INSTRUCTION MANUAL
LCD TV
LCD-24K50
LCD-24K50(R)
LCD-24K50(W)
IMPORTANT INFORMATION
If a television is not positioned in a sufficiently stable location, it can be potentially
hazardous due to falling. Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
● Using cabinets or stands recommended by the manufacturer of the television.
● Only using furniture that can safely support the television.
● Ensuring the television is not overhanging the edge of the supporting furniture.
● Not placing the television on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television to a suitable
support.
● Not standing the televisions on cloth or other materials placed between the
television and supporting furniture.
● Educating children about the dangers of climbing on furniture to reach the
television or its controls.
Warning:
To prevent the spread of fire, keep candles or other open flames away from
this product at all times.
2
TO THE OWNER
Before operating this LCD TV, read this manual thoroughly and operate the LCD TV properly.
This LCD TV provides many convenient features and functions. Operating the LCD TV properly enables
you to manage those features and maintains it in better condition for a considerable time.
Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard,
or other accidents.
If your LCD TV seems to operate improperly, read this manual again, check operations and cable
connections and try the solutions in the “Troubleshooting” section on page 25 of this booklet. If the
problem still persists, contact the dealer where you purchased the LCD TV or the service center.
Safety Precaution
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
● Install the LCD TV in a proper position. If not, it may result in a fire
hazard.
● Provide appropriate space on the top, sides and rear of the LCD
TV cabinet for allowing air circulation and cooling the LCD TV.
Minimum clearance must be maintained. If the LCD TV is to be
built into a compartment or similarly enclosed, the minimum
distances must be maintained. Do not cover the ventilation slot on
the LCD TV. Heat build-up can reduce the service life of your LCD
TV, and can also be dangerous.
● If the LCD TV is not to be used for an extended time, unplug the
LCD TV from the power outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
10 cm
SIDE and TOP
10 cm
10 cm
REAR
6 cm
Caution In Installing
● Handle the
carefully when installing it and do not drop.
LCD TV
● Locate set away from heat, excessive dust, and direct sunlight.
● For correct installation and mounting it is strongly recommended to use a trained, authorized dealer.
Failure to follow correct mounting procedures could result in damage to the equipment or injury to the
installer.
NOTE :
When LCD TV is not used for a long period of time, unlighted dots may be observed. This is caused by
characteristic of the LCD TV. If this occurs, turn the LCD TV on and leave it on about 1 hour. These dots
will gradually disappear.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
3
SAFETY INSTRUCTIONS
All the safety and operating instructions should be
read before the product is operated.
Read all of the instructions given here and retain
them for later use. Unplug this LCD TV from AC
power supply before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for cleaning.
Follow all warnings and instructions marked on the
LCD TV.
For added protection to the LCD TV during a
lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from
the wall outlet. This will prevent damage due to
lightning and power line surges.
Do not expose this unit to rain or use near water...
for example, in a wet basement, near a swimming
pool, etc...
Do not use attachments not recommended by the
manufacturer as they may cause hazards.
Do not place this LCD TV on an unstable cart,
stand, or table. The LCD TV may fall, causing
serious injury to a child or adult, and serious
damage to the LCD TV. Use only with a cart or
stand recommended by the manufacturer, or sold
with the LCD TV. Wall or shelf mounting should
follow the manufacturer's instructions, and should
use a mounting kit approved by the manufacturers.
An appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.
Slots and openings in the back and bottom of
the cabinet are provided for ventilation, to insure
reliable operation of the equipment and to protect it
from overheating.
The openings should never be covered with cloth
or other materials, and the bottom opening should
not be blocked by placing the LCD TV on a rug, or
other similar surface. This LCD TV should never be
placed near or over a radiator or heat register.
This LCD TV should not be placed in a built-in
installation such as a book case unless proper
ventilation is provided.
Never push objects of any kind into this LCD TV
through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in
a fire or electric shock. Never spill liquid of any kind
on the LCD TV.
Do not place items such as vases containing liquid
on top of the LCD TV.
Do not install the LCD TV near the ventilation duct
of air-conditioning equipment.
This LCD TV should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supplied,
consult your authorized dealer or local power
company.
Do not overload wall outlets and extension cords as
this can result in fire or electric shock. Do not allow
anything to rest on the power cord. Do not locate
this LCD TV where the cord may be damaged by
persons walking on it.
Do not attempt to service this LCD TV yourself
as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
Unplug this LCD TV from wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or
frayed.
b. If liquid has been spilled into the LCD TV.
c.
If the LCD TV has been exposed to rain or water.
d.
If the LCD TV does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the LCD TV to normal operation.
e. If the LCD TV has been dropped or the cabinet
has been damaged.
f. When the LCD TV exhibits a distinct change in
performance-this indicates a need for service.
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
injury to persons.
Upon completion of any service or repairs to this
LCD TV, ask the service technician to perform
routine safety checks to determine that the LCD TV
is in safe operating condition.
DISPOSAL PRECAUTIONS
CONTAINS MERCURY
LAMPS, DISPOSE OF
PROPERLY
4
TABLE
FEATURE AND DESIGN.......................................6
PREPARATION........................................7
PART NAMES AND FUNCTIONS 7
CONNECTING LCD TV......................8
INSTALLING & UNINSTALLING
STAND BASE 8
CONNECTING AC POWER CORD 9
CONNECTING A COMPUTER 9
CONNECTING VIDEO EQUIPMENT &
AERIAL 10
BEFORE OPERATION..........................11
OPERATION OF REMOTE CONTROL 11
REMOTE CONTROL BATTERIES
INSTALLATION 11
BASIC OPERATION..............................12
TURNING ON/OFF LCD TV 12
PLUG & PLAY
SELECTING INPUT SOURCE 13
CHANNEL RECALL 13
CHANNEL SELECTION 13
INFO 13
VOLUME CONTROL 14
MUTE 14
STEREO/MONO 14
SOUND MODE 14
PICTURE MODE 14
SPORT MODE 14
OFF TIMER 15
WIDE 15
12
MENU OPERATION (TV/AV/HDMI MODE)............16
CHANNEL
SOUND
TIMER
OSD 19
SETUP 20
MENU OPERATION(PC MODE)
SETUP 21
DEALER MODE
APPENDIX..............................................................24
CLEANING LCD TV 24
FUNCTION OF PRODUCT SAFETY FEATURE
TROUBLESHOOTING 25
TECHNICAL SPECIFICATIONS 26
SIGNAL MODE COLUMN (Recommended) 27
16-17
18
18
19
............................21
22-23
24
is registered trademarks of HDMI Licensing, LLC.
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark
of its respective corporation.
5
Feature and Design
¡ Picture
●
High Definition LCD Panel
1366 x 768 pixel HD LCD Panel with high
contrast ratio and wide viewing angle.
●
VIZON Engine
VIZON Engine, SANYO High Quality Image
Processing Technology reproduces clear,
dynamic, natural and realistic picture along
with HD LCD Panel Technology.
● Dynamic AI
The AI (Automatic Image Control) circuit
compensates picture contrast and brightness
level dynamically and reproduces bright and
high-contrast picture.
¡ Sound
● NICAM/A2 Stereo
It's the Stereo Sound PAL Color TV Broadcasting
System upgrading mono-sound TV service to
stereo or dual-language sound.
● Bass Expander
Bass Expander reinforces bass effect to improve
overall sound quality.
¡ Feature
● Sport Mode
Just by pressing the button, sport mode optimizes
picture and sound settings suitable for each
sport program.
OFF
Normal setting.
Football
Use to watch football progarm, golf progarm
or etc.
Winter Sport
Suitable setting for Skiing
Marine Sport
Suitable setting for Swimming, Diving
progarm or etc.
Indoor Sport
Suitable setting for Basketball, Badminton
progarm or etc.
progarm or etc.
¡ Compatibilty
● Full Multi System
PAL, PAL 60Hz, SECAM, NTSC, NTSC 4.43
system can be connected.
● HD-Ready
1080p, 1080i, 720, High Definition signals
are receivable.
● HDMI
HDMI provides complete transmission of digital
image and sound signals without any quality
deterioration.
DVI can be connected to HDMI.
● PC Input
Personal Computer/Laptop can be connected
with automatic resolution adjustment.
● Terminals
HDMI for BluRay Player etc.
D-SUB 15-pin for PC input etc.
Component Video for DVD
¡ Others
● Wall Mounting
It's designed for VESA Standard wall hanging
bracket.
● Light Commercial Mode
By entering Dealer mode, Volume Lock,
Tuning Lock, Start Mode, OSD, RC, AC
Power Mode, Start Volume Level, Music
Mode and Reset can be selected.
Convenient for placing in Hotel, Hospital,
School, Store, Bank etc.
● SHOP Mode
Picture mode will be Dynamic and ECO mode
will be OFF in SHOP
MODE.
6
PREPARATION
PART NAMES AND FUNCTIONS
FRONT
Side Control
Power/Timer
Indicator
CARE FOR USING LCD TV
● Do not bump or scratch the panel surface as this causes flaws on the surface of the screen.
● There may be some tiny black points and/or bright points on the SCREEN. These points are normal.
SIDE CONTROL
Each button on the control
panel has the same function
with its counterpart on the
remote control.
-Used to turn the LCD TV on or off.
-Open or close the On-Screen Menu.
-
Used to select input source: TV/AV1/ AV2(DVD)
-Used to confirm the selected item on On-Screen Menu.
-Used to adjust the volume.
-Used to adjust the value of the selected item on On-Screen Menu.
-Used to execute the selected item on On-Screen Menu.
-Used to Change channels.
-Used to select items on On-Screen Menu.
POWER ON/ OFF button
MENU button
INPUT MODE button
VOLUME
CHANNEL UP/DOWN (▲/▼)
(+/-)
buttons
/HDMI(DVI)/PC.
buttons
Infrared
Remote
Receiver
BACK TERMINAL
HDMI Input Terminal
Connect video and audio outputs
from video equipment.
PC Input Terminals
Connect computer outputs to
these terminals.
● RGB (D-SUB)
AV1 Terminals
Connect video and audio outputs from
video equipment.
● Video (RCA type)
● Audio L and R (RCA type)
Monitor Output Terminals
Connect a television, video recorder or
external audio amplifier to these jacks.
● Video (RCA type)
● Audio L and R (RCA type)
● Audio (L/R)
AV2 Terminals
Connect video and audio outputs
video equipment.
from
● DVD component (RCA type)
● Audio L and R (RCA type)
Connect the cable with a plug
from aerial jack to the aerial
socket on the cabinet back.
Aerial Jack
Panel
7
CONNECTING LCD TV
INSTALLING & UNINSTALLING STAND BASE
Please according to the following procedure to install stand.
Be careful of the panel. Suggest to put down the panel side on the cushion or other soft material before
1
installing the stand.
To align the corresponding pilot holes and fix the stand by screws.
2
Screws A for LCD-24K50/(R)/(W): 2 pcs
Screws B for LCD-24K50/(R)/(W): 2 pcs
Installing of stand is completed.
3
Model LCD-24K50/(R)/(W):
A
B
CAUTION IN UNINSTALLING STAND BASE
● Through in uninstalling work, handling with more than two people is recommended.
When holding (moving or lifting) the LCD Display, hold the display's body.
●
TV by holding the attached accessory parts (speakers), otherwise it may result in damage.
Before uninstalling, provide a desk (or a part of it) which is strong enough to support the weight of
●
the LCD TV and this stand. The desk must be larger than the LCD
surface must be flat and maintained with
surface.
Before putting the LCD Display on the desk, make sure there is no object on it. Leaving any object
●
under the screen may cause damage on the screen.
●
The LCD TV with this stand should be uninstalled on
an non flat, unlevel or unstable cart or stand. The display may fall,
to the products but serious injury to a person.
soft material (such as a blanket) for protecting the screen
flat and level place. Do not place on such as
Do not handle the LCD
Display screen size. The desk's
causing not only serious damage
SAFETY NOTE
For correct installing, mounting and uninstalling LCD TV Stand, it is strongly recommended to use
a trained, authorized dealer. Failure to follow correct procedures could result in damage to the
equipment or injury to the installer.
8
CONNECTING AC POWER CORD
This LCD TV uses nominal input voltages of 110-240V
AC. This LCD TV automatically selects the correct
input voltage. It is designed to work with singlephase power systems. To reduce risk of electrical
shock, do not plug into any other type of power
system. Consult your authorized dealer or service
station if you are not sure of the type of power being
supplied.
Connect the LCD TV with all peripheral equipment
before turning the LCD TV on.
CAUTION
For safety, unplug AC power cord when the LCD
TV is not in use.
CONNECTING A COMPUTER
Cables used for connection (These cables are not
supplied with this LCD TV.)
● PC/VGA Cable (D-SUB 15pin)
● HDMI Cable: HDMI Input
● MAC Adapter (in the case of connecting Macintosh
computer)
●
Audio Cable [Mini Plug (L/R)]
CONNECTING LCD TV
AC POWER CORD
To the AC Outlet (110
- 240V AC).
AC power cord out from
the LCD TV.
outlet must be near this
equipment and must be
easily accessible.
NOTE:
When connecting the cables, AC Power Cords
of both LCD TV and external equipment should
be disconnected from AC outlet. Turn LCD
TV and peripheral equipment on before your
computer is switched on.
Pulls the
The AC
IBM-compatible
computers
or Macintosh
computers
(VGA / SVGA /
XGA )
Digital AV Equipment
Desktop
type
HDMI Output
Audio Output
(stereo)
Laptop
type
HDMI Input
Audio Input
(stereo)
Monitor Output
MAC
Adapter
PC Input
Note:
1. You can connect the DVI source to HDMI input terminal by using the DVI to HDMI converter.
2. When inputting 1080p signal to HDMI terminal, please use High Speed HDMI Cables to avoid picture/
sound noise and no picture/sound.
9
CONNECTING LCD TV
CONNECTING VIDEO EQUIPMENT & AERIAL
Cables used for connection (These cables are not supplied with this LCD TV.)
● Video Cable(RCA X1), Audio Cable (RCA X2) : Video 1 or Video 2
● Video Cable(RCA X3), Audio Cable (RCA X2) : DVD (Component Video)
● Video Cable(RCA X1), Audio Cable (RCA X2) : Monitor Output
● HDMI Cable: HDMI Input
NOTE : When connecting the cable, AC Power Cords
of both LCD TV and external equipment should
be disconnected from AC outlet.
DVD video equipment.
(such as DVD player or high-definition
TV source)
Component Video Source
(example)
DVD Player
R/PR,CB/PB, Y
C
R L
MONITOR OUT
Note:
Video (RCA) output is for
TV, or AV.
Composite Video
and Audio Output
External
monitor
Video Source (example)
Video Cassette
Recorder
Audio Amplifier
Audio
Speaker
(stereo)
External Audio
Equipment
Video Disc
Player
Video cable
(RCA x1)
Audio cable
(RCA x 2)
Video and Audio
cable (RCA x 3)
Note:
When connect to HDMI Input terminal, it needs
few seconds to display picture.
R , L , V
Audio cable
(RCA X 2)
Outdoor Aerial
DVD
(RCA X 3)
10
Aerial Cable
BEFORE OPERATION
OPERATION OF REMOTE CONTROL
INPUT button
INFO / VA·B button
SPORTS button
TIMER button
NUMERIC buttons
CHANNEL UP/
CHANNEL RECALL button
POINT ▲/
DOWN
DIGIT button
MENU button
▼/◄
/►buttons
buttons
POWER ON/OFF button
SOUND button
PICTURE button
WIDE button
VOLUME +/- buttons
MUTE button
BACK button
ENTER button
REMOTE CONTROL BATTERIES INSTALLATION
Remove the battery compartment cover.
1
Insert two size AA batteries (1.5V) according to
2
"+" and "-" polarity markings inside the battery
compartment.
Close the battery compartment cover.
3
11
BASIC OPERATION
I AM SEARCHING ALL PROGRAMMES
PLEASE WAIT!
MENU
: CANCEL
1
PLEASE SELECT AND PRESS ENTER BUTTON
HOME MODE SHOP MODE
ENTER
: ENTER
: SELECT
AUTO SET-UP COMPLETED
HAPPY VIEWING!
NO STATION
PLEASE CONNECT ANTENNA PLUG!
ENTER
: ENTER
: SELECT
PLEASE SELECT AND PRESS ENTER BUTTON
TEMPORAL CANCEL PERMANENT CANCEL
TURNING ON / OFF LCD TV
Complete the peripheral connections before turning on LCD
1
TV. (Please refer to "CONNECTING LCD TV".)
Connect LCD TV's AC Power Cord into an AC outlet.
2
Press POWER ON/OFF button on Side Controls of LCD TV
3
or on Remote Control to turn it ON. The POWER indicator
will light up (green). Press POWER ON/OFF button again
to shift it to stand-by status, the POWER indicator will become
red.
NO SIGNAL SHUT OFF
This TV set incorporates the NO SIGNAL SHUT OFF function.
If no signal is input in TV mode, "OFF 00:10" will display for
about 10 minutes and TV will be turned off automatically.
By PLUG & PLAY, when the TV reset and powered on for the
first time, it will automatically search and preset all the receivable
TV programs.
Plug the power, connect the antenna, and press Main Power
1
ON/OFF button, the TV set will automatically search the
programs.
After programs searching, SHOP MODE menu will appear.
2
Press POINT ◄► buttons to select and press ENTER
for SHOP MODE or HOME MODE. Then the pop
button
disappears.
up menu
Auto searching completed and message "AUTO SET-UP
3
COMPLETED HAPPY VIEWING!" appears. About 5 seconds
later, the TV set will automatically return to programme
position “1”.
Note:
Message "NO STATION PLEASE CONNECT ANTENNA PLUG!"
●
will appear if there is no TV stations are searched after
automatically programs searching.(see Figure A.) Then
SHOP MODE menu appears, the same operations as step 2
above will be excuted and returns to normal TV picture.
● Press MENU button while searching programs, message
"PLEASE SELECT AND PRESS ENTER BUTTON" appears
(see Figure B), press POINT
"TEMPORAL CANCEL" or "PERMANENT CANCEL".
-
"TEMPORAL CANCEL" to cancel temporary PLUG & PLAY
function. The
mode while turning on the LCD TV.
- "PERMANENT CANCEL" to cancel permanetly PLUG &
PLAY function. When turn on television the PLUG & PLAY
is not actived.
Press ENTER button to enter SHOP MODE menu. the same
operations as step 2 above will be excuted and returns to
normal TV picture.
12
PLUG & PLAY
PLUG & PLAY
◄► buttons to select
function
is actived only in TV
SIDE CONTROL
POWER ON/ OFF
button
REMOTE CONTROL
POWER ON/
OFF button
Figure A.
Figure B.
BASIC OPERATION
SELECTING INPUT SOURCE
Select mode "TV", "AV1-S", "AV2", "HDMI" or "PC" by pressing INPUT button on Remote Control or on
Side Controls, you can also press POINT ▲▼ buttons to select different mode. To enter the selected mode,
press ENTER button or POINT ◄► buttons.
INPUT
TV
1. TV
2. AV1-S
3. AV2
4. HDMI
5. PC
: SELECT : EXIT
1~5
Note:
●
User can directly displayed selected input source by
pressing NUMERIC buttons (1-5)
BACK
on Remote Control.
CHANNEL RECALL
Press CHANNEL RECALL button to switch between
the previous channel and the current channel.
For example, now you are watching channel "4", but
you watched channel "2" previously. If you press
CHANNEL RECALL button, channel "2" will appear
immediately.
CHANNEL SELECTION
There are 256 channels can be selected on the LCD TV.
DIRECT SELECTION
For direct access to programmes using the (0-9) numeric buttons.
1) For selection of channel position 0 - 9. Example: For
channel position 8, press “8” button.
2)
For selection of channel position 10 - 99. Example:
For channel position 25, press the DIGIT
display "- -", then press “2” and “5” buttons.
For selection of channel position 100 - 199. Example:
3)
For channel position 125, press the DIGIT button
twice to display "1 - -", then press “2” and “5” buttons.
4) For selection of channel position 200 - 255.
Example: For channel position 225, press the DIGIT
button three times to display "2 - -", then press “2”
and “5” buttons.
button to
CHANNEL UP/ DOWN
Press CHANNEL UP/DOWN (▲▼) buttons on Side Control or on Remote Control to select programs.
●
Press CHANNEL UP (▲) button to select next channel.
●
Press CHANNEL DOWN (▼)
Note:
CHANNEL RECALL and CHANNEL SELECTION function only use in TV mode.
button to select previous channel.
INFO
Press INFO button on Remote Control to display the status of LCD TV. Press again to remove the display.
11
A
Channel
Colour System
Sound System
Bilingual
AUTO
D/K
SIDE CONTROL
INPUT button
REMOTE CONTROL
INPUT button
INFO button
NUMERIC
buttons
CHANNEL UP/
DOWN (▲▼)
buttons
CHANNEL
RECALL button
DIGIT button
13
BASIC OPERATION
VOLUME CONTROL
To adjust the volume value desired by pressing VOLUME(+/-)
buttons on Remote Control or on Side Control. The volume
dialogue box will appear on the screen for a short while.
VOLUME(+) button to increase volume, and VOLUME(-)
button to decrease volume.
MUTE
Should you wish to mute the sound, press MUTE button.
To switch the sound back on, press MUTE button again
or press VOLUME(+/-) buttons on Side Control or on
Remote Control.
STEREO/MONO
Press the
information display. And then press
select the following audio signals: "STEREO", "MONO",
"NICAM", "A", and "B".
VA·B
button on Remote Control to show the
V A·B
button to
SOUND MODE
Select sound level by pressing SOUND button on Remote
Control.
STANDARD: Normal sound state preset on LCD TV.
NEWS: Select this mode for talk programs.
MUSIC: Select this mode for music programs.
PERSONAL: Select this mode for user to call out the
preset sound adjustment in SOUND menu.
PICTURE MODE
Select image level by pressing PICTURE button on
Remote Control.
STANDARD: Natural and splendid picture level preset on this LCD TV.
VIVID: Present colourful and lively picture level.
SOFT: Inhibit strong contrast and color, it is beneficial for eye protection.
PERSONAL: User presets picture adjustment in PICTURE MODE.
DYNAMIC: Bright and dynamic picture. It is suitable for nice playback, such as DVD program.
Note:
Select ECO in SETUP menu. Then press ◄► buttons to select "ON". While in ECO status, press PICTURE
button to choose any of options of "ECO/STANDARD", "ECO/VIVID", "ECO/SOFT", "ECO/PERSONAL"
and "ECO/DYNAMIC".
SPORT MODE
Select SPORTS mode "OFF", "FOOTBALL", "WINTER
SPORT", "MARINE SPORT" and "INDOOR SPORT"
by pressing SPORTS button repeatly on Remote Control.
OFF: Turn off the sport mode to return to normal picture.
FOOTBALL: Use to watch football program, golf program or etc.
WINTER SPORT: Use to watch skiing program or etc.
MARINE SPORT: Use to watch swimming program, diving program or etc.
INDOOR SPORT: Use to watch basketball program, badminton program or etc.
Note:
Press SOUND button in SPORT mode, only current SPORT mode is displayed.
REMOTE CONTROL
SOUND button
VA·B
button
PICTURE button
SPORTS button
VOLUME(+/-)
buttons
MUTE button
14
OFF TIMER
To set OFF TIMER by pressing TIMER button on Remote
Control. The timer dialogue box will appear on the screen
for a short while.
To select "OFF", "30 MIN", "60 MIN", "90 MIN" or "120
MIN" with TIMER buttons.
WIDE
Select screen size among "FULL", "ZOOM", "ZOOM[CAPTION-IN]",
"NORMAL" and "NATURAL" by pressing WIDE button on
Remote Control.
* This function doesn't work in TV/ AV/ DVD/ HDMI/ PC
modes when no signal is input.
* Only "FULL" mode can be selected when the input mode
is
"HDMI" or "DVD" and the input signal is 1080i, 720p or
1080p.
* "FULL" and "NORMAL" can be selected in PC mode.
FULL: Provides image to fit width of screen by expanding
image width uniformly. This function can be used for
enjoying a squeezed video signal with wide video aspect
ratio of 16 : 9
DVD) has 16 : 9
to provide better
quality.
ZOOM: Provides image to fit screen size (16 : 9 aspect
ratio) by expanding image width and height uniformly. This
function can be used for enjoying a letter box mode picture
(4 : 3 aspect picture with black bar on top and bottom
edges) with wide video aspect of 16 : 9 screen.
ZOOM[CAPTION-In]: Provides the image that is expanded
as "ZOOM" mode and moved
include captions. This function can be used for enjoying a
letter box picture with captions.
screen. When your video equipment (such as
output mode, select 16 : 9 and select "Full"
up to show more image to
BASIC OPERATION
REMOTE CONTROL
WIDE button
TIMER button
NORMAL: Provides real 4 : 3 image on 16 : 9 screen.
NATURAL: Provides image to fit width of screen by
expanding up/down/left right of image. This function is
suitable to enjoy a normal
with wide video aspect ratio of 16 : 9 screen.
video signal (4 : 3 aspect ratio)
15
MENU OPERATION (TV/AV/HDMI mode)
CHANNEL
SEMI-AUTO SEARCH
MANUAL SEARCH
COLOUR SYSTEM
SOUND SYSTEM
SKIP
CHANNEL SWAP
AUTO
B/G
OFF
AUTO SEARCH
SELECT
ADJUST
BACK EXIT
::
:
:
CHANNEL
SEMI-AUTO SEARCH
MANUAL SEARCH
COLOUR SYSTEM
SOUND SYSTEM
SKIP
CHANNEL SWAP
AUTO
B/G
OFF
AUTO SEARCH
SELECT
ADJUST
BACK EXIT
::
:
:
AUTO SEARCHING, PLEASE WAIT…
: EXIT
55.25 MHZ CH 2
: BACK
SEMI-AUTO SEARCHING
55.25 MHZ
CHANNEL 15
SEARCH
SELECT
ADJUST
BACK
::
:
SEMI-AUTO SEARCH COMPLETED
55.25 MHZ
CHANNEL 15
SEARCH
SELECT
ADJUST
BACK
::
:
CHANNEL
Press MENU button and the main menu will appear. Whenever
1
MAIN MENU is accessed initially, CHANNEL will be the
default selection.
Press POINT ▲▼ buttons or ENTER button to enter into
2
CHANNEL menu.
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to adjust the item.
4
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu
operation.
Note:
● "CHANNEL" menu doesn't work in HDMI mode and PC mode.
●
In AV mode, only "COLOUR SYSTEM" in "CHANNEL"
can be selected
●
The settings for "SOUND SYSTEM", "COLOUR SYSTEM" or "SKIP"
automatically memorized in the programme position.
are
.
menu
AUTO SEARCH
All receivable channels are automatically tuned in and memorized
in consecutive programme position.
● The Automatic Tuning operation can be cancelled at any time
by pressing BACK button or MENU button.
● After all receivable channels have been found and stored,
the TV set will automatically return to programme position “1”.
CHANNEL MENU
AUTO SEARCH MENU
Note:
POINT ◄► buttons or ENTER button: Start or Restart AUTO
SEARCH.
SEMI-AUTO SEARCH
Use to preset a receivable channel in any desired programme
position, e.g. the position with the same number as the channel.
Select channel “15”.
1
Enter into CHANNEL menu, press POINT ▲▼ buttons to
2
select "SEMI-AUTO SEARCH". Press POINT ◄► buttons
to enter into the SEMI-AUTO SEARCH menu.
Press POINT ▲▼ buttons to select "SEARCH". Press POINT
3
◄► buttons to start the channel searching.
Press POINT ► button and the tuning will go to the higher
4
frequencies. Press POINT ◄ button and the tuning will go
to the lower frequencies.
Use POINT ◄ buttonorPOINT ► button to search for
required TV
automatically
■ Press BACK button to return to the previous menu.
■ Press MENU button to exit menu operation.
16
station. Once a station is located, searching will
stop. Continue till desired channel is located.
SEMI-AUTO SEARCH MENU
MENU OPERATION (TV/AV/HDMI mode)
CHANNEL
SEMI-AUTO SEARCH
MANUAL SEARCH
COLOUR SYSTEM
SOUND SYSTEM
SKIP
CHANNEL SWAP
AUTO
B/G
OFF
AUTO SEARCH
SELECT
ADJUST
BACK EXIT
::
:
:
CHANNEL
CURRENT CHANNEL
TARGET CHANNEL
SWAPPING OK
CHANNEL SWAP
12
16
SELECT
ADJUST
BACK EXIT
::
:
:
CHANNEL
CURRENT CHANNEL
TARGET CHANNEL
SWAPPING
CHANNEL SWAP
12
16
SELECT
ADJUST
BACK EXIT
::
:
:
MANUAL SEARCH
55.25 MHZ
CHANNEL 15
SEARCH
SELECT
ADJUST
BACK
::
:
STORE
:
ENTER
MANUAL SEARCH
55.25 MHZ
CHANNEL 15
SEARCH
SELECT
ADJUST
BACK
::
:
STORE
:
ENTER
MANUAL SEARCH
Manual search a channel if it cannot be automatically tuned, such
as when the signal is poor.
Select channel “15”.
1
Enter into CHANNEL menu, press POINT ▲▼ buttons to
2
select "MANUAL SEARCH". Press POINT ◄► buttons to
enter into the MANUAL SEARCH menu.
Press POINT ▲▼ buttons to select "SEARCH".
3
◄► buttons
Press and hold POINT ◄ or POINT ► button to search for
4
required TV station. Press ENTER button to save desirable
station.
■ Press BACK button to return to the previous menu.
■ Press MENU button to exit menu operation.
COLOUR SYSTEM
The setting for colour system is only active in TV or AV mode.
Usually, the colour system is set to the position of "AUTO". In case
of abnormal colour, repeatedly press POINT ◄► buttons to select
"AUTO", "PAL", "SECAM", "NTSC" or "NTSC4.43" until the best
colour effect is reached.
SOUND SYSTEM
The setting for sound system is only active in TV mode.
Usually, the sound system is set to the position of "B/G". In case
of abnormal sound, repeatedly press POINT ◄► buttons to select
"D/K", "I", "M" or "B/G" until the best sound effect is reached.
SKIP
This feature is used to remove unwanted channels from the
channel scanning memory.
You can skip the unused or undesired channels when you are
selecting a channel using CHANNEL UP/DOWN (▲▼) buttons.
This function is only active in TV mode.
CHANNEL SWAP
To swap the channels between two stored programme positions.
Press MENU button to display the main menu.
1
Enter into "CHANNEL" menu, press POINT ▲▼ buttons to
2
select CHANNEL SWAP.
Press POINT ◄► buttons
3
CHANNEL SWAP
the CURRENT CHANNEL or TARGET CHANNEL, then press
POINT ◄► buttons to select the swap channel. And then
press POINT ▲▼ buttons to select SWAPPING item, then
press POINT ◄► buttons or ENTER button to select "OK".
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu
operation.
Note:
When enter into CHANNEL SWAP menu again, TARGET CHANNEL
will be turn to 0.
start the channel searching.
to
or ENTER button
to enter into the
menu. Press POINT ▲▼ buttons to select
Press POINT
MANUAL SEARCH MENU
17
MENU OPERATION (TV/AV/HDMI mode)
CONTRAST
COLOUR
SHARPNESS
PICTURE MODE
TINT
COLOUR TONE
BRIGHTNESS
SELECT
ADJUST
BACK EXIT
::
:
:
STANDARD
NORMAL
SOUND
EQUALIZER
SOUND MODE
BALANCE
BASS EXPANDER
OFF
AUTO VOLUME
OFF
SELECT
ADJUST
BACK EXIT
::
:
:
STANDARD
SOUND
EQUALIZER
SOUND MODE
BALANCE
BASS EXPANDER
OFF
AUTO VOLUME
OFF
STANDARD
SELECT
ADJUST
BACK EXIT
::
:
:
SOUND
EQUALIZER
500 Hz
1.5K Hz
5K Hz
10K Hz
SELECT
ADJUST
BACK EXIT
::
:
:
CONTRAST
COLOUR - R
COLOUR - B
PICTURE MODE
COLOUR - G
BRIGHTNESS
COLOUR TONE
SELECT
ADJUST
BACK EXIT
::
:
:
STANDARD
NORMAL
Press MENU button and the main
1
menu will appear.
buttons to select "PICTURE", and will
display
PICTURE menu.
Press POINT ▲▼ buttons or ENTER
2
button to enter into PICTURE menu.
Press POINT ▲▼ buttons to select
3
the item desired.
Press POINT ◄► buttons to
4
adjust the item.
Press POINT ◄►
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit
menu operation.
PICTURE MODE: Used for
selecting "STANDARD",
"VIVID", "SOFT", "PERSONAL" or "DYNAMIC"
CONTRAST: Used to decrease and increase
contrast.
BRIGHTNESS: Used to adjust darken and brighten
image.
COLOUR: Used for lighten and darken colour.
(Only in TV/AV/HDMI mode).
TINT: Used to obtain proper colour.
SHARPNESS: Used for soften and sharpen the
image. (Only in TV/AV/HDMI mode).
SOUND
TV/AV/HDMI MODE PC MODE
Note:
"TINT" cannot be selected except for NTSC/
NTSC4.43
system.
COLOUR TONE: Used for selecting colour
.
temperature. Select "NORMAL", "WARM" or
"COOL".
COLOUR-R: Used to lighten and deepen red tone.
(Only in PC mode).
COLOUR-G: Used to lighten and deepen green
tone. (Only in PC mode).
COLOUR-B: Used to lighten and deepen blue tone.
(Only in PC mode).
Press MENU button and the main menu will
1
2
3
4
Press POINT ◄► buttons to select
appear.
"SOUND", and will display
SOUND menu.
Press POINT ▲▼ buttons or ENTER button to
enter into SOUND menu.
Press POINT ▲▼ buttons to select the item
desired.
Press POINT ◄► buttons to enter the item
selected.
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to
exit menu operation.
18
SOUND MODE: Press POINT ◄► buttons
to select "STANDARD", "NEWS", "MUSIC" or
"PERSONAL".
EQUALIZER: Select different frequency ranges of
sound separately by pressing
or ENTER button.
Adjust values of "500 Hz", "1.5
KHz", "5KHz", "10KHz" by pressing
POINT ◄► buttons
POINT ◄►
buttons.
BALANCE: Adjust the balance of the left and right
channels. (-15~15)
BASS EXPANDER: Switch Bass Expander ON or
OFF.
AUTO VOLUME: Switch Auto Volume ON or OFF.
Note:
SOUND MODE, EQUALIZER and BASS
EXPANDER is disabled when SPORT mode is ON.
MENU OPERATION (TV/AV/HDMI mode)
TIMER
ON TIMER 12 : 30
OFF TIMER
OFF
ON TIMER CH
16
SELECT
ADJUST
BACK EXIT
::
:
:
OSD
H - POSITION
TRANSPARENCY
LANGUAGE
INPUT LABEL
V - POSITION
ENGLISH
DURATION
5 SEC
SELECT
ADJUST
BACK EXIT
::
:
:
OSD
AV2
AV1
OFF
HDMI
INPUT LABEL
OFF
OFF
SELECT
ADJUST
BACK EXIT
::
:
:
TIMER
Press MENU button and the main menu will appear.
1
Press POINT ◄► buttons to select "TIMER", and will display
TIMER menu.
Press POINT ▲▼ buttons or ENTER button to enter into
2
TIMER menu.
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to enter the item selected.
4
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu
operation.
OFF TIMER: Once OFF TIMER has been set, when the set time is reached, the TV will shift to stand-by
status. To select "OFF", "30 MIN", "60 MIN", "90 MIN" or "120 MIN" with POINT ◄► buttons or TIMER
button. To cancel "OFF TIMER ", you can choose any option by the following ways.
- Setting "OFF" in OFF TIMER menu.
- Pressing POWER ON/OFF button on Side Control.
- Pressing POWER ON/OFF button on Remote Control.
ON TIMER: Once ON TIMER has been set, you won't miss any opportunity to watch the program you like.
To set channel position, you can use NUMERIC buttons or DIGIT
TIMER INDICATOR will be light.
To cancel "ON TIMER MODE", you can choose any option by the following
button.
After ON TIMER has been set, ON
ways.
- Setting "- - : - -" in ON TIMER.
- Disconnecting the AC power cord.
ON TIMER CH: This function is only active that ON TIMER has been set. When the set time in ON TIMER
is reach, the TV will turn on and enter the channel position you set directly.
use NUMERIC buttons or DIGIT
button.
Note:
●
When OFF TIMER countdown time reach 1 minute, OFF TIMER OSD always showed for user information
about power off time
OFF TIMER will be cancel when press any button during the countdown time dsplay.
●
remain.
● If ON TIMER didn't set, ON TIMER CH function will not actived.
● OFF TIMER and ON TIMER will be automatically cancelled during searching channels.
● The settings for OFF TIMER and ON TIMER will be automatically
cancelled after the settings has been
operated for one time.
● In case you left TV without any operation for 2 hours after power
on by ON timer, TV will automatically power
off itself.
OSD
Press MENU button and the main menu will appear. Press POINT ◄►
1
buttons to select "OSD"
Press POINT ▲▼ buttons or ENTER button to enter into OSD menu.
2
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to enter the item selected.
4
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu operation.
, and will display
OSD menu.
TIMER MENU
To set channel position, you can
LANGUAGE: Press POINT ◄► buttons to choose ENGLISH, ARABIC or
PERSIAN.
H-POSITION: OSD moves to the left side when POINT ◄ button is pressed.
OSD moves to the right side when POINT ► button is pressed. (0~100)
19
MENU OPERATION (TV/AV/HDMI mode)
SETUP
CHILD LOCK
ON
ECO
OFF
DYNAMIC AI
ON
ACTIVE CONTRAST
ON
PC ADJUST
SHOP MODE
SELECT
ADJUST
BACK EXIT
::
:
:
ENTER
: ENTER
: SELECT
PLEASE SELECT AND PRESS ENTER BUTTON
HOME MODE SHOP MODE
INITIAL SETTING RECALLED FOR DEMO
V-POSITION: OSD moves up when POINT ◄ button is pressed. OSD moves down when POINT ► button
is pressed. (0~100)
DURATION: Use this function to set the display time of the MENU when there
Press POINT ◄ button to decrease time, press POINT► button to increase time. (5~60 seconds)
TRANSPARENCY: The background of OSD darkens when POINT ◄ button is pressed.
lightens when POINT ► button is pressed. (0~100)
INPUT LABEL: Use this function to give input source tag name follows input
device (ex: DVD player, Blu-Ray player, etc). Press POINT ◄►
source
buttons or ENTER button to enter into INPUT
▲▼
buttons to select INPUT source,
LABEL menu. Press POINT
press POINT ◄► buttons to select
"OFF"(blank), VCR, DVD, AUX, STB or GAME.
Note:
User can switch off or fill INPUT LABEL names with blank, by
choosing "OFF" at INPUT LABEL menu option.
SETUP
Press MENU button and the main menu will appear.
1
Press POINT ◄► buttons to select "SETUP", and will display
SETUP menu.
Press POINT ▲▼ buttons or ENTER button to enter into
2
SETUP menu.
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to enter the item selected.
4
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu
operation.
Note:
"PC ADJUST" can not be selected except for PC mode.
CHILD LOCK: When CHILD LOCK is set
"ON", the Side Control buttons will be locked
except for POWER ON/OFF button. When
Press the Side Control buttons, TV will display
"LOCKED".
ECO: To select ECO "ON" or "OFF".
DYNAMIC AI: Used to adjust contrast and color
parameters until the display looks good. Set it ON or OFF
by pressing POINT ◄► buttons.
ACTIVE CONTRAST: Used to improved picture contrast
by panel's backlight. Set it ON or OFF by pressing
POINT ◄► buttons.
SHOP MODE: Press POINT ◄► buttons to choose HOME MODE or SHOP
enter into HOME MODE or SHOP
MODE.
HOME MODE: In this mode, the adjustments you have set of "Picture mode" and "ECO" will be stored as
the last memory automatically. The initial settings are "DYNAMIC" and "OFF".
SHOP MODE: In this mode, 30 minutes later after you made some adjustments of "Picture mode" and
"ECO" and no other operation on the LCD
TV, the initial setting will be recalled. (The initial settings
are "DYNAMIC" and "OFF".) The message of "INITIAL SETTING
appear on the screen for 3 seconds.
is no operation on the TV.
The background of OSD
INPUT MENU
INPUT
TV
1. TV
2. AV1-S
3. AV2
4. HDMI
5. PC
: SELECT : EXIT
1~5
MODE. Press ENTER button to
RECALLED FOR DEMO" will
VCR
GAME
DVD
BACK
SETUP MENU
Note:
Shop mode setting will be continued even after power off /on
●
●
At the first power on and just after plug and play channel set-up,
20
◄► buttons to select and press ENTER button for SHOP MODE or HOME MODE.
disappears.
by Remote control, LCD TV or AC power plug.
SHOP MODE menu will appear. Press POINT
Then the pop up menu
MENU OPERATION (PC mode)
SETUP
CHILD LOCK
ON
ECO
OFF
DYNAMIC AI
ON
ACTIVE CONTRAST
ON
PC ADJUST
SHOP MODE
SELECT
ADJUST
BACK EXIT
::
:
:
SETUP
CHILD LOCK
ON
ECO
OFF
DYNAMIC AI
ON
ACTIVE CONTRAST
ON
PC ADJUST
SHOP MODE
SELECT
ADJUST
BACK EXIT
::
:
:
SETUP
AUTO ADJUST
AUTO SHUT DOWN
ON
PC ADJUST
V - POSITION
CLOCK
PHASE
H - POSITION
SELECT
ADJUST
BACK EXIT
::
:
:
AUTO ADJUST
SETUP
Press MENU button and the main menu will appear.
1
Press POINT ◄► buttons to select "SETUP", and will display
SETUP menu.
Press POINT ▲▼ buttons or ENTER button to enter into
2
SETUP menu.
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to enter the item selected.
4
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait for 5~60 seconds to exit menu
operation.
Note:
● "PC ADJUST" is only active in PC mode.
PC ADJUST
This function is used to adjust the position of image displayed on screen.
It can be selected when the LCD TV could be received PC signal
and in PC mode.
to enter PC ADJUST menu.
Press POINT ◄► buttons or ENTER button
It can be select "AUTO ADJUST",
"H-POSITION", "V-POSITION", "PHASE", "CLOCK" or "AUTO
SHUT DOWN" to adjust.
AUTO ADJUST: Press POINT ◄► buttons, and the TV
automatically detects incoming signal, and adjust itself to optimize
its performance. If the image is not displayed properly, a manual
adjustment is required (Refer to following adjustments).
SETUP MENU
H-POSITION: The horizontal picture position will be moved to the
left side by pressing POINT ◄ button. And it will be moved to the
right side by pressing POINT ► button. (0~100)
V-POSITION: The vertical picture position will be moved down
side by pressing POINT ◄ button. And it will be moved up side by
pressing POINT ► button. (0~100)
PHASE: Eliminate disorder from the image. Press POINT ◄►
buttons to adjust PHASE. (0~100)
CLOCK: Eliminate flicker from the image. Press POINT ◄►
buttons to adjust CLOCK. (0~100)
AUTO SHUT DOWN: Press POINT ◄► buttons to set AUTO SHUT DOWN ON or OFF. When PC is
switched Off, ''NO SIGNAL'' appears for 30 seconds, TV will be automatically switched to Backlight off
mode. During Backlight Off Mode within 10 minutes, TV will be switched to On Mode if PC is switched
On. After Backlight Mode continues for 10 minutes, it will be switched to Standby Mode. During Standby
mode, TV will not be switched to On mode even if PC is switched On. During Backlight Off mode, POWER
indicator will become green.POWER ON/OFF button, NUMERIC (0-9) buttons and CHANNEL up/down
buttons are enabled to switch On TV.
21
DEALER MODE
TUNING LOCK
START MODE
OSD
RC
AC POWER MODE
OFF
OFF
DEALER MODE
VOLUME LOCK
OFF
RESET
MUSIC MODE SETUP
OFF
OFF
STAND
: SELECT
: ADJUST
: BACK
: EXIT
START VOLUME LEVEL
OFF
DEALER MODE
TO DISPLAY DEALER MODE:
Press INFO button on remote control while holding MENU button on Side control to display Dealer mode
menu.
The Dealer Mode has 9 different modes: VOLUME LOCK,
TUNING LOCK, START MODE, OSD, RC, AC POWER MODE,
START VOLUME LEVEL, MUSIC MODE SETUP and RESET.
Take the way of setting VOLUME LOCK for example:
Press POINT ◄► buttons to select a maximal volume.
1
Press INFO button on remote control while holding MENU
2
button on Side control to display Dealer mode menu.
VOLUME LOCK will be the default selection. (When you
3
adjust others, press POINT ▲▼ buttons to select the item
desired.)
Press POINT ◄► buttons to select "ON". (The maximal
4
volume is the set value by step 1.)
Press menu button to exit menu operation.
5
VOLUME LOCK
This function is used to limit the maximal volume.
TUNING LOCK
The way to prevent user from executing the Tuning function.
REMOTE CONTROL
INFO button
POINT ▲/▼/◄/►
buttons
SIDE CONTROL
MENU button
START MODE
The LCD TV will automatically enter to the setting mode while
being turned on. You can select OFF, TV(0-10), AV1, AV2(DVD),
HDMI or PC in START MODE. When it is set "OFF", it will keep
the mode before being turning off.
OSD
When it is set "OFF", Corresponding OSD cannot display on the
screen while operating.
RC
You can set "ON" or "OFF" in RC MODE. Use this feature to set
Remote Control Function including Power ON/OFF function.
● ON
- Set Remote Control to normal function.
● OFF
-
Set buttons on the Remote Control to prohibit to use include
Power button.
22
DEALER MODE MENU
AC POWER MODE
TUNING LOCK
START MODE
OSD
RC
AC POWER MODE
OFF
OFF
DEALER MODE
VOLUME LOCK
OFF
RESET
MUSIC MODE SETUP
OFF
OFF
STAND
: SELECT
: ADJUST
: BACK
: EXIT
START VOLUME LEVEL
OFF
: SELECT
: ADJUST
: BACK
: EXIT
MUSIC MODE POS2
MUSIC MODE POS3
MUSIC MODE POS4
MUSIC MODE POS5
255
255
255
255
MUSIC MODE POS1
1
MUSIC MODE SETUP
You can set "STAND", "LAST" or "ON" in AC POWER MODE.
Use this feature to set TV condition when AC cord plug-in.
● STAND
- When AC cord plug-in, LCD TV always STAND-BY.
● LAST
- When AC cord plug-in, the LCD TV will depend on last TV
condition. (ON or Stand-by)
● ON
- When AC cord plug-in, LCD TV always ON.
START VOLUME LEVEL
You can select "OFF" or "1-100" in START VOLUME LEVEL.
Use this feature to set volume bar level position every time
TV turned on.
Note:
Even Start Volume Level set to higher value then Volume Lock,
the Start Volume Level value automatically set to Volume Lock
value.
MUSIC MODE SETUP
MUSIC mode is used to block picture on channel program.
Use this feature to set Music Mode condition in set 5
Position
Channel.
Press and hold Menu button on Side Controls, and press
1
INFO button on remote control to display Dealer mode menu.
Press POINT ▲▼ buttons to select MUSIC MODE SETUP.
Press POINT ◄► buttons or ENTER button to enter into
2
MUSIC MODE SETUP menu.
Press POINT ▲▼ buttons to select the item desired.
3
Press POINT ◄► buttons to enter the item selected.
4
DEALER MODE
■ Press BACK button to return to the previous menu.
■ Press MENU button or wait to exit menu operation.
Note:
When the channel set with Music mode is selected, Eco mode
is ON.
RESET
This function returns all setting values to the factory
default
settings.
23
APPENDIX
CLEANING LCD TV
Be sure to disconnect the AC Power cord from AC outlet before cleaning the LCD TV.
Clean your LCD TV as follows:
● Gently wipe the screen and cabinet with dry soft cloth.
● The screen is likely to be damaged if it is not maintained properly. Do not use hard objects
like a hard cloth or paper. Do not use solvents or abrasions.
CAUTION :
Do not use benzene, thinner, or any volatile substances to clean the LCD TV. These
chemicals may damage the cabinet finish.
FUNCTION OF PRODUCT SAFETY FEATURE
For protecting product safety, protection feature provided inside LCD TV. Refer to the
following please.
AUTO POWER OFF
When a trouble is detected in the LCD TV, the protection function works and turn the LCD TV
OFF automatically. When the LCD TV is turned OFF with this function, the POWER indicator
becomes red and LCD TV's power cannot be turned ON.
Disconnect Power cord and contact sales dealer where you purchased the LCD TV or the
service center.
To turn on LCD TV again for checking:
1) Disconnect Power cord from AC outlet and plug it on again.
2) Refer to "TURNING ON/OFF LCD TV" to attempt to turn on LCD TV.
If LCD TV is not turned on, disconnect Power cord and contact to service center.
24
APPENDIX
TROUBLESHOOTING
Before calling your dealer or service center for assistance, check the matters below once again.
1.
Make sure you have connected LCD TV to your equipment as described in the section "CONNECTING
LCD TV" .
Check cable connection. Verify that all external equipment and power cords are properly connected.
2.
3. Verify that all power is switched on.
4. If LCD TV still does not produce an image, re-start the external equipment.
If the image still does not appear, unplug LCD TV from the external equipment and check the external
5.
equipment. The problem may be with your graphics controller rather than with LCD TV. (When you
reconnect LCD TV, remember to turn the external equipment and TV off before you power up LCD TV.
Power the equipment back on in order of : LCD TV and external equipment.)
6. If the problem still exists, check the following chart.
Problem:
NO
POWER
Remote
Control
does not
work
No image
No sound
There are
tiny black
points
and/or
bright
point on
the TV
Abnormal
colour of
WARNING :
High voltages are used to operate this LCD TV. Do not attempt to open the cabinet.
● Plug this LCD TV into the AC outlet.
●
Press ON/STAND-BY button on SIDE Control or on Remote Control to
● Check POWER Indicator. If this indicator flashes, LCD TV has any trouble.
● Check the batteries.
●
Make sure nothing is between the Remote Receiver and the
● Make sure you are not too far from LCD TV when using Remote Control.
Maximum operating range is 16.4' (5m).
● Is direct sunlight or strong artificial light shining on LCD TV's Infrared Remote
Receiver? Eliminate the light by closing curtains, pointing the light in a different
direction, etc.
● Check the connection between the external equipment and LCD TV.
● When turning LCD TV on, it takes a few seconds to display the image.
● Check the system that you select is corresponding with the external equipment or the video
equipment.
● Make sure the temperature is not out of the Operating Temperature (0°C ~ 40°C).
● Turn off power, then turn on again, re-start LCD TV.
● Check Audio cable connection from Audio input source.
● Adjust the Audio source.
● Press VOLUME (+) button.
● Press MUTE button.
● Dark or bright points of light (red, green, or blue) may appear on the screen. This is a
characteristic of the LCD panels, not a malfunction of the LCD TV.
● Adjust the value of colour.
● Select different colour system.
Try these Solutions
open this LCD TV.
Remote Control.
If the problem still persists after following all operating instructions, contact the sales dealer where you
purchased LCD TV or the service center. Give the model number and explain the difficulty. We will
advise you how to obtain service.
25
APPENDIX
TECHNICAL SPECIFICATIONS
Model LCD-24K50/(R)/(W)
Maximum Visible Range LCD-24K50/(R)/(W): 61cm (Screen Diagonal Size)
Picture Resolution
Voltage AC110-240V 50/60Hz
Power Consumption LCD-24K50/(R)/(W): 57W
Power Management VESA DPMS
Colour System PAL/PAL 60Hz/SECAM/NTSC/NTSC4.43
Sound System D/K, I, M, B/G
Channel Coverage - VHF: E2-E12, R1-R12, K1-K9, J1-J12, A2-A13
- UHF: 21-69, A14-A69, J13-J62
- CATV: S1-S41, X, Y, Z, Z+1, Z+2
Aerial input impedance 75Ω
Speaker Size Mains: 32.5mm x 87.0mm x 2pcs
Sound speciality Maximum Output Power is 3W+3W
Total Harmonic Distortion(THD)≤10%
Input and Output terminals
AV1 Input Video Input: Composite video Input (RCA Jack) x1
Audio Input: L/R Stereo Input (RCA Jack) x 1 set
AV2 Input Video Input: Component Y (combined with composite video input),
CB, CR Input (RCA Jack) x1 set
Audio: L/R Stereo Input (RCA Jack) x 1 set
HDMI Input HDMI Terminal 19 pin x1
PC Input Video Input: D-SUB 15 pin x1
Audio Input: Mini stereo jack x 1
Output Terminals Video Monitor Output: RCA jack x 1
Audio Monitor Output: L/R Stereo Output (RCA jack) x 1 set
Headphone Jack: Mini stereo jack x1
Dimensions
(Width x Height x Depth) LCD-24K50/(R)/(W): 608 x 424 x 190 mm (Including Stand)
1366(H) x 768(V)
Net Weight
(Including Stand ) LCD-24K50/(R)/(W): 5.5 KG
Operating Environment
Operating Temperature 0ºC~40ºC（32ºF~104ºF
Operating Humidity 20~80%
Storage Temperature -10ºC~50ºC（14ºF~122ºF
Storage Humidity 20~80%
）
26
）
APPENDIX
Frame
Frequency
ResolutionNO.
Audio Freq. Format :
HDMI (V.1.3 with Deep Color）
TM
EIA1920×1080i@60
EIA1920×1080p@60
EIA1920×1080i@50
EIA1920×1080p@50
EIA1280×720p@60
EIA1280×720p@50
EIA720x480p(w)@60
EIA720x576p(w)@50
33.750
67.500
28.125
56.250
45.000
37.500
31.500
31.250
60.00H
Z
60.00HZ
50.00HZ
50.00HZ
60.00HZ
50.00HZ
60.00HZ
50.00HZ
SIGNAL MODE COLUMN (Recommended)
This LCD TV can correspond to the signals below. After connecting with the computer, LCD TV can automatically recognize the signal from the connected PC( computer)/ HDMI.
PC SIGNAL MODE COLUMN (recommended)
Note:
● In case LCD TV can not display properly due to the connecting cable or the graphic hardware,
please make adjustments about phase, clock and so on.
● In principle, LCD TV can not display the signal mode which not described in the above column.
But sometimes it can display a signal very similar with one of the signal described.
● If you want to change the definition and colour of PC, please select one from the column.
It is not the trouble of LCD TV if interference appears on the picture while switching the signal mode.
●
●
It is different from CRT Monitor that it is no blink of the picture when the V-Freq. of the signal s 60Hz.
It is recommended to select 60Hz V-Freq. of your computer to display better pictures.
● The Dot Clock of the computer's signal must be less than 100 MHz.
● Specifications are subject to change without notice.
In case of the following things, some messages will display on the screen.
● When the input signal from PC is out of the display range, "OUT OF RANGE" will display.
When input signal is digital from DVD terminal, refer to the chart below.
When input signal is digital from HDMI terminal, refer to the chart below.
27
Part No: 1AA6P1P5952-- Z5JJ (UE7-C
)
SANYO Electric Co., Ltd.
Printed in Indonesia
Loading...
