Hall Research SC-VGA-2B User Manual

VGA/HDTV Video Processor

CUSTOMER
SUPPORT
INFORMATION

SC-VGA-2B

UMA1169 Rev. B

Order toll-free in the U.S. 800-959-6439
FREE technical support, Call 714-641-6607 or fax [phone]
Mail order: Hall Research, 1163 Warner Ave. Tustin, CA 92780
Web site: www.hallresearch.com E-mail: [e-mail]

VGA / HDTV Video Processor

TRADEMARKS USED IN THIS MANUAL

Hall Research and its logo are trademarks of Hall Research.

Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owners.

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE

STATEMENT

This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used properly, that is,
in strict accordance with the manufacturer’s instructions, may
cause interference to radio communication. It has been
designed to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part
15 of FCC rules, which are intended to provide reasonable
protection against such interference when the equipment is
operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference, in
which case the user at there own expense will be required to
take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This digital apparatus does not exceed the Class A limits for
radio noise emission from digital apparatus set out in the Radio
Interference Regulation of the Canadian Department of
Communications.

1

Model SC-VGA-2B

Contents

1. Introduction.............................................. 3

1.1 General ................................................................... 3

1.2 Features .................................................................. 3

2. Installation................................................ 3

2.1 Connections ............................................................. 3

2.2 Connection Block Diagram ........................................... 4

3. Configuration & Operation...................... 4

3.1 Input and Output........................................................ 4

3.2 Menus and Adjustments .............................................. 5

4. Troubleshooting ...................................... 8

4.1 Contacting Hall Research ............................................ 8

4.2 Shipping and Packaging .............................................. 8

5. Specifications .......................................... 9

5.1 General ................................................................... 9

5.2 Input and Output Resolutions........................................ 9

2

VGA / HDTV Video Processor

1. Introduction

1.1 General

SC-VGA-2B is a high-performance universal VGA / HDTV to VGA / HDTV
Scan Rate converter with a local loop out.

The SC-VGA-2B has the ability to output a specified resolution and refresh rate
regardless of the input. Output timing to the display is constant regardless of
the input so when switched from one input to another, the display device does
not see any interruption in the signal coming to it.

The video processor combines the functions of a video scaler, scan-converter,
and format transformer. The SC-VGA-2B also includes a horizontal mirroring
feature which is useful for teleprompter’s and rear projection systems.

The SC-VGA-2B features an OSD menu for configuration, picture setup,
system information and many other advanced options.

1.2 Features

• Any PC or HDTV video signal can be scaled up or scaled down to
any other PC or HDTV resolution.

• Adjustable output frame rate.

• Additional loop-out to bypass signal processing.

• Large Video memory for real-time frame rate capture & conversion.

• Signal format conversion between RGBHV and YPbPr.

• Automatically detects input mode and timing parameters.

• Allows adjustment of sampling clock, phase, and position on screen.

• Easy- to- use push buttons and OSD menu control.

• Horizontal mirroring (X-Axis Flip)

2. Installation

2.1 Connections

The SC-VGA-2B accepts both PC and HDTV input and output.

Use the 15-pin D-sub to YPbPr/3 RCA cable to convert YPbPr for HDTV
devices.

The SC-VGA-2B includes a display local loop out connection labeled “Bypass
Output”. Use this connection to send a non-processed signal
display.

to a secondary

3
