Hakko APS-301A, APS-351B, APM-301A, APM-301C User Manual

Power Supply

Instruction Manual

Applicable Models: APS-301A, APS-351B,
APM-301A, APM-301C

■ Thank you for purchasing the CHP Assembly Tool. In order to ensure maximum performance and

product life, please read this manual before operating your power supply.

-Table of Contents-

General Safety Warnings ................................................................................................................

Care/Maintenance .............................................................................................................................

Read Before Use ...........................................................................................................................

Declaration of Conformity (CE) .......................................................................................……….

Product Information ..............................................................................................................................

Operation ………………..………………………………………………………………............................

Troubleshooting ……………..…………………………………………………...………………………

03
03
03
04
04
05
08

2

1. General Safety Warnings

WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury. Keep this manual readily
accessible for reference.

■Working area safety

- Keep working area clean and well lit.

- Do not operate power tools in the presence of flammable liquids, gases or dust.

- Keep the power tool away from children.

■Electrical safety

To avoid risk of electric shock:

- Never modify the plug in any way.

- Do not expose the power tool to wet conditions.

- Do not pull or damage the power cord.

- Use suitable extension cord when operating outdoor.

- Use a residual current device (RCD) when operating in a damp location.

■Personal safety
To avoid injury during operation:

- Do not use the power tool when under influence of drugs, alcohol or medication.

- Ensure that the switch is in OFF/Neutral position before connecting the power source.

- Remove and adjusting key or wrench before turning on the power tool.

- Keep proper footing and balance at all time.

- Do not wear loose clothing or jewelry. Keep hair, clothing and gloves away from moving parts.

2. Care/Maintenance

- Use the appropriate power tool for the application. Do not force the power tool.

- Do not use the power tool if the switch is malfunctioning.

- Disconnect the power source before making adjustments, changing accessories or storing the tool.

- Keep the tool away from children or untrained personnel.

- Periodically check for any misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the operation.

- Keep the screw bits clean before and after use.

- Only use compatible power supplies and accessories.

3. Read Before Use

■Set-up Notice

- Use the controller in dry place indoors without the presence of dust or metal grindings.

- Position the controller on a stable surface.

- Keep the controller away from high voltage sources or noise generating sources.

- Do not place objects on the top of the controller, keep surroundings clear to allow heat dissipation.

■Caution during operation:

- Only use the power supply on an AC circuit with an overload relay.

- Ensure the ground pin is connected to a socket equipped with a ground circuit to avoid electric shock.

- Ensure that the power cord is tightly plugged into the socket.

- When plugging in or unplugging the power cord, hold the plug firmly. Never pull on the cord.

- Do not switch between forward and reverse when the electric screwdriver is in operation.

- We recommend only use up to 80% of the rated maximum torque to avoid inaccurate clutch
escape (The maximum torque may vary with the flexibility of the fastened object).
If over 80% of the rated maximum torque is needed, using a screwdriver with higher torque is recommended.

3
