Haier HDW100WCT, HDW100SCT User Manual
Dishwasher
HDW100WCT
HDW100SCT
Instructions for Use
0120505591
Index
Safety Is Very Important
Close-up View (Control Panel)
Close-up View (Interior)
Detergent and Rinse Aid
Loading the Dishwasher
Turning on the Appliance
Energy Saving Tips
How to Keep Your Dishwasher in Shape
Wash Cycle Table
Cleaning and Special Maintenance
Troubleshooting
Installation
Technical data
Diagram
2
3
3
4
5
6
7
7
8
9
9-12
13-14
15
15
1
Safety Is Very Important
Carefully read the instructions contained in t his manual, as it provides inf ormation that is es sential to safe
and proper installation, use and maintenance of this appliance.
Carefully remove and dispose of the packing material.
Check to make sure that the appliance is not damaged. If in doubt, contact the retailer it was purchased
from.
This dishwasher is designed for washing household dishes and cooking utensils.
Do not install this appliance outdoors, even if a roof covers the area.
Do not lean or sit on the door when it is open, as it may over turn the dishwasher.
Do not touch the heating element during or after a wash cycle.
If the appliance malfunc tions, turn off water supply to the appliance and disconnect the plug from the wall
socket and refer to t he sec tion ent itled, " T rouble shoo ting". If you cann ot solv e the problem, cont act a n
authorised service centre/agent.
Only selected service centres/agents are authorised to make repairs.
If the supply cord is damage d ,it must be replaced by the manufacture, a servic e agent of similar qualified
persons in order to avoid a hazard.
The ap plia nce is n ot i nstr uc t for u se o f y oung chi ldr en of inf ir m pe rsons wit hou t su pe rvis ion. Yo ung
children should be supervised to ensure that they do not play with the appliance.
Dishwasher detergents are strongly alkaline. They can be extremely danger ous if swallowed. Avoid contact with the skin and eyes and keep children a way from the dishwas her when the door is open. Check
that the detergent receptacle is empty after completion of the wash cycle.
Do not use extension cords or multiple sockets.
The plug must be accessible after installation.
During installation the power cord must not be bent or flattened excessively.
If the appliance is not operating properly,disconnect the appliance from the power supply.
Warning
Dishwas her det erge nts c an be e xtr emely dang erou s if s wal lowed . Av oid c onta ct with sk in,
eyes and keep children away from the dishwasher when the door is open. Check that the
detergent receptacle is empty after completion of the wash cycle.
To maintain the EFFICIENCY and SAFETY of this appliance:
Only call a authorised service centre.
Always use original Spare Parts.
Children and infirm must be supervised at all times during use of the dishwasher by an adult.
2
Close-up View (Control Panel)
"POWER" Button
A
"END" Light
B
Close-up View (Interior)
Handle For Opening Door
C
Knob For Selecting Cycle
D
Upper Rack
A
Rack Height Adjustor
B
Top Spray Arm
C
Lower Rack
D
3
Bottom Spra y A rm
E
Washing Filter
F
Detergent and Rinse Aid Dispenser
G
Detergent and Rinse Aid...
Detergent
Detergent specifically intended for use with dishwas hers must be used . T he dispenser must be refilled before the start of each wash cycle f ollowing the instructions provided in the "W ash Cycle Table. " The det ergent dispenser is located on the inside panel the door.
Loading the detergent
To open th e "A" c ove r on the dispe nser , pres s the "B" bu tton . The
detergent for the wash cycle should be poured into the "C"
compartment.The detergent for the pre-wash cycle should be poured
into the “D” compartment.
After the detergent has been placed in the dispenser , clos e the cov er
and press down until it clicks in place.
Notice:
To facilitate closing the cover, remove any excess detergent on the edges of the dispenser.
Dishwasher detergents are stron ly a lkali ne. They can be ex t remely d anger ous if swal lowed.
Avoid contact with the s kin a nd eye s and keep childr en aw ay fro m the dis hwas her w hen t he
door is open. Check that the detergent receptable is em pty after completion of the wash cy cle.
B
CA
D
Rinse Aid
This product makes dishes sparkle and helps them to dry without spotting. The dispenser is located on the
inside panel of the door and should be filled after every 80 wash cycle (or when the rinse aid indicator light
comes on for models with this feature).
Loading the Rinse Aid
To open the dispenser, turn the "E" cap in an anti-clockwise direction
and then pour in the rinse aid, making sure not t o ov er fill. Th e am ount
of rinse aid used for each cycle, turn the dosage adjust er "F" , beneath
the cap, with a screwdriver. There are 6 different settings; the normal
dosage setting is 3.
Important
Proper dosage of the rinse aid improves drying.
If drops of water remain on the dishes or spotting occurs, the dosage adjuster should be turned to a higher
setting.
If the dishes have white streaks, turn the dosage adjuster to a lower setting.
E
F
4
