HAIER RRTG18PABB User Manual

115V, 60 Hz

Haier America

New York, NY 10018

Printed in China

tmnfr141618-2 Issued: July-03

IMPORTANT

Do Not Return This Product To The Store

If you have a problem with this product, please contact the "Haier Customer

Satisfaction Center" at 1-877-337-3639.

DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE

IMPORTANT

Ne pas Réexpédier ce Produit au Magasin

Pour tout problème concernant ce produit, veuillez contacter le service des

consommateurs ‘Haier Customer Satisfaction Center’ au 1-877-337-3639.

UNE PREUVE D’ACHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.

IMPORTANTE

No regrese este producto a la tienda

Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al

Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A).

NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA

Part #:RF-9999-82

What The World Comes Home To

Réfrigérateur

à Congélateur Anti Givre

User Manual-

14, 16, 18, 21 cu. ft. models

Guide de l’Utilisateur-

modèles à 0,4 0,45 0,5 0,6 m_

Refrigeradores

con Congelador Superior

sin Escarcha

(Las funciones pueden variar

según el modelo)

Manual del Usuario-

para modelos de 0,4 0,45 0,5 0,6 m_

(Features may vary by model)

(Les caractéristiques peuvent

varier en fonction du modèle)

What The World Comes Home To

Top Mount No Frost

Refrigerators

SAFETY PRECAUTIONS

Read all of the instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the following:

1) Use this appliance only for its intended purpose as described in this use and care guide.

2) This refrigerator must be properly installed in accordance with the installation instructions before it is used. See grounding instructions in the installation section.

3) Never unplug your refrigerator by pulling on the power cord. Always grasp the plug firmly and pull straight out from the outlet.

4) Repair or replace immediately, all electric ser vice cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length, the plug or the connector end.

5) Unplug your refrigerator before cleaning or before making any repairs. Note: If for any reason this product requires ser vice, we strongly recommend that a certified technician performs the ser vice.

6) Do not use any electrical device or any sharp instrument in defrosting your refrigerator.

7) If your old refrigerator is not being used, we recommend that you remove the doors. This will reduce the possibility of danger to children.

8) After your refrigerator is in operation, do not touch the cold surfaces in the freezer compartment, particularly when hands are damp or wet. Skin may adhere to these extremely cold surfaces.

9) Do not refreeze foods, which have been thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No. 69 reads: "…You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold-below 40˚F".

"…Thawed ground meats, poultry, or fish that have any off-odor or offcolor should not be refrozen and should not be eaten. Thawed ice cream should be discarded. If the odor or color of any food is poor or questionable, discard it. The food may be dangerous to eat."

"…Even partial thawing and re-freezing reduce the eating quality of foods, particularly fruits, vegetables, and prepared foods. The eating quality of red meats is affected less than that of many other foods. Use refrozen foods as soon as possible, to save as much of its eating quality as you can."

English

Thank you for using our Haier product. This easy-to-use manual will guide you in getting the best use of your refrigerator.

Remember to record the model and serial number. They are on a label in back of the refrigerator.

Model number

Serial number

Date of purchase

Staple your receipt to your manual.

You will need it to obtain warranty service.

10) This refrigerator should not be recessed or built-in an enclosed cabinet. It

is designed for freestanding installation only.

11) Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

DANGER

Risk of child entrapment. Before you throw away your old refrigerator or

freezer, take off the doors. Leave the shelves in place so that children may

not easily climb inside.

English

Table Of Contents

PAGE

Safety Precautions ..........................................................................1

Parts And Features ..........................................................................4

Installing Your Refrigerator............................................................5

Unpacking Your Refrigerator ..................................................................5

Adjusting Your Refrigerator......................................................................5

Proper Air Circulation ............................................................................5

Electrical Requirements............................................................................6

Door Handle Installation..........................................................................7

Door Alignment......................................................................................8

Reversing the Door Swing.......................................................................8

Reversing The Door Handles ................................................................11

Installing Front Grill..............................................................................11

Refrigerator Features And Use..........................................................12

General Features..................................................................................12

Refrigerator Interior Shelves..................................................................12

Utility Drawer And Cover......................................................................13

Crisper and Crisper Cover....................................................................14

Refrigerator Door Shelves ....................................................................16

Freezer Features ..................................................................................17

Food Storage Information ....................................................................19

Normal Operating Sounds....................................................................21

Proper Refrigerator Care and Cleaning ....................................22

Cleaning and Maintenance ..................................................................22

Light Bulb Replacement ........................................................................23

Power Interruptions ..............................................................................23

Vacation and Moving Care ..................................................................23

Troubleshooting..............................................................................24

Warranty Information ..................................................................26

English

Parts And Features

1. Ice Storage Bin (not on all models)

2. FULL WIDTH Wire Freezer Shelf

(not on all models)

3. Ice Cube Tray (not on all models)

4. Utility Shelf/Ice Cube Tray Holder

(not on all models)

5. Refrigerator Light

6. Utility Drawer (not on all models)

7. Glass Crisper Cover (not on all

models)

8. Crispers (not on all models)

9. Cover Frame And Optional Humidity

Control (not on all models)

10. Covered Dairy Compar tment

11. Interior Refrigerator Shelves (type and quantity varies by model)

12. Bottom Rollers (located front and rear, not shown)

13. Refrigerator Door Shelves (type and quantity varies by model)

14. 2 Leveling Legs (not shown)

15. Shelf Bottle Hugger (not on all models)

16. Bottom Front Grille (not shown)

(not on all models)

English

1. Remove all packaging material. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed

materials before powering on the refrigerator.

Leveling Your Refrigerator:

• Your refrigerator has two leveling legs which are located in the front corners of your refrigerator. After properly placing your refrigerator in its final position, you can level your refrigerator.

• Leveling legs can be adjusted by turning them clockwise to raise your refrigerator or by turning them counterclockwise to lower your refrigerator. The refrigerator door will close easier when the leveling legs are raised.

• To assure your refrigerator works at the maximum efficiency it was designed for, you should install it in a location where there is proper air circulation, plumbing and electrical connections.

• The following are recommended clearances around the refrigerator: Sides……………3/4 "(19mm)

Top....................1" (25mm)

Back..................1" (25mm)

English

Installing Your Refrigerator

Unpacking Your Refrigerator

Adjusting Your Refrigerator

Proper Air Circulation

English

Electrical Requirement

• Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator.

• Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard.

• Avoid the use of an extension cord because of potential safety hazards under certain conditions. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot outlet that will accept the plug. The marked rating of the extension cord must be equal to or greater than the electrical rating of the appliance.

• Do not install your refrigerator in any location not properly insulated or heated e.g. garage etc. Your refrigerator was not designed to operate in temperature settings below 55˚ Fahrenheit.

• Select a suitable location for the refrigerator on a hard even surface away from direct sunlight or heat source e.g. radiators, baseboard heaters, cooking appliances etc. Any floor unevenness should be corrected with the leveling legs located on the front bottom corners of the refrigerator.

Install Limitations

Use of Extension Cords

Handle installation of freezer door:

1. Take out door handle, screws and screw covers from refrigerator

accessory bag.

2. Align the lower part of door handle with the screw hole of the lower

edge of freezer door, and fix them by screws.

3. Align the upper screw holes of the door handle with the holes in the

freezer door, fix them with screws, and cover them with screw covers.

(NOTE: Insert the inner screw

first and then the outer screw)

For Type 2 Handle Only

1. Align handle cover with handle cutout.

2. Push handle cover up.

3. Snap into place.

4. Snap on handle molding.

Handle installation of refrigerator door:

1. Take out door handle, screws and screw covers from refrigerator

accessory bag.

2. Align the upper part of door handle with the screw hole of the upper

edge of refrigerator door, and fix them by screws.

3. Align the lower screw holes of the door handle with the holes in the

refrigerator door, fix them with screws, and cover them with screw covers.

(NOTE: Insert the inner screw first and then the outer screw)

Door Handle Installation (handle style varies by model)

Screw cover

fig. # 1

fig. # 2

English

Inner Screw

Outer Screw

Inner Screw

Type 2

See Above Instructions

outer screw

inner screw

1. Remove hinge cover screw.

2. Remove the top hinge cover.

3. Loosen the top hinge screws using a phillips head screwdriver.

4. Adjust the door or put a spacer in between and then tighten the screws.

5. Replace the top hinge cover.

Note: Door reversal not available on stainless steel door models.

Left/right door opening method:

This product provides the reversing of the left/right door opening. You can select your preference of door opening by following the procedure to make the change.

Door Alignment (see fig. # 3)

Reversing the Door Swing

fig. # 3

Hinge box cover

Top hinge

English

Dismantling: (see fig. # 4)

1. Fix refrigerator and freezer door by sticking adhesive tape on both

sides to hold doors in place.

2. As shown in fig. 3, dismantle the hinge box cover on the upper part of

freezer door with a phillips head screwdriver. Then remove the two screws from the hinge. Take out the hinge by pulling it vertically, and keep it in a safe place.

3. Remove the adhesive tape on freezer door, lift and take the door down,

and carefully put it aside.

4. As shown in fig. 4, dismantle three screws of the central hinge, lift and

take down the central hinge and pad, and keep them in a safe place.

5. Remove the adhesive tape on refrigerator door, lift and take down

refrigerator door, and carefully put it aside.

Central hinge axle

Central hinge pad

fig. # 4

Reinstallation: (see fig. # 5 and # 6)

1. As shown in fig. 5, dismantle the lower hinge and plastic pad from

right side and then install them on the left side.

2. Install refrigerator door: make the left bottom hole of the refrigerator

compartment door fall over the lower hinge axle, move back and forward the door to make it straight and in alignment with central hinge. Install the central hinge again, turn the hinge axle until it completely enters the door body, then fix it with screws.

3. As shown in fig. 6, install the central hinge and pad to the left side.

4. Install freezer door: make the left bottom hole of freezer door fall over

the central axle; raise upper hinge, so that hinge axle can be installed in the upper hole of the upper part of the freezer door; adjust door to make it straight and level. Tighten the screws of upper hinge.

5. As shown in Fig. 3, install the upper freezer hinge to the left

corresponding position.

6. Replace the hinge cover as shown in Fig. 3.

English

Bottom hinge axle

Plastic pad

Central hinge pad

Bottom hinge pad

Bottom hinge

Central hinge

Central hinge axle

fig. # 5

fig. # 6

Note: Not reversible on stainless steel door models.

Freezer: (see fig. # 7a)

1. Remove screw cover from the handles.

2. Using a phillips head screwdriver, remove the inside screw and both the

screws at the bottom of the freezer door that holds the handle.

3. Install the handle on the opposite side.

4. Remove screw plugs.

5. Install the screws and the screw cover on their corresponding position.

Refrigerator: (see fig. # 7)

1. Remove screw cover from the handle.

2. Using a phillips head screwdriver, remove the inside screw and both

screws from the top of the refrigerator door that holds the handle.

3. Install the handle on the opposite side.

4. Remove screw plugs.

5. Install the screws and screw covers to their corresponding position.

Front Grill Installation: (see fig. # 7b)

1. Snap into place as shown below.

Reversing the Door Handles

Hole cover

fig. # 7

English

Hole cover

fig. # 7a

fig. # 7b

Refrigerator Features And Use

The refrigerator shelves of your refrigerator were designed with you in mind. Their varied adjustability allows you to satisfy your personal storage needs. Your model may have wire, glass, or no spill glass shelves. Your model may have full-width or half-width shelves. Only your model purchase and your imagination limit the possibilities.

To remove or adjust a full-width slide-out non-cantilevered shelf: (see fig. # 8)

1. Gently tilt the shelf up and slide forward until the shelf has been completely removed.

2. To replace the shelf, select the desired setting and gently slide the shelf back until it rests in the locking position.

To remove a full-width or half-width cantilevered shelf: (see fig. # 9)

1. Tilt up front of the shelf until the rear shelf hooks are no longer locked in place in the rear metal shelf supports.

2. Pull the shelf gently until it is removed.

General Features

NOTE: All features not available on all

models

Adjustable temperature dial:

Your refrigerator will automatically maintain the temperature level you select. The temperature control dial has 7 settings plus off. 1 is the warmest. 7 is the coldest. Turning the dial to OFF stops cooling in both the refrigeration and freezer sections. At first, set the dial to 4 and allow 24 hours to pass before adjusting the temperature to your needs.

(Note: If the refrigerator has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in.)

Refrigerator Section Interior Light:

Your refrigerator is equipped with an automatic interior light in the fresh food section for you to easily locate your food.

Refrigerator Interior Shelves

fig. # 8

English

To replace a full width or half-width cantilevered shelf: (see fig. # 9)

1. Guide the rear shelf hooks into the desired slots in the metal shelf supports located on the back refrigerator wall.

2. Tilt up front of the shelf to set the shelf hooks in place.

3. Lower the front of the shelf into position until the rear hooks lock into the slots of the metal shelf supports.

To remove the utility drawer: (see fig. # 10)

1. Slide utility drawer out until it reaches the stop.

2. Grasp front of drawer with one hand while supporting the bottom of the drawer with the other hand. Slide drawer out gently the rest of the way.

To remove utility drawer cover shelf: (see fig. # 11)

1. Remove utility drawer first following the above instructions.

2. Tilt up front of the shelf until the rear shelf hooks are no longer locked in place in the rear metal shelf supports.

3. Pull the shelf gently until it is removed.

Utility Drawer and Cover

English

fig. # 9

fig. # 10

To install utility drawer cover shelf: (see fig. #11)

1. Guide the rear shelf hooks into the desired slots in the metal shelf supports located on the back refrigerator wall.

2. Tilt up front of the shelf to set the shelf hooks in place.

3. Lower the front of the shelf into position until the rear hooks lock into the slots of the metal shelf supports. Replace the utility drawer.

To remove and install the crisper: (see fig. # 12)

1. Slide crisper straight out to the stop.

2. Gently lift the front of the crisper.

3. Grip the crisper firmly and slide out completely.

4. Replace the crisper by placing the crisper properly in its tracks and gently sliding it back into place.

Crisper and Crisper Cover

English

fig. # 11

fig. # 12

To remove the crisper cover: (see fig. # 13)

1. First remove both crispers (see page 14 ).

2. Gently push upward from the underside of the crisper cover to remove it from the crisper cover frame.

3. Carefully grasp the crisper cover and slide out to remove.

4. Lift crisper cover frame up and remove.

To replace the crisper cover: (see fig. # 13)

1. Insert the rear of the crisper cover frame into the support bracket the side walls of the refrigerator.

2. Lower the front of the crisper cover frame into place.

3. Slide the rear of the crisper cover into the frame and carefully lower the front into place.

4. Replace the crispers as previously instructed.

Crisper Humidity Control:

(see fig. # 14)

Your refrigerator model may be equipped with slide controls to raise or lower the humidity levels of your crispers. This feature will increase the storage life of your fruits and vegetables. Simply adjust the controls to the appropriate setting for the items you are storing in the crispers.

English

fig. # 13

• LOW setting allows moist air to exit the crisper for optimum storage of

fruits and/or vegetables, which have skins.

• HIGH setting retains moist air in the crisper for optimum storage of

fresh, leafy vegetables.

Gallon door storage: (see fig. # 15)

Your refrigerator may be equipped with gallon door storage shelves. This feature will allow for the storage of gallon size containers.

To remove refrigerator door shelves: (see fig. # 15)

1. Remove all items stored on the shelf.

2. Gently push up each side until the shelf is clear of the door shelf

brackets and then remove.

To replace refrigerator door shelves: (see fig. # 15)

1. Align the ends of the shelves with the door shelf brackets.

Refrigerator Door Shelves

English

High/Low Settings

fig. # 14

Low

High

2. Carefully push down on each end of the door shelf until it is locked in place in the refrigerator door brackets.

To adjust the door shelf bottle huggers: (see fig #16)

1. Grasp the hugger firmly and slide right or left until it is snug against the items stored on the shelf.

Removing the full-width freezer shelf:

(see fig. # 17)

1. Grasp the freezer shelf firmly and slide to the left as far as possible.

2. Lift up on the right side until the shelf is free of the brackets on the right side wall of the freezer.

3. To replace the freezer shelf insert the shelf into the left side brackets as far as possible.

4. Slide the right side of the shelf into the brackets located on the right side wall.

Freezer Features

English

fig. # 15

fig. # 16

upper door shelf

lower door shelf

shelf bottle hugger

Remove freezer door shelves: (see fig #18)

1. Remove all items stored on the shelf.

2. Gently push up each side until the shelf is clear of the door shelf brackets and then remove.

To install freezer door shelves: (see fig #18)

1. Align the ends of the shelves with the door shelf brackets.

2. Carefully push down on each end of the door shelf until it is locked in place in the freezer door brackets.

Ice Storage Bin: (see fig # 19)

The ice storage bin can be used to store additional ice cubes in your freezer. It can also be used to store items in the refrigeration section such as eggs or other small items.

English

fig. # 17

fig. # 18

fig. # 19

freezer door shelves

ice storage bin

Ice Cube Trays:

Your refrigerator is equipped with one or two ice cube trays depending upon the model you have purchased.

Fresh Food

• When storing fresh food, which is not prepackaged, be sure to wrap or

store food in airtight and moisture proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes.

• Wipe containers before storing to avoid needless spills.

• Eggs should be stored in an upright position in their original carton to

maximize shelf life.

• Fruit should be washed and dried then stored in a crisper set for low

humidity. If you do not have humidity controlled crispers place the items in sealed plastic bags before storing in the crisper.

• Vegetables with skins should be stored in plastic bags or containers and

stored in crisper with low humidity setting.

• Leafy vegetables should be washed and drained and then stored in

plastic bags or containers in crisper with high humidity setting.

• Hot food should be allowed to cool before storing in the refrigeration.

This will prevent unnecessary energy use.

• Fresh seafood should be used the same day as purchased.

• When storing meats in the fresh food section, keep in the original

packaging or rewrap as necessary. Follow the suggestions below for safe storage:

• Chicken 1-2 Days

• Ground Beef 1-2 Days

• Cold Cuts 3-5 Days

• Steaks/Roasts 3-5 Days

• Smoked/Cured Meats 7-10 Days

• All others 1-2 Days

If longer periods of storage are required, store immediately in the freezer section.

Food Storage Information

English

Frozen Food

• Proper freezer storage requires correct packaging. All foods must be in

packages, which do not allow the flow of air or moisture in, or out. Improper storage will result in odor and taste transfer and will result in the drying out of the improperly packaged food.

• Follow package or container instructions for proper storage.

• Packaging Recommendations:

Plastic containers with air tight lids Heavy duty aluminum foil Plastic wrap made from saran film Self-sealing plastic bags

• Do not refreeze defrosted/thawed foods.

• It is recommended that the freezing date be marked on the packaging.

English

• The fan circulating air inside the interior of your unit to maintain the

temperature you have selected.

• Boiling water, gurgling sounds or slight vibrations that are the result of

the refrigerant circulating through the cooling coils.

• Sizzling or popping sounds resulting from frost melting during the

defrost cycle and dripping on the defrost heater.

• The sound of dripping water as ice melts from the evaporator and flows

into the drip pan during the defrost cycle.

• Cracking or popping sound caused by the expansion and/or

contraction of the cooling coils during the defrost cycle.

• Both the defrost timer and the thermostat control will click when they

cycle on and off.

Normal Operating Sounds You May Hear

English

Warning: To avoid electric shock always unplug your

refrigerator before cleaning. Ignoring this warning may result in death or injury.

Caution: Before using cleaning products, always read and

follow manufacturer’s instructions and warnings to avoid personal injury or product damage.

General:

•Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with warm water. Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your refrigerator.

• Rinse with clean warm water and dry with a soft cloth.

• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated detergents, solvents or metal scouring pads. SOME of these chemicals may dissolve, damage and/or discolor your refrigerator.

• Clean door gaskets every three months according to general instructions. Gaskets must be kept clean and pliable to assure a proper seal.

• Petroleum jelly applied lightly on the hinge side of gaskets will keep the gasket pliable and assure a good seal.

Proper Refrigerator Care and Cleaning

Cleaning and Maintenance

English

Door Gaskets:

English

1. Switch off power to refrigerator.

2. Remove the highest shelf.

3. Allow light bulb to cool before removing.

4. Remove bulb by screwing it out counter-clockwise.

5. Always replace with appliance type light bulb rated at 40 watts or lesser wattage.

6. Do not exceed the 40 watts rating at any time.

• Occasionally there may be power interruptions due to thunderstorms or

other causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, replug power cord to AC outlet. If outage is for a prolonged period, inspect and discard spoiled or thawed food in freezer and refrigerator. Clean refrigerator before reusing.

• For long vacations or absences, empty food from refrigerator and

freezer, move the temperature DIAL to the OFF position and clean the refrigerator and door gaskets according to "General cleaning" section. Prop doors open, so air can circulate inside.When moving always move the refrigerator vertically. Do not move with the unit lying down. Possible damage to the sealed system could occur.

Light Bulb Replacement

Power Interruptions

Vacation and Moving Care

Refrigerator Does Not Operate

• Check thermostat control is not in the “OFF” position.

• Check refrigerator is plugged in.

• Check there is power at the ac outlet, by checking the circuit breaker.

• Wait for 30-40 minutes to see whether refrigerator will start. It may be

in "defrost" mode and must complete this cycle before Compressor starts to operate.

Food temperature appears too warm

• Frequent door openings.

• Allow time for recently added warm food to reach fresh food or

freezer temperature.

• Check gaskets for proper seal.

• Clean condenser coils (for models with exposed condenser coils).

• Adjust temperature control to colder setting.

• Check freezer compartment for air duct blockage from

frozen food packages.

Food temperature is too cold

• If temperature control setting is too cold, adjust to a warmer setting

and allow several hours for temperature to adjust.

Refrigerator runs too frequently

• This may be normal to maintain constant temperature during

high temperature and humid days.

• Doors may have been opened frequently or for an extended

period of time.

• Clean condenser coils.

• Check gasket for proper seal.

• Check to see if doors are completely closed.

TroubleShooting

English

+ 58 hidden pages
