STINGRAY 2 CHANNEL
USB OSCILLOSCOPE
(HT070202)
QUICK START GUIDE
LIMITED WARRANTY
Lockin Pty Ltd trading as Haltech warrants the HaltechTM Programmable Fuel Injection System to be
free from defects in material or workmanship for a period of 12 months from the date of purchase.
Proof of purchase, in the form of a bill of sale or receipted invoice, which indicates that the product is
within the warranty period, must be presented to obtain warranty service. Lockin Pty Ltd trading as
Haltech suggests that the purchaser retain the dealer’s dated bill of sale as evidence of the date of
retail purchase.
If the HaltechTM Programmable Fuel Injection System is found to be defective as mentioned above, it
will be replaced or repaired if returned prepaid along with proof of purchase. This shall constitute the
sole liability of Lockin Pty Ltd trading as Haltech.
To the extent permitted by law, the foregoing is exclusive and in lieu of all other warranties or
representations, either expressed or implied, including any implied warranty of merchantability or
fitness. In no event shall Lockin Pty Ltd trading as Haltech, be liable for special or consequential
damages.
DISCLAIMER
Haltech will not be held responsible for any damage caused by the incorrect installation or tuning of this
product. It is the installers responsibility to ensure the wiring connections and pinouts match that of the
vehicle the unit is being installed into.
Haltech has taken all care to make sure the connections match the specified vehicles listed, but variations
in wiring and connections on vehicles can occur and therefore this should be checked BEFORE the unit
is installed.
Haltech highly recommends installation and tuning of this product is to be carried out by a professional,
with an understanding on installing and tuning engine management systems.
Misuse of this product can destroy your engine.
WARNING
This ECU is designed and sold for Racing use only. Using this product for street / road use may be
prohibited by law. Please check with your local vehicle authority before using this product.
GENERAL INSTALLATION WARNING
Avoid open sparks, flames or operation of electrical devices near flammable substances.
Always disconnect the battery cables when doing electrical work on your vehicle.
Do not charge the battery with a 24 Volt truck charger or reverse the polarity of the battery
or any charging unit. Do not charge the battery with the engine running as this could
expose the ECU to an unregulated power supply that could destroy the ECU and other
electrical equipment.
All fuel system components and wiring should be mounted away from heat sources,
shielded if necessary and well ventilated. Disconnect the Haltech ECU from the electrical
system whenever doing any arc welding on the vehicle by unplugging the wiring harness
connector from the ECU.
After completing the installation, make sure that there are no fuel leaks, and no wiring
left un-insulated in case a spark or short-circuit occurs and causes a fire. Also make sure
that you follow all proper workshop safety procedures. If you're working underneath
a jacked-up car, always use safety stands!
Haltech Stingray 2 Channel USB Oscilloscope
Quick Start Guide
Congratulations on your purchase of the Haltech Stingray 2 Channel USB Oscilloscope.
This guide contains the specifications and installation procedure for the oscilloscope,
drivers and application software.
The Haltech Stingray 2 Channel USB Oscilloscope combines the functions of
Oscilloscope, Data Logger, Spectrum Analyzer, Volt Meter, Frequency Meter and
Signal Generator into a single instrument.
It features simultaneous 12-bit sampling on both channels, a native sampling rate of
1MS/s (20MS/s for repetitive signals) and sophisticated hardware triggering including
delayed time base and pulse width. It also has a 3rd channel which can be a waveform
generator output or an external trigger input. Powered from USB, the Haltech Stingray
2 Channel USB Oscilloscope needs no external power supply.
The Software Easy Scope II (oscilloscope) and Easy Logger (data logging) software for
windows is included on the Haltech Resource CD supplied.
Alternatively it can be downloaded from the Haltech website www.haltech.com
Haltech Stingray 2 Channel USB Oscilloscope Kit HT070202 includes
• Haltech Stingray 2 Channel USB Oscilloscope
• 2 x Probes
• USB Cable
• Case
• Haltech Resource / Software CD
• Quick Start Guide
Features
Hardware Features
• Combined Oscilloscope, Data Logger, Signal Generator, Spectrum Analyzer, Voltage
Meter and Frequency Meter functions
• 12-Bit ADC Resolution
• 12-Bit data streaming simultaneously on both channels
• 32k Byte Waveform buffer
• Sampling Rate
• Oscilloscope – 20MS/s (repetitive) , 1MS/s native
• Data logger – up to 50kS/s
• Maximum input voltage +/- 50V DC (35V RMS AC)
• AC/DC coupling
• Edge min / max, pulse width and delayed trigger modes
• Analog Bandwidth 250KHz
• Inbuilt 10-bit waveform generator with +/- 3.5V output range and 1k buffer
• Bus Powered USB Interface (250mA)
• Instrument carrying bag included
• Attractive enclosure with rubberized mouldings
• Dimensions – W: 116mm x H: 30mm x D: 100mm
• Weight: 160g (excluding cable)
Easy Scope II Software Features
• Timebase – 2us / div to 50ms / div in 14 steps
• Y-Scale 10mV / div to 5V / div
• On screen X and Y measurement cursors
• FFT Spectrum Analyser display on both channels
• Meter displays – Min, Max, Mean, True RMS Voltage and Frequency
• Save results to CSV file
• Save screen to BMP file
• Waveform generation – Sine, Square, Triangle, Sawtooth and user defined waveforms
Easy Logger Software Features
• Sampling Rate selectable from >100,000 samples / sec to 100 sec/sample
• Flexible Y-axis scaling (V, mV, User Defined)
• Flexible X-axis scaling (Sample Number or Time)
• Save to CSV, BMP. TXT or Binary files
• Up to 3 on-screen cursors to track data
• Up to 4 pop-up or email alerts
• Text memos for incorporating user notes in the data
Getting Started
The Haltech Stingray 2 Channel USB Oscilloscope requires device drivers to be
installed on your PC to enable communication with the instrument. Install the device
drivers prior to installing the applications below.
Driver Installation
The latest device drivers are available through the Microsoft Windows Update service.
Simply plug in the Haltech Stingray 2 Channel USB Oscilloscope via the USB Cable
provided in the kit. When the Found New Hardware wizard appears, allow it to find the
drivers from the windows update service. Windows 7 defaults to automatically download
the drivers without prompts.
The Haltech Stingray 2 Channel USB Oscilloscope utilizes a 2-Channel FTDI chip, so
the wizard will re-appear a second time to install the drivers for the second channel.
On completion of installation the device I ready to use.
Application Installation
Easy Scope II
The Easy Scope II application file is found on the software page on the Haltech
Resource CD, Click on the Easy Scope II software link to start the installation.
Follow the on screen prompts to install the application.
Easy Logger
The Easy Logger application file is found on the software page on the Haltech
Resource CD, Click on the Easy Logger software link to start the installation.
Follow the on screen prompts to install the application.
Once installed the applications can be accessed through the Windows start menu
Hardware Information
The Haltech Stingray 2 Channel USB Oscilloscope has the following connections
• Channel A Input
• Channel B Input
• Signal Generator Output / External Trigger Input
• USB Input
The connections are outlined in figures 1 and 2 below
Figure 1- Haltech Stingray 2 Channel USB Oscilloscope front panel connections
Figure 2- Haltech Stingray 2 Channel USB Oscilloscope rear panel connection
Caution: Measuring High Voltages
The Haltech Stingray 2 Channel USB Oscilloscope is rated at +/- 50V DC Maximum
Input (35V RMS AC) even with a x 10 oscilloscope lead attached. Measuring higher
voltages than this directly may damage the instrument and invalidate the warranty.
The instrument is not isolated. The ground of the internal circuitry connects directly to
the ground of the host PC via the USB connection.
Troubleshooting
If a static / ESD discharge occurs down the earth lead of the oscilloscope, the unit may
lock up and require the host PC to be re started to resume operation. In practice, this is
an unusual condition and should not affect normal operation.
HALTECH HEAD OFFICE: PH: +612 9729 0999
FAX: +612 9729 0900
EMAIL: sales@haltech.com
HALTECH US OFFICE: EMAIL: usa@haltech.com
See the Haltech Website for your local authorized dealer.
www.haltech.com
Version 1
