Color Television
®
What The W
orld Comes Home To
TM
User Manual
English • Anglais • Inglés . . . . . . . . . . . .1
page
TN201AUV
TN131AUV
T
able Of Contents
PAGE
Important Safeguards................................................................................................2
Remote Control Functions ..........................................................................................4
Features ..................................................................................................................4
English
Getting Started With Personalized Setup ....................................................................
Turning the TV on......................................................................................................5
Defining VIDEO........................................................................................................5
Defining SETUP ........................................................................................................5
Set TIME ..................................................................................................................6
Defining SPECIAL......................................................................................................6
Setting V-CHIP..........................................................................................................6
Option Menu............................................................................................................6
TV Rating ................................................................................................................7
Block OFF ................................................................................................................7
Troubleshooting ........................................................................................................8
Warranty ................................................................................................................9
Specifications ........................................................................................................10
Warning: To reduce the risk of fire or electric shock, do not expose this appliance to
rain or moisture.
5
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
THIS SYMBOL INDICATES THAT HIGH VOLTAGE IS PRESENT INSIDE. IT IS
DANGEROUS TO MAKE ANY KIND OF CONTACT WITH ANY INSIDE PART OF
THIS PRODUCT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE
!
This Important note is located on the rear of the cabinet.
"Note to CATV system Installer: This reminder is provided to call the CATV system
installer’s attention to section 820-40 of the NEC which provided guidelines for
proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable
entry as practical."
APPLIANCE.
!
1
EXAMPLE OF
ANTENNA GROUNDING
GROUND CLAMP
ANTENNA
LEAK IN WIRE
ANTENNA
DISCHARGE UNIT
GROUNDING
CONDUCT
ORS
GROUND GLAMPS
POWER SERVICE GRONDING
ELECTROOE SYSTEM
ELECTRIC
SERVICE
EQUIPMENT
English
IMPORTANT SAFEGUARDS
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the following:
1) Save these Instructions — the safety and operating instructions should be retained for future reference.
2) All warnings on the appliance and in the operating instructions should be followed.
3) Cleaning — Unplug TV from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use only a damp cloth for cleaning.
Exceptions: Some products are designed for uninterrupted service, eg. Cable TV converters, unplugging such
accessories may result in loss of authorisation codes. In such cases, please follow instructions for unplugging
such devices as provided by the accessories manufacturer
4) Attachments — do not use attachments not recommended by the TV manufacturer as they may cause hazards.
5) Water and moisture — do not place this TV near water, for example, near a bathtub, wash bowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool, and the like.
6) Accessories — do not place this TV on an unstable cart, stand, tripod, bracket, or table. The TV may fall,
causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufactur
should follow the manufacturer’s instr
manufacturer. An appliance and car
uctions and should use a mounting accessory recommended by the
t combination should be moved with care. Quick stops, excessive force,
er, or sold with the TV. Any mounting of the appliance
and uneven surfaces may cause the appliance and cart combination to over
.
turn.
7) Ventilation — Slots and openings in the cabinet and the back or bottom are provided for ventilation and to
ensure overheating. These openings must not be blocked in a built in installation such a bookcase or rack
unless proper ventilation is provided or the manufacturer instructions have been adhered to.
8) POWER Sources — this TV should be operated only from the type of power sources indicated on the electrical
nameplate. If you are not sure of the type of power supply to your home,
consult your appliance dealer or local power company. For TV’s intended to
operate from battery power or other source, refer to the operation
instructions.
9) Grounding or polarization — This TV is equipped with a polarized alternating current line plug (a plug having one blade wider than the other is). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to inset the plug fully
into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your
outlet. Don’t defeat the safety purpose of the polarized plug.
10) Power cord protection — Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords or plugs, convenience
receptacle, and the point where they exit from the appliance.
11) Outdoor antenna grounding — If an outside
antenna or cable system is grounded so as to
provide some protection against voltage surges
and built up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA No.70,
provided information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna discharge unit, connection
to grounding electrodes, and requirement for
the grounding electrode. (Fig. A)
2
(Fig.
A)
12) Lighting precaution — for added protection for this TV receiver during a lighting storm or when it is left
unattended for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the TV due to lighting and power line surges.
English
13) Object and liquid entry — never push objects of any kind into this TV thr
dangerous voltage point or short out parts that could result in a fire or electric shock. Avoid spilling liquid of
any kind on the TV.
14) Servicing — do not attempt to service the TV by yourself, as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
15) Damage Requiring Service — Unplug this TV from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a. When the power supply cor
b. If liquid has been spilled, or objects have been fallen into the TV.
c. If the TV has been exposed to rain or water.
d.
If the TV does not operate normally by following the operating instructions. Adjust only those controls
that are covered by the operating instructions, as improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the TV to its normal
operation.
e. If the TV has been dropped or damaged in any way.
f. When the TV exhibits a distinct change in per
16) Replacement parts — when replacement parts a required, be sure the service technician uses r
parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, injury to persons or other hazards.
17) Safety check — Upon completion of any ser
routine safety checks to deter
d or plug is damaged or frayed.
formance; this indicates a need for service.
vice of repairs to this TV, ask the service technician to perform
mine that the TV is in proper operation condition.
ough openings as they may touch
eplacement
18) Heat — This TV product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (Including amplifiers) that produce heat.
19) Modifications — Any changes or modifications not expressly approved by the Federal Comunications
Commission on this product could void the users authority to operate the equipment
For Future Reference Please
SAVE THESE INSTRUCTIONS
Thank you for using our Haier product. This easy-to-use manual will guide you in getting the best use of your TV.
Remember to record the model and serial number. They are on a label in back of the TV.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain warranty service.
3
English
Remote Control Functions
1. POWER: Power on/off
2. Access/Exit Main M (MENU)
3. MUTE: Press key to Activate/deactivate Mute
Function
Featur
FRONT
es
4. DISPLAY
5. TV/AV: TV/AV select
6. –VOL+: Increase or decrease sound.
7. –CH+: Select next higher or lower channel
8. Recall: Return to previous channel
9. Rating: V-chip Set
10. CHANNEL NUMBER BUTTON: Direct channel
tuning (TV channel 02-69, CATV channel 01-
125.)
1. V-IN: Video Input
2. A-IN: Audio Input
: Display receiving channel
BACK
3. AV/TV: AV:TV Select
4. M: Access/Exit Main M (MENU)
5. Vol-: decr
6. VOL+: increase sound
7. CH-: select next lower channel
8. CH+: select next higher channel
9. Power Indicator
10. Info Sensor Windows
11. POWER: power on/off
12. ANT: Antenna
13. AC CORD
ease sound
4
Information to user: This television receiver
is equipped with close caption decoder and
parental blocking technology as required by
the FCC.
English
Defining VIDEO
VIDEO parameters:
* Press M (MENU) key and select VIDEO.
Getting Started W
ith
Personalized Setup
Setting up this TV can be personalized, please refer to
this manual. It contains instructions to help you. The TV
is preset with default setting preset by manufacturer. T
get personalized settings, please read on.
1. Page 5 a brief introduction to the key functions.
2. Page 5 VIDEO.
3. Page 5 SETUP
4. Page 5 TIME
5. Page 6 SPECIAL
6. Page 6 V-CHIP
o
Turning The TV On
1. When the television is connected to power outlet, the
power indicator displays red. To turn on the set press
the ON/OFF button or press the on/off key on the
remote controller.
2. Press the M (MENU) key on the remote controller,
you will see a menu on the screen. Use key CH and
key VOL to set the TV to your preference
3. Pressing CH- or CH+ to the selected item will
highlight to green.
4. When a desired item is selected press VOL- and
VOL+ to change its parameter.
• Press CH- and CH+ to select an item (menu will roll
and show those hidden items with the action of the
CH+ and CH-)
• When a certain item is selected, it will be highlighted
green, use VOL+ and VOL- to change the parameter
to your preference.
Item VOL+ VOL-
CONTRAST CONTRAST+ CONTRASTBRIGHT BRIGHTNESS+ BRIGHTNESSCOLOR COLOR+ COLORSHARP SHARPNESS+ SHARPNESSTINT TINT+ TINT-
Defining Setup
1. Press M (MENU), the main menu displays on the
screen:
2. Select item with CH+ and CH-, the selected item e.g.
language will highlight green;
3. Select the language you would like to see on your
screen (ENGLISH, ESPANOL, FRANCAIS) with VOL+
and VOL-;
4. RECEPTION: the default parameter is AIR, which
indicates the signal r
antenna of the TV. Use VOL+ to change it to CABLE if
you are using cable service.
5. AUTO PROGRAM, Pressing the VOL+ and VOL-, will
automatically search for TV channels. (When
available signal is detected, the channel will locked
in to release the lock, press VOL+, and the search
resumes)
eceiving method is through the
6. ADD/DELETE use CH+ and CH-, press VOL- and
VOL+ to add or delete TV channels to/from the
program.
7. INPUT, you can alter the input method between AV
and TV. This could also be done by pressing the
AV/TV key on the remote controller.
8. Press M (MENU) to exit the menu.
5
English
Set TIME
1. Press MENU, the main menu displays on the screen:
2. TIME, select CLOCK, selected item will highlight to
green;
3. Use VOL+ and VOL- to select one of the three
components of CLOCK—hour, minute and AM/PM;
4. Press CH+ and CH- to change the selected Parameter
as you wish;
4. Similarly, you can set a ON TIME/OFF TIME
5. Select SLEEP under TIME menu;
6. Press VOL+ and VOL- to set a count down timer off.
The time you set is displayed in highlighted green
and the SLEEP label in blue.
0:15 / 0:30 / 0:45 / 1:00 / 1:15 / 1:30 / 1:45 / 2:00
7. CHANNEL is useful if you would like to set a
Power-on to a default channel.
8. Press M (MENU) again to exit the menu
Setting V-CHIP
This function enables you to block certain TV channels
in according to the V-CHIP requirement established by
the FCC.
How to use the V-CHIP function:
1. Press V-CHIP when the main menu is active, v-chip
menu displays on the screen:
2. Press CH+ and CH- to select a certain item, the
selected item is red highlight:
3. When you’ve selected an item, press M (MENU); it
will bring up the contents of this item.
4. Pr
ess M (MENU) to exit to V-CHIP menu.
5. Press V-CHIP, exit to the main menu:
6. Press V-CHIP again, exit main menu.
OPTION MENU
Defining SPECIAL
1. Press M (MENU), the main menu displays;
2. Press CH+ and CH- to select SPECIAL, then select
C.CAPTION, the selected item highlighted with
green. When OFF displays, C.CAPTION is set off;
When C1 displays, C.CAPTION is set active.
3. Press CH-, highlight CC ON MUTE, press VOL+ and
VOL- to adjust its contents, process similar to the
above figure. When OFF display, no matter what is
set for C.CAPTION, it will not work. When C1
displays while C.CAPTION set to OFF, the C.
CAPTION function will automatically recalled by the
system.
4. Press CH- to select POWER RESTORE, press VOL+
and VOL- to configure this item.
5. Select AUTO TINT, press VOL+ and VOL- to
determine whether to bring into use the automatic tint
tuning method.
6. Select MENU OFFSET, this item allow you to adjust
the position of the main menu displays on the screen.
7. Select MUTE B.G.C, you can select a more comfortable background color (blue/green/cyan/red/yellow/purple/white/black) of the main through pressing VOL- and VOL+
1. Press M (MENU), press V-CHIP
2. Select OPTION MENU, then press M (MENU) again,
the OPTION MENU is brought to the screen
3. Press CH+ and CH- to select a item from the given
menu, selected item will turn to green while unselected items stay yellow
4. When HELP is selected, the contents of this item are
to be shown by pressing M (MENU), CH+ and CHwill help in selecting a certain help topic. Press M
(MENU) to exit to OPTION MENU.
5. When NO-INFO RATING is selected, press M
(MENU), THEN YOU CAN SELECT between
UNBLOCK, BLOCK functions.
6. When NO RATING is selected, press M (MENU),
then you can select between UNBLOCK, BLOCK
functions.
7. When ENTER PASSWORD is selected, press M
(MENU), a dialog box displays on the left lower area
of the screen. You can enter a 4 numeric password
here to prevent your personal settings from possible
changes by others. Press V-CHIP again to return to
upper directory. (Note: When a password is
activated here, access to other menu under V-chip
menu will require this pass word)
Press M (MENU) to exit a current menu.
6
English
TV RATING
1. Press M (MENU), press V-CHIP
2. When TV Rating is selected, press M (MENU) will
bring to screen the following table
3. TV-Rating
TV-Y
TV-Y7 V
TV-G
TV-PG V V V
TV-14 V V V V
TV-MA V V V V
Rating FV V S L D
All items marked with V are blocked. If you would like
to block all items in the table, move the cursor to the cell
on top left of the table, then press M (MENU).
1 If you wish to unblock all items, move the cursor to the
left bottom cell and press M (MENU) twice.
V
Block Off
1. Press M (MENU), press V-CHIP
2. When BLOCK is highlighted with red, press M
(MENU), BLOCK options BLOCK OFF and BLOCK ON
display.
Note: BLOCK OFF means block function is
turned off, and V-CHIP function will not act to
input v-chip signal even if you have set TV
RATING and MPAA RATING.
BLOCK ON means block function is activated.
If you have set TV RATING and MPAA RATING,
the V
-CHIP function will act to input V-CHIP
signal.
2 To block a cer
a line, and press M (MENU) to specify the line, then,
use VOL+ and VOL- to select the item you want to
block, press M (MENU) to block it.
3 To unblock a blocked item, repeat the above process
4 Press V-CHIP to return to V-CHIP menu
tain item, press CH+ and CH- to select
MPAA Rating
1. Press M (MENU) press V-CHIP
2. When MPAA RATING is highlighted with red. Press
M (MENU), MPAA RATING options displays
3. To select all options, move the cursor by pressing
CH+ and CH- to the left to corner and press M (MENU).
4. To cancel all selections, move the cursor to the left
bottom corner and press M (MENU) twice.
5. This subdirectory only allows selection on the cursor
pointed item and its upper directory.
6. Press V-CHIP to return to V-CHIP MENU.
5
English
Troubleshooting Guide
Sometimes checking seemingly apparent but often-overlooked possibilities can easily solve a performance problem.
Before arranging for service, check these items. It could save your time and money by avoiding unnecessary
service calls.
QUICK SER
POSSIBLE REMEDY
TRY A NEW CHANNEL,
IF OK, THEN POSSIBLE
STATION TROUBLE X X X X X X X
IS TV PLUGGED IN?
POWER IN OUTLET? X
IS TV’S BUTTON ON? X
VICING CHECK LIST
PROBLEM
CONTROL
REMOTE
BAR
SCREEN
ON
DOESN’T
DISTOR
IS
WORK
TED
ROLLS
COLOR
NO
TICALL
VER
WEAK
Y
LINE
STREAKS
OR
GHOST
IN
BLURRED
SOUND
X X X
OR
NO
POOR
IS
SOUND
OR
IS ANTENNA CONNECTED
TO TERMINAL ON THE
BACK OF THE SET? X X X X X X X X X
IF OUTSIDE ANTENNA
IS BEING USED,
CHECK FOR BROKEN WIRE. X X X X X X X X X X
CHECK FOR LOCAL
INTERFERENCE X X X X X X X X
TURN OFF POWER BUTTON
AND THEN TURN IT ON
AFTER ABOUT A MINUTE. X
ADJUST COLOR CONTROL X
ADJUST CONTRAST & X X
BRIGHTNESS CONTROL
CHECK BATTERIES IN
REMOTE CONTROL X
8
Warranty Information
English
This Haier brand product (the "PRODUCT"), when
shipped in its original container, will be free from
defective workmanship and materials, and agrees that
it will, at its option, either repair the defect or replace
the defective product with a new or re-manufactured
equivalent at no change to the purchaser, for parts or
labor for the periods set forth below:
This warranty does not apply to the appearance of the
product or the exterior of the product, which has been
damaged or defaced, altered or modified in design or
construction. It does not apply to the additional
excluded items set forth below:
The warranty commences on the date the item was purchased and the original purchase receipt must be presented to the authorized service center before warranty
repairs are rendered.
The limited warranty described herein is in addition to
whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR USE ARE LIMITED TO THE PERIOD(S)
FROM THE DATE OF PURCHASE SET FORTH BELOW.
Some states do not allow limitations on how long an
implied warranty lasts, so the above limitation may not
apply to you.
Neither the sales personnel of the seller nor any other
person is authorised to make any warranties other than
those described herein, or to extend the duration of
any warranties beyond the time period described herein on behalf of Haier.
constitute full satisfaction of all claims, whether based
on contract, negligence, strict duality or otherwise. In
no event shall Haier be liable, or in any way responsible for any damages or defects in the product which
were caused by repairs or attempted repairs performed
by anyone other than an authorized service center or
dealer; nor shall Haier be liable, or in any way responsible for incidental or consequential economic or property damage. Some states do not allow the exclusion
of incidental or consequential damages, so that above
exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
Warranty period for this product: 90 days parts and
Labor. The warranty period continues for a total of one
year for parts only, other than the picture tube for
which it continues for two years. Services are not provided free of charge for these additional periods.
Additional items excluded from warranty coverage:
non-rechargeable batteries.
Where to obtain ser
Haier authorized service center or to obtain pr
erature, accessories, supplies or customer assistance,
please call 1-877-337-3639.
What to do to obtain service: ship or car
product to an authorized ser
sure to have proof of purchase. If you ship the product,
be sure it is packaged carefully.
vice: For the location of the nearest
oduct lit-
ry in your
vice dealer or center. Be
The warranties described herein shall be the sole and
exclusive warranties granted by Haier and shall be the
sole and exclusive r
Correction of defects in the manner and for the period
of time described herein, shall constitute complete
fulfilment of all abilities and r
the purchaser with respect to the product, and shall
emedy available to the purchaser.
esponsibility of Haier to
Haier America Trading. L.L.C.
New York. New York 10018
9
If you have a pr
DA
IMPORTANT
Do Not Retur
oblem with this product, please contact the "Haier Customer Satisfaction
TED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE
n This Product To The Store
Center" at 1-877-337-3639.
Model No.
TN201AUV/TN131AUV
120V, 60 Hz
Made in China
TN201AUV/TN131AUV
Issued: July-00
What The World Comes Home To
Haier America Trading,
New York, NY 10018
Printed in China
®
TM
Loading...
