Haier XQB60-68 User Manual

Fully automatic washing machine

This manual is for

XQB60-68

User's manual

Special number: 0030805945
Please read this manual
carefully before using.
Retain it for future reference.

Contents

Names of the parts
Safety precautions

Installation and adjustment

Installation the water inlet hose

Preparation before washing

Put in the laundries

Put in the detergent

Use the operation knobs

Close the top lid
Finish washing
Disposal after washing

Trouble shooting
*Answers to question

Packing list

Specification

Water level/Water quantity (about)

Injection pressure(MPa

Rated washing / spinning capacity(kg)

High/52L, Medium/43L, Low/30L

6.0/6.0 (weight of standard dry cloth)

Names of the parts

Top lid

Detergent box

Lint filter(Installed by user)

Control panel seat

Filter cover

Inner tub

Front control board

Control panel sheet

Pulsator

Cabinet

Adjustable foot

Adjustable foot seam

Power switch

Power wire

Water
channel

Drain hose
hanging hole

Drain outlet
protecting cover

Meaning and description of the symbols

Contents marked with that symbol are related

Warning sign

to the safety of the product and the personal
safety of the users. Please operate in strict
conformity to the contents, otherwise it may
cause damageof the machine or injure the
personal safety of the user.

Water level knob

Water inlet valve

Cabinet handle

Drain hose

Drain hose bushing

Back cover

Rear fixed foot

Forbidding sign

Contents marked with that symbol are actions
forbidden to perform. Performing of those
actions may result in damage of the machine
or injure the personal safety of the user.

Please check if the power receptacle has good earthing
condition before using to guarantee your safety.

Safety precautions

Please insert the power cord into
special receptacle with rated vol­tage.Be sure to use single-phase
three pins receptacle.The earthing
terminal of the receptacle must be
earthed reliably.If possible,please
adopt electric leakage protector.

When the machine is normally
using, please put the power plug
at the location easily to be insert­ed and extracted by hand. Be sure
to pull the plug off when there's
power failure, or the machine is
being moved, cleaned orwhen it
is idle.

Earth

If the power cord is bad, to avoid risk it is required to replace it by the
technicians ofour special shop or the after-sale service department.
Keep the pin of the power plug clean.

Do not put the machine at damp
place like the bathroom . Never
wash it with water. Do not place
wet laundries on the control panel.

Do not use water hotter than 50 C .

In case the washing machine is in­stalled on ground with carpet, do not
block the ventilation hole with carpet.

The ventilation holes
at the bottom

Do not let the machine share one receptacle
with other electric appliances. If the power
plug is damaged, or the plugging into the
receptacle is loose, do not use the plug any
more.

Do not wash water-proof laundries like
the raincoat, bike covers etc. to avoid
abnormal vibrations in spinning.

Safety precautions

Do not stretch hands into the working
machine. It is dangerous even if the
rotation is slow. Take special care of
the children.

Do not put any hot or heavy items (such
as the kettle with hot water ) on the
washing machine.

The handicapped or children without
care shall not use the machine.

Do not decompose, repair or alter the
machine by yourself.

Do not wash laundries with volatile
materials (such as thinner, petrol etc.)

l

r

e

Petro

inn

h

T

Keep the machine away from direct
sunlight and heat source like the heater.

To prevent the lint inside the tub from
blockingthe cascade outlet during
washing, please keep the lint filter in
good condition, and install it to proper
position. If the lint filter is lost or da­maged, please contact the local after­sales service department of our company.

Dismantle

Install

To protect your laundries and wash­ing machine, please take out all of the
coins, buttons, sand, hairpin and
other foreign materials before washing.

Please check if the water faucet is open,
and if the connection of the water inlet
pipe is proper.
It is suggested to use foamless washing
powder.

Installation and adjustment

Please install and adjust the machine according to the requirement of the manual. It is
very important to your security and correct operating the machine.

Install the bottom plate

After you open the package, please lean
the washing machine gently down on soft
items ( like the towel cloth, blanket, etc. ).
Install the bottom plate to the bottom of
the machine with the eight screws by
a cross screwdriver, then lift the machine
up gently. See to the figure:

Back

Front

Bottom plate

Screw

Soft items

Adjust the installation position

The largest allowed slope of the base of the machine is 2 . The slanting or rough
ground will result in unstable running or stoppage of the machine. Please adjust
it with following methods:

Confirm it's horizontal:

Hang the lead line to confirm if it is horizontal.

Adjust the adjustable foot:

1.To twist the adjustable foot, please first lift up the side of the foot slightly, loosen
the adjustable nut, and twist the foot.

2.Fasten the nut after adjustment.

Loosen

High

Fasten

Low

Adjustable nut

Adjustable foot

Install the lint filter

After opening the package, please take out the lint

filter from the document bag, install it to the

inner tub. See to the figure.

Install

How to change the direction of the drain hose

1.Dismantle the back cover of the washing
machine.

2.Put down the drain hose. Take off the
drainhose frame. As indicated in Figure
1, put thedrain hose into the cabinet.
Then stretch onehand into the cabinet
to nip the claw of the drain hose bush­ing to remove the claw fromoriginal
position. Take off the drain hose bush­ing with the other hand. (As indicated in
Figure 2 and 3).

Outer
drain
hose

Drain hose frame

Figure 1

Drain hose
bushing claw

Inner

Press

Press

Drain hose bushing

Cabinet

Outer

Figure 2

Drain hose
bushing

Take off

Figure 3

3.Dismantle the protecting cover of the
drain outletat the other side (method
the same as the bushing). Install the
bushing as per indicated in Figure 4.

4.Extend the drain hose from the other
side. Fix thedrain hose onto the base
frame with the drain hoseframe. (As
indicated in Figure 5)

Drain outlet
protecting cover

Drain hose bushing

Figure 4

Figure 5

5.Install the protecting cover of the drain
outlet at the other side as per indicated
in Figure 6.

Figure 6

The drain hose shall drain smoothly

1.The height of the drain hose shall be less than

10cm, or the drainage will not be smooth, and
cost such long time that the machine may stop
at mid way.

2.Do not ramp or press the drain hose.

3.If the drain hose is too long, cut it at mid point.

To make smooth drainage, cut the front end of

the hose slantingly.

4.If extra drain hose is needed, please make

separate purchase. The inner diameter of
the extra hose shall not less than 30mm,
and the length shall not exceed 1.5m.

If the extra is too long,cut it eigher A or at B point.

Install the water inlet hose

Confirm the water faucet

Water faucet, suitable

It is required that the front end shall be longer than 10cm.
The outlet end surface of the faucet shall be flat and smooth. If not please file it to
avoid leakage.

Water faucet, not suitable

Connection between the water inlet hose jointer and the water faucet

1.Press the lower end of the lock lever and push down the slider. Take off the
water inlet hose jointer from the water inlet hose component. See to Figure 1.

2.Loosen the screw till the water faucet can be accessed. Put the jointer of the
water inlet hose on the faucet. See to Figure 2. (If the faucet is too large and
the jointer can not be set on the water faucet, please loosen the four screws
and take out the bushing in the jointer. The front end of the faucet must be
smooth, otherwise it may leak water. See to Figure 3.)

Water inlet hose jointer

Figure 1

Slider

Screwdriver

Nameplate

Figure 2

Nut

Figure 5)Figure 4

Lock lever

Water inlet hose

3.Fasten the four screws evenly. See to Figure 4.

4.Take off the nameplate. Twist the fastening nut as per the indication of the
figure to seal up the outlet end surface of the faucet. See to Figure 5.
Remarks:
Before installation, the threading is 4mm above the upper surface of the
nut. After installation, the threading is 2mm above the upper surface of the nut.
See to Figure 6.

Screw

Figure 3

About 4mm
before twisting;
about below 2mm
after twisting

Figure 6

Bushing

Connection between the water inlet hose and the washing machine

1.Do not take off the water absorption cushion.
Please check if the cushion is dropped or
damaged before each usage. If it happens
please contact our after-sale department
immediately.

2.Put the nut of the water inlet hose on the
valve jointer.

3.Fasten the nut. Swing it gently to confirm
if it's suitable.

Jointer of the
water inlet valve

Nut of the water I
nlet hose

Water absorption cushion

Connection between the jointer of the water inlet hose and the water inlet hose

1.Push down the slider. Insert the water inlet
hose into the jointer.

2.Hang the lock lever to the jointer. Release
the slider till a click sound is heard.

Locking lever

Jointer of the
water inlet hose

Slider

Check the connection between the jointer of the water inlet hose and the water faucet

1.Swing the hose gently to confirm if it is fastened
stable.

2.After installation, open the faucet to check if it leaks.

3.Do not bend the hose with overstrain.

4.Each time before use please check if the
connection between the jointer of the water inlet
hose and the water faucet, and the installation
of the water inlet hose are firm, so as to prevent
dropping from improper installation position.

Dismantle the water inlet hose

1.Close the water faucet.

2.Press the locking lever. Push down the slider.
Then pull off the water inlet hose. If the machine
is used more than once every week, the jointer
of the water inlet hose can be kept on the faucet
to prevent damaging the fixing screw.

Locking lever
Slider

1Preparation before washing

Preparation before washing

1.Connect the water inlet hose. Open
the water faucet.

2.Confirm that the washing machine is
earthed reliably. Then insert the
power plug into the receptacle. The
earth terminal shall not link to gas
pipeline and faucet water pipeline.

3.Put down the drain hose.

Pay attention to followings before washing the laundries

Check if
the laundries
has special
requirement
on washing

Clear the
pocket. Take
out the coins,
sand, hairpins
etc.

Tie the long
strips; fasten
the buttons;
close zippers.

The quantity of
the laundries
shall not be too
large. Stretch
and loosen the
laundries before
putting them in
the tub.

When the pulsator
is running , the
buttons of the
laundries may
cause noise. For
the sake of
discretion, please
put the laundries
with buttons into
other laundries.

a. Check if the laundries are applicable for washing with machine.
b. Divide the laundries that are not colorfast from other laundries.
c. Put those laundries difficult to absorb water into water with hand.
d. For those laundries with heavy soil, please first remove the dirt like
mud or dust. For the parts with heavy soil, please apply detergent on
them in advance, which can make it easier to remove the soil.
e. For those laundries that may get lint ball and those with long fur, turn
it over before putting in.
f. Do not put those laundries polluted by chemicals into the washing
machine directly.

2 Put in the laundries

3 Add the detergent

How to use the whitener

Fill water to decided level. Dilute
the whitener with container. Pour
it slowly into the washing tub.
Avoid using whitener on laundries
with color or pattern as they are
prone to lose color.
The whitener shall not touch the
laundries directly.
Refer to the user's manual for the
usage and quantity of the whitener.
For powder whitener, please dissolve
it before use.

The capacity of washing and spinning of
the machine refer to the largest weight of
the standard laundries under dry condition
that can be washed or spinned in one time.
One time washing quantity shall be lower
than the rated capacity.
The thickness, size, type of the cloth will
influence the actual washing capacity. It is
suitable for one time washing to put in
reasonable amount of laundries and the
laundries can be turned round in washing.
Do not select "High"water level for laundries
small than 1.0kg, so as to avoid splashing
of water.

How to use the washing powder

Direct dissolved in the machine

1.Fill water to "Low" water level.

2.Add the power. Run for 30 seconds to
dissolve it completely.

3.Put in the laundries. Select suitable
water level.
The instant dissolving of the washing
powder:

1. Prepare warm water of 30 and a
container.

2. Add the powder while stirring to fully
dissolve it.
The powder is more prone to pollute the
laundries than the detergent. Therefore
please use it with proper quantity.
It is suggested not to use high sudsing
detergent.
Different washing powders have different
dosage. Please refer to the usage manual
of the washing powder for the details.

4 Use the operation knobsand buttons

a Description of the function of the knobs and buttons

Mode and meaning of the indicators

Flashing: indicate the running program

On: indicate the program about to run, or indicate the selected mode

Flashing rapidly: indicate abnormal condition

Process
Selection

Quick­ wash

Process selection button

""

One or more out of the five process programs
are available for your option: quick- wash, twice­wash,wash, rinse, spin

Twice­ wash

Wash

Start

Pause

Spin

Rinse

"Start/Pause" button

After the power is switched on, push it
to start the machine
During working, push it to pause
working.
During pause, push it to resume
working.

b .Steps of using the operation buttons and description of the steps

"Power" botton

Push the "Power" button to
switch on or off the power.
When the power is on, push it
again to switch off the power.

Water Level

Low

Medium

High

Reset

Power

Auto off

On

Off

Process
Selection

Quick­ wash

Twice­ wash

"Water Level " button

Select or adjust the water level.

1 Push the "Power " button to switch on the power

2 Push the "Process Selection" button to select
the suitable process

Reset

Wash

Low

Medium

High

Rinse

ON

Spin

Power

Auto off

On

Process
Selection

Start
Pause

Off

OFF

After switching on the power, the machine will set to standard program automatically
including " wash-rinse-spin ". To select other program, push the "Process Selection"
button to select one or more programs among "Quick- wash" "Twice- wash" "Wash"
"Rinse" "Spin". Refer to the "Selection method of the procedure programs " for the
selection.

Page 12

Attention

Even there's no water in the tub, the
spinning will start after a certain period.
Do not use the "Twice wash" program
for the woolen laundries.
Wash the laundries that are prone to
lose colors separately from other laundries.
The pulsator will not rotate unless the water is filled to selected water level.

Selection method of the procedure programs

Times of pushing
the "Process
Selection" button

Selected procedure
program

Wash, rinse, spin
(standard program)

Wash (the washing
liquid remains in
the tub)

Wash, rinse ( the
rinsing liquid remains
in the tub)

Rinse, spin

Spin
(spin after drain)

Twice-wash, wash,
rinse, spin

Quick-wash, wash,
rinse, spin

Applicable procedure

When the common laundries
need washing , rinsing and
spinning

Repeat using the washing
liquid

Repeat using the washing
liquid

When the laundries need
rinsing and spinning after
manual washing

When the laundries need
only spinning after manual
washing (first drain then spin)

If the laundries are very dirty,
or the sleeve and collar are
dirty, first soak then wash

When quickly wash the
light dirty laundries.

Contents (the lighted indicators
indicate the programs about to run)

Quick-

Twice­ wash

Twice­ wash

Twice­ wash

Twice­ wash

Twice­ wash

Twice­ wash

Twice­ wash

Wash rinse spin

Wash rinse spin

Wash rinse spin

Wash rinse spin

Wash rinse spin

Wash rinse spin

Wash rinse spin

wash

Quick­ wash

Quick­ wash

Quick­ wash

Quick­ wash

Quick­ wash

Quick­ wash

If you push the "Process Selection" button for 7 times, it will resume the original mode, and
it will circulate like that.
If you select the "Quick wash" program, you have to set the full procedure of wash, rinse
and spin. The procedure cannot be selected.

* Total time: including the normal water inlet time, drain time, excluding the power off
time. The total washing time may be influenced by the water inlet pressure and
water level.
* Spin time: the time from intermittent running to finishing
* When selecting " Twice-wash " program, first soak for about 20 minutes, pre-wash
for about 8 minutes, then soak for about 5 minutes, then do washing, rinsing and
spinning. The wash time in the list includes the pre-wash time.

3.Adjust the "water level “ knob to select suitable water level

Three water levels available according to the laundries quantity: High; Medium; Low.

Page 11

After the water inlet as per the preset water level, in case additional water
quantity is required, please first set the button to the "Reset", push and hold it
to perform automatic water inlet. When it reaches the suitable water level, you
can turn it to the needed water level.
After the water inlet under set water level, if higher water level is needed, please
first turn the knob to " Reset ", then turn back to needed water level. The wash­ing machine will fill water to the new water level.

4 Press the "Start/Pause" button

S

tart

P

ause

5 Close the top lid

If you open the top lid, the machine
will stop working before spinning

6 The washing is finished

When the washing is finished, the
three indicators of "Wash" "Rinse"
"Spin" are all on.The power will be
switched off automatically about 10
minutes after the finishing of the
washing.

Disposal after washing

After using, please clean the lint and foreign materials of the lint filter etc. in time.
Otherwise it may influence your using the machine.
Please first pull off the power plug from the receptacle before cleaning.

Clean the detergent box and set it on
the control panel seat.

The filter screen of the water inlet valve is
likely to be blocked by foreign materials
and influence the water inlet. Please clean
it with brush every two months.

The lint filter must be used during
washing.
It must be cleaned in time after each
using
Lint filter:

1.Pull it up to dismantle.

2.Push it down to install.

3.Clean the filter screen after washing.

Install

Dismantle

Clean

If the cabinet is dirty, wipe it with wet cloth
Do not flush it directly with water.
Wipe it with neutral detergent.
Do not wipe it with thinner, petrol,
alcohol etc.

l

Petro

Thinner

Alcohol

1.After washing, close the water faucet. ( If needed, you can dismantle the water inlet hose).

2.Do not store water in the washing machine for a long period. Drain the water completely
after each using.

3.Be sure to pull off the power plug before maintenance.

4.Hang up the power cord and drain hose.

5.Wipe off the water drops on the surface of the machine and inside the tub. Open the top lid
for some time (about 1 hour), then close the top lid.

Trouble-shooting Answers to question

(If there's breakdown, please pull off the power plug before checking) The following
phenomena are not breakdowns sometimes. Please confirm again before sending it
to repair. If there are real breakdowns, please come to the special maintenance
department or after-sale service department of our company. Do not repair it by yourself.

Phenomenan The reason How to settle

In spinning, the machine stops
running. (The "wash" "rinse"
"spin" indicator flash quickly)

The draining does not work,
or the speed of draining is
too slow ( the indicators of
"rinse" "spin" flash)

The safety switch acts. The
spinning can not work (the
indicators of "wash" "rinse"
flash quickly)

The program pauses after
about 15 minutes of water
inlet (the indicators of "wash"
"spin" flash quickly)

No wash

The machine does
not act.

No spin

There's abnormal sound
inside the machine.

The water faucet leaks.

The top lid is not closed.

Is the drain hose blocked
by foreign material?

Are the laundries put
slantingly?
Is the machine slanting?

The water faucet is not open.

The water inlet valve is
blocked

The water pressure is too low
and the current is too small.

Is there power failure?
Is the power plug loose?

If water level reach the appoint level?

Is the power plug loose?

Is the top lid is not closed.?

Are the laundries put
slantingly?

Is the machine slanting?

Are the laundries slanting

in spinning?

Is the jointer screw of the
water inlet hose is loose
or twisted awry?

Close the top lid.

Clean the foreign material.
Open and close the top lid once.

Re-order the laundries.
Close the top lid.

Level the machine in right position.
Open and close the top lid once.

Open the water faucet. Push
the "Start/Pause" button.
Clean the water inlet valve.
Push the "Start/Pause" button.

Wait for the normal water
pressure before use.

Use it when the power is on.
Insert the power plug tightly.

Affusion to appoint level.

Insert the power plug tightly.

Close the top lid

Re-order the laundries.
Close the top lid.

Level the machine properly.

Re-order the laundries.

Fasten the jointer screw
properly.

Common phenomena

Phenomena Explanation

The spinning is intermittent when it starts.

Push the "Process selector" button to
select "Spin", but it doesn't work.

There may be some water flowing out of
the drain hose in the first use of the machine.

In the final spinning, it stops and displays
"Rinse", and starts water inlet.

Balance the laundries to avoid slanting.

The program is setting the drain time. Some
time is needed before it starts spinning.

It is the water remained in the factory
inspection of performance.

It is because that the laundries are slanting
to one side, and the safety switch acts. After
water inlet and stirring, the slanting will be
removed and the spinning will work.

Paching list

Name

User's manual

Components of the
water inlet hose

The end connecting to
the washing machine

Jointer connecting the
water inlet hose and
the water faucet

The end connecting
to the water inlet hose
jointer

Bottom plate

Tapping screws

Lint filter

Fully automatic
washing machine

Quantity

One piece

One piece

One piece

Eight pieces

One piece

One set

WASHING POWDER BOX

0030505636
