Haier HF-130, HF-250, HF-190 User Manual
HF-130
HF-190
HF-250
Freezer
Owner’s Manual
IMPORTANT: Congratulations for choosing a high quality freezer by Haier
Thermocool. Please read this owner’s manual carefully before using your
new freezer. Now you will cool ,with Haier Thermocool.
English
Content Page
1. Environmental Protection and Proper Disposal..............2
2. Location...........................................................................2
3. Installation....................................................................2-3
4. Rating Rate.....................................................................3
5. Electric Connection..........................................................3
6. Operation Instructions..................................................3-4
7. Freezer Compartment.....................................................4
8. Ice &Ice Cream Making...................................................5
9. Preparing for Vacation.....................................................5
10. Cleaning &Maintenance..................................................5
11. Defrosting......................................................................5-6
12. Problem Diagnosis..........................................................6
13. Troubleshooting............................................................6-7
14. During a Power Interruption............................................7
15. Making A Service Call.....................................................7
16. Installation In Kitchen......................................................7
17. Warranty...........................................................................7
18. IIIustration of Parts..........................................................7
Please read the these instructions carefully before use. Under-
line the important instruction. Keep the user’s Manual in a safe
place for later reference. Remember to hand it over to the owner
if you ever sell the appliance.
What you have bought is a safe freezer. With appropriate use
and maintenance, it will be in service for years. The last page of
this user’s manual sets out specifications of this appliance and
the performance data indicated in the rating plate are test results
obtained at an ambient temperature range of 18-43℃.
Important!
It is intended strictly for household use. If using it for industrial or
commercial purpose, be sure to observe the relevant norms and
regulations.
A leakage test has been conducted in accordance with relevant
safety standard.
To avoid the risk of child entrapment. Please make sure your old
freezer is inoperative and sale by removing the latches and bolt
locks before disposal.
User’s Manual
important!
It must be noticed that freezer system contains freezer which
require specialized waste disposal. Contact your local waste dis-
posal center for proper disposal of an old appliance and contact
your local authority or your dealer if you have any question. Please
ensure that the pipe work of your freezer does not get damaged
prior to being picked up by the relevant waste disposal center,
and contribute to environmental awareness by insisting on an
appropriate anti-pollution method of disposal. Please see the
rating plate for the type of freezer and insulation used.
The plug should be accessible after the appliance is positioned.
If the power cord is damaged, it must be replaced with a new
power cord from the manufacturer or an authorized service agent.
Caution:
The appliance should be installed in a well ventilated place. The
shipment package should be removed.
Caution:
Don’t use a sharp or pointed item to defrost.
Caution:
Don’t use electrical appliance inside the food storage compart-
ments of the appliance, other than models recommended by the
manufacturer.
Caution:
This user’s Manual is applicable to a variety of models and there
may be slight change in certain aspects from models to models.
English
!
1.Environmental Protection and Proper
Disposal.
Package materials
The appliance is packaged in a way to prevent damages during
transportation. Recyclable materials are used.
The packing box is made of corrugated board/cardboard (mainly
from recyclable paper).
● Polystyrene parts(CFC-free foamed polystyrene)
● Linings and polystyrene bags
● Polystyrene straps
All these valuable materials may be taken to a waste collecting
center and used again after adequate recycling.
All waste materials should be disposed properly.
2.Location
Make sure the freezer is kept upright during handling. If an incli-
nation is required, it should exceed 45 degrees. Otherwise the
appliance may get damaged resulting not only in compromised
refrigeration performance.
To avoid product damage or personal injury, the freezer should
be unpacked by two persons after it is located in a previously
selected position.
Before installation, make sure the freezer has no visible exterior
damage.
When handling the freezer, do not lift it by holding the worktop,
to prevent any damage to the freezer.
Do not start up a freezer that is damaged.
Check the freezer carefully for:
●Damaged package due to inappropriate handling during trans
portation
● Damage in the exterior
● Damage in power cord/plug
Any doubt, please contact Customer Service for a thorough
checkup of the appliance.
Take necessary measure to prevent leakage of refrigerant at the
start up of freezer that may result in environmental pollution.
User’s Manual
3.Installation
a) Remove all package materials.
b) Remove items in the freezer.
c) Make sure to remove film and tape on the cabinet and the
door.
d) Remove polystyrene chips(if any) around the freezer.
e) Take out accessories and literature in the freezer.
f) Clean the inside of the freezer with lukewarm water and
vinegar and then dry it with a soft cloth.
g) Use the spanners supplied to adjust the leveling leg to
ensure the freezer is stable.
Do not use detergents, sharp or pointed instruction or soda-
based cleansers to clean the freezer.
●Before installation, make sure the refrigeration system is free
of any damage.
●The freezer should be used for its intended purpose only.
●The freezer should be poisoned on the solid and even floor to
ensure refrigerant circulation and refrigerating performance.
●If possible, position the freezer in a cool and dry well venti
lated room.
●Do not expose the freezer to direct sunshine and make sure
the ambient temperature is not extremely high.
●Keep the freezer from a heat source, such as heating system,
oven or cookers. Otherwise the compressor will operate more
frequently resulting in extra power consumption.
If the freezer will be placed near a heat source, it is recommended
to install a thermal barrier between the freezer and the heat re-
source (asbestos is prohibited) or maintain adequate space be-
tween the freezer and the heat source as follows:
Cooker or electric stove 3 cm
Radiator or oven 30 cm
Another freezer 2 cm
Do not place any radiating apparatus, such as microwave oven
or roaster, on top of the freezer.
Make sure the air vent is not obstructed.
Never unplug the freezer by pulling on the power cord. Always
grip the plug firmly and pull it straight out from the outlet.
