6 2
230
230
BTU/h
11260
７
C
Dimension
A(inch)
B(inch)
C(inch)
B
Model
HWS12VHA
1
"
22
16
11
"
25
32
3
15
"
4
A
HWS18VHA
3
27
4
5
33
32
2
9
17
32
HWS24VHA
"
"
"
27
33
17
3
"
4
5
"
32
2
9
"
32
Exploded View
Model:HWS12VHA
:1)View of electrical control:
Exploded View
Exploded View
List of electrical control:
No Parts Code Name Q'ty Remark
1 0010544573 scale 1
2 5002013 screw 4
3 0010202820 electric box 1
4 0010200885 top cushion for electric box 1
5 3600007A fan motor capacitor 1 ▲
6 0010402029 thermostat 1 ▲
7 3600032 compressor capacitor 1 ▲
8 0010100001 capacitor clip 1
9 0010402192 mode selection switch 1
10 5002098 screw 4
Exploded View
2)View of frame work
Exploded View
List of frame work
No Parts Code Name Q'ty Remark
1 0010200862 wind entering bar 1
2 0010200852 knob 2
3 0010544573 scale 1
4 0010200866 guiding pole 1
5 0010200853 bottom support 1
6 1431146A vertical flap 3
7 1431078 top support 1
8 0010200882 cushion for front cover board 1
9 1301098 front cover board 1
10 1431152 Vent 1
11 0010202170 centrifugal fan 1 ▲
12 1101031A front partition panel 1
13 0010402032 motor 1 ▲
14 1301106 short plank 1
15 1301105 long plank 1
16 1301097 water keeping off block 1
17 1742274 left cushion for rear cover 1
18 1301099 rear cover 1
19 5002013 screw 4
20 1742273 back cushion for rear cover 1
21 2331021 axial fan 1 ▲
22 1101032A rear partition panel 1
23 1301104 plank for motor 1
24 0010200860 connecting rod 1
25 0010200858 horizontal blade 8
26 0010200861 panel 1
Exploded View
3)View of system
Exploded View
List of system
No. Parts Code Name Q'ty Remark
1 0010600240 bottom screw 3
2 0010101242 chassis 1
3 0010802746 water meeting tray 1
4 0010704438 super-cooling pipe group 1 ▲
5 0400189 evaporator assembly 1
6 2111254A liquid discharge pipe of evaporator 1
7 0010704492 suction pipe group 1
8 0010100992 evaporator partition panel 1
9 1301101 full wind panel 1
10 0010802745 scroll case 1 ▲
11 14311188 wire holder cover of compressor 1
12 0400188 condensor assembly 1
13 0010704491 discharge pipe 1
14 5102050 flare nut 3
15 0010704319 compressor 1
16 17561305 shock absorption cushion for compressor 3
17 0010402031 heater 1 ▲
Exploded View
4)View of casing
List of casing
No. Parts Code Name Q'ty Remark
1 1301094 front panel 1
2 0010100258 casing 1
3 0010100257 top fixing bar 1
4 5002109 bolt 3
5 1301095 back board 1
6 1734265 cushion for casing 1
7 1734264 cushion for casing 1
8 0010200014 cushion for casing 1
9 1734267 cushion for casing 2
10 1301841 bottom guide 2
Exploded View
Model:HWS18VHA
1)
View and list of electrical control:
No Parts Code Name Q'ty Remark
1 0010101118 scale 1
2 0010802160 electric box 1
3 0010402192 mode selection switch 1
4 0010402236 thermostat 1 ▲
5 0010100001 capacitor clip 1
6 5002013 screw 5
7 3600131 compressor capacitor 1 ▲
8 3600134 fan motor capacitor 1 ▲
9 5002114 screw 2
Exploded View
2) View of frame work
Exploded View
List of frame work
No Parts Code Name Q'ty Remark
1 0010202401 centrifugal fan 1 ▲
2 0010100190 evaporator partition panel 1
3 0010802747 scroll case 1
4 1231253 wind door 1
5 0010100192 front partition panel 1
6 1301697 motor bracket one 1
7 0010200892 cushion for front cover board 1
8 0010100188 front cover board 1
9 5002013 screw 4
10 3000270 motor 1 ▲
11 0010100196 top board 1
12 1301698 motor bracket two 1
13 5002013 screw 4
14 2331087 axial fan 1 ▲
15 0010100199 rear partition panel 1
16 0010100189 rear cover 1
17 5002013 screw 4
18 5701100 thermo induction pipe clip 2
19 13011266 stop piece 1
20 0010200824 connecting rod 1
21 0010200823 horizontal blade 12
22 0010200821 panel 1
23 0010200822 wind entering bar 1
24 1303965 draught pole 1
25 1301673 draught pole 2
26 0010200794 cushion 1
27 1436876 top board of electric box 1
28 0010800240 electric box group 1
29 5002114 bolt 2
30 0010200852 knob 2
31 0010200826 draught pole of vertical blade 1
32 1231320 vertical blade 3
33 1231249 fixing box 1
34 1301672 fixation axis 1
35 0010100229 draught patch 1
36 0010402031 heater 1 ▲
Exploded View
3) View of system
List of system
Exploded View
No Parts Code Name Q'ty Remark
1 0010703285 evaporator assembly 1
2 0010802748 water meeting tray 1 ▲
3 0010703230 evaporator 3
4 001B0700562 suction pipe 1
5 0010703280 super-cooling pipe group 1 ▲
6 0010703286 condensor assembly 1
7 0010703234 liquid discharge pipe of evaporator 1
8 0010703281 suction pipe group 1
9 0010202519 wire holder cover of compressor 1
10 0010703231 vent-pipe one 1
11 0010703253 compressor 1 ▲
12 5102050 flange nut 3
13 0010202523 cushion robber of compressor 1
14 0010100247 chassis 1
15 5001301 bottom screw 3
Exploded View
4) View of casing
List of casing
No Parts Code Name Q'ty Remark
1 1301919 right bottom guide 1
2 1301841 left bottom guide 1
3 0010100186 front panel 1
4 17421079 cushion for casing 2
5 17421078 cushion for casing 1
6 0010100248 casing 1
7 0010100249 top guide 2
8 5002114 bolt 3
9 0010100187 back board 1
Exploded View
Model:HWS24VHA
1)View of electrical control
List of electrical control
No Parts Code Name Q'ty Remark
1 0010101118 scale 1
2 13011283 electric box 1
3 0010402192 mode selection switch 1
4 0010402236 thermostat 1 ▲
5 0010100001 capacitor clip 1
6 5002013 screw 5
7 3600030 compressor capacitor 1 ▲
8 3600134 fan motor capacitor 1 ▲
9 5002114 screw 2
Exploded View
2)View of frame work
Exploded View
List of frame work
No Parts Code Name Q'ty Remark
1 0010202401 centrifugal fan 1 ▲
2 0010100190 evaporator partition panel 1
3 0010802747 scroll case 1
4 1231253 wind door 1
5 0010100192 front partition panel 1
6 1301697 motor bracket one 1
7 0010200892 cushion for front cover board 1
8 0010100188 front cover board 1
9 5002013 screw 4
10 0010401044 motor 1 ▲
11 0010100196 top board 1
12 1301698 motor bracket two 1
13 5002013 screw 4
14 2331087 axial fan 1 ▲
15 0010100199 rear partition panel 1
16 0010100189 rear cover 1
17 5002013 screw 4
18 5701100 thermo induction pipe clip 2
19 13011266 stop piece 1
20 0010200824 connecting rod 1
21 0010200823 horizontal blade 12
22 0010200821 panel 1
23 0010200822 wind entering bar 1
24 1303965 draught pole 1
25 1301673 draught pole 2
26 0010200794 cushion 1
27 1436876 top board of electric box 1
28 0010802200 electric box group 1
29 5002114 bolt 2
30 0010200852 knob 2
31 0010200826 draught pole of vertical blade 1
32 1231320 vertical blade 3
33 1231249 fixing box 1
34 1301672 fixation axis 1
35 0010100229 draught patch 1
36 0010402034 heater 1 ▲
Exploded View
3)View of system
Exploded View
List of system
No Parts Code Name Q'ty Remark
1 0010703276 evaporator assembly 1
2 0010802748 water meeting tray 1 ▲
3 0010703230 evaporator 3
4 0010703316 suction pipe 1
5 0010703328 super-cooling pipe group 1 ▲
6 0010703278 condensor assembly 1
7 0010703234 liquid discharge pipe of
1
evaporator
8 0010703279 suction pipe group 1
9 0010202830 wire holder cover of compressor 1
10 0010703231 vent-pipe one 1
11 0010704327 compressor 1 ▲
12 0010600254 flange nut 3
13 0010202829 cushion robber of compressor 1
14 0010101161 chassis 1
15 5002050 bottom screw 3
Exploded View
5) View of Casing
List of Casing
No Parts Code Name Q'ty Remark
1 1301919 right bottom guide 1
2 1301841 left bottom guide 1
3 0010100186 front panel 1
4 17421079 cushion for casing 2
5 17421078 cushion for casing 1
6 0010100248 casing 1
7 0010100249 top guide 2
8 5002114 bolt 3
9 0010100187 back board 1
