. Gorąca linia: +49 9091 502-115 (niem./ang.) Dodatkowe informacje są dostępne na stronie: www.hama.com
Page 67
66
9. Dane techniczne
Zestaw słuchawkowy
Bluetooth
Technologia Bluetooth Bluetooth v3.0
Obsługiwane prole HSP, HFP, A2DP
Częstotliwość dla transmisji
Bluetooth
2,402 GHz – 2,480 GHz
Zasięg < 10 m
Akumulator
Typ
3,7 V akumulator litowo-
polimerowy 80 mAh
Czas ładowania ~ 2h
Page 68
67
10. Informacje dotycząca recyklingu
Wskazówki dotyczące ochrony środowiska:
Od czasu wprowadzenia europejskiej dyrektywy 2012/19/EU i 2006/66/EU do prawa narodowego obowiązują następujące ustalenia: Urządzeń elektrycznych, elektronicznych oraz baterii
jednorazowych nie należy wyrzucać razem z codziennymi odpadami domowymi! Użytkownik zobowiązany prawnie do odniesienia zepsutych, zniszczonych lub niepotrzebnych urządzeń elektrycznych i elektronicznych do punktu zbiórki lub do sprzedawcy. Szczegółowe kwestie regulują przepisy prawne danego kraju. Informuje o tym symbol przekreślonego kosza umieszczony na opakowaniu. Segregując odpady pomagasz chronić środowisko!
11. Deklaracja zgodności
Hama GmbH & Co. KG oświadcza niniejszym, że
niniejsze urządzenie jest zgodne z podstawowymi
wymaganiami i innymi właściwymi przepisami dyrektywy 2014/53/UE. Deklaracja zgodności wg odpowiedniej dyrektywy dostępna jest na stronie www.hama.com
Page 69
"The Bluetooth
®
word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Hama GmbH & Co KG is under license. Other trademarks and trade names are those of their respective owners."
All listed brands are trademarks of the corresponding companies. Errors and omissions excepted, and subject to technical changes. Our general terms of delivery and payment are applied.
00137423/04.16
Hama GmbH & Co KG
86652 Monheim
/Germany
www.hama.com
Loading...
