PREPARE
WINDOW FOR
INSTALLATION
Inspect window track, sash, and sill
for its ability to support the weight of
air conditioner .
Measure width between window
moldings to ensure Inst ant Mount
will fit window frame. Instant Mount
models are designed for windows
wide (the detail See Page 18).
Instant Mount kit supplied with unit
is designed for mounting in most
double-hung windows without
storm windows. For installation in
window frame with storm window ,
modify sill by adding wood strips
(not included) to inner and outer sills.
This raises unit and eliminates
interference of storm window frame.
2
Mobile home window installation
Add wood strip (at least 1 1/2î wide)
along entire width of window sill.
Thickness of wood strip should match
height of front lip on window frame.
Fasten wood strip to sill with a
minimum of three countersunk wood
screws (not supplied with kit). This
provides a smooth surface for
mounting air conditioner.
Storm window installation
If storm window frame does not allow
adequate clearance below sill (1/2î
required), remove storm window
frame or create clearance by adding
a wood strip (at least 1 1/2î wide)
along entire width of sill. Fasten
wood strip to sill with at least three
countersunk wood screws (not
supplied with kit). This provides a
smooth surface for mounting air
conditioner .
3
INSTALL UNIT IN
WINDOW
Place unit in window. Lower sash
until it rests behind front flange of top
rail. Bottom rail must rest behind
window sill.
INSTALL
BASEPAN ANGLE
Back front attachment screw out
several turns and slip Basepan Angle
over screw head. Snug screw with
angle resting on window ledge.
Install T wo 31/32" screws through
angle into window ledge. Repeat for
opposite side.
4
SILL
Wood
Strip
1/2"
Minimum
O
U
T
D
O
O
R
Storm Window
Frame
1 1/2"
Minimum
I
N
D
O
O
R
1 1/2"
Minimum
Wood
Strip
I
N
D
O
O
R
O
U
T
D
O
O
R
Window
Frame
Must be a minimum
of 1/2" to clear
bottom rail on unit
Curtain assembly cut
away for clarity.
31/32"
screws
Basepan
angle
English
Top rail
Bottom rail
About
5∞
20
Models ESA3083, ESA3103, ESA3123
6
English
21
ASSEMBLE
CURTAINS/TOP
RAIL
2
PREPARE
WINDOW FOR
INSTALLATION
Inspectwindow track, sash,and sill
for it s ability to support the weight of
air conditioner.
Measure width between window
moldings to ensureInstant Mount
will fit window frame. Instant Mount
models are designed for windows
wide (the detail see page 18)
Instant Mount kit supplied with unit
is designedfor mounting in most
double-hung windows without
storm windows. For installation in
window frame with stormwindow ,
modify sill by adding wood strip
s
to
3
Mobile home window installation
Add wood strip (at least 1 1/2" wide)
along entire width of window sill.
Thicknessof wood strip should match
height of front lip on window frame.
Fastenwood strip to sill with a
minimum of three countersunkwood
screws(not supplied with kit). This
provides a smooth surface for
mountingair conditioner.
Storm window installation
If stormwindow frame does not allow
adequateclearancebelow sill (1/2"
required), remove storm window
frame or create clearance by adding a
wood strip (at least 1 1/2" wide) along
entire width of sill. Fastenwood strip
to sill with at least three countersunk
wood screws(not supplied with kit).
Thisprovides a smooth surface for
mountingair conditioner.
SI LL
W ood
Str i p
1/2"
Min i mum
O
U
T
D
O
O
R
St orm Wi ndo w
Fram e
1 1/2"
Min imum
I
N
D
O
O
R
1 1/ 2"
Minimum
W ood
St rip
I
N
D
O
O
R
O
U
T
D
O
O
R
Window
Frame
Mus t be a mini mum
of 1/2" to cl ear
botto m rail on unit
(not included)
Slide lef t-hand curtain assembly
into left end of top and bottom
rails. Repeatfor right-hand curtain
assembly. Fastencurtain retainer
strips to sidesof outer casewith
six13/32" screws.
Install top rail with three 13/32"screws.
stormwindow frame.interferenceof
Thisraises unit and eliminates
inner and outer sills.
English
22
4
INSTALL OUTER
CASE IN WINDOW
Place outer case in window. Lower
sash until it rests behind front flange
of top rail. Bottom rail must rest
behind window sill.
Curtain assembly cut
away for clarity.
Use two casement to window securance screws(1")
to fix the case to windows sash.
INSTALL BASEPAN ANGLE
5
Install Two 31/32" screws
through angle into window ledge.
Repeat for opposite side.
Top rail
Bottom rail
About
5∞
Expand both curtains to contact the
window frame. Install two 31/32"
screws. One in each upper right and
left corner of the curtains.
NOTE: To make screws easier to
drive, drill a pilot hole into sash
through clearance hole in curtains.
Install three 31/32" top mounting rail
screws.
English
6
INSTALL
DRAIN ELBOW
drain tube(drain elbow)
drain tube(drain elbow)
.
12
English
13
English
(For ESA3063, the function is not
available)
14
English
15
English
16
window seal
gasket
curtain
attachment
screws 13/32"
drainelbow
window seal
gasket
curtain
attachment
screws 13/32"
draintube
English
Parts
PartsSupplied
PartsSupplied
PartsSupplied
Remote
control
Remote
control
ìCR2025ì battery
ìCR2025ì battery
ìCR2025ì battery
curtain
attachment
screws 13/32"
window seal
gasket
curtainsash
screws
31/32"
Remote
control
basepan angle
leftand right
sidecurtains
Model: ESA3063
curtainsash screws
31/32"
Casement to
window
securance
screw 1"
Model: ESA3083
leftand right
sidecurtains
basepan angle
toprail
curtainsash screws
31/32"
Casement to
window
securance
screw1"
Model: ESA3103, ESA3123
leftand right
sidecurtains
basepan angle
toprail
17
English
18
Installing Unit into A Window
Window Opening Requirements
The air conditioner is designed to fit into double or single hung sash type windows. Each of the
units comes with an installation kit that provides adjustable mounting louvers, to fill the gaps
between the sides of the unit, and the window frame. The chart below reflects the dimensions of
the units with, and without installation kits. Measure your window opening width and compare
it to the chart below to ensure that it meets the minimum and maximum window width requirements.
Model
A(inch)
Dimension
B(inch)
C(inch)
D(inch) Max
Case High
Case Width
D(inch) Min
Case Depth
ESA3063
ESA3083
7
32
15
13
32
31
35
32
1
25
32
9
13
8
3
20
32
15
20
32
15
"
"
"
"
"
"
"
"
13
32
31
Slide left-hand curtain assembly into
left ends of top and bottom rails.
Repeat for right-hand curtain
assembly. Fasten curtain retainer
strips to sides of outer case with six
Model ESA3063
ASSEMBLE
CURTAINS
Unpack unit on floor next to
installation location.
13/32" screws.
1
Caution: Never expose plastic front
or grille to extreme
temperatures.
ESA3103
ESA3123
10
8
5
16
32
11
36
8
5
26
32
27
15
4
3
22
16
1
23
8
5
"
"
"
"
"
"
"
"
16
32
11
A
B
C
ESA3063
D
A
B
C
ESA3083, ESA3103, ESA3123
D
13
16
20
1
4
5
8
24
English
25
English
26
PUSH
PUSH
PUSH
PUSH
Always use a soft cloth dampened with water or mild soap
and water solution to wipe the front if the cabinet.
T o clean the front panels or the cabinet DO NO T use harsh
chemicals, abrasives, ammonia, chlorine, bleach, concentrated
detergents, solvents or metal scouring pads.
DO NOT use your air conditioner without the air filter in place.
Always unplug your air conditioner before cleaning.
Air filter needs to be cleaned at least once a mouth for your
unit to operate at optimum efficiency.
English
27
English
28
(See page 8)
(See page 19, 22)
English
