Halton ECOV-10 Installation Manual

ECOVENT - Condensate Hoods

Operators Instructions

ECOVENT - Condensate Hoods

Model: ECOV-10, ECOV-20, ECOV-30, ECOV-40

Table of Contents

Section 1 – Installation Page

1.1 Identification or parts 3

1.2 Fitting to Oven 4

1.3 Fitting Door Magnet 4

1.4 Connection to Services 5

1.5 Commissioning 6

Section 2 – Operation

2.1 Safety 7

2.2 Regular Operation 7

2.3 Cleaning and Maintenance 8

Section 3 – Technical and Performance Data

3.1 Canopy Information 9

3.2 Wiring Diagram 10

Section 4 – Recommended Spare Parts 12

Section 5 – EC Declaration of Conformity 13

ECOVENT Operating Instructions

2

ECOV/112012/rev1/EN

Section 1 - Installation

Identification of Parts

1. Outer Casing

2. Top Shell

3. Bottom Shell

4. Cassette

5. Mesh Moisture Eliminator

6. Baffle Filter

7. Back Plate

8. Fixing Bracket

9. ¾” Nylon Branch

10. Flexible Hose

11. Instruction Manual pack,
Incl. Door Magnet

ECOVENT Operating Instructions

3

ECOV/112012/rev1/EN
