L47A18-AK
TFT-LCD TELEVISION
OWNER`S MANUAL
MODELS: L52A18-AK
L52A18-A
L47A18-AK
L42A18-AK
L37A18-AK
L32A18-AK
Please READ this manual carefully before
operating your TV, and retain it for future
reference.
Congratulations on your purchase, and welcome to the family !
Dear Haier product owner:
Thank you for your confidence in Haier. You`ve selected one of the
best-built, best-backed products available today. We`ll do everything
in our power to keep you happy with your purchase for many years to
come.
As a member of the Haier family, you`re entitled to protection by
one of the most comprehensive warranties and outstanding service
networks in the industry.
thanks for investing in a Haier product.
""
""
CONTENTCONTENT
BEFORE OPERATING
Warning..............................................................................................................1
Important Safety Instructions..............................................................................2
Buttons and interface location........................................................................... 4
Remote controller...............................................................................................6
Remote controller key function...........................................................................7
External equipment connections........................................................................8
BASIC OPERATING
Switching on/off the TV set................................................................................13
Choose the Menu language............................................................................. 13
Choose the Input Source ................................................................................. 13
Searching Channel............................................................................................14
Watching TV Program........................................................................................17
Picture Control Functions................................................................................. .18
Sound Control Functions....................................................................................20
Timer Functions..................................................................................................22
Function Menu...................................................................................................23
Adjust Menu.......................................................................................................26
Lock Setup ........................................................................................................27
OTHERS
Others functions................................................................................................29
Stream media broadcast system.......................................................................30
Maintenance......................................................................................................43
Troubleshooting.................................................................................................44
Specifications ...................................................................................................45
Format..............................................................................................................46
Accessories
Remote controller
User's manual
Alkaline battery
(AAA) 2
Power cable
Warning
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
*To avoid electric hazards, it is strongly suggested that the back cover not be opened, as
there is no any accessory inside the casing.
*If necessary, please contact authorized after-sales services.
*A lighting flash mark in a triangle: A potentially hazardous situation, which, if not avoided,
could result in serious injury by high voltage.
*An exclamation mark in a triangle: Major part or accessory of which technical specifications
must be followed if it is to be replaced.
Warning:
To avoid fire or electric hazards, never place your television receiver in an area
with heavy moisture. Attention should be paid to avoid accidental scratches or
impacts onto the screen.
Caution:
Please read this manual carefully before using your television and keep this
manual in a good place for future reference.
To achieve the best performance of your television, read this User's Manual
carefully and properly store it for future reference.
Information of screen displays and figures in the User's Manual may vary due
to technical innovations.
Caution:
Unauthorized disassembly of this product is prohibited.
1
Important Safety Instructions
The product should be tightly fixed to avoid
drop damages and even fire.
Do not locate the product close to water
or oil, which may cause fire hazards.
Do not use damaged or worn electric plugs
and keep electric cord away from heat sources
to avoid electric shocks or fire hazards.
To avoid fire hazards, do not use this
product under direct sunlight or closely
to heat sources.
Unplug the power supply and antenna of
the product when there is a rainstorm,
especially
Thunderstorm.
Do not connect excessive sockets in parallel
or share the same socket by multiple plugs
to avoid fire hazards.
The product must be placed on a solid and
stable surface to avoid collapse.
Keep the product away from a transformer
or heat source to avoid fire hazards.
2
Unauthorized disassembly of the television
is prohibited to avoid electric shocks or fire
hazards. Contact
authorized after-sales
service if technical
service is needed.
Disconnect the product from power supply
and contact authorized after-sales service
if abnormal sound is heard in the product.
Important Safety Instructions
3
Buttons and interface location
- This is a simplified representation of front panel.
- Here shown may be somewhat different from your TV.
Front panel Control
P-
P+ V- V+
1. P-/+ :
2. V-/+ :
3.
4.
Channel number decrease/ increase
Volume decrease/increase,adjusting the menu
TV/AV button
MENU button
5. Remote Sensor
6.
Power and Indicator
TV/AV MENU
Buttons and functions
Card jack
Side
CARD
VIDEO
L
AUDIO
R
Printer jack
USB1 jack
USB2 jack
VIDEO(AV2)
L AUDIO
R AUDIO
Back cover
Warning
Please don`t open the small back
cover yourself in order to prevent
electric shock.
If you have any question, please
contact with the local authorized
service centre.
4
AC IN jack and Power
Buttons and interface location
Rear panel Control
ANT. IN
S-VIDEO IN
L AUDIO R VIDEO
AV OUT
AV1 IN
L AUDIO R
IN
Y Pb/Cb Pr/Cr
VGA IN
HDMI /DVI VIDEO
IN1 IN2
HDMI Input Connnect a signal to HDMI/DVI
VGA Input
DVD/DTV Input (Component )
Connect a component video/audiodevice to these jacks.
Av1
Connect audio/video out from an audio/video device to these jacks.
S-Video Input Connect S-Video out from a S-Video device to these jacks.
Antenna Input Connect cable or antenna signals to the TV, either directly or
through your cable box.
Earphone jack Earphone Audio output terminal
Video/Audio output terminal
Connect ordinary video/audio or other appliance audio input terminals.
Connect the monitor output connector from a PC to the jack
Input
5
Remote controller
Battery loading
1.Slide open the cover of the battery compartment on the back of the remote controller.
2.Load two 7# (AAA)alkaline batteries in the compartment. (plus and minus poles to
respective mark)
3.Replace the cover of the battery compartment.
1
2
Precautions
As strong light may interfere the
signals, change your position to
operate the remote controller if
the television cannot be turned
on or off as you expect.
Keep the remote controller away from
heat source or humid area to ensure
effective performance of the remote
controller.
3
Make sure that two AA alkaline batteries
are loaded. The batteries must be of the
same type. The batteries must be
located properly. The batteries are not
rechargeable.
Make sure that there is no obstacle
between the remote controller and
television set.
6
Remote controller key function
Information display
Display of current channel
signals, program and systems
Picture still
Switches the sound on or off.
select S-Video.
VOLUME UP/DOWN
Increases/decreases
the sound level.
CHANNEL UP/DOWN
Selects available channels
found with Auto search.
Picture mode option
Standard, Soft,
Bright, Personal
CHANNEL select
PIP mode buttons
Swap: main picture and
sub picture exchange
MUTE
S-Video mode
TV/VIDEO
OK button
(no available)
PIP: PIP select
Shuttle button
Sleep button
POWER
Turns your TV or any other
programmed equipment on
or off, depending on mode.
DISPLAY
MUTE
STILL
POWER
I/II
PIC.SIZE
Nicam select button
Picture SIZE button
picture scale
DVD mode
S-VIDEO
DVD/DTV
TV/AV
PC/DVI
Select DVD mode
PC/DVI mode
OK
Q.VIEW
Select PC/DVI mode.
Q.VIEW
Return to the last channel
viewed.
MENU
VOL-
CH+
MENU
VOL+
Brings up the main menu
CH-
S
5
H.LOCK
SM
3
6
ZOOM/MOVE
CH.EDIT
Timer SKIP
PSM
1 2
4
7 8 9
-/-- 0
PIP SWAP SCAN
SHUTTLE
SLEEP
to the screen.
Sound mode option
, Personal,
Theater
Standard, Music
NUMBER buttons
Zoom/Move
Program edit
Scan
scan program
Timer skip button
USB
ZOOM
RETURN
HELPENTER
H.clock button
USB system buttons
7
External Equipment Connections
- Antenna or Cable Service without a Cable Box Connections
- For optimum picture quality, adjust antenna direction if needed.
outdoor
antenna
(not supply)
Antenna input
75 standard
coaxial type
ANT IN
300 twin-lead cable
Antenna adapter
(not supply)
75 coaxial cable
Plug
(additional purchase)
Note
* It is recommended that you'd better use 75
disturbance caused by airwave.
* Don't bind antenna cable and electric wire together.
To improve picture quality in a poor signal area, purchase
and install a signal amplifier.
If the antenna needs to be split for two Tv`s, install a 2-
WaySignal Splitter in the connections.
If the antenna is not installed properly, contact your dealer
for assistance.
coaxial cable to remove the
8
External Equipment Connections
NOTE: All cables shown are not included with the TV.
Choose Your Connection
There are several ways to connect your television, depending on the components you
want to connect and the quality of the signal you want to achieve. The following are
examples of some ways to connect your TV.
Choose the connection which is best for you.
VCR Connection
- To avoid picture noise (interference), leave an adequate distance between the VCR and TV.
Connection Option 1
Set VCR output switch to channel 3 or 4 and
then tune the TV to the same channel number.
Connection Option 2
1. Connect the audio and video cables from the
VCR's output jacks to the TV input jacks, as
shown in the figure.
When connecting the TV to VCR, match the
jack colors (Video = yellow, Audio Left = white,
and Audio Right = red).
If you connect an S-VIDEO output from VCR to
the S-VIDEO input, the picture quality is
improved; compared to connecting a regular
VCR to the Video input.
2. Insert a video tape into the VCR and press
PLAY on the VCR. (Refer to the VCR owner`s
manual.)
3. Select the input source with using the
INPUT button on the remote control, and
then press CH+/- button to select the source,
press the VOL+ button to confirm.
L AUDIO R
AV OUT
L AUDIO R
VIDEO
S-VIDEO IN
AV IN
ANT. IN
9
External Equipment Connections
DVD Setup
How to connect
1. Connect the DVD video outputs (Y, Pb/Cb,
Pr/Cr) to the COMPONENT (Y, Pb/Cb, Pr/Cr)
input jacks on the TV and connect the DVD
audio outputs to the AUDIO jacks on the TV,
as shown in the figure.
2. If your DVD only has an S-Video output jack,
connect this to the S-VIDEO input on the TV
and Connect the DVD audio outputs to the AV IN
jacks on the TV, as shown in the figure.
NOTE: If your DVD player does not have
component video output, use S-Video.
How to use
1. Turn on the DVD player, insert a DVD.
2. Use the S-Video button on the remote
control to select S-VIDEO or YPbPr/YCbCr
mode.
3. Press Play button on external equipment
for program play.
4. Refer to the DVD player's manual for
operating instructions.
Y PbPr CbCr
L AUDIO R
IN
or
DVD
AV1 IN
AV OUT
L AUDIO R VIDEO
S-VIDEO IN
HDMI or DVI Setup
-To watch digitally broadcast programs,
purchase and connect a digital set-top
box.
How to connect
Use the TV`s COMPONENT (Y, Pb/Cb,
IN1 IN2
HDMI/DVI VIDEO
Pr/Cr) INPUT jacks, VGA or HDMI port for
video connections, depending on your
set-top box connections available.
Then, make the corresponding audio
connections.
How to use
1. Turn on the digital set-top box.
(Refer to the owner`s manual for the digital set-top box.)
2. Use TV/AV on the remote control to select VGA or HDMI
(Y, Pb/Cb, Pr/Cr) mode.
3. Press Play button on external equipment for program play.
10
VGA IN
Y PbCb CbCr
L AUDIO R
AV OUT
L AUDIO R VIDEO
AV IN
External Equipment Connections
PC Setup
How to connect
1. Use the TV`s VGA IN port for video connections.
2. Then, make the corresponding audio
connection. If using a sound card, adjust the
PC sound as required.
How to use
1. Turn on the PC and the TV.
2. Turn on the display by pressing the POWER
button on the TV's remote control.
IN1 IN2
HDMI/DVI VIDEO
VGA IN
Y PbCb PrCr
L AUDIO R
IN
3. Use PC/DVI on the remote control to select
VGA source.
4. Check the image on your TV. There may be
noise associated with the resolution, vertical
pattern, contrast or brightness in PC mode.
If noise is present, change the PC mode to
another resolution, change the refresh rate to
another rate or adjust the brightness and contrast
on the menu until the picture is clear. If the refresh
rate of the PC graphic card can not be changed,
change the PC graphic card or consult the manufacturer
of the PC graphic card.
NOTES:
1 Avoid keeping a fixed image on the TV's screen for a long period of Time. The fixed image
may become permanently imprinted on the screen.
2 The synchronization input form for Horizontal and Vertical frequencies is separate.
3 To obtain the best picture, do not play the USB, YPbPr, HDMI or VGA source at the same
time.
Monitor Out Setup
The TV has a special signal output capability which allows
you to hook up a second TV or monitor.
Connect the second TV or monitor to the TV`s AV OUT.
See the Operating Manual of the second TV or monitor for
further details regarding that device`s input settings.
L AUDIO R
AV OUT
L AUDIO R VIDEO
S-VIDEO IN
AV IN
Notes:
YPbPr, VGA, HDMI, S-Video input sources cannot be used
for Monitor out.
When connecting with external audio equipments, such
as amplifers or speakers, please turn the TV speakers off.
11
External Equipment Connections
Connecting Headphones
You can connect a set of headphones to your set if you wish to watch a
TV programme without disturbing the other people in the room.
Plug a set of headphones into the 3.5mm
mini-jack socket on the rear panel of the set.
ANT IN
Note
Prolonged use of headphones at a high volume
may damage your hearing.
You will not receive sound from the speakers
when you connect headphones to the system.
Power source
Wider Hole
and Blade
Polarized AC Cord Plug
12
AC Outlet
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for
operation on AC. Insert the AC cord plug into
a standard polarized AC outlet.
NOTES:
Never connect the AC line cord plug to other
than the specified voltage. Use the attached power
cord only.
If the polarized AC cord does not fit into a nonpolarized AC outlet, do not attempt to file or cut
the blade. It is the user`s responsibility to have
an electrician replace the obsolete outlet.
If you cause a static discharge when touching
the unit and the unit fails to function, simply
unplug the unit from the AC outlet and plug it
back in. The unit should return to normal operation.
Polarized AC Cord Plug.
Loading...
