HALO HLB6 Instruction Manual

Project Catalog # Type

HLB6ROTMW

Oversized trim

3.16"

[80.29mm]

1.66"

[42.15mm]

10"

[254mm]

wire length

6.5" [165mm]

6.8" [172.72mm]

8.86"

[225mm]

max. ceiling cutout

6-1/8"

[155.58mm]

cutout

4.18"

6.7" [170.07mm]

Ø 5.02"

[127.6mm]

.

47"

[11.9mm]

.12"

[3.05mm]

HLB6ROTMW

Oversized trim

6.8" [172.72mm]

8.86"

[225mm]

max. ceiling cutout

6.7" [170.07mm]

Ø 5.02"

[127.6mm]

.

47"

[11.9mm]

.12"

[3.05mm]

HLB6ROTMW

Oversized trim

6.8" [172.72mm]

8.86"

[225mm]

max. ceiling cutout

Prepared by Notes Date

MicroEdge HLB6

Smart 6” LED Lens Downlight with Bluetooth®
Mesh connectivity and remote driver/
junction box

Typical Applications

Residential

Interactive Menu

• Order Information page 2

• Photometric Data page 2

• Product Specication page 3

• Product Warranty page 3

Top Product Features

• Delivers up to 1,061 lumens, achieves L70 at 50,000 hours in IC and non-IC applications (120V)

• Adjustable white tuning via the app: 2700K-5000K, 90 CRI (min), R9 50 and color accuracy within 4 SDCM

• Connects to the HALO Home Bluetooth Mesh network, no hub required

• Suitable for new construction and remodel

• Wet location listed for showers and protected ceilings

Dimensional Details

Product Certication

Refer to ENERGY STAR® Certified Products List.
Can be used to comply with California Title 24 High Efficacy requirements.
Certified to California Appliance Efficiency Database under JA8.

Product Features

c

m

o

r

o

a

l

w

adjustable

2

white

7

K

0

0

0

0

K

0

5

PS518163EN page 1

September 11, 2020 11:50 AM

Order Information

6

”

6

”

HLB6099BLE40AWH

SMART DIRECT MOUNT DOWNLIGHT

SMART DIRECT MOUNT DOWNLIGHT

LUMINARIA FOCAL LED DE MONTAJE EN SUPERFICIE

WHOLE HOME SMART LIGHTING SYSTEM

MicroEdge HLB6

MicroEdge HLB6

Scaled Data Report

0 cd

82 cd

164 cd

246 cd

328 cd

180°

170°

160°

150°

140°

130°

120°

110°

100°

90°

Luminous Intensity Polar Plot

HLB6ROTMW

Oversized trim

6.8" [172.72mm]

8.86"

[225mm]

max. ceiling cutout

SAMPLE ORDER NUMBER: HLB6099BLE40AWH

Models Lumens CRI / CCT Protocol Finish

Models Lumens CRI / CCT Protocol Finish

HLB6 = 6-Inch LED lens

downlight with remote
driver / junction box

Notes Notes Notes Notes Notes

Mounting Frames
HL6RSMF = 6” round and square mounting frame
HLB6ROTMW = 6” round oversized trim, matte white

Designer Trims
HLB6RTRMMW = 6” round decorative overlay, matte white
HLB6RTRMSN = 6” round decorative overlay, satin nickel
HLB6RTRMTBZ = 6” round decorative overlay, tuscan bronze

09 = 900 lumens (nominal) 9 = 90 CRI minimum, white tuning, select CCT

2700K - 5000K via mobile app

Accessories

Accessories

Extension Cables (HALO Home-only)
HLB06BLEEC = 6 ft. extension cable
HLB12BLEEC = 12 ft. extension cable
HLB20BLEEC = 20 ft. extension cable

BLE40A = Bluetooth Mesh

wireless control, 4.0

HLB6 Series

WH = Matte white bae

Photometric Data

HLB6099BLE40AWH-3000K

Luminaire lumens 943

Input watts 13.26

LER (LPW) 71.1

0 1.29

Spacing

Criteria

Beam angle (degrees) 110

Field angle (degrees) 163

Zonal lumen Lumens % Lumens

0-30 260 27.6

0-40 428 45.4

0-60 746 79.1

0-90 939 99.6

90-180 4 0.4

0-180 943 100

* Tested in accordance with IES LM63. Field results may vary.

90 1.29

45 1.38

10°

0°

60°

20°

50°

40°

30°

Energy Data

Lumens 951 lm @ 3000K

Input Voltage 120V

Input Current 115mA

Input Power 13.3(W)

Hertz 60

Eciency 71.5 (LPW)

80°

70°

Inrush 1.8 A @50 µS

THD ≤ 20%

PF ≥ 0.90

T Ambient -30° - +40°C

Sound Rating ≤ 22 dba

Color Metric Summary - 3000K

TM-30-15

CRI/CIE

CCT - Range of 2700K- 5000K

Rf = 92

Rg = 100

Ra = 96

R9 = 78

Product Specifications

PRODUCT SPECIFICATIONS

Brightness 951 lumens
Energy Used 13.3 watts

Lumens per Watt

Life

(Based on 6 hrs/day) 22 yrs

Color Accuracy 94

Correlated Color Temperature (CRI)

HLB6 6-inch

In-app

Adjustable

110°

White Tuning

Light Color (CCT) 3000K

Correlated Color Temperature (CCT)

warm white

2700K 5000K

Performance metrics are measured at the factory setting: 3000K
Las métricas de rendimiento se miden en la configuración de fábrica: 3000K

CCT Lumens Power (W) LPW

2700K 915 13.6 67.3

3000K 951 13.3 71.5

3500K 988 13.3 74.3

4000K 1018 13.3 76.5

5000K 1061 13.5 78.6

(Efficacy) 71.5

daylight

Color Temp Range
