OPERATING INSTRUCTIONS OF

REFRIGERATOR

MODEL: HBF130

HBF130S

CONTENT

Name of Each Part

Please read this operation manual
carefully before operation.
Keep it properly for future reference.

Adjusting

For Domestic Use Only

Setting up

Operation Instruction

Left/Right - opened door

Reparing

Main T echnical Data

The manufacturer keeps on developing various types

*

of refrigerators, so he has the right to modify designs,
products and technical data without further notice.

○○○○○○○○○

○○○○○○○○○○○○○○

○○○○○○○○○○○○○

○○○○○○○

○○○○○○

○○○○○○○○○○○○○

○○○○○○○○

4-6

1

2

3

7

8

9

Name of each part

(1)

(2)
(3)

(4)

(5)

(6)

(7)

(8)

(1)=Evaporator door
(2)=Ice-tray
(3)=Evaporator
(4)=Drip tray

(5)=Shelf
(6)=Vegetable box
(7)=Bottle rack
(8) Knob of thermostat

.1.

Adjusting

Adjusting

If the floor is uneven please adjust the adjustable screws at the
front of the refrigerator by using the spanner to level the
refrigerator. (the spanner is included in the bag).

!

WARNING:
If the supply cord is damaged, it must be replaced by the manufacturer, or
authorised service agent or similar qualified person in order to avoid a hazard.
The plug should be accessible after the appliance is positioned.
WARNING:

!

The appliance is not intended for use by young children or infirm persons with­out supervision.

!

WARNING:
Young children should be supervised to ensure that they do not play with the
appliance.

.2.

Setting up

>10cm

>10cm

>2cm

Setting up

The appliance can’t be placed with its
rear panel directly against the wall.For
good air circulation, the vent grille at the
back of the worktop must not be blocked.
It should be placed on flat and firm
ground lest it gives off higher noise than
usual.

Poorly ventilated rooms are unsuitable.
A void positioning the appliance in direct
sunlight or exposing to similar sources
of heat.

Never store anything dangerous in the
appliance,such
exposives, strong acid and alkali.etc.

The appliance is not intended for use by
young children or infirm persons with­out supervision.

as

combustibles,

Young children should be supervised to
ensure that they do not play with the
appliance.

The power supply for appliance is
240V~,50Hz single phase.

It is not recommended to use extention
cords.

Connect the appliance with a properly
earthed three-wire plug and socket.

.3.
