MD-2485M
MD-2485MG
Household Microwave Oven
Contents
Before Use
Features of the Product ............ 2
M'
Names of the Parts ................... 3
S'
Time Adjust
-
Med
Low
Stop
M
MD-2485
Safety Precautions ................... 4
+
Installation Environment ........... 6
M.H
Open the Package Carton *
High
Installation .............................. 6
Usage
* Please read this manual carefully
before use.
* Please keep it attentively.
* See to the physical sample for the
appearence color or pattern.
Instructions of the Control Panel
Functions ................................7
Usage .....................................9
Selection of the Cooking
Dishware ...............................12
Cooking Tips ..........................13
Maintenance*Repair
Maintenance * Repair .............14
Answers to Questions ............ 15
After-sales Service ................ 16
Features of the Product
Safe to use
The door adopts unique anti-choke structure and integrated punch forming,
And thus effectively prevents the microwave from leaking.
It is controlled by two-step interlock switch. The power will be switched off
automatically when the door is open, therefore it is much safer to use.
Shining appearance
It has modern appearance and superior quality, and thus becomes the
best choice for the household microwave oven.
Healthy and germicidal
The sealing part of the cavity is produced with antiseptic materials, and
can suppress the reproduction of the bacteria effectively.
The special function of the microwave oven can eliminate the germ in the
food quickly and completely.
Names of the Parts
door hook
door
door seal
cavity
baking
mesh
glass rotary
tray
tray support
shell
operation
board
M'
S'
Time A
dju
st
+
Med
M.H
Low
High
Stop
Po
wer Le
vel
MD
-2
485
M
useful volume of the
cavity is 161
(only for MD-2485MG)
diagrammtic sketch for
the accessory installation
Safety precautions
Please read the safety precautions carefully to guarantee safe and convenient
use of Haier microwave oven.
Danger
Warning
Attention
Electric
shock
hazard
No
dismantle
No one except the professional technicians
are permitted to disassemble the microwave
oven, or it may result in electric shock.
Danger
Do not apply excess force to the door. It
may cause distortion of the door and result
in microwave leakage.
Warning
Do not cook eggs in their shells to avoid
bursting
Do not use metal rod to enter the interlock'
switch hole on the front side of the cavity. It
may cause hazard.
interlock switch hole
Danger
Do not use sealed containers . For those
foods with skin, please prick holes on the
skin.
Warning
Remember to clear away excess grease
from the inside the cavity. Otherwise it may
cause smoke or fire during heating.
Warning
Do not use the microwave oven for purposes
other than for cooking food
Warning
This appliance must be earthed
safe and
reliable
Warning
Warning
Safety Precautions
When roasting, the face of the door and
the top of the cabinet may become hot to
touch.
warning
Do not use metallic dishware to cook with
microwave as it will cause internal arcing.
warning
Do not use it with the cavity empty. It will
damage the microwave oven.
warning
Allow the cavity to cool after long cooking
processes (i.e. Roasting etc) before
starting another cook cycle.
warning
Warning
1. If the door seal or the door body is damaged, please do not use the
appliance before it is repaired by professional technicians.
2. Before use, please check if the cooking containers are suitable for
microwave oven.
3. If you find smoke in the oven, leave the door in the closed position, and
switch off the power supply of the oven (remove the plugtop from the
supply socket).
4. We do not recommend the use of plastic, paper or other combustible
materials containers for cooking, please be sure to observe the operating
instructions for the microwave oven, in order to avoid accidents
5. When you heat liquid in the oven, please take care of the delayed
splashing of possible boiling liquid.
6. Do not use the microwave oven if there's no food inside, so as to avoid
damaging the appliance by no-load running.
7. Children are not allowed to operate the microwave oven without the
instruction of adults.
Do not use the product for any industrial and commercial purpose.
Installation Environment
Ventilation space is required in installation
of the microwave oven.
Do not install the microwave oven in
environment that is humid or with high
temperature.
attention
Open the Package Carton* Installation
M'
S'
TimeAdjust
+
Med
Open the
carton
M.H
Low
High
Stop
M
MD-2485
accessory box
user's
manual
card
guarantee
certificate
attention
baking mesh
glass rotary tray
rotary tray support
Install
Put the microwave oven levelly at the
position you choose . Keep good
ventilation.
M'
S'
TimeAdjust
+
Med
M.H
Low
High
Stop
M
MD-2485
The gaps shall be all above 15cm
Select independent special socket,
with current at least 10A. Be sure to
ground it reliable.
5
Instructions of the control panel functions
The lamp of Minute
The lamp of Second
Time Adjust
The time adjust
Turn clockwise to add
the cooking time
MD-2485
M
Turn clockwise to reduce
the cooking time
The power select
Power level
Power Level
6
Instructions of the control panel functions
The lamp of Minute
The lamp of Second
Time Adjust
The time adjust
Turn clockwise to add
the cooking time
MD-2485
M
Turn clockwise to reduce
the cooking time
The power select
Power level
Power Level
G
7
Usage
The use of the power select
Name
Combi2
Combi1
Grill
The rate of
work period
Output
power
0
309W
540W
695W
850W
Function
In the position of stop, the microwave oven
neither working nor setting cooking time.
During the microwave oven working, if you
turn the power select to the position, the MWO
will stop working with a rings.
When you don't use the MWO, please turn
the power select to the position to avoid the
MWO working without food.
Defrost
Middle power level. It is used to heat milk
and beverage.
Medium high. It is used to stew food.
Heat food quickly.
Grill and microwave work in turn. It is used
to heat little block.
Grill and microwave work in turn. It is used
to heat big block.
Grill food
8
Usage
The use of time select
Direction
Clockwise Add
Anticlockwise
Cooking
Time
Reduce
Function
In stand-by mode, LED displays "00".After
setting the power level, If you turn the time
select clockwise, the LED display:10-20-30
-40-50-60 in turn with the lamp of second on
Turn the time select clockwise continually, the
lamp of minute is on ,LED display "02-03-04..
28-29-30",The max cooking time is 30 minutes
During the microwave oven working ,you can
add working time through turn the time select
clockwise.
Whenever you can turn the time select
anticlockwise to reduce the cooking time until
the microwave stop working.
Setting the power level
For instance: To cook for 3 minutes with M.H power level.
In stand-by mode, turn the power level to the position of M.H
then turn the time adjust knob clockwise until LED display "03"
with the lamp of minute on. Two seconds later, the microwave oven
start working, LED display the rest cooking time the lamp flash.
When the rest cooking time less than 1 minute ,LED display "59
-58-57-.." With the lamp of minute off. The lamp of second flash.
When the microwave oven stops working ,LED display "00".The
buzzer will sound five times to indicate that the cooking is finished.
9
Usage
Explanation
Condition The microwave oven display
Turn the power select to the
middle of two position.
Open the door when the
microwave oven is working.
Open the door to take food
then close the door
A djust the power select
during the microwave oven
working. For instance, when
the microwave work with
Medpowerlevel,youturn
the power select to the high
power level.
The buzzer sounds continual and
transitory to indicate that the setting
of power level is wrong ,please turn
the power select to the accuracy
position
The microwave oven stop working
with the LED stop counting ,at the
same time the lamp of cooking time
on the control est stop flashing.
Two seconds later ,the microwave
oven start to work automatic, LED
continue to count rest cooking time
at the same time the lamp of cooking
time on the control est stop flashing
The microwave work with the
adjusted power level(high power )
During the microwave oven working
the power level may adjust.l
A djust the time select
during the microwave oven
working.
Turn clockwise to add cooking time
the max cooking time is 30 minute.
Turn anticlockwise to reduce the
cooking time ,the minimum cooking
time is 0 minute
10
Selection of the Cooking Dishware
Selection of the microwave
cooking dishware
Microwave characters
Cooking dishware
Heatproof
glass
container
Non heatproof
glass container
Heatproof pla stic
container
Non heatpro of
plastic container
Ceramic container
Lacquer
container
Microwave cooking
Yes
No
Yes
Please use containers
labelled with apply fo r
microwave oven" mark
No
Materials deteriorated by
microwave can not be
used.
The foam tray can be used
in single defrosting the
fresh food.
Containers with color pattern
or golden/silver decoration
can not be used.
Yes
It may cause paint drops,
Please select suitable cooking dishwere for
the microwave oven.
absorbed by the food
penetrate the glass
reflected by the metal
Roast-cooking
Yes
No
No
No
No
Containers with color pattem at inner
side may cause color drops. Please
avoid using such containers.
No
Combined cooking
Yes
No
No
No
Yes
No
Metal
containers
such as
aluminum
Wooden,
bamboo, paper
container
Film
Aluminum
foil
The metal screen may also cause
arc, and thus can not be used.
The coloring plate special for
microwave oven (metal product) can
not be used either
No
It may cause combustion
Do not use it in cooking
with much oil because it will
produce high temperature
It can be used for suitable
extent in defrosting food
Yes
No
11
No
If the container has
resin handle, do not
use it.
Those paper container
treated with heatproof
processing can be used.
It will melt under high
temperature
Wrap the food with alumi-
num foil to do roasting
No
No
Yes
No
No
No
No
Cooking Tips
Cooking tips for microwave oven
Food temperature
Food moisture
Food shape
Food density
Food quantity
Bone and fat
Add cover
Settle
Lower temperature requires longer cooking time. Frozen
food needs longer heating time than common food.
As the microwave cavity is smaller it will retain a higher level of
humidity, larger humidity levels result in shorter cooking time.
As the microwave can only penetrate 2-4cm into the food,
the thickness of the food will influence the cooking time.
Heating times are different between dense food
(meats) and loose(peas) food. The former requires
longer time.
The selected power level of the microwave is a certain value, and
will not change along with the quantity of the food. Therefore larger
quantity of food requires longer cooking time.
Bones have quicker heat transmission, and fats absorb more
energy. Therefore please pay attention to the overheat
possibility in cooking the meat with bones and fats.
The production of heat and vapour can be reduced by
placing the food into a container with a cover, this will
shorten the cooking time.
Please form the food in circular shape during cooking,
and avoid piling up as far as possible. It can improve
the evenness.
Stir
Seal
Lay aside
When cooking Iiquid food like the soap, juice or
beverage etc., stir it slightly before and during cooking.
Seal the food with freshness-preserve film to avoid
splashing and contaminating the cavity. It can also
preserve the moisture and nutrition.
When the food is removed from the microwave oven, the
inside of the food is still heating. Place it aside for some time.
Take the factor of duration into consideration.
12
Maintenance * Repair
Maintenance: Frequently cleaning and maintenance can guarantee normal
performance of the microwave oven.
Be sure to switch off the power before
cleaning.
Use soapy water to clean the shell, and
wipe it with soft cloth.
Use wet cloth to clean food scraps on the door
door seal and inside the cavity. Use wet cloth
soaked with soapy water to clean the other
deposits
Keep the inner side of the door clean. Keep
it free from food scraps.
Take it out at least once per week, put into
water to clean, to prevent deposits from
corroding the rotary wheel.
Note that the power supply cable shall not
be damaged or broken. If the power supply
cable is damaged, be sure to replace it with
special cable.
Do not use detergent and materials
containing metal to clean the cavity and
door.
combustible
detergent
alkaline
detergent
forbidden
acid
detergent
whitener
forbidden
forbidden
Remarks:
If the microwave oven is to be idle for a long time, please clean
thoroughly each part of the oven to avoid rusting.
If the microwave oven appears abnormal or is
Warning
damaged, do not use it any more before it is
repaired by professional technicians.
13
Answers to Questions
Answers to questions
Why is the lamp not on?
1. The lamp has failed.
2. The timer is not set.
Why is the vapor emitted from
the air discharge outlet?
Why is there water overflowing
below the door?
Can the microwave leak from
the view window of the door?
If start the microwave oven
without load of food, will it
damage the oven?
Why does the food need to be
laid aside after cooking?
Why is it not so quick as stated
in the manual to cook with my
microwave oven?
Why is there sparking or
cracking sound during cooking
sometimes?
In maintenance, the technicians shall pay attention that:
Components that are easy to dismantled and
likely to touch voltage above 240V:
1. Magnetron
2. High-voltage transformer
3. High-voltage capacitor
4. High-voltage diode
5. AK rectifier
Components that may
Do not expose yourself to the radiation of the microwave generator or
other components that transfer the microwave energy.
It is normal that the vapor may emit during cooking.
Sometimes the vapor will condensed into water and flow
out. It is normal phenomenon.
No. The metal shelter can reflect the energy back into the
oven. The view window only allows harmless light to pass
through. The microwave energy can not pass through.
Yes. NEVER do that.
It is important to lay the food aside for several minutes.
Cooking by microwave oven makes the food retrain heat
inside. After you take out the food from the oven, the inside
of the food will continue heating for 2-3 minutes. It can
assist the cooking the joint of the food, vegetables or
cookies completely outside the oven by laying aside.
Check the user's manual. Confirm that you follow the
instruction completely. Find out the reason for setting
different times. The setting of cooking time is only for
reference. To avoid excess cooking, you shall learn the
technology of cooking with microwave. The volume, weight
and shape of the food can all influence the cooking. Take
the instruction as reference, and learn it independently.
It may be owing to following:l. Dishware with metal part is
used (including gold and silver);
2. Fork or other metal dishware are left in the oven;
3. Too much metallic foil are used;
4. Metallic thread is used to bind the food.
cause excess microwave leakage:
1. Improper installation of the magnetron on the
wave guide
2. Improper adjusting of the door hook, door body
3. Door body and shell are damaged
microwave leakage
Microwave radiation
and up/down hinges
The above problems can cause excess
14
After-sales Service
After-sales service
1. Please glue the invoice on the invoice column in the warranty certificate and keep it with
care.
2. This product has one year's warranty (subject to the purchase date on invoice) with
maintenance free of charge. Please contact the special shop for maintenance by the
warranty certificate and invoice if maintenance is needed.
3. The following cases will not enjoy the maintenance free of charge. We will offer maintenance
with relative charges for them:
(1) Those damaged owing to misoperation of the user;
(2) Those damaged owing to decomposing by the user;
(3) Those without invoice and warranty certificate;
(4) Those with altered invoice or warranty certificate;
(5) Those exceeding the warranty period;
15
Loading...
