Haier EB-3190E User Manual
Microwave Oven
Instruction for use
EB-3190E
Specific No. :0050502179A
Electricity schematic diagram
The Primary
interlock switch
CPU
L
N
U
F
E
Thermostat
The door
interlock switch
SE
Lamp
MF
The secondary
interlock
switch
Fan motor
MT
RELAY
Turn table motor
RW
Warning!
No one except the professional technicians can decompose the microwave oven. Electric shock
1.
danger may occur!
2.
Monitoring switch
HVC
AK
Rectifier
HV
H
D
V
T
FA
F
Magnetron
Do not put metal stick into the interlock hole at the front of the cavity. It may cause microwave leakage!
3.
Do not add excessive force to opposite direction on the door. Otherwise the door may be deformed
and cause microwave leakage.
4.
Do not cook food with vacuum package or packed into enclosed container. For the food with skin,
remember to puncture it before cooking.
5.
Do not cook eggs with shell. It may cause bursting.
Remove the grease remained in the cavity . Otherwise it may cause smoking or fire in heating.
6.
7.
Do not use the microwave oven for purposes other than cooking.
Be sure to earth the microwave oven reliably in installation and usage.
8.
Reserve enough space for the rotation of the tray At least 5cm space above the microwave oven.
9.
is required for heat radiation.
Do not put microwave oven in humid or high-temperature environment.
10.
Do not touch the upper part of the shell and the outer screen of the door . It may cause scalding.
11.
12.
Do not run the microwave oven without load. It may damage the microwave oven.
Do not use metal container to cook with microwave oven. It may cause igniting phenomenon.
13.
14.
After long time cooking, the cavity is under high temperature. It is suggested to wait for some time
to cool it down before next usage.
15.
Before usage, please check if the cooking utensils are applicable for microwave oven.
When cooking food with plastic or paper package, be sure to check if it strikes a fire.
16.
17.
If there's smoking during cooking with microwave oven, please keep the oven door closed and pull
off the power plug.
18.
If you heat beverage, it will slowly expand. Be sure to watch out for bursting.
For those drinks or food prepared for children, be sure to stir or shake evenly and check the tem-
19.
perature before feeding to avoid scalding.
20.
If the door , door frame or door seal is damaged, do not use the oven before it is repaired by the
professional technicians.
During maintenance, be sure to switch off the power supply . To decompose the shell of the oven, be
21.
sure to have it done by professional technicians. The inner components are electrified, and may
cause electric shock.
22.
Children shall use the microwave oven under the instruction of adult, or use the oven by self after
they have received complete instruction and description from the adult. The adult shall teach the
children the general knowledge on the danger of operating the microwave oven.
The door seal and all of the relative parts shall be cleaned with soap liquor once each week to keep
23.
the cavity clean.
If the power cord is damaged, only the sellers or professional technicians authorized by the manu-
24.
facturer can make maintenance to avoid any electric shock danger.
25.
If you use cook utensils not recommended by us, be sure to watch out for the cooking proceeding in
the microwave oven.
If you heat liquor , in handling the liquor , please notice that the boiled liquor may have delayed
26.
bursting and cause scalding.
13
English
Instruction for use
English
Instruction for use
Operating panel
Control Panel Buttons
g
kg
Enter
Clock
BEVERAGE
POPCORN
VEGETABLES
FISH/SEAFOOD
FROZEN DINNER
PLUS
30S
1
DEFROST
3 MENU
4
REHEAT
7
KEEP
TIME
WARM
PAUSE/STOP
POWER
LEVEL
Visual Displays
Words around the display will light to indicate what function in progress
Please see the following pages.
g
Enter
kg
Cook
POULTRY
Cook
2
5
8
0
Time
Time
MEAT
PIZZA
BAKED POTATO
3
6
9
CLOCK
START
Page 7
Page 7
Page 8
Page 8
Page 8
Page 6
Page 6
Page 6
Page 7
Page 6
DEFROST
POWER
REHEAT
LEVEL
Contents
Electricity schematic diagram
1 Potential dangers
2 Where to install the oven
3 Installing the oven
4 Rating plate
5 Plugging in your appliance
6 Using the microwave oven
7 How to operate your microwave oven
8 Cleaning and care
9 Customer support service
10 Calling the Customer Support Service
11 Guarantee
Components
Operating panel
Warning
Page
inside of cover sheet
2
3
3
4
4
5
6
9
9
10
10
11
12
13
Caution ! Microwave ovens may only be installed, plugged in and started up in full compliance with the
instructions for use. Therefore, please read the instruction manual carefully from start to finish before
you start to use your appliance. The manufacturer is not liable for any damage caused by failure to
pay heed to the operating instructions when operating the appliance. Highlight the points that are
especially important to you and keep this document in a place where it can be consulted at any time
and be passed on to future owners. This appliance must be kept out of children's reach.
Important !
The appliance(s) described in this instruction manual is / are solely designed for domestic use and may
not be used for professional or commercial purposes.
You have chosen an excellent appliance which will serve you reliably for many years, if it is operated
and maintained properly.
Detailed drawings (FIG.A) with a legend you shall find on the page 11 of this manual.
Should your newly purchased appliance replace an old microwave oven, cut off the power cable of the
old appliance as close as possible to the cabinet. Please have the old appliance ecologically disposed
off by a company specialised in environmental protection. (ask your civic Centre)
Clock
12
KEEP
WARM
1
